TP-Link TL-SF1005D 5-Port Unmanaged Network Switch
TP-Link Logo

The TL-SF1005D is a 5-Port 10/100Mbps Desktop Switch featuring Green Ethernet technology for power-saving and IEEE 802.3x flow control, ensuring reliable data transfer. With plug and play design and auto-negotiation RJ45 ports, seamless connectivity is guaranteed.

Features

5 10/100Mbps Auto-Negotiation RJ45 ports, Supports Auto MDI / MDIX
Green Ethernet technology saves power consumption
IEEE 802.3x flow control provides reliable data transfer
Plastic case, desktop design
Plug and play, no configuration required
What's in the box

TL-SG105PP-M2
Power Adapter
Installation Guide
Specifications

Interface: 5 10/100Mbps RJ45 Ports, AUTO Negotiation/AUTO MDI/MDIX
Fan Quantity: Fanless
Power Supply: External Power Adapter (Output: 5.0VDC / 0.6A)
Dimensions: 4.1 x 2.8 x 0.9 in. (103.5 x 70 x 22 mm)
Mounting: N/A - Desktop Switch
Power Consumption: 1.87W(220V/50Hz), Max Heat Dissipation: 6.38BTU/h
Performance: Transfer Method: Store and Forward
Managed Features: Green Technology, 802.3X Flow Control, Back Pressure
Management: N/A - Unmanaged
System Requirements: N/A
*For complete specification see the documentation tab above

Express View Logo
In Stock: Next Day
£6.66
£7.99 Inc Vat
Add To Cart
TP-Link Logo
5-Port Fast Ethernet Desktop PoE Switch

5-Port 10/100Mbps Desktop Switch with 4-Port PoE provides the seamless network connection. It integrates 100Mbps Fast Ethernet and 10Mbps Ethernet network capabilities.

4 of the 8 Auto-Negotiation RJ45 ports (port-1 to port-4) of the switch support Power over Ethernet (PoE) function. These PoE ports can automatically detect and supply power with those IEEE 802.3af compliant Powered Devices (PDs). In this situation, the electrical power is transmitted along with data in one single cable allowing you to expand your network where there are no power lines or outlets, where you wish to fix devices such as APs, IP Cameras or IP Phones, etc.

Features:

Supports PoE power up to 15.4W for each PoE port
Supports PoE power up to 58W for all PoE ports
Supports PoE IEEE 802.3af compliant PDs
Supports IEEE 802.3x flow control for Full-duplex Mode and backpressure for Half-duplex Mode
2K entry MAC address table of the TL-SF1005P
LED indicators for monitoring power, link, activity and speed
External power adapter supply
Overload Arrangement

TL-SF1005P has the priority* function which will help protect the system when the system power is overloaded. If all PoE PDs power consumption is >= 58W, a priority will be arranged among the PoE ports, then the system will cut off the power of the lowest-priority port.

Port Priority Function

Priority (port-1>port-2>port-3>port-4): This function will help protect the system if the system power becomes overloaded. For example, Port 1, 2 and 4 are using 15.4w (maximum power per port is 15.4W), the system power is 46.2w in total (PoE max LED is red ). If there is an additional PD inserted to Port 3 with 10w then the system will cut off Port 4 to protect the system, this means Port 1, 2 will use 15.4w, and Port3 will use 10w, and no power will be supplied to Port 4.

Easy To Use

TL-SF1005P is easy to install and use. It requires no configuration and installation. With desktop design, outstanding performance and quality, the TP-LINK TL-SF1005P 5-Port 10/100Mbps Desktop Switch with 4-Port PoE is a great selection for expanding your home or office network.

Switch Comparison

SF1005P SG1008P SG1008PE SG1008D SG1005P Form Factor Desktop Desktop Desktop, Rackmount Desktop Desktop Switch Management Unmanaged Case Type Metal Metal Metal Plastic Metal Port Speed Fast Ethernet Gigabit Gigabit Gigabit Gigabit Copper  (RJ-45) Ports 5 8 8 8 5 Traffic Prioritisation No Yes Yes Yes Yes PoE/PoE+ Ports 4 x PoE 802.3af 4 x PoE 802.3af 8 x PoE+ 802.3at N/A 4 x PoE 802.3af PoE Total Budget 58W 55W 126W N/A 56W Power Supply 1 external 1 external 1 external 1 external 1 external Fan Fanless Fanless 1 Fanless Fanless Dimensions (WxDxH) 100 x 98 x 22.5 mm 171 x 98 x 27 mm 294 x 180 x 44 mm  180 x 90 x 25.5 mm 100 x 98 x 22.5 mm   Buy Buy Buy Buy Buy

Express View Logo
In Stock: Next Day
£25.76
£30.91 Inc Vat
Add To Cart
D-Link DES-1005D
D-Link Switch Logo
Five 10/100 Mbps Fast Ethernet ports

The DES-1005D 5-Port Fast Ethernet Unmanaged Desktop Switch is a five port fast Ethernet switch that allows you to quickly set up a wired network. Connect the DES-1005D to multiple computers together to share files and folders, or connect it to a router to share an Internet connection.

Key Features

Inexpensive Fast Ethernet solution for Home/SOHO
Five 10/100 Mbps Fast Ethernet ports
Auto MDI/MDIX crossover for all ports
Store-and-forward switching scheme
Full/half-duplex for Ethernet/Fast Ethernet speeds
IEEE 802.3x Flow Control
Plug-and-play installation
RoHS compliant
Auto-Sensing 10/100 Ports

The DES-1005D 5-Port Fast Ethernet Unmanaged Desktop Switch uses auto-sensing 10/100 Mbps ports, allowing a small workgroup to flexibly connect to Ethernet and Fast Ethernet devices to create an integrated network. These ports detect the network speed and auto-negotiate between 10BASE-T and 100BASE-TX, as well as between full and half-duplex, allowing you to get the maximum speed possible for each device connected to your network.

Auto MDI/MDIX Crossover

All ports support automatic MDI/MDIX crossover, eliminating the need for crossover cables or uplink ports. Each port can be plugged directly to a server, hub, router, or switch using regular straight-through twisted-pair Ethernet cables.

Flow Control for Secure Transmission

802.3x flow control on each port minimises dropped packets when the port’s receiving buffer is full. This gives you a more reliable connection for all of your connected devices.

Express View Logo
In Stock: 1-2 Weeks
£9.52
£11.42 Inc Vat
Add To Cart
D-Link DES-105
D-Link Logo

The DES-105 5-Port Fast Ethernet Unmanaged Desktop Switch is a 5-port 10/100 Mbps Fast Ethernet switch that allows you to quickly set up a wired network. Connect the DES-105 to multiple computers together to share files and folders, or connect it to a router to share an Internet connection.

Features:

Plug and Play operation
5 Fast Ethernet ports
Non-blocking architecture: simultaneous full speed on all ports
Quality of Service (QoS) queues for traffic prioritisation
Solidly built with metal housing, ideal for industrial and hazardous environments
D-Link Green technology, saves energy and increases the product's lifespan
Auto-Sensing 10/100 Ports

The DES-105 uses auto-sensing 10/100 Mbps ports, allowing a small workgroup to flexibly connect to Ethernet and Fast Ethernet devices to create an integrated network. These ports detect the network speed and auto-negotiate between 10BASE-T and 100BASE-TX, as well as between full and half-duplex, allowing you to get the maximum speed possible for each device connected to your network.

Auto MDI/MDIX Crossover

All of the ports on the DES-105 support automatic MDI/MDIX crossover, eliminating the need for crossover cables or uplink ports. Each port can be plugged directly to a server, hub, router, or switch using regular straight-through twisted-pair Ethernet cables. In addition, the DES-105 features multiple front, easy-to-access Ethernet ports with two colour LED indicators per port to easily distinguish link status.

Flow Control for Secure Transmission

When a port reaches its receiving buffer capacity, the 802.3x flow control feature activates to minimise dropped packets. By minimising the number of dropped packets, the switch provides a more reliable connection for all of your connected devices while surfing the web, playing games, or accessing media.

Think Green

The DES-105 is a plug-and-play networking switch that offers D-Link’s Green Technology to save energy and reduce heat, which in turn extends product life without sacrificing performance or functionality. The switch supports IEEE 802.3az Energy-Efficient Ethernet (EEE) which detects when a connected computer is shut down or when there is no Ethernet traffic, in which the switch will proceed to power down the idle port, saving a substantial amount of power.

Express View Logo
In Stock: Next Day
£17.06
£20.47 Inc Vat
Add To Cart
Cisco SF110D-05 - 5 Port Fast Ethernet Unmanaged Desktop Switch
Cisco Small Business Logo
5 Port 10/100

Get Easy-to-Use Switches with Zero Configuration

Build a fast, reliable network with these entry-level, low-cost, reliable networking solutions that provide plug-and-play connectivity. The SF110D-05 Unmanaged Desktop Switches deliver Fast Ethernet switching with key features like energy efficiency, traffic prioritisation, and network diagnostics for seamless integration into the rest of the network.

Features and Capabilities

The SF110D-05 Cisco Small Business 110 Series Unmanaged Switches delivers a wire-speed Fast Ethernet connectivity to connect your small business office. The 5 Port desktop model offers plug-and-play basic Layer 2 connectivity. That includes quality of service (QoS), cable diagnostics, and loop detection - all in a switch that you can set up by yourself in just minutes.

Features:


5 Port 10/100 Fast Ethernet Unmanaged Desktop Switch
Delivers powerful network performance and flexibility for small business networks, without the complexity. With no installation software and nothing to configure, you get an affordable, reliable network that just works right out of the box
QoS intelligence
Prioritises delay-sensitive services such as voice or video to improve your network's performance
An eco-friendly solution
A variety of power-saving features, including Energy-Efficient Ethernet, optimises power usage and reduces energy consumption without compromising performance.
Ease of use
Ready to use right out of the box, there is no software to install and nothing to configure.
Simple setup: Designed for small office spaces, desktop models offer a wall-mount option for discreet mounting under a desk or on the wall of an office or conference room
Switch Comparison

SF110D-05 SF110D-08 SF110D-08HP SG110D-05 SG110D-08 SG110D-08HP Form Factor Desktop Desktop Desktop Desktop Desktop Desktop Ports 5 x 10/100 8 x 10/100 8 x 10/100 5 x 10/100/1000 8 x 10/100/1000 8 x 10/100/1000 Number of PoE Ports     4     4 Power Dedicated to PoE     32 watts     32 watts Features Flow control, Layer 2 switching, auto-negotiation, auto-uplink (auto MDI/MDI-X), Weighted Round Robin (WRR) queuing, quality of service (QoS), cable diagnostics, loop detection, Energy Efficient Ethernet Status indicators Power, link/activity, cable diagnostics, loop detection Power, link/activity, cable diagnostics, loop detection Power, link/activity, PoE, cable diagnostics, loop detection Power, link/activity, cable diagnostics, loop detection Power, link/activity, cable diagnostics, loop detection Power, link/activity, PoE, cable diagnostics, loop detection Jumbo frame support     Performance Switching capacity: 1Gbps, Forwarding performance (64-byte packet size): 0.74 Mpps Switching capacity: 1.6Gbps, Forwarding performance (64-byte packet size): 0.74 Mpps Switching capacity: 1.6Gbps, Forwarding performance (64-byte packet size): 0.74 Mpps Switching capacity: 10Gbps, Forwarding performance (64-byte packet size): 11.9 Mpps Switching capacity: 16Gbps, Forwarding performance (64-byte packet size): 11.9 Mpps Switching capacity: 16Gbps, Forwarding performance (64-byte packet size): 11.9 Mpps Power Supply 1 external 1 external 1 external 1 external 1 external 1 external Fanless Physical Specifications 93(w) x 27(h) x 91(d)mm 130(w) x 27(h) x 130(d)mm 160(w) x 30(h) x 129(d)mm 110(w) x 30(h) x 110(d)mm 140(w) x 33(h) x 140(d)mm 160(w) x 30(h) x 129(d)mm

Express View Logo
In Stock: 1-2 Weeks
£24.06
£28.87 Inc Vat
Add To Cart
100Mbps Desktop Switch
TP-Link Logo
with 4-Port PoE

Product Overview

The TL-SF1005LP is a Professional Fast Ethernet Switch with 4 PoE Ports, Plug and Play and PoE Transmission for Surveillance up to 250 m


Product Features
5× 10/100 Mbps RJ45 ports


4× PoE ports transfer data and power on individual cables


Works with IEEE 802.3af compliant PDs


Up to 250 m data and power transmitting range under Extend Mode**


Priority Mode ensures high priority of ports 1–2 to guarantee the quality of sensitive application


Supports PoE Power up to 41 W for all PoE ports*


Plug and play with no configuration required

Dedicated 4-Port PoE Switch (41 W Budget) for Numerous Applications

Compliance with the 802.3af PoE standard supports up to 15.4 W on each PoE port. The total 41 W PoE power budget* for the 4× PoE ports opens up a wide range of applications, such as surveillance for offices, dormitories, and small businesses. It is fully compatible with IP cameras, access points, IP phones, computers, printers, and more.


Priority Video

Quality Guaranteed Quality of sensitive applications like video monitoring in critical business areas is guaranteed by offering higher priority options for ports 1–2 when one-touch Priority Mode is on.
Intelligent Power Management

When total power consumption exceeds 41 W, the intelligent power management will cut the lower priority port power.

This ensures the high priority port’s power supply and protects the device from power overload.

It also automatically detects and provides the required power for your PoE devices while protecting your PoE and non-PoE equipment from being damaged.
Durable Metal Casing

The interior components of TL-SF1005LP are protected by high-quality metal casing to ensure a long product life.

Having passed an array of stringent reliability tests, TL-SF1005LP delivers switching performance you can depend on.



Express View Logo
In Stock: Next Day
£22.56
£27.07 Inc Vat
Add To Cart
100Mbps Unmanaged Network Switch
TP-Link Logo

5-Port 10/100Mbps Desktop Network Switch The TL-SF1005D 5-Port 10/100Mbps desktop switch provides an easy way to expand your wired network. All 5 ports support auto-MDI/MDIX, eliminating the need to worry about the type of cable to use. Featuring full duplex mode, the TL-SF1005D can process data at a rate of up to 200Mbps making it an ideal choice for expanding your high performance wired network. Moreover, with innovative energy-efficient technology, the TL-SF1005D can save up to 68% of power consumption, making it an eco-friendly solution for your home or office network.

5 10/100Mbps Auto-Negotiation RJ45 ports, Supports Auto MDI / MDIX

IEEE 802.3x flow control provides reliable data transfer

Green Ethernet technology saves the power up to 68%

  Plastic case, desktop design

Plug and play, no configuration required

  High Performance

TL-SF1005D Fast Ethernet Switch provides 5 10/100Mbps Auto-Negotiation RJ45 ports. All ports support Auto MDI/MDIX function, eliminating the need for crossover cables or Uplink ports..Featuring non-blocking switching architecture,TL-SF1005D forwards and filters packets at full wire-speed for maximum throughput. With 10K Jumbo frame, the performance of large files transfers is improved significantly. And IEEE 802.3x flow control for Full Duplex mode and backpressure for Half Duplex mode alleviate the traffic congestion and make TL-SF1005D work reliably.

Easy to Use

The auto features of this ethernet switch make installation plug and play and hassle-free. No configuring is required. Auto MDI/MDIX eliminates the need for crossover cables. Auto-negotiation on each port senses the link speed of a network device (10, 100 Mbps) and intelligently adjusts for compatibility and optimal performance.

Express View Logo
In Stock: Next Day
£6.76
£8.11 Inc Vat
Add To Cart
TL-SF1006P
TP-Link Logo
with 4-Port PoE+

Product Overview

The TL-SF1006P is a Professional High-Power Switch with 4 PoE+ Ports, Plug and Play and PoE Transmission for Surveillance up to 250 m


Product Features
6× 10/100 Mbps RJ45 ports


4× PoE+ ports transfer data and power on individual cables


Works with IEEE 802.3af/at compliant PDs


Up to 250m data and power transmitting range under Extend Mode**


Priority Mode ensures high priority of ports 1–2 to guarantee the quality of sensitive application


Supports PoE Power up to 30 W for each PoE port


Supports PoE Power up to 67 W for all PoE ports*


Plug and play with no configuration required

Dedicated 4-Port PoE+ Switch (67 W Budget) for Numerous Applications

Compliance with the 802.3af/at PoE standard supports up to 30 W on each PoE port. The total 67 W PoE power budget* for the 4× PoE ports opens up a wide range of applications, such as surveillance for offices, dormitories, and small businesses. It is fully compatible with IP cameras, access points, IP phones, computers, printers, and more.


Priority Video
Quality Guaranteed


Quality of sensitive applications like video monitoring in critical business areas is guaranteed by offering higher priority options for ports 1–2 when one-touch Priority Mode is on.
Intelligent Power Management

When total power consumption exceeds 67 W, the intelligent power management will cut the lower priority port power.

This ensures the high priority port’s power supply and protects the device from power overload.

It also automatically detects and provides the required power for your PoE devices while protecting your PoE and non-PoE equipment from being damaged.
Durable Metal Casing

The interior components of TL-SF1006P are protected by high-quality metal casing to ensure a long product life.   Having passed an array of stringent reliability tests, TL-SF1006P delivers switching performance you can depend on.



Express View Logo
In Stock: Next Day
£31.03
£37.24 Inc Vat
Add To Cart
D-Link Switch Logo
5 x 10/100BaseT(X) ports Unmanaged Switch

The DIS-100E-5W Industrial Fast Ethernet Unmanaged Switch is designed specifically to withstand wide temperature range, vibrations and shock. These rugged, yet easy to deploy, switches have superior environmental specification compared to those of commercial network switches. With its hardened design combined with high availability network features, these switches form vital parts of any network infrastructure facilitating the increasing demand for smart cities, city-wide surveillance and wireless connectivity. The DIS-100E-5W Unmanaged Switch provides 5 Fast Ethernet ports and is designed for supporting standard industrial applications without complex setup to make the network truly plug-and-play

Features

5 x 10/100BaseT(X) ports
Unmanaged plug-and-play simplicity
Hardened housing and Discreet size
Withstands extreme temperatures
Certified for vibration, shock, free-fall, EMC
Fan-less design
Unmanaged Plug and Play
Unmanaged Plug and Play Plug in and go. The DIS-100E-5W reliably forwards Ethernet frames Fast Ethernet Connectivity
Designed with 5 x 10/100BaseT(X) Fast Ethernet ports to suit your network layout. Officially Certified
Certifications for vibration, shock, free-fall and electromagnetic compatibility to maximise network uptime in a variety of deployment environments, including smart city surveillance, factory automation, and outdoor wireless networks. Strong Build
The tough housing has been created to keep your network protected and reliably rugged. That’s why every DIS-switch comes with a 5-year D-Link warranty. Fanless Design
With no moving parts inside to reduce downtime and maintenance call outs, the rugged housing has been optimised for the transfer of heat. Withstands Extreme Temperatures
Operates effortlessly in a range of industrial and harsh environments in temperatures from -40°C to +75°C, and can cold start from -40°C. Fast Deployment
For instant installation it features a snap-to-DIN-rail clip, and also supports wall mounting. Discrete Size
Small but mighty. To make the most of cabinet space, it measures: 109.2 x 29.1 x 89.4 mm.



Created to withstand extreme heat and below-freezing temperatures

The DIS switches are designed to easily handle hot and cold temperature variances and can cold start at their coldest temperatures. With superior environmental protections to commercial switches, these switches are reliable in a huge variety of field applications.





Easy to Deploy

Suited to outdoor cabinet environments, the DIS-100E has multiple mounting options. .

Their compact sizes make efficient use of curbside cabinet space, and they feature snap-to-rail clips for instant deployment.







Built tough, built to last

With their strong build, the whole family of DIS industrial switches are certified against vibration, shock and free-fall. Comes with D-Link 5-year warranty as standard.



Fanless Design

Heat is steadily dissipated through the rugged build which has been optimised for the transfer of heat.

With no moving parts inside, the DIS family prioritises network uptime reducing the need for maintenance call outs.



Express View Logo
In Stock: Next Day
£117.97
£141.56 Inc Vat
Add To Cart
SMC Logo

SMC’s EZ Switch™ 10/100 Ethernet switches are dual-speed, plug-and-play network switches that can deliver full performance on every network. These solid switches are ideal for small offices and require no special configuration; just plug in your devices and away you go. Quiet fanless operation makes them ideal for office environments and comprehensive LEDs make troubleshooting a breeze.

Key Features
Manageability: Unmanaged
Maximum number of concurrent connections: 8
Number of ports PoE: 8
Number of ports 10/100 Mbps RJ45: 8
Power over Ethernet: 802.3 at (PoE+)
Max. PoE power: 105 W
IEEE 802.3az Energy-Efficient Ethernet Support
Plug-and-play
At-a-Glance LED Indicators
Auto MDI/MDI-X and Auto-Negotiation
Power-Saving Feature
CRC Filtering
Lifetime Advance Replacement Warranty

Express View Logo
End of Life Product
£ POA
£ POA Inc Vat
Trendnet Logo
TI-E50 (Version v1.0R)

TRENDnet's Industrial Fast Ethernet DIN-Rail Switches feature a rugged IP30 rated metal enclosure.

These industrial Ethernet switches are designed to withstand high levels of vibration and shock, operate in both low and high temperatures for industrial environments within a -40°C to 75°C  wide-temperature range.

Redundant power inputs with overload current protection on each industrial Ethernet switch minimizes network downtime.


Key Features:



5 x Fast Ethernet ports
1Gbps switching capacity
Hardened IP30 rated metal switch
Includes DIN-Rail mount and wall mount brackets
Wide operating temperature range of -40°C to 75°C
Dual inputs provide redundant power with overload current protection
Power supply sold separately (model: TI-M6024)
Fanless design for silent operation



Datasheets / User Manuals / Quick Start Guides can be downloaded from our Documentation tab (above)

Express View Logo
In Stock: 2-3 Weeks
£50.46
£60.55 Inc Vat
Add To Cart
Trendnet Logo
TI-PE50 (Version v1.0R)

TRENDnet's Industrial Fast Ethernet PoE+ DIN-Rail Switches feature a rugged IP30 rated metal enclosure.

These industrial unmanaged PoE+ switches are designed to withstand a high degree of vibration and shock, while operating in both high and low temperatures for industrial environments within -40°C to 75°C.

Redundant power inputs with overload current protection on each industrial unmanaged PoE+ switch minimizes network downtime.

Installers and integrators can save on equipment costs and reduce installation time with TRENDnet's Industrial Fast Ethernet Switches by delivering up to 30W per port of PoE power and data over existing Ethernet cables.


Key Features:


4 x Fast Ethernet PoE+ ports
1 x Fast Ethernet port
90W PoE power budget
1Gbps switching capacity
Hardened IP30 rated metal switch
Includes DIN-Rail mount and wall mount brackets
Wide operating temperature range of -40°C to 75°C
Dual inputs provide redundant power with overload current protection
Power supply sold separately (model: TI-S12048)

With PoE technology, users only need one set of cables to deliver both data and power from the industrial unmanaged PoE+ switch.


With these industrial unmanaged PoE+ switches, easily network PoE devices such as high-power wireless access points, PTZ and other advanced IP cameras, VoIP phone systems, IPTV decoders, access controls, and more.


Datasheets / User Manuals / Quick Start Guides can be downloaded from our Documentation tab (above)

Express View Logo
In Stock: 2-3 Weeks
£108.88
£130.66 Inc Vat
Add To Cart
Trendnet Logo

TPE-S50 (Version v2.0R)

Easy installation
4 x Fast Ethernet PoE+ ports and 2 x Fast Ethernet ports
1.2Gbps switching capacity
60W PoE budget
Wall mountable design
Sturdy metal switch
Use with TRENDnet's PoE splitter to network and power non-PoE devices
Lifetime Warranty*
The 6-Port Fast Ethernet PoE+ Switch, model TPE-S50, delivers data and power over existing Ethernet cables to Power over Ethernet (PoE) devices such as access points, VoIP phones, and IP Cameras. It supports both PoE (802.3af) and PoE+ (802.3at) devices with a 60W PoE budget. Plug and play this sturdy metal switch for reliable high speed PoE networking. Its fanless design is perfect for quiet environments that require silent operation.

PoE+ Power
A 60W PoE power budget supplies up to four Power over Ethernet devices.




Fast Ethernet
Six Fast Ethernet ports provide a 1.2Gbps switching capacity to support edge network installations.



Compact Design
With a compact and lightweight housing design, this switch is well-suited for desktop installations. Its fanless design is perfect for quiet environments that require silent operation.     PoE+
Supplies up to 30W of PoE+ power per PoE port with a 60W power budget Ports
Four Fast Ethernet PoE+ ports and two Fast Ethernet ports Switching Capacity
1.2Gbps switching capacity Housing
Wall mountable metal housing LED Indicators
LED indicators convey port status

Express View Logo
In Stock: Next Day
£33.80
£40.56 Inc Vat
Add To Cart
Trendnet Logo

4 x Gigabit ports
1 x SFP slot
10 Gbps switching fabric
Quality of Service traffic prioritization (802.1p QoS)
Jumbo Frame support
Fanless design
Metal housing
Magnet Mount
TRENDnet’s metal housing 4-Port Gigabit Switch with SFP Slot, model TEG-S51SFP, provides performance, proven reliability, and flexible extension of your Gigabit network. This fanless unmanaged desktop switch offers a total switching capacity of 10 Gbps combined with the flexibility of fiber networking. 802.1p QoS maintains your voice and video priority throughout the network. Magnetic mounting kit for easy and flexible setups.


  Plug and Play
Simply power up the switch and plug in connected devices Rear Facing Ports
4 x Gigabit Ethernet ports and 1 x SFP slot Switching Capacity
10 Gbps switching capacity Jumbo Frame
Sends larger packets, or Jumbo Frames (up to 9 KB), for increased performance LED Indicators
LED indicators convey port status Fanless
Fanless design lowers energy consumption and eliminates operating noise Housing
Rugged metal enclosure with magnet mount

Express View Logo
In Stock: 2-3 Weeks
£42.13
£50.56 Inc Vat
Add To Cart
Trendnet Logo

Plug and Play installation
5 x Gigabit ports
10 Gbps switching fabric
Up to 70% energy savings with GREENnet technology*
Sturdy metal switch
TRENDnet’s 5-Port Gigabit GREENnet Switch, model TEG-S50g, provides performance, proven reliability, and power savings of up to 70%*. Eliminate network congestion with Gigabit speeds and total switching capacity of 10 Gbps. Plug and Play this sturdy metal switch for reliable high speed network connectivity.






  Plug and Play
Simply power up the switch and plug in connected devices Ports
5 x Gigabit ports Switching Capacity
10 Gbps switching capacity Metal Enclosure
Rugged and reliable metal enclosed switch LED Indicators
LED indicators convey port status Jumbo Frame
Sends larger packets, or Jumbo Frames, for increased performance Energy Savings
Embedded GREENnet technology reduces power consumption by up to 70%*

Express View Logo
In Stock: Next Day
£16.17
£19.40 Inc Vat
Add To Cart
Tenda Logo

The TEF1105P-4-63W is a Tenda PoE switch that offers 5 10/100 Mbps Base-TX RJ45 ports. Up to 250 meters long distance transmission, beyond hundred meters transfer limit. 6KV lightning protection PoE switch is the real monitoring private switch. Ports 1-4 support IEEE 802.3at and IEEE 802.3af PoE standard. It provides 30W maximum PoE output a single port and 58W for the whole device.

6KV lighting protection PoE switch is the real monitoring private switch

For surveillance projects, AP or IP cameras are often installed in an outdoor environment or a higher position, which also increases the risk of cameras and PoE switches probability of a lightning shock. This results in the individual equipment getting damaged or could lead to a whole local area network (LAN) paralysis.

The Tenda TEF11 series switches have the professional lightning protection design - up to 6kV surge protection, with two levels of protection design respectively, effectively preventing the power of lightning from damaging the cable, which is the equivalent to giving the entire network system a security fence. The test standard is much higher than the national CCC request. In thunderstorm weather, it can also provide monitoring network stability, reliable service and maintain the images transmission.

Up to 250 meters long distance transmission beyond hundred meters transfer limit

Due to the complex monitoring environment, when making cabling and networking, it is very common to encounter the problem of inadequate network transmission distance. The distance of each camera terminal to the monitoring centre is different, some only a few metres, some hundred metres, while others can be kilometres away. The Tenda TEF11 series PoE monitoring switches exclusive patent network extension technology, uses the common existing twisted pair, can support 250 metres data transmission, breaks the existing twisted pair hundred meters transmission limit.

58W PoE power supply simplified wiring

Ports 1-4 comply with the IEEE802.3af and IEEE802.3at power supply standards. The entire switch offers a maximum PoE power output of 58W, whereas each port offers a maximum PoE power output of 30W. The ports can be used to supply power to and exchange data with APs and IP cameras.

Express View Logo
In Stock: Next Day
£15.59
£18.71 Inc Vat
Add To Cart
100M Switch
Tenda Logo

Dedicated for Surveillance With Uplink & NVR double uplink ports and QoS



6kV lightning Protection

250m Extend mode

QoS

Dual uplink ports   Dual uplink port, more convenient for connecting Router and NVR

TEF1106P-4-63W is an unmanaged PoE switch with 2 uplink ports that can connect with Router & NVR. Compliant with IEEE 802.3at/af standards, it can identify PoE-powered devices intelligently. The switch supplies a maximum PoE power output of 63 W, and 30 W for a single port. TEF1106P-4-63W is an ideal choice for SMBs, supermarkets and restaurants with small-sized video surveillance requirement

Up to 250 meters long distance transmission under the Extend Mode?beyond hundred meters transfer limitation

Due to the complex monitoring environment, the distance from each terminal to the monitoring center is different, some even more than hundred meters. TEF1106P-4-63W can support 250 meters data transmission in the Extend mode, which can save the cost of your project with less devices used.

Excellent lightning Protection

TEF1106P-4-63W supports professional lightning protection of 6KV for uplink ports & 4KV for power, which can protect the switch from the inductive lightning strike coming from the thunderstorm weather.

QoS Priority design makes the key video data to be prioritized

1-2 ports support QoS Priority function, and it will prioritize them when meeting network congestion, which can ensure the network stable and fluent transmission of the surveillance video without breaking up.

Express View Logo
In Stock: Next Day
£19.81
£23.77 Inc Vat
Add To Cart
Tenda Logo
Steel Case

Security surveillance in SMBs

Extraordinary heat dissipation

A housing made of 0.8 mm galvanized industrial-grade steel plates for excellent durability has a good heat dissipation performance, which can ensure stable switch operation, a long service life, and more reliable outdoor security surveillance.

Stay connected for 7x24 hours

5 * 10/100Mbps auto-negotiation RJ45 ports that support wire-speed forwarding and large-capacity cache, ensuring smooth surveillance video playback and stable data transmission for 7x24 hours.

User-friendly design

RJ45 ports and LED indicators are located on the same side and aligned vertically for more intuitively showing network status. The RJ45 ports and the power port are designed in the same orientation to reduce the mounting space requirement, allowing the switch to fit into the slimmest outdoor weak current box.

Express View Logo
In Stock: Next Day
£5.98
£7.18 Inc Vat
Add To Cart
Tenda Logo

The Tenda 5-port Ethernet Switch S105 is a desktop switch specially designed for families, offices, dormitories etc. Five 10/100 Mbps auto-negotiation ports with full duplex rate up to 200Mbps bring blazing fast Internet access. Its plug and play design makes installation easily in no time.

No matter if you are a tech-savvy enthusiast or a first-time user, the S105 is very easy and intuitive to setup without time-consuming operations. With an ultra-compact design, the Tenda S105 also supports desktop and wall-mounting so you can put the S105 anywhere you wish for more flexibility. Compatible with computer, printer, smart TVs, NAS, smart game console, IP-cameras, Tenda S105 makes your home network fun & easy.

Key Features:
5x10/100 Mbps auto-negotiation RJ45 ports obtains the fastest possible connection
Compliant with IEEE802.3?IEEE802.3u?IEEE802.3X standard
5x LED indicators display the connection status
Supports10/100M full duplex and half duplex
Store-and-forward mode
Supports MAC address auto learning and auto aging
Supports to connect with IP-camera
Plug-and-play without configuration
Supports wall-mounting and desktop installation

Cost-Effective SOHO Switch

Whether you have a small office or a home office, the Tenda S105 can satisfy all your needs and expand your network. What's more, it also competitively priced.

Plug and play

Whether you are a tech-savvy enthusiast or a first-time user, the S105 is very easy and intuitive to setup without time-consuming operations.

Blazing fast network without data loss

With store and forwarding mode, MAC address auto learning and auto aging, the S105 can transfer data over long distances without loss to ensure the stable and blazing fast WiFi performance.

Nice and Small

S105 is nice and small. It won't take up much desk or floor space. Because of the small design, users can put the S105 anywhere for flexibly.

It comes in a pretty dome-shaped pattern case. It will fit equally well in any desktop decor. Not only for WiFi use but also can be a home ornament.

Express View Logo
In Stock: 1-2 Weeks
£5.21
£6.25 Inc Vat
Add To Cart
Hikvision Logo

Main Features Intelligent PoE Management. When the power supply exceeds the limit, PoE ports intelligently manage the power supply, which extends the switch lifetime.
Up to 300 m Long Range PoE Transmission. The distance between IPCs and switch can reach maximum 300 meters.
4/8-Core Adaptive Power Supply with Less Power Loss. 8-core power supply reduces the power loss on cables.
6KV Surge Protection to Improve Reliability in Harsh Environment. The built-in surge protection device protects the switch from the sudden lightning surge in harsh environment.
Design for Video Transmission. VIP port ensures important data transmission when network congestion occurs.

Express View Logo
In Stock: 7-10 Days
£ POA
£ POA Inc Vat
Hikvision Logo

4 Port Fast Ethernet Smart POE Switch

Smart managed switches are developed by Hikvision, featuring in easy management and maintenance. You can easily deploy, monitor and expand your surveillance system anytime and anywhere with our software platforms. You can view the network topology, monitor the health of the network and receive device alarms in real time, which greatly reduces the cost of network operation and maintenance.




Key Features • 4 × 100 Mbps PoE RJ45 ports, 1 × 100 Mbps network RJ45 port. • IEEE 802.3at/af standard for PoE ports. • Network topology management, alarm push, network health monitor. • 6 KV surge protection for PoE ports. • AF/AT camera can reach up to 300 m in extend mode.










Full specification and details can be found in the Product Datasheet PDF file

A user quick start guide can be found in the User guide PDF file

A user manual can be found in the User Manual PDF file

Express View Logo
In Stock: 2-3 Days
£ POA
£ POA Inc Vat
Hikvision Logo

4 Port Fast Ethernet Smart POE Switch

Smart managed switches are developed by Hikvision, featuring in easy management and maintenance. You can easily deploy, monitor and expand your surveillance system anytime and anywhere with our software platforms. You can view the network topology, monitor the health of the network and receive device alarms in real time, which greatly reduces the cost of network operation and maintenance.




Key Features • 4 × 100 Mbps PoE RJ45 ports, 2 × 100 Mbps network RJ45 ports • IEEE 802.3at/af/bt standard for PoE ports • Network topology management, and alarm push • 6 KV surge protection for PoE ports • Up to 300 m long-range transmission • AF/AT camera can reach up to 300 m in extend mode


Full specification and details can be found in the Product Datasheet PDF file

A user quick start guide can be found in the User guide PDF file

A user manual can be found in the User Manual PDF file

Express View Logo
In Stock: 2-3 Days
£ POA
£ POA Inc Vat
Hikvision Logo

4 Port Fast Ethernet Unmanaged POE Switch

DS-3E0106HP-E switches are layer 2 100 Mbps long-range PoE switches, providing 1 × 10/100 Mbps Hi-PoE port, 3 × 10/100 Mbps PoE ports, and 2 × 10/100 Mbps RJ45 ports. The switches provide advanced Hi-PoE/PoE technology and support extend mode with long-range access up to 300 m. The prior and stable transmission of the important surveillance area videos can also be guaranteed when connected to the high priority ports. Meanwhile, the 2 × 10/100 Mbps RJ45 uplink ports guarantee applications of multiple network solutions.




Feature and Function • Intelligent PoE Management. -When the power supply exceeds the limit, PoE ports intelligently manage the power supply, which extends the switch lifetime. • Up to 300 m Long Range PoE Transmission. -The distance between IPCs and switch can reach maximum 300 meters. • IEEE 802.3bt Standard Hi-PoE, Max. 60 W for One Port. -IEEE 802.3bt standard Hi-PoE port provides max. 60 W power supply for high power devices such as domes or other 802.3bt devices. • 4/8-Core Adaptive Power Supply with Less Power Loss. -8-core power supply reduces the power loss on cables. • 6KV Surge Protection to Improve Reliability in Harsh Environment. -The built-in surge protection device protects the switch from the sudden lightning surge in harsh environment. • Design for Video Transmission. -VIP port ensures important data transmission when network congestion occurs.










Full specification and details can be found in the Product Datasheet PDF file

A user quick start guide can be found in the User guide PDF file

Express View Logo
In Stock: 2-3 Days
£ POA
£ POA Inc Vat
Hikvision Logo

4 Port Fast Ethernet Unmanaged Harsh POE Switch

DS-3T0306HP-E/HS switches are layer 2 Hi-PoE switches, providing advanced PoE power supply technology and wider temperature (-30 to 65 °C) design on the basis of high-performance access to ensure stable data upload. The switches support Hi-PoE, long range, port isolation, and PoE watchdog function.




Key Features • 3 × 100M PoE ports, 1 × Hi-PoE port, 1 × gigabit RJ45 port and 1 × gigabit SFP Fiber Optical Port. • IEEE 802.3at/af/bt standard for Hi-PoE port (Max. 60 W PoE output). • IEEE 802.3at/af standard for PoE ports (Max. 30 W PoE output). • IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z and IEEE 802.3ab standard. • 6 KV surge protection for PoE ports. • Up to 300 m long-range transmission. • PoE watchdog to auto detect and restart the cameras that do not respond. • Port isolation to improve network security. • Wire-speed forwarding. • Wider temperature (-30 to 65 °C) design. • Store-and-forward switching. • Solid high-strength metal shell. • Reliable fan-free design.


Full specification and details can be found in the Product Datasheet PDF file

A user quick start guide can be found in the User guide PDF file

Express View Logo
In Stock: 2-3 Days
£ POA
£ POA Inc Vat
Hikvision Logo

4 Port Fast Ethernet Unmanaged Industrial POE Switch




Key Features • High performance industrial PoE switch. • DS-3T0306P supports IEEE 802.3AF/AT standard. • POE port maximum output power 30W (input voltage is greater than 50V). • Design of redundant dual power input. • Working environment temperature of no fan -40?to +75?. • The average failure time reached 400 thousand hours. • IEEE802.3x full duplex, backpressure flow control


Outdoor Scenarios:





Full specification and details can be found in the Product Datasheet PDF file

An installation guide can be found in the User Manual PDF file

Express View Logo
In Stock: 2-3 Weeks
£ POA
£ POA Inc Vat
Other Ranges Available
Unmanaged Switch - 5 Port
5 Port Unmanaged Switches
View Range
5 Port Gigabit Switches | Comms Express
5 Port Gigabit Switches
View Range
5 Port Smart Switches
5 Port Smart Switches
View Range
5 Port PoE Switches
5 Port PoE Switches
View Range
Join Our Mailing List
Social Links
  • Apply for Credit
