with Onie Boot Loader Only 48 SFP28 Ports and 8 QSFP28 Ports 2 Power Supplies (AC) X86 CPU Short Depth P2C Airflow Rail Kit ROHS6
NVIDIA MSN2410-CB2FO Spectrum Based 25GbE/100GbE 1U Open Ethernet Switch
Bare Metal / ONIE 48 SFP28 Ports / 8 QSFP28 Ports / 2 Power Supplies AC / x86 Dual Core / Short Depth /
non-PoE / AFI/P2C Airflow (air flows from Back-to-Front/Power side to Connector side) / Rail Kit / RoHS6
Spectrum Based 48-port 25GbE + 8-port 100GbE Open Ethernet Network Switch
NVIDIA Networking SN2410 provides the most predictable, highest performance 100GbE top of rack (ToR) switching platform for the growing demands of today's data centers.
The SN2410 switch is an ideal top-of-rack (ToR) solution, allowing maximum flexibility, with port speeds spanning from 10Gb/s to 100Gb/s per port. Its optimized port configuration enables high-speed rack connectivity to any server at 10GbE or 25GbE speeds. The 100GbE uplink ports allow a variety of blocking ratios that suit any application requirement.
Powered by the Spectrum ASIC and packed with 8 ports running at 100GbE (can be split to 16 ports running 50GbE) and 48 ports running at 25GbE, the SN2410 carries a whopping throughput of 4Tb/s with a landmark 2.97Bpps processing capacity in a compact 1RU form factor.
Benefits
• A predictable data center through predictable, affordable network
• Choice, no vendor lock-in
• Zero Packet Loss
• Future proof solution: enhanced scalability
• Arranged and organized data center
• Supports speeds of 1/10/25/40/50/56/100GbE
• Easy deployment
• Easy maintenance
• Unprecedented performance
• Line rate performance on all ports at all packet sizes
• Storage and server applications run faster
• Software Defined Networking (SDN) support
• Running Onyx, Cumulus Linux, and alternative operating systems over ONIE
The SN2410 has 8 ports running at 100GbE (can be split to 16 ports running 50GbE) and 48 ports running at 25GbE, carrying a throughput of 2Tb/s with a 2.97Bpps processing capacity in a compact 1RU form factor. The SN2410 switch is an ideal top-of-rack (ToR) solution, allowing maximum flexibility, with port speeds spanning from 10GbE to 100GbE per port. Its optimized port configuration enables high-speed rack connectivity to any server at 10 or 25GbE speeds. The 100GbE uplink ports allow a variety of blocking ratios that suit any application requirement.
The NVIDIA® Spectrum™ SN2000 series switches are the 2nd generation of NVIDIA switches, purpose-built for leaf/spine/super-spine datacenter applications. Allowing maximum flexibility, SN2000 series provides port speeds spanning from 1 to 100GbE, with a port density that enables full rack connectivity to any server at 1/20/25/40/50/100GbE speeds. In addition, the uplink ports allow a variety of blocking ratios to suit any application requirement
The SN2000 series is ideal for building wire-speed and cloud-scale layer-2 and layer-3 networks. The SN2000 platforms deliver high performance, consistent low latency along with support for advanced software defined networking features, making it the ideal choice for web scale IT, cloud, hyperconverged storage and data analytics applications.
Key Features
Throughput
• 4Tb/s
• 2.97 billion packets per second (Bpps)
High density
• 8 40/56/100GbE ports in 1RU
• Up to 48 10/25-ports
• Up to 16 50GbE ports
Lowest latency
• 300nsec port-to-port
• Flat latency across L2 and L3 forwarding
• Cut-through latency between ports in different speeds
Lowest power
RoHS compliant
Network Disaggregation: Open Ethernet
Open Ethernet breaks the paradigm of traditional switch systems, eliminating vendor lock-in. Open Ethernet offers customers the flexibility and freedom to use a choice of operating systems on top of Ethernet switches, thereby re-gaining control of the network, and optimizing utilization, efficiency and overall return on investment.
Encouraging an ecosystem of open source, standard network solutions, Open Ethernet allows IT managers and data center planners the option to make independent selections with regard to their switching equipment. They can “mix and match” offerings from different equipment vendors to achieve optimal configuration and have better control of capital and operational expenditures.
With a range of system form factors, and a rich software ecosystem, SN2000 series allows you to pick and choose the right components for your data center.
SN2000 Platforms
SN2000 series platforms are powered by the Spectrum ASIC and available in 4 configurations. Each delivers high performance combined with feature-rich layer 2 and layer 3 forwarding—ideal for both top-of-rack leaf and fixed configuration spines. Superior hardware capabilities including dynamic flexible shared buffers and predictable wire speed performance with no packet loss for any packet size. While the SN2000 Ethernet switch series is aimed for the 25/50/100GbE market, NVIDIA offers similar systems for the 10/40GbE market: SN2000B switches are priced comfortably for the 10/40 GbE market and provide the superior feature set of NVIDIA Spectrum. The SN2000 series are standards compliant and fully interoperable with third party systems.
Visibility
• WHAT JUST HAPPENED? (WJH) telemetry dramatically reduces mean time to issue resolution by providing answers to: When, What, Who, Where and Why
• Hardware-accelerated histograms track and summarize queue depths at submicrosecond granularity
• Inband Network Telemetry (INT)-ready hardware
• Streaming Telemetry
• Up to 256K shared forwarding entries
Performance
• Fully shared packet buffer provides a fair, predictable and high bandwidth data path
• Consistent and low cut-through latency
• Intelligent hardware-accelerated data movement, congestion management and load balancing for RoCE and Machine learning applications that leverage GPUDirect
• Best-in-class VXLAN scale—6X more tunnels and tunnel endpoints
Agility
• Comprehensive Layer-2, Layer-3 and RoCE
• Advanced network virtualization with high performance single pass VXLAN routing and IPv6 segment routing
• Programmable pipeline
• Deep Packet Inspection – 512B deep
Full specification and details can be found in the Product Datasheet PDF file
