For the convenience of your installation, ATEN offers various mounting kits that allow you to install the LCD KVM Switch/Console on the rack. Please refer to Datasheet on the Documentation page for more information about the mounting kits.
The CS1708A KVM allows access to 8 directly connected computers, and through Daisy chain architecture as many as 256 total servers may be controlled from a single keyboard, mouse and monitor. To simplify installation and to keep track of so many servers a custom ASIC (patent pending) provides an auto-sensing function that recognizes the position of each KVM station in the chain. A front panel USB port provides server access to USB devices such as Hard Drives, or CDROM s, eliminating the need to physically connect a storage device to a server to install patches or updates.
Features:
A single console controls up to 8 computers
Daisy-chain up to 31 additional units - control up to 256 computers from a single console
Front accessible USB port allows each computer to access USB peripherals
Dual Interface - supports computers and console with PS/2 or USB keyboards and mice
Auto PS/2 and USB interface detection
USB / PS/2 keyboard and mouse emulation - computers boot even when the console focus is elsewhere
Video resolution up to 2048 x 1536; DDC2B
Two level password security; only authorized users view and control computers (up to four users)
Auto Scan feature for monitoring user-selected computers
Broadcast mode; operations simultaneously performed on all selected computers
Hot pluggable - add or remove computers without having to power down the switch
Buzzer on/off via hotkey and OSD
Firmware upgrades to all the chained KVM switches at the same time via the daisy-chain cable
Rack mountable in 19" system rack (1U)
The CS1716A KVM switch is a control unit that allows access to multiple computers from a single PS/2 or USB console (keyboard, mouse, and monitor). A single CS1716A can control up to 16 computers. As many as 31 additional switches can be daisy-chained to each other, so that up to 512 computers can all be controlled from a single keyboard-monitor-mouse console. Additionally, a front panel USB port is available for each computer to access any peripherals connected to it on a one-at-a-time basis.
Features
Superior video quality - up to 2048 x 1536; DDC2B
One USB-PS/2 console controls up to 16 computers; Daisy-chain up to 31 additional units - control up to 512 computers from a single console
Broadcast Mode - operation simultaneously performed on all selected computers... etc
Video DynaSync™ - stores the console monitor EDID to optimize display resolution
Designed for seamless integration, the ATEN Rack Mounting Kit ensures your Presentation Matrix Switch is securely and conveniently installed within a rack setup. Built with durability and precision in mind, this mounting kit provides a professional and reliable solution for organizing your AV equipment.
Key Features of ATEN Rack Mounting Kit
Effortless installation for ATEN Presentation Matrix Switches
Sturdy metal brackets for enhanced stability
Compatible with a range of ATEN Presentation Matrix models
Includes all necessary mounting hardware
Optimized for professional AV environments
Reliable Mounting Solution
The ATEN Rack Mounting Kit offers a robust and secure setup for Presentation Matrix Switches, ensuring minimal movement and maximum operational efficiency within a standard rack configuration.
Precision Fit
Each bracket is engineered to align perfectly with ATEN Presentation Matrix Switch mounting points, allowing for quick and accurate installation without the need for additional modifications.
Comprehensive Package
The kit includes two high-quality mounting brackets and four Philip hex head cap screws, providing everything needed for a streamlined installation process.
Professional Design
Crafted for system integrators and AV professionals, this mounting kit supports a clean, organized rack layout while maintaining easy access for maintenance or upgrades.
Compatibility Reference
Refer to the Compatible Products section and User Manuals of your ATEN Presentation Matrix Switch under the Support and Download tab to ensure proper model selection.
For additional convenience, ATEN offers Rack Mount Kits that allow Secure KVM Switches to be installed on a rack.
For the convenience of your installation, ATEN offers various mounting kits that allow you to install the LCD KVM Switch/Console on the rack. Please refer to Datasheet on the Documentation page for more information about the mounting kits.
For the convenience of your installation, ATEN offers a mounting kit that allows you to install the Presentation Matrix Switch or Rack KVM Switches under the table. Please refer to the Compatible Products information in the specifications and the User Manuals of the Presentation Matrix Switches/Rack KVM Switches located in the Documentation tab for further information.
For additional convenience, ATEN offers a Dual Rack Mount Kit that allows the installation of several 1U devices on a server rack.
For the convenience of your installation, ATEN offers various mounting kits that allow you to install the LCD KVM Switch/Console on the rack. Please refer to Datasheet on the Documentation page for more information about the mounting kits.
The ATEN 2-in-1U Mounting Kit allows you to combine the CL3800/CL3700/CL3100 LCD KVM Console with a rack KVM switch in 1U of space, which helps users save space for a more convenient and flexible working environment.
To meet users’ needs, ATEN offers two options of 2-in-1U Mounting Kit: the 2K-0001 (rack KVM switch option) / 2K-0007 (KVM over IP switch option), a Standard Installation that calls for at least two people to rack mount, and the 2K-0002, an Easy Installation accessory enabling one person to rack mount, which streamlines the rack mounting process.
Combining LCD KVM Console, rack KVM switch with the 2-in-1U Mounting Kit, users can enjoy ideal workstations with work space efficiency, limited space is no more a problem!
Note: Please refer to Datasheet on the Documentation page for more information on the applicable rack depth and the compatibility between LCD KVM consoles and KVM switches.
ATEN’s Video Extender Rack Mount Kit offers a range of flexible mounting solutions for installing ATEN video extenders and KVM extenders in a rack. Users can choose from three VE-RMK rack mount kits (1U, 2U, and 3U) to match the extender type that is being installed for a well-organized and easy-to-maintain setup.
For the convenience of your installation, ATEN offers various mounting kits that allow you to install the LCD KVM Switch/Console on the rack. Please refer to Datasheet on the Documentation page for more information about the mounting kits.
For the convenience of your installation, ATEN offers various mounting kits that allow you to install the LCD KVM Switch/Console on the rack. Please refer to Datasheet on the Documentation page for more information about the mounting kits.
The ATEN 2K-0008 2-in-1U Mounting Plate provides a reliable and efficient way to mount your 2K-0001 or 2K-0002 in a single 1U rack space. Designed for seamless compatibility, this mounting solution ensures a tidy setup that optimizes rack space and enhances system organization for professional installations.
Key Features of ATEN 2K-0008 2-in-1U Mounting Plate
Standard 1U design allows a perfect fit within any rack configuration, improving space efficiency.
Equipped with four integrated cable tie holes for secure and organized cabling.
Universal anchor pin ensures fast, accurate alignment and effortless installation.
Package Contents
1x 2K-0008 2-in-1U Mounting Plate
4x Cable Tie
1x M3*5 Flathead Screw Set (4 Screws)
1x User Instructions
Optimized for Space and Maintenance
The 2K-0008 Mounting Plate simplifies maintenance operations while maintaining a clean and organized rack layout. Its durable build and thoughtful design help minimize downtime, providing a dependable mounting solution for modern IT environments.
Seamless Compatibility
Engineered to integrate with ATEN’s 2K-0001 and 2K-0002 models, this plate delivers flexibility and consistency, making it an ideal choice for professionals seeking efficiency and order in high-density rack setups.
For the convenience of your installation, ATEN offers various mounting kits that allow you to install the LCD KVM Switch/Console on the rack. Please refer to Datasheet on the Documentation page for more information about the mounting kits.
ATEN’s Video Extender Rack Mount Kit offers a range of flexible mounting solutions for installing ATEN video extenders and KVM extenders in a rack. Users can choose from three VE-RMK rack mount kits (1U, 2U, and 3U) to match the extender type that is being installed for a well-organized and easy-to-maintain setup.
The ATEN 2-in-1U Mounting Kit allows you to combine the CL3800/CL3700/CL3100 LCD KVM Console with a rack KVM switch in 1U of space, which helps users save space for a more convenient and flexible working environment.
To meet users’ needs, ATEN offers two options of 2-in-1U Mounting Kit: the 2K-0001 (rack KVM switch option) / 2K-0007 (KVM over IP switch option), a Standard Installation that calls for at least two people to rack mount, and the 2K-0002, an Easy Installation accessory enabling one person to rack mount, which streamlines the rack mounting process.
Combining LCD KVM Console, rack KVM switch with the 2-in-1U Mounting Kit, users can enjoy ideal workstations with work space efficiency, limited space is no more a problem!
Note: Please refer to Datasheet on the Documentation page for more information on the applicable rack depth and the compatibility between LCD KVM consoles and KVM switches.
ATEN’s Video Extender Rack Mount Kit offers a range of flexible mounting solutions for installing ATEN video extenders and KVM extenders in a rack. Users can choose from three VE-RMK rack mount kits (1U, 2U, and 3U) to match the extender type that is being installed for a well-organized and easy-to-maintain setup.
The CS1708i is an 8-port KVM switch in a 1U housing for convenient rack mounting. This device allows system administrators to access the attached servers both locally and over IP (LAN and/or WAN). CS1708i works platform independent and supports e.g. Windows, Linux, MAC, SUN
The special KVM cables and the Aten feature “Video DynaSync", makes sure that an optimal video resolution can be maintained. In addition it's easy to expand the KVM installation. By using Daisy Chain cables the number of accessible servers can be increased up to 128.
Box Includes:
1x CS1708i KVM over IP Switch
1x 2L-5202P PS/2 KVM Cable
1x 2L-5202U USB KVM Cable
1x LIN5-27X6-U21G Console Cable
1x Firmware Upgrade Cable
1x Mounting Kit
1x Foot Pad Set (4 pcs)
1x 0AD8-1605-24M1 Power Adapter
1x User Instructions
The CS1716i KVM switches is an IP-based KVM control unit that allows both local and remote operators to monitor and access multiple computers. Remote users access the switches over the Internet by means of a web browser using TCP/IP for its remote communications protocol. The CS1716i supports up to 32 concurrent user logins for single-bus computer access. A built-in feature that resembles an Internet chat program - the Message Board - lets them communicate with each other. The ability to exchange information in real time allows them to cooperatively manage the installation in a smooth and efficient manner.
Among the CS1716i other outstanding features, a Panel Array Mode provides the ability to monitor up to 16 servers per switch; while the Mouse DynaSync™ feature automatically synchronizes the local and remote mouse pointer movements for perfect alignment regardless of what the mouse acceleration settings on the server are.
The CS1716i supports the highest security protocols, such as TLS 1.2 encryption for the browser, and RC4 encryption for secure keyboard, mouse, and video data transmission. For easier and more efficient user management integration, the CS1716i also supports authentication and authorization via remote servers, such as RADIUS, LDAP, LDAPS, and MS Active Directory.
These powerful features not only help administrators manage their server room in an efficient and flexible manner, they provide a cost effective management solution for the SMB sector.
Note: ** The video quality of CS1716i has been enhanced to Full HD.
KVM Switch Features
Superior video quality - up to 2048 x 1536; DDC2B for the local console; up to 1920 x 1200 @ 60Hz** and 1600 x 1200 @ 60Hz / 24 bit color depth for remote sessions
Supports TLS 1.2 data encryption and RSA 2048 bit certificates for secure user logins from a browser
Panel array mode enables user to monitor multiple servers from single screen at the same time - each selected server's video output appears in a separate panel - users can easily select the number of panels to view
Package Contents
1x CS1716i KVM over IP Switch
1x Custom KVM Cable (VGA, USB; 1.8m/6ft)
1x Custom KVM Cable (VGA, PS/2; 1.8m/6ft)
1x Custom Console Cable (VGA, USB, PS/2; 27cm/0.88ft)
1x Firmware Upgrade Cable
1x Mounting Kit
1x Foot Pad Set (4 pcs)
1x Power Adapter
1x User Instructions
Overview
The KVM over IP Console Station KA8270 is a standalone console that replaces PC or NB, enabling users to remotely access, monitor and control all servers connected to multiple ATEN's KVM over IP switches* with impenetrable security against virus threats
It also supports various data encryption methods, ensuring impervious data protection
The KVM over IP Console Station can be deployed anywhere instant access is needed and stringent security required, ideal for applications such as studios, offices, data centers, broadcast stations, control rooms, or network operations centers (NOC).
The KA8270 supports USB mouse/keyboard and two USB ports for Virtual Media function, and supports 1 VGA video output at resolutions up to 1920 x 1200 @ 60 Hz.
In addition, the KVM over IP Console Station provides Panel Array Mode™ function, enabling administrators to monitor the video output of up to 64 servers simultaneously
The feature makes it possible for previewing the content of all the ports at the same time, which is especially suitable for environments such as manufacturing and surveillance that often require monitoring of a much higher number of ports.
The KVM over IP Console Station can be set on a desk, mounted on a wall or at the rear of a rack with its spacesaving 0U rack mount design
It is flexible and easy to install, and provides a GUI with multi-language interface for device management, user profile customization, as well as hassle-free configuration for large deployments.
Product Features
A standalone Java-free console that replaces PC or NB, enabling users to remotely access and control ATEN's KVM over IP switches
Advanced FPGA graphics processor - with a Full HD resolution of 1920 x 1200
Panel Array Mode™ - allows administrators to monitor the video output of up to 64 servers on one screen simultaneously
Supports Boundless Switching - allows users to control up to 3 screens between two console stations by using one set of keyboard & mouse
