APC NetShelter CX Accessories

AR4602 Features NetShelter CX High Security Handle Adaptor Kit

This easy to install adaptor kit facilitates the use of NetShelter SX handles (including 'Combination Lock Handles' - part number: AR8132A and NetBotz Rack Access PX-HID part number: AP9361) on the NetShelter CX. When combined with Netbotz Rack Access PX-HID, this adaptor kit enables remote and local access control of the NetShelter CX. This High Security Handle Adaptor Kit is used typically in Healthcare, Education, Finance, Retail and Hospitality to enhance the security level, access control and compliance capability of the NetShelter CX 'Server Room in a Box' enclosure. This solid & rugged design adaptor kit is made of 1.5mm steel and comes in smart black finish.

Includes : Door mounting hardware, Installation guide

Compact - The slim design integrates with office design style of NetShelter CX.
Compatibility with lock handles - Compatible with NetShelter SX handles (including Standard Mechanical lock handle, Combination lock handle & Electro-Mechanical NetBotz Rack Access PX-HID lock handle) and other general lock handles based on the same design.
Easy to install - Innovative design allows for fast, easy installation by almost anybody.
Retrofittable Design - Easily mounts on existing NetShelter CX cabinets in field.
NetShelter CX Features & Benefits Agility Lockable front doors - Protect IT equipment from unwanted access
Light oak veneer finish - The enclosure blends discretely into almost any office environment.
Plug and Play setup - Fast and Easy set up
Toolless Rack Mounting Capabilities - Server cases do not require additional tools to mount into NetShelter Enclosures, which allows the users to quickly and easily mount units in the rear of the enclosure.
Acoustic foam lining for noise dampening - Superior noise reduction of installed IT equipment allowing the enclosure to be placed in a quiet environment.

AR4602A Features

NetShelter CX High Security Handle Adapter Kit

This easy to install adapter kit facilitates the use of NetShelter SX handles (including 'Combination Lock Handles' - part number: AR8132A and NetBotz Rack Access PX-HID part number: AP9361) on the NetShelter CX. When combined with Netbotz Rack Access PX-HID, this adaptor kit enables remote and local access control of the NetShelter CX. This High Security Handle Adaptor Kit is used typically in Healthcare, Education, Finance, Retail and Hospitality to enhance the security level, access control and compliance capability of the NetShelter CX 'Server Room in a Box' enclosure. This solid & rugged design adaptor kit is made of 1.5mm steel and comes in smart black finish.

Includes : Door mounting hardware, Installation guide

Compact - The slim design integrates with office design style of NetShelter CX.
Compatibility with lock handles - Compatible with NetShelter SX handles (including Standard Mechanical lock handle, Combination lock handle & Electro-Mechanical NetBotz Rack Access PX-HID lock handle) and other general lock handles based on the same design.
Easy to install - Innovative design allows for fast, easy installation by almost anybody.
Retrofittable Design - Easily mounts on existing NetShelter CX cabinets in field.
NetShelter CX Features & Benefits

Agility

Lockable front doors - Protect IT equipment from unwanted access
Light oak veneer finish - The enclosure blends discretely into almost any office environment.
Plug and Play setup - Fast and Easy set up
Toolless Rack Mounting Capabilities - Server cases do not require additional tools to mount into NetShelter Enclosures, which allows the users to quickly and easily mount units in the rear of the enclosure.
Acoustic foam lining for noise dampening - Superior noise reduction of installed IT equipment allowing the enclosure to be placed in a quiet environment.

AR4703 Features

NetShelter CX Fan Booster Kit

The NetShelter CX Fan Booster Kit is a user-fitted accessory which will increase the thermal capacity of the NetShelter CX. Allowing for more density of equipment, such as Blade Servers & high-density Switches. This Booster Kit consists of a replacement Power Supply Unit - PSU (24V) and a replacement Fan Tray. One Kit is needed per Fan Unit. Compatible with all generations of NetShelter CX 18U, 24U & 38U - this Kit can be retro-fitted to NetShelter CX already in the field, or to newly purchased NetShelter CX units. New Thermal loadings 18U : 1200 Watts > 2400 Watts, 24U : 2400 Watts > 3500 Watts, 38U : 3600 Watts > 5000 Watts

Includes : Installation guide

Easily Installed - The existing PSU & FanTray can be removed and the replacement Booster Kit installed in minutes and using only a screw driver and a pair of clippers or scissors.
Increases Airflow and enclosure thermal capacity - Increases: (from and to) NetShelter CX 18U : 1200 Watts > 2400 Watts (1 Fan Unit) NetShelter CX 24U : 2400 Watts > 3500 Watts (2 Fan Units) NetShelter CX 38U : 3600 Watts > 5000 Watts (3 Fan Units) Assumes all Fan Units in the NetShelter CX Enclosure are upgraded to the Fan Booster Kit.
Remains office-quiet - Despite increasing air-flow, the Fan Booster Kit does not audibly effect the noise levels from the NetShelter CX itself. Conversely, as more noisy equipment is installed in the NetShelter CX, so too the effectiveness of the soundproofing increases.
Zero White Space - All cooling equipment is placed outside the data center, allowing for valuable white space to be fully utilized for IT equipment.
NetShelter CX Features & Benefits

Agility

Lockable front doors - Protect IT equipment from unwanted access
Light oak veneer finish - The enclosure blends discretely into almost any office environment.
Plug and Play setup - Fast and Easy set up
Toolless Rack Mounting Capabilities - Server cases do not require additional tools to mount into NetShelter Enclosures, which allows the users to quickly and easily mount units in the rear of the enclosure.
Acoustic foam lining for noise dampening - Superior noise reduction of installed IT equipment allowing the enclosure to be placed in a quiet environment.

AR4000MV-FR Features

NetShelter CX Mini Fixed Rail Kit

This 2-component Fixed Rail Kit enables a wide variety of equipment to be rack mounted by providing 2 horizontal ledges on which to slide and place equipment. Note: requires the Netshelter CX Mini - 4 post 12U Rack Kit (AR4000MV12U) for installation.

Includes: Installation guide , Mounting hardware , Qty 2 - Horizontal Rails Convert Tower Servers to rack Servers - Use the Fixed Rail Kit to mount tower servers horizontally in the Rack.
One-size fits all for non-compatible servers - Resolves issues of non-conpatability between various 3rd party vendor equipment, rails and racks.

AR4701 Features

Dust Filter Pack NetShelter CX Mini, 18U & 24U - Includes 2 Small Filters

This Dust Filter Pack for the NetShelter CX allows the user to reduce the airborne particles entering the enclosure. The reticulated plastic filter material is washable and easily removed/replaced. Using the Dust Filter Pack on the NetShelter CX reduces the risk of dust related equipment issues, such as overheating, system failure, and permanent data loss.

Includes : Installation guide , Mounting hardware , Qty 2 - Metal filter lower cassettes , Qty 2 - Washeable filters for lower cassettes

Easily Washed - No purchasing of additional filters required. Simply remove the existing filter material, wash it in warm running water, and replace it back in its metal cassette.
Increases Airflow - Provides proper intake temperatures, increasing equipment life.
Increases IP Specification - Ingress Protection (IP) rating increases from IP44 to IP54 by installing the Dust Filter Kit on to the CX enclosures. This can be beneficial in certain cases such as for Government, Health & Education sectors.
Reduce dust related equipment issues - Protecting the equipment inside the CX from airborne contaminants such as dust reduces the risk of related equipment issues, such as overheating, system failure, and permanent data loss.

AR4702 Features

Dust Filter Pack Netshelter CX 38U 2 Small Filters & 2 Large Filters

This dust filter pack for the NetShelter CX allows the user to reduce the airborne particles entering the enclosure. The reticulated plastic filter material is washable and easily removed/replaced. Using the dust filter pack on the NetShelter CX increases the Ingress Protection (IP) rating of the enclosure from IP44 to IP54 and reduces the risk of dust related equipment issues, such as overheating, system failure, and permanent data loss.

Easily Washed - No purchasing of additional filters required. Simply remove the existing filter material, wash it in warm running water, and replace it back in its metal cassette.
Reduce dust related equipment issues - Protecting the equipment inside the CX from airborne contaminants such as dust reduces the risk of related equipment issues, such as overheating, system failure, and permanent data loss.

AR4601 Features

NetShelter CX Bolt Down Kit

Added safety - Use the Bolt-down kit to provide added safety in dynamic environments (such as on board a ship) or in seismically active regions.
Added security - Ensure your CX cannot easily be moved or stolen.

AR4000MV12U Features

This 12 U vertical mounting rail kit bolts into pre-existing holes in the Netshelter CX mini to convert the basic enclosure into a 12 U rack enclosure with a fixed rack depth of 600 mm (26").

Quick install vertical mounting rail kit - Using pre-existing holes and supplied hardware, these vertical mounting rails fit quickly and conveniently into place, transforming the CX Mini into a 12U Rack Enclosure.

NetShelter CX Base/Plinth Surround Kit

Base cable access Allows power and data cable to be routed into the enclosure from under a raised floor.
Agility Plug and Play setup Fast and Easy set up
Toolless Rack Mounting Capabilities Server cases do not require additional tools to mount into NetShelter Enclosures, which allows the users to quickly and easily mount units in the rear of the enclosure.
Lockable front doors Protect IT equipment from unwanted access
Light oak veneer finish The enclosure blends discretely into almost any office environment.
Acoustic foam lining for noise dampening Superior noise reduction of installed IT equipment allowing the enclosure to be placed in a quiet environment.

A soundproofed server room in a box which allows for IT deployment wherever and whenever it is needed, saving space, cost and deployment time.

A soundproofed server room in a box which allows for IT deployment wherever and whenever it is needed, saving space, cost and deployment time. Features: Superior noise reduction of installed IT equipment allowing the enclosure to be placed in a quiet environment
The enclosure blends discretely into almost any office environment
Fast and easy set up
Protect IT equipment from unwanted access
