Vertiv Avocent KVM Power Supply Units & Power Cables

Vertiv Power Cord for Europe (Legacy - 202 SKUs)

Power Cord for UK & Ireland (legacy -201 skus)

Power Supply for LongView 3000/4000 series products

POW0030 Avocent TSx00 terminal server power supply only (does not include power cord).

For Use With The Avocent® HMX high performance KVM extender system 5000 and 6000 series transmitters and receivers

Product Overview

Low-voltage devices, like the Avocent® HMX and Avocent LV Extender, often require the use of external power supplies for operation. Avocent power supplies provide great reliability and efficiency, but when IT infrastructures require flexibility coupled with the highest levels of efficiency, the Avocent® RMPSU delivers.

The Avocent RMPSU increases reliability while providing economies of scale and convenience that aren't possible with external power supplies.

Consolidate for More Efficient Power Distribution

Power integrity, safety and management are core elements of the RMPSU system. At start up, the RMPSU checks the status of the power module(s). It then enables each of the power outputs in sequence to reduce the instantaneous load on the power modules.

After start up each power output is protected by overlapping safety features that guard against excess demand by any connected device. Additionally, the RMPSU can be controlled and monitored via a web interface. Temperature, fan speeds and individual current measurements are viewable and each output can be individually controlled.

The RMPSU features either one, or two, hot-swappable switched mode 460W power modules. A single power module is rated at 500,000 hours MTBF and can easily meet the needs of sixteen ports. However, in situations where redundancy is required, a second power module is available. With two power modules, the normal load will be intelligently balanced; with the full power load transferring immediately to the healthy module should one of the modules cease operation.

Ready for Change

Whether, the requirement is adding new capability or optimizing current space in the rack, the RMPSU makes it easy to add or relocate systems without the need to manage external power supplies. Each RMPSU can support up to 8 or 16 devices. All power outputs feature a locking connector to guard against accidental disconnection and provides a maximum of 20W at 12V.

The Avocent Rackmount Power Supply (RMPSU) is a perfect solution for organizations that need to reduce power usage, increase flexibility and optimize precious rack real estate.

Product Overview

Low-voltage devices, like the Avocent® HMX and Avocent LV Extender, often require the use of external power supplies for operation. Avocent power supplies provide great reliability and efficiency, but when IT infrastructures require flexibility coupled with the highest levels of efficiency, the Avocent® RMPSU delivers.

The Avocent RMPSU increases reliability while providing economies of scale and convenience that aren't possible with external power supplies.

Consolidate for More Efficient Power Distribution

Power integrity, safety and management are core elements of the RMPSU system. At start up, the RMPSU checks the status of the power module(s). It then enables each of the power outputs in sequence to reduce the instantaneous load on the power modules.

After start up each power output is protected by overlapping safety features that guard against excess demand by any connected device. Additionally, the RMPSU can be controlled and monitored via a web interface. Temperature, fan speeds and individual current measurements are viewable and each output can be individually controlled.

The RMPSU features either one, or two, hot-swappable switched mode 460W power modules. A single power module is rated at 500,000 hours MTBF and can easily meet the needs of sixteen ports. However, in situations where redundancy is required, a second power module is available. With two power modules, the normal load will be intelligently balanced; with the full power load transferring immediately to the healthy module should one of the modules cease operation.

Ready for Change

Whether, the requirement is adding new capability or optimizing current space in the rack, the RMPSU makes it easy to add or relocate systems without the need to manage external power supplies. Each RMPSU can support up to 8 or 16 devices. All power outputs feature a locking connector to guard against accidental disconnection and provides a maximum of 20W at 12V.

The Avocent Rackmount Power Supply (RMPSU) is a perfect solution for organizations that need to reduce power usage, increase flexibility and optimize precious rack real estate.

Power supply, IEC Adapter & 4 output cable to support up to 4 MPUIQ-SRL modules

The Vertiv ADX Power Supply comes with a 2-way and a 4-way splitter for IP KVM devices.

Redundant Power Supply

For use with the HMX 5000/6000 High-Performance KVM Solution

Control and monitor the RMPSU via a secure HTTP interface

Available with one or two hot-swappable power module

Independently controllable Outputs

All power outputs lockable to guard against accedental disconnection

For use with the HMX 5000/6000 High-Performance KVM Solution

Control and monitor the RMPSU via a secure HTTP interface

Available with one or two hot-swappable power module

Independently controllable Outputs

All power outputs lockable to guard against accedental disconnection
