Zyxel WiFi 6 Access Points

The Simple Path to WiFi 6 for Small Businesses & Home Offices

The Zyxel NWA50AX is the true WiFi 6 access point that comes with the right-fit feature set for small businesses and SoHo users looking to upgrade to 11ax (WiFi 6) without an expensive price tag. Supporting both 2.4Ghz and 5Ghz frequencies, the AP is aimed to empower you to enjoy all the best things WiFi 6 has to offer such as faster speeds even when congested or in high-density environments, expanded range in your wireless network, increased capacity for IoT deployments, and a lot more.


Simple Installation. Easy Configuration.

No networking expertise required - The NWA50AX can be easily installed and configured by everyone in small hotels, coffee shops, home offices, or boutique/retail stores. It supports both local GUI management and Nebula Cloud networking management, the simple setup allows you to quickly configure the AP with only a few clicks, making it super easy to set up guest and employee network on your own and start enjoying the ultra-fast WiFi 6 speeds in no time.

Easy Networking for Uncompromised Security

The average user is more likely to favor using the easiest method to get their network set up quickly than dealing with complex configurations, resulting in insecure encryption with compromised security. Supporting the latest WPA3 Personal standard, the NWA50AX is designed to bring stronger encryption to protect your wireless network without complicated configurations.

Manage it your way!

The NWA50AX with NebulaFlex offers the flexible manageability for you to freely choose between the local GUI management or onboarding to our super easy Nebula cloud management interface that you never need to worry about forgetting the IP address or lost account and password whatsoever.

Technical Specification

Wireless Standard IEEE 802.11 ax/ac/n/g/b/a MIMO MU-MIMO Wireless speed 2.4GHz: 575 Mbps
5GHz: 1200 Mbps Frequency band 2.4 GHz
USA (FCC): 2.412 to 2.462 GHz
Europe (ETSI): 2.412 to 2.472 GHz

5 GHz
USA (FCC): 5.15 to 5.35 GHz; 5.470 to 5.850 GHz
European (ETSI): 5.15 to 5.35 GHz; 5.470 to 5.725 GHz

Bandwidth 20-, 40-, 80-MHz Conducted typical transmit output power US (2.4GHz/5GHz): 23/26 dBm
EU (2.4GHz/5GHz): 20/25 dBm RF Design Antenna type 2x2 + 2x2 MIMO embedded antenna Antenna gain 2.4GHz: 3 dBi
5GHz: 4 dBi Minimum Receive sensitivity Min. Rx sensitivity up to -99 dBm WLAN feature Band Steering Yes WDS/Mesh Yes Fast roaming Yes DCS Yes Load balancing No Security Encryption WPA Personal, WPA2 Personal, WPA3 Personal Authentication No Access management MAC filtering, Rogue AP detection Networking IPv6 Yes VLANs Yes WMM Yes U-APSD Yes Management Operating mode Nebula Cloud managed
Standalone ZON Utility Discovery of Zyxel switches, APs and gateways Centralized and batch configurations: IP configuration
IP renew
Device factory reset
Device reboot
Device locating
Web GUI access
Firmware upgrade
Password configuration
Zyxel Wireless Optimizer WiFi AP planning Web UI/CLI Yes SNMP No Physical Specifications Item Dimensions (WxDxH)(mm/in.): 140 x 140 x 37.5/5.51 x 5.51 x 1.48
Weight (g/lb.): 290/0.64 Packing Dimensions (WxDxH)(mm/in.): 240 x 155 x 60/9.45 x 6.10 x 2.36
Weight (g/lb.): 600/1.32 Included accessories Power adapter, Mount plate, Mounting screws MTBF (hr) 1,010,980 Physical Interfaces Ethernet port 1 x 10/100/1000M LAN Power Input: AC 100 - 240V - 50/60 Hz 0.3A; Output: DC +12V 1.5A
PoE (802.3at): power draw 16 W Environmental Specifications Operating Temperature: 0°C to 50°C/32°F to 122°F
Humidity: 10% to 90% (non-condensing) Storage Temperature: -40°C to 70°C/-40°F to 158°F
Humidity: 10% to 90% (non-condensing) Certifications Radio FCC Part 15C
FCC Part 15E
ETSI EN 300 328
EN 301 893; LP0002
EN 60601-1-2 EMC FCC Part 15B
EN 301 489-1
EN 301 489-17
EN55022
EN55024
EN61000-3-2/-3
BSMI CNS13438 Safety EN 60950-1
IEC 60950-1
BSMI
CNS14336-1 All specifications are subject to change without notice.

Multi-gig WiFi 6 access point for small businesses

Zyxel NWA50AX Pro AX3000 Dual-Radio Multi-gig PoE Access Point

Delivering AX3000 WiFi speed with 2.5G Ethernet uplink port, the Zyxel NWA50AX Pro provides the powerful and fastest WiFi 6 speed for small businesses, SoHo, and home offices.

Small business owners looking for an affordable WiFi 6 access point with multi-gig connectivity, Zyxel's NWA50AX Pro is no doubt the ideal choice for them to support more connected devices and applications with the fastest speeds.

Access Point Features

5Ghz extended range for small biz

AX3000 (3x3:2 in 5Ghz; 2x2:2 in 2.4Ghz) AP provides maximum data rate of 3000 Mbps, and the 2.5G uplink port enables multi-gig connectivity for small biz networks

Multi-gig WiFi with connection stabilization design

Obtain the multi-gigabit performance with a 2.5Gbps PoE port to support the most demanding wireless requirements. The Multi-gig Connection Stabilization Pad secures the connection between the Cat 5E cable and the RJ45 connector to ensure the 2.5G speed is linked for maximum throughput.

Flexible Management

NebulaFlex allows users to switch between standalone or intuitive Nebula cloud managed modes as needed

Easy installation & configuration

Easy self-installation/configuration with right-fit feature set, perfect for small business and SOHO

  Boost your WiFi performance

To better leverage the faster speeds in 5Ghz band, Zyxel NWA50AX Pro equips with 3x high-gain antennas to boost WiFi signals and extend coverage, especially to previously hard-to-reach areas.

In addition to the WiFi boost, NWA50AX Pro also comes with the premium multi-gig Ethernet connections. As it can run on the common-type Cat5e cabling, a 2.5G uplink port breaks through the 1.0G bottleneck without re-cabling, making it easy to create an affordable high-speed network environment for your business or home.

Set up your wireless network in minutes!

No networking expertise required - The NWA50AX Pro is designed to be easily configured and installed in places like small hotels, retail stores, restaurants, or home offices.

The simple configuration allows you to set up the network for your customers and employees in minutes. The AP can be managed either with Nebula Cloud networking platform or the device's local interface.

Easy deployment with Zyxel's Smart Mesh

Zyxel's Smart Mesh technology automatically forms dynamic wireless links between access points and mitigates the complex, inconvenient cabling for WiFi deployment.

The Smart Mesh technology can save you from extra wiring by enabling the wireless connectivity between APs for extended range and flexible deployment.

Manage it your way!

The NWA50AX Pro with NebulaFlex offers the flexible manageability for you to freely choose between the device's local web interface or onboarding to our super easy Nebula cloud management interface that you never need to worry about forgetting the IP address or lost account and password when managing it on cloud.

Multi-gig WiFi 6 access point for small businesses

Zyxel NWA90AX Pro AX3000 Dual-Radio Multi-gig PoE Access Point
with secure authentication support

Delivering AX3000 WiFi speed with 2.5G Ethernet uplink port, the Zyxel NWA90AX Pro provides the powerful and fastest WiFi 6 speed for small businesses, SoHo, and home offices.

Small business owners looking for an affordable WiFi 6 access point with multi-gig connectivity, Zyxel's NWA90AX Pro is no doubt the ideal choice for them to support more connected devices and applications with the fastest speeds.

Access Point Features

5Ghz extended range for small biz

AX3000 (3x3:2 in 5Ghz; 2x2:2 in 2.4Ghz) AP provides maximum data rate of 3000 Mbps, and the 2.5G uplink port enables multi-gig connectivity for small biz networks

Multi-gig WiFi with connection stabilization design

Obtain the multi-gigabit performance with a 2.5Gbps PoE port to support the most demanding wireless requirements.

The Multi-gig Connection Stabilization Pad secures the connection between the Cat 5E cable and the RJ45 connector to ensure the 2.5G speed is linked for maximum throughput.

Flexible Management

NebulaFlex allows users to switch between standalone or intuitive Nebula cloud managed modes as needed

Secure WiFi Authentication

Captive portal and IEEE 802.1X authentication support provides enterprise-level security

Easy installation & configuration

Easy self-installation/configuration with right-fit feature set, perfect for small business and SOHO

  Boost your WiFi performance

To better leverage the faster speeds in 5Ghz band, Zyxel NWA90AX Pro equips with 3x high-gain antennas to boost WiFi signals and extend coverage, especially to previously hard-to-reach areas.

In addition to the WiFi boost, NWA90AX Pro also comes with the premium multi-gig Ethernet connections. As it can run on the common-type Cat5e cabling, a 2.5G uplink port breaks through the 1.0G bottleneck without re-cabling, making it easy to create an affordable high-speed network environment for your business or home.

Secure authentication to protect business networks

With the support of captive portal and IEEE802.1x authentication, the NWA90AX Pro not only offers small business users the enterprise-level security to protect their networks, but also the flexible opportunity to customize wireless network usage login for marketing and business recognition.

Set up your wireless network in minutes!

No networking expertise required - The NWA90AX Pro is designed to be easily configured and installed in places like small hotels, retail stores, restaurants, or home offices.

The simple configuration allows you to set up the network for your customers and employees in minutes. The AP can be managed either with Nebula Cloud networking platform or the device's local interface.

Easy deployment with Zyxel's Smart Mesh

Zyxel's Smart Mesh technology automatically forms dynamic wireless links between access points and mitigates the complex, inconvenient cabling for WiFi deployment.

The Smart Mesh technology can save you from extra wiring by enabling the wireless connectivity between APs for extended range and flexible deployment.

Manage it your way!

The NWA90AX Pro comes with the support of NebulaFlex Pro, which offers the full flexibility for users to easily switch between, Zyxel Nebula cloud-managed, controller-managed, and standalone modes. You can choose the appropriate managed-mode best suited for your needs.

Zyxel’s NWA210AXv2 takes WiFi 6 to the next level with AX5400 throughput and dual 2.5GbE ports, providing true multi-gigabit performance and flexible deployment options. Equipped with advanced 802.11ax technologies such as OFDMA and BSS Coloring, it delivers faster speeds, greater capacity and a smooth, reliable experience in high-density, performance-driven environments.

Key Features of NWA210AXv2 AX5400 WiFi 6 connectivity for high-speed performance
Dual-band Smart Mesh for extended coverage
Nebula cloud management for centralized control
Dual 2.5GbE Multi-gig LAN for seamless multi-gig performance
Connect & Protect security at the network edge
Flexible power inputs via PoE+ or USB Type-C
RF-first design for minimal 4G/5G interference
6-stream 4x4:4 (5GHz) + 2x2:2 (2.4GHz) antenna design
Dual 2.5GbE connectivity Enjoy multi-gig speeds that eliminate WiFi 6 bottlenecks, boost throughput, and ensure seamless performance for demanding applications.

AX5400 WiFi 6
6-stream 4x4:4 (5GHz) + 2x2:2 (2.4GHz) antenna design ensures consistent, high-quality coverage even in high-density environments.

Connect & Protect (CNP) Secures your network edge by providing application visibility, traffic control, and automatic blocking of phishing, malware, and harmful sites through advanced IP reputation and DNS filtering.

Flexible power inputs The NWA210AXv2 can be powered via PoE+ or a USB Type-C, offering greater installation flexibility while maintaining efficient power usage.

RF-first by design Advanced cellular coexistence minimizes interference from 4G/5G networks, ensuring stable connections and consistent WiFi performance across every deployment.

Smarter, safer WiFi with Connect & Protect
Connect & Protect delivers per-device security, automatically blocking phishing, malware, and malicious sites, while prioritizing key applications to ensure fast, reliable WiFi.

Nebula mobile app Get up and running in minutes with a step-by-step setup wizard. Manage, monitor, and adjust your network from anywhere with a user-friendly interface.

Powerful, effortless, and scalable connectivity Manage your wireless, switching, security, and LTE/5G devices through a single centralized cloud platform. Real-time monitoring, instant alerts, and complete network visibility make operations simple, secure, and scalable.

A self-optimizing WiFi network Nebula’s AI-powered smart automation continuously monitors WiFi performance, detects issues, pinpoints problem areas, and resolves them in real time to deliver a seamless, reliable, and exceptional user experience.

Instant 2.5x performance boost When paired with the XMG1915-10EP/18EP switch, the NWA210AXv2 delivers up to 2.5x faster speeds over standard gigabit networks, enabling effortless multi-gigabit upgrades while maximizing the full potential of next-generation WiFi.

Whats in the box

WiFi 6, Wait No More

The NWA110AX is truly the next generation of wireless (WiFi 6) AP for businesses looking for a most economical upgrade path to 11ax. Its built-in 2nd Generation WiFi 6 (Qualcomm 802.11ax 2.0) chipset allows the access point to take advantage of the full range of WiFi 6 technologies including uplink OFDMA and MU-MIMO which can’t be found in earlier releases of 802.11ax products.


Built for Superior performance

The NWA110AX boasts an impressive quad-core processor to provide consistently smooth delivery to wireless clients. The NWA110AX is also built with premium power amplifiers and 4G/5G interface filters to deliver superior quality of service that make it one of the best in its class.




Simpler upgrade path

The NWA110AX has been designed to be highly efficient in PoE budget, allowing for an easy upgrade path for those wishing to experience all that WiFi 6 has to offer without the need to upgrade existing PoE+ switches


Manage it your way!

As it comes with support for NebulaFlex, Zyxel’s scalable, cloud-based management system, the NWA110AX can be managed via NCC (Nebula control Center) or simply operate alone (controller less). You can choose the way that is best suited to your needs.

Zyxel WAX300H Wall Plate WiFi 6 Access Point with NebulaFlex Pro The Zyxel WAX300H Wall Plate WiFi 6 Access Point with NebulaFlex Pro is designed to deliver superb in-room connectivity for hospitality environments. Built with WiFi 6 and 160MHz channel support, it ensures faster speeds, stronger coverage, and seamless access for guests and in-room services.

Key Features WiFi 6 technology with 160MHz channel support
AX3000 performance delivering up to 3000 Mbps
PoE-powered with four Ethernet ports (1 uplink + 3 downlinks)
One PoE out port to support VoIP phones or other devices
NebulaFlex Pro with WiFi Aid for proactive network management
Versatile mounting options with slim and aesthetic design
Superb WiFi 6 Performance Supporting AX3000 (2x2:2 in 2.4GHz and 5GHz), the WAX300H provides blazing speeds of up to 3000 Mbps with 160MHz channels. This ensures guests enjoy faster and more stable connections for streaming, browsing, and online communication.

Flexible Mounting Options The compact design blends seamlessly into room interiors and can be installed on an outlet box, mounted discreetly, or placed on a desktop with the optional ACCESSORY-ZZ0107F desk kit. Cable channels ensure a clean, space-saving setup.

Extending In-Room Services More than just an access point, the WAX300H functions as a switch to extend both wired and wireless services. With four Ethernet ports, including one PoE out for devices like VoIP phones, it reduces costs and simplifies cabling while enhancing service options.

Nebula WiFi Aid Management With NebulaFlex Pro, hotel IT administrators can use WiFi Aid to proactively monitor guest connectivity issues. This advanced tool provides valuable insights, allowing staff to address potential problems before guests raise complaints.

Zyxel WAX630S NebulaFlex Pro WiFi 6 Access Point w/ 1-Year Connect & Protect Plus Licence The Zyxel WAX630S is an ultra-fast WiFi 6 access point designed for high-density environments, delivering consistent, reliable, and high-speed connectivity for multiple devices. Featuring advanced smart antenna technology, it ensures optimum performance and seamless user experiences, making it the ideal solution for schools, hotels, retail, and enterprises.

Key Features: WiFi 6 technology with 6 spatial streams (4x4:4 in 5GHz, 2x2:2 in 2.4GHz)
Supports OFDMA and MU-MIMO for faster, smarter connections
Smart antenna technology for optimized performance and interference reduction
Delivers up to 2.90 Gbps WiFi speeds
2.5 Gbps multi-gigabit Ethernet port for hassle-free upgrades
Built with high-quality components for long-term reliability
Flexible management with NebulaFlex Pro (cloud, controller, or standalone)
Ultra-fast, Smarter WiFi 6 Access Point With support for multiple simultaneous connections, the WAX630S delivers superior speed and performance. Ideal for environments handling large numbers of devices, it provides a seamless, responsive WiFi experience every time.

Unleashing the Power of Smart Antenna Built-in smart antenna technology constantly adapts to ensure each connection receives the best signal quality. This results in minimized interference and maximized performance, even in high-density deployments.

Robust Hardware You Can Trust Engineered with premium components, the WAX630S is built for reliability and lasting performance, making it a dependable choice for long-term network infrastructure needs.

Hassle-free Upgrade Enhance your network capacity effortlessly with WiFi speeds up to 2.90 Gbps and a 2.5 Gbps multi-gigabit port that works with existing cabling, eliminating costly rewiring projects.

Manage It Your Way Enjoy flexible management options with NebulaFlex Pro, allowing you to switch between cloud-managed, controller-managed, or standalone modes depending on your needs.

Zyxel WAX655E Outdoor WiFi 6 Access Point w/ NebulaFlex Pro The Zyxel WAX655E is designed to deliver strong, multi-gigabit wireless connectivity in demanding outdoor environments. Built for stadiums, parking lots, and other open spaces, it combines cutting-edge WiFi 6 performance with rugged durability, ensuring reliable coverage where it’s needed most.

Key Features Latest WiFi 6 technology for high-performance connectivity
Ideal for high-density outdoor areas such as stadiums and parking lots
IP67-rated weatherproof design for harsh environments
Built-in surge protection against lightning strikes
Smart Mesh technology for dynamic coverage expansion
NebulaFlex Pro for flexible management options
Extend WiFi to Crowded Outdoor Environments Combat poor connectivity and mobile data congestion with robust WiFi coverage designed for large public areas. The WAX655E ensures seamless user experiences, even in challenging high-traffic locations.

Ideal for Harsh Outdoor Connectivity Engineered with IP67-grade weather resistance, this access point withstands extreme temperatures while maintaining performance. Its built-in surge protector adds protection against outdoor hazards like lightning.

Extending Your WiFi Coverage with Smart Mesh Leverage Zyxel’s Smart Mesh Technology to form dynamic wireless links between APs. Expand coverage in high-density environments or create stable inter-building wireless bridges with ease.

Manage it Your Way With NebulaFlex Pro, the WAX655E adapts to your management style. Choose between cloud-managed, controller-managed, or standalone modes for full flexibility and control.

Product Overview

The WAX510D is truly the next generation of wireless (WiFi 6) AP, especially for businesses looking to strike the right balance between performance and budget. Its built-in 2nd Generation WiFi 6 (Qualcomm 802.11ax 2.0) chipset allows the access point to take advantage of the full range of WiFi 6 technologies including uplink OFDMA and MU-MIMO, which can’t be found in the earlier releases of 802.11ax products.

We understand that mounting an access point to the ceiling isn’t always possible due to the challenging environments like warehouses, historical buildings or stylish hotels were the aesthetics of the building are a priority.

The WAX510D is equipped with a dual-optimized antenna that is selectable, allowing the access point to be mounted on the wall or on the ceiling without compromising on performance and coverage.

The WAX510D boasts an impressive quad-core processor with 2 network accumulators to guarantee that a smooth and consistently fast service is provided to each client at all times.


Product Features
Dual-optimized Antenna Design


True WiFi 6 Qualcomm quad-core processor


Longevity Solid Capacitor


Anti-noise spreader
4G/5G Filter


Surge and ESD Protection
- 6x surge protection
- 2x ESD protection


High Performance FEM
- +50% performance

Product Benefits

The smartest choice

The WAX510D is not only efficient at delivering impressive high speeds with smooth and consistent delivery to wireless clients, but also it’s efficient on power. The WAX510D can deliver its impressive performance while keeping the consumption of PoE within the PoE+ standard, so that you can enjoy the latest WiFi 6 technology offering without the need to invest in upgrading your traditional switching architecture.


Manage it your way!

As it comes with support for NebulaFlex Pro, Zyxel’s scalable, cloud-based management system, the WAX510D can be managed via NCC (Nebula control Center), on-premises controller or simply operate alone (controller less). You can choose the way that is best suited to your needs.
