APC NetShelter Data Cable Partitions

The solid Partition allows overhead routing of networking cables on top of the NetShelter enclosures and 4-post racks. Two partitions attach without tools to the roof in a variety of depths. The solid partition is designed to be mounted in the front for a clean look. Each partition ships with ground studs and one 8 inch/203mm grounding strap.

Includes: Installation guide

Facilitates overhead cable management

Overhead cable troughs and partitions install toollessly on the roof of the enclosure eliminating the need for ceiling mounted or underfloor mounted cable trays. Cable troughs and partitions are designed to manage both power and data cables while maintaining separation.

Protective grounding provisions

NetShelter VS Enclosures incorporate a series of ground studs within each enclosure, providing adequate means for grounding all loose sheet metal panels and/or internally rack-mounted equipment.

Installation:

The Data Cable Partition for NetShelter 600mm Wide enclosures provides a clean, organized solution for overhead cable routing. Designed for tool-less installation, it ensures efficient separation of power and data cables while maintaining safety with built-in grounding features.

Key Features Facilitates overhead cable management
Protective grounding provisions
Efficient Cable Management The solid partition allows overhead routing of networking cables on top of NetShelter enclosures and 4-post racks, eliminating the need for ceiling or underfloor trays.

Tool-less Installation Two partitions attach directly to the enclosure roof without tools, available in multiple depths for flexible configurations.

Clean and Professional Appearance Designed to be mounted at the front, the partition provides a streamlined look that enhances organization and enclosure presentation.

Grounding for Safety Each partition includes ground studs and an 8-inch (203mm) grounding strap, ensuring safety from electric shock and reducing EMI emissions.

Included Components Installation guide and one 8-inch (20cm) grounding strap are included with each partition for convenience.

The APC NetShelter Data Cable Partition (AR8163ABLK) is a reliable cable management solution designed to streamline power and data organization within enclosures. With a pass-through configuration, it ensures efficient cable routing, separation, and safety without the need for complex installations.

Key Features Facilitates overhead cable management for organized routing
Toolless roof installation eliminates need for ceiling or underfloor trays
Maintains separation between power and data cables
Protective grounding reduces EMI emissions and enhances safety
Incorporates ground studs for securing panels and mounted equipment
Durable black finish with compact dimensions
Efficient Cable Organization Designed to optimize space, the partition supports clean, structured routing of both data and power cables, preventing clutter inside the enclosure.

Toolless Installation Engineered for convenience, the partition mounts directly to the roof of the enclosure without additional tools, saving setup time and effort.

Safe and Reliable Grounding Integrated grounding studs ensure protective bonding of loose panels and rack-mounted equipment, reducing the risk of electric shock and minimizing interference.

Compact and Sturdy Design Measuring 597 mm wide, 122 mm high, and 71 mm deep, the partition delivers robust cable support in a sleek black finish while fitting seamlessly within NetShelter enclosures.

Practical Packaging Packaged securely at 610 mm width, 178 mm depth, and 203 mm height, the product is easy to transport and store before installation.

Data Cable Partition, NetShelter, 750mm Wide – A solid shielding partition designed to streamline overhead cable management while ensuring safety with protective grounding features. The tool-less mounting system simplifies setup, making it an efficient solution for modern enclosures.

Key Features of Data Cable Partition Facilitates overhead cable management with separation for power and data.
Protective grounding provisions to ensure safety and reduce EMI emissions.
Tool-less installation for faster, hassle-free setup.
Facilitates Overhead Cable Management Overhead cable troughs and partitions mount directly to the roof of the enclosure without tools. This eliminates the need for ceiling or underfloor cable trays, helping maintain clear separation between power and data cables.

Protective Grounding Provisions Safety is built into the design with grounding studs integrated into each enclosure. These provide effective grounding for all loose sheet metal panels and rack-mounted equipment, protecting against electric shock and reducing EMI emissions.

The APC AR8173BLK Pass-Through Partition offers an efficient way to route and organize networking cables across the top of NetShelter enclosures and 4-post racks. Designed for simplified cable management, this partition supports overhead routing, enhances accessibility, and promotes an organized infrastructure layout.

Key Features of APC Pass-Through Partition Enables overhead cable routing on top of NetShelter enclosures and 4-post racks.
Tool-less installation for easy setup and removal.
Includes a dedicated cable access hole for simplified routing.
Comes with ground studs and an 8-inch (203mm) grounding strap for added safety.
Provides protective grounding provisions to reduce EMI and enhance safety.
Efficient Cable Routing The pass-through partition is engineered to allow clean and organized overhead routing of networking cables. It eliminates the need for ceiling or underfloor cable trays, simplifying the cable management process.

Tool-less Mounting Design Two partitions can be easily attached to the roof of NetShelter enclosures without tools, accommodating various depths and allowing quick installation or repositioning as needed.

Cable Access Optimization Designed with a precise cable access hole, the partition facilitates streamlined cable routing, minimizing clutter and improving accessibility during maintenance or upgrades.

Protective Grounding and Safety Each partition includes ground studs and an 8-inch (203mm) grounding strap, ensuring reliable grounding connections that enhance electrical safety and minimize electromagnetic interference (EMI).

Comprehensive Cable Management This shielding pass-through partition enhances the enclosure’s efficiency by providing both cable pass-through and grounding features. It ensures separation between power and data cables, promoting safe and organized cabling in data centers and IT environments.
