Edimax PoE Switches

Product Features Five 10/100Mbps Fast Ethernet ports and four PoE+ ports

IEEE 802.3af/at PoE compliant (ports 1 - 4) for simplified deployment and installation

Up to 30W per PoE port (total power budget: 60W) for powering PoE-enabled devices

Auto-detection of powered devices (PD) and power consumption levels

Hardware DIP switch for “Standard” and “Extend” mode selection; the “Extend” mode features 30-watt PoE transmit distance of 200m at speed of 10Mbps

Port-based VLAN and Loop Protection features

Supports 802.1p Quality of Service (QoS)

Plug & play, no installation required & Fanless quiet operation

External power adapter included

Product Features IEEE 802.3af/at PoE compliant.

Eight Gigabit Ethernet ports with four PoE+ ports.

Up to 30W per port for powering PoE-enabled devices.

Long range PoE power delivery distance extending up to 200 meters.

Power backfeed protection support to avoid damaging the PoE ports.

Auto-detection of powered devices (PD) and power consumption levels.

Auto fault-detection on over/under current & voltage.

Access Control List (ACL) support.

Switch capacity:16Gbps & Forwarding rate: 11.9Mpps.

IEEE 802.1Q-based VLAN for network segmentation to improve performance and security.

IEEE 802.1p QoS with 4 priority queues.

IGMP Snooping V1 / V2 / V3 support.

4K MAC address table and jumbo frame support up to 9KB.

Small desktop form-factor for small office and home office.

Product Features Eight 10/100/1000Mbps Gigabit PoE+ ports.

IEEE 802.3af/at PoE compliant for simplified deployment and installation.

Up to 30W per PoE port (total power budget: 130W) for powering PoE-enabled devices.

Auto-detection of powered devices (PD) and power consumption levels.

Hardware DIP switch for “Standard” and “Extend” mode selection; the “Extend” mode features 30-watt PoE transmit distance of 200m at speed of 10Mbps.

Port-based VLAN and Loop Protection features.

Supports 802.1p Quality of Service (QoS).

Product Features Twenty-four Fast Ethernet ports and four Gigabit RJ45/SFP combo ports.

IEEE 802.3af/at PoE compliant.

Up to 30W per port (total power budget: 280W) for powering PoE-enabled devices.

PoE long range mode with Ethernet cable to extend up to 200 meters.

Auto-detection of powered devices (PD) and power consumption levels.

PoE powered devices (PD) alive check to enhance the reliability of the network.

Power backfeed protection to avoid damaging the PoE ports.

DHCP snooping to protect the integrity of legitimate DHCP server and its operations.

Surge Protection 6KV to avoid the damage of the switch and connected devices.

Supports SNMP v3, Access Control List (ACL), QoS, CoS, STP, 802.1Q VLAN, IPv4/IPv6, Port Trunk, IGMP v1/v2/v3 Snooping and Mirror.

12.8Gbps switch capacity.

16K MAC address table and jumbo frame support up to 9KB.

19-inch 1U rack-mount design.

Product Features Eight 10/100Mbps Fast Ethernet ports and four PoE+ ports.

IEEE 802.3af/at PoE compliant (ports 1 - 4) for simplified deployment and installation.

Up to 30W per PoE port (total power budget: 60W) for powering PoE-enabled devices.

Auto-detection of powered devices (PD) and power consumption levels.

Hardware DIP switch for “Standard” and “Extend” mode selection; the “Extend” mode features 30-watt PoE transmit distance of 200m at speed of 10Mbps.

Port-based VLAN and Loop Protection features.

Supports 802.1p Quality of Service (QoS).

Product Features Eight 10/100Mbps Fast Ethernet PoE+ ports

IEEE 802.3af/at PoE compliant for simplified deployment and installation.

Up to 30W per PoE port (total power budget: 130W) for powering PoE-enabled devices.

Auto-detection of powered devices (PD) and power consumption levels.

Hardware DIP switch for “Standard” and “Extend” mode selection; the “Extend” mode features 30-watt PoE transmit distance of 200m at speed of 10Mbps.

Port-based VLAN and Loop Protection features

Supports 802.1p Quality of Service (Qo

Product Features Gigabit High Speed PoE+: Equipped with 8 Gigabit PoE+ ports, IEEE 802.3af/at PoE compliant, supports up to 30W per PoE port (total power budget: 70W)

PoE Long Range Extension: Guaranteed PoE transmit distance to 200 meters at speed of 10Mbps

Port-based VLAN: Port isolated from each other to prevent multicast or broadcast storms

Hardware QoS: Easy DIP switch setup QoS, supports 802.1p, for video & voice traffic priority

PoE Auto Detection: Auto detect PoE and non-PoE devices to avoid from being damaged by incorrect power sending

Power Backfeed Protection: Equipped with power backfeed protection to avoid damaging the PoE ports

Plug-and-Play, Flexible Network Deployment and Energy Efficient

Fanless, Compact, Rack-Mount, Durable Metal Casing

Product Features Supports ONVIF Profile Q standard which is compatible with working ONVIF compliant Profiles G/Q/S/A/C/T/M devices to provide fast and easy system settings, device discovery, and user authentication.

Guaranteed PoE long distance to 200 meters.

PoE powered devices (PD) alive check to enhance the reliability of the network If a PD fails to respond, the GS-5210PL will reboot the PD.

IEEE 802.3af/at PoE compliant, up to 30W per port (total power budget: 110W) for powering PoE-enabled devices.

Dual-firmware image for robust failover mechanisms

It can activate the backup firmware right away while the current one faces problems.

IP Surveillance VLAN and Voice VLAN to enhance video and voice quality.

4-digit LED display showing total PoE power, available power, and power consumption.

Auto-detection of powered devices (PD) and power consumption levels.

Power backfeed protection to avoid damaging the PoE ports.

DHCP snooping to protect the integrity of legitimate DHCP server and its operations.

Supports SNMP v3, Access Control List (ACL), QoS, CoS, STP, 802.1Q VLAN, IPv4/IPv6, Port Trunking, IGMP v1/v2/v3 Snooping and Port Mirroring

Product Features IEEE 802.3af/at PoE compliant.

Eight Gigabit Ethernet ports.

Up to 30W per port (total power budget: 150W) for powering PoE-enabled devices.

Auto-detection of powered devices (PD) and power consumption levels.

Auto fault-detection on over/under current & voltage.

Switch capacity:16Gbps & Forwarding rate:11.9Mpps.

IEEE 802.1Q-based VLAN for network segmentation to improve performance and security.

IEEE 802.1p QoS with 4 priority queues

IGMP Snooping V1 / V2 / V3 support.

4K MAC address table and jumbo frame support up to 9KB.

19-inch 1U rack-mount brackets included.

Product Features Supports ONVIF Profile Q standard which is compatible with working ONVIF compliant Profiles G/Q/S/A/C/T/M devices to provide fast and easy system settings, device discovery, and user authentication.

PoE powered devices (PD) alive check to enhance the reliability of the network If a PD fails to respond, the GS-5216PLC will reboot the PD.

IEEE 802.3af/at PoE compliant, up to 30W per port (total power budget: 280W) for powering PoE-enabled devices.

Guaranteed PoE long distance to 200 meters.

4-digit LED display showing total PoE power, available power, and power consumption.

Dual-firmware image for robust failover mechanisms

It can activate the backup firmware right away while the current one faces problems.

IP Surveillance VLAN and Voice VLAN to enhance video & voice quality and security.

Auto-detection of powered devices (PD) and power consumption levels.

Power backfeed protection to avoid damaging the PoE ports.

DHCP snooping to protect the integrity of the legitimate DHCP server and its operations.

Supports SNMP v3, Access Control List (ACL), QoS, CoS, STP, 802.1Q VLAN, IPv4/IPv6, Port Trunking, IGMP v1/v2/v3 Snooping and Port Mirroring.

Hot-swappable fan and 19-inch 1U rack-mount design.

Product Features Supports ONVIF Profile Q standard which is compatible with working ONVIF compliant Profiles G/Q/S/A/C/T/M devices to provide fast and easy system settings, device discovery, and user authentication.

PoE powered devices (PD) alive check to enhance the reliability of the network If a PD fails to respond, the GS-5424PLC V2 will reboot the PD.

Guaranteed PoE long distance to 200 meters.

Dual-firmware image for robust failover mechanisms

It can activate the backup firmware right away while the current one faces problems.

IP Surveillance VLAN and Voice VLAN to enhance video and voice quality.

IEEE 802.3af/at PoE compliant, up to 30W per port (total power budget: 400W) for powering PoE-enabled devices.

Power backfeed protection to avoid damaging the PoE ports.

DHCP snooping to protect the integrity of the legitimate DHCP server and its operations.

Supports SNMP v3, Access Control List (ACL), QoS, CoS, STP, 802.1Q VLAN, IPv4/IPv6, Port Trunking, IGMP v1/v2/v3 Snooping and Port Mirroring.

56 Gbps switch capacity, and Forwarding rate 41.6Mpps .

Two fans with hot-swappable fan tray and 19-inch 1U rack-mount design.

Product Features ?Gigabit Ethernet ports and 4 x 10 Gigabit SFP+ ports.

Supports ONVIF Profile Q standard which is compatible with working ONVIF compliant Profiles G/Q/S/A/C/T/M devices to provide fast and easy system settings, device discovery, and user authentication.

Guaranteed PoE long distance to 200 meters.

Dual firmware to reduce switch downtime.

128 Gbps switch capacity, and Forwarding rate 95.2Mpps (64-byte package size)

IEEE 802.3af/at PoE compliant.

IP Surveillance VLAN and Voice VLAN to enhance video and voice quality.

Up to 30W per port (total power budget: 400W) for powering PoE-enabled devices.

Auto-detection of powered devices (PD) and power consumption levels.

PoE powered devices (PD) alive check to enhance the reliability of the network.

Power backfeed protection to avoid damaging the PoE ports.

Dedicated Intelligent Thermal Controller to control fan speeds, turn on/off each fan for power saving and noise reduction.

DHCP snooping to protect the integrity of the legitimate DHCP server and its operations.

Supports SNMP v3, Access Control List (ACL), QoS, CoS, STP, 802.1Q VLAN, IPv4/IPv6, Port Trunking, IGMP v1/v2/v3 Snooping and Port Mirroring.

16K MAC address table and jumbo frame support up to 12 KB.

Two fans with hot-swappable fan tray and 19-inch 1U rack-mount design.
