Juniper Networks SRX550M Interface Modules

Antenna extension

For WLAN MPIM on SRX Series platforms

1-Port VDSL2 Annex A Mini-Physical Interface Module1-Port VDSL2 Annex A Mini-Physical Interface Module

Supported on SRX320, SRX340, SRX345, SRX380, and SRX550M Firewalls; ROHS compliant

Very-high-bit-rate digital subscriber line (VDSL) technology is part of the xDSL family of modem technologies, which provide faster data transmission over a single flat untwisted or twisted pair of copper wires. The 1-Port VDSL2 Annex A Mini-PIM carries the Ethernet backplane. When the Mini-PIM is plugged into the chassis, the Mini-PIM connects to one of the ports of the baseboard switch. The 1-Port VDSL2 Annex A Mini-PIM on the SRX Series Services Gateway provides ADSL backward compatibility.


Key Features:

• ADSL/ADSL2/ADSL2+ backward compatibility with Annex-A, Annex-M support • Packet Mode Transfer (PTM) or Ethernet in the First Mile (EFM) (802.3ah) support • Operation, Administration, and Maintenance (OAM) support for ADSL/ADSL2/ADSL2+ mode • Asynchronous Transfer Mode (ATM) quality of service (QoS) (supported only when the VDSL2 Mini-PIM is operating in ADSL2 mode) • Multilink Point-to-Point Protocol (MLPPP) (supported only when the VDSL2 Mini-PIM is operating in ADSL2 mode) • Support for a maximum of 10 permanent virtual connections (PVCs) (only in ADSL/ADSL2/ADSL2+ mode) • Dying Gasp support (ADSL and VDSL2 mode)

1-Port T1/E1 Mini-Physical Interface Module

Supported on SRX320, SRX340, SRX345, SRX380, and SRX550M Firewalls; ROHS compliant

The 1-Port T1/E1 Mini-Physical Interface Module (Mini-PIM) provides the physical connection to T1 or E1 network media types and also performs T1 or E1 framing and line-speed signaling.


Key Features:

• Channel service unit/data service unit (CSU/DSU) to eliminate the need for a separate external device

• 56-Kbps and 64-Kbps operating modes

• Independent internal and external clocking option

• Alarm reporting with a 24-hour history maintained

• Loopback, BERT, FDL (T1 only), and Long Buildout (T1 only) diagnostics

• Multilink Frame Relay and Multilink PPP support


Standards:

• ANSI TI.107, TI.102

• GR 499-core, GR 253-core

• AT&T Pub 54014

• ITU G.751, G.703
