Aten Multi-view KVMP Switches

Overview The CS1642A 2-Port USB DVI Dual View KVMP™ Switch is a multi-application device that integrates a 2-port KVM switch with 2-port USB hub. The newest version now supports Quad-View functionality with two Dual View KVM Switches connected.

The new CS1642A features multi-view capabilities, which allow two switches to be daisy chained for a dual, triple, or quadview display across multi-monitor installations. The CS1642A supports advanced nVidia 3D Vision ready 120Hz 3D displaying,allowing you to manage various 3D visual effects. It allows you to manipulate all connected computers from a single console to save resources and work space. It enables each computer to access connected peripherals on a one-computer-at-a-time basis, making it ideal for users who need delicate visual effects and multi-tasking on several computers. The CS1642A is perfect for graphic designers, banking and financial consultants, gamers and medical professionals-demanding a high quality switch that provides stunning color, clarity and functionality.





Package Contents 1x CS1642A 2-Port USB DVI Dual View KVMP™ Switch
2x KVM Cable (DVI-D DL, USB, Audio; 1.8m/6ft)
2x DVI-D DL Cable (1.8m/6ft)
1x Power Adapter
1x User Instructions




Features One dual-screen USB console controls two/four dual-screen computers and two additional USB devices
Multi-View Display – Easily connect two CS1642A/1644A's units for a second dual-screen setup controlled through a single connection
Superior video quality – 2560 x 1600 at 60Hz (DVI Dual link); and 3D displays up to 1920 x 1200 at 120Hz (DVI Single link)
Supports widescreen resolutions
Independent switching of KVM, USB, and Audio focus
DVI digital and analog monitor support – fully compliant with DVI specifications; and HDCP compliant
Multiplatform support – Windows 2000/XP/Vista, Linux *, Mac, Sun,and FreeBSD
Sun/Mac keyboard support and emulation **
Video DynaSync, exclusive ATEN technology, to eliminate boot-up display problems and optimizes resolution when switching between ports
Power on detection - if one computer is powered off, the CS1642A will automatically switch to the next powered-on computer

Overview The CS1644A 4-Port USB DVI Dual View KVMP™ Switch is a multi-application device that integrates a 4-port KVM switch with 2-port USB hub. The newest version now supports Quad-View functionality with two Dual View KVM Switches connected.

The new CS1644A features multi-view capabilities, which allow two switches to be daisy chained for a dual, triple, or quadview display across multi-monitor installations. The CS1644A supports advanced nVidia 3D Vision ready 120Hz 3D displaying,allowing you to manage various 3D visual effects. It allows you to manipulate all connected computers from a single console to save resources and work space. It enables each computer to access connected peripherals on a one-computer-at-a-time basis, making it ideal for users who need delicate visual effects and multi-tasking on several computers. The CS1644A is perfect for graphic designers, banking and financial consultants, gamers and medical professionals-demanding a high quality switch that provides stunning color, clarity and functionality.





Package Contents 1x CS1644A 4-Port USB DVI Dual View KVMP™ Switch
4x KVM Cable (DVI-D DL, USB, Audio; 1.8m/6ft)
4x DVI-D DL Cable (1.8m/6ft)
1x Power Adapter
1x User Instructions




Features One dual-screen USB console controls two/four dual-screen computers and two additional USB devices
Multi-View Display – Easily connect two CS1642A/1644A's units for a second dual-screen setup controlled through a single connection
Superior video quality – 2560 x 1600 at 60Hz (DVI Dual link); and 3D displays up to 1920 x 1200 at 120Hz (DVI Single link)
Supports widescreen resolutions
Independent switching of KVM, USB, and Audio focus
DVI digital and analog monitor support – fully compliant with DVI specifications; and HDCP compliant
Multiplatform support – Windows 2000/XP/Vista, Linux *, Mac, Sun,and FreeBSD
Sun/Mac keyboard support and emulation **
Video DynaSync, exclusive ATEN technology, to eliminate boot-up display problems and optimizes resolution when switching between ports

Overview CS1744 KVM Switch integrates functions of video signal dual output and USB KVM switches. It allows a computer with dual-screen support to pair with two VGA/SVGA/Multisync displays via a USB keyboard and mouse. Furthermore, CS1744 provides 1 USB port on each of the front and rear panels, allowing each server to share any USB peripheral device that is connected to this HUB.





Package Contents 1x 4-Port USB Dual-View KVMP™ Switch
4x Custom KVM Cable (VGA, USB; 1.8m/6ft)
4x Custom KVM Cable (VGA, Audio; 1.8m/6ft)
1x Firmware Upgrade Cable
1x User Instructions




Features Allows one USB keyboard, USB mouse, speakers, microphone and two displays to control four dual display computers
2 port USB Hub built in
Multiplatform support: compatible with all operation platforms PC (Windows, Linux and most others), Mac and Sun
With speaker and microphone support
Bi-directional switching and flexible interoperability; switch permits independent PC, independent peripheral, and independent audio function, regardless of KVM switch focus
Buzzer On/Off via hotkey
Keyboard and mouse emulation for error free booting
Computer selection via front panel pushbuttons and hotkeys
Superior video quality - up to 2048 x 1536; DDC2B
Firmware upgradeable
OS Support:Windows 2000, Windows XP, Windows Vista, LINUX, Mac, Sun and FreeBSD
SUN/Mac keyboard support and emulation*
*PC keyboard combinations emulate SUN/Mac keyboards
*SUN/Mac keyboards only work with their own computers

Aten CM1284-AT-E 4-Port USB HDMI Multi-View KVMP Switch

ATEN CM1164A 4-Port USB DVI Multi-View KVMP™ Switch improves the operational efficiency of intensive monitoring applications. With limited screen, to allow users to manage the data more efficiently, up to 16 video sources can be selected, switched and displayed at the same time with independent keyboard, mouse control.

The CM1164A provides users a real-time monitoring functionality by combining a 4-port DVI-D switch with a 2-port USB hub and providing the following display modes: Quad View, Picture in Picture (PiP), Picture by Picture (PbP), Picture on Picture (PoP), and Full Screen mode.

Box Includes:

1x CM1164A 4-Port USB DVI Multi-View KVMP™ Switch
4x LIN5-35W1-W11G KVM Cables (DVI-D, USB, Audio)
1x LIN2-418K-E12G Power Cord
1x 2XRT-0013G IR Remote Control
1x Rack Mount Kit
1x User Instructions
