TP-Link Omada Access Points

The TP-Link EAP215-Bridge KIT delivers up to 867 Mbps on the 5 GHz band for fast and reliable data transmission. Ideal for long-range wireless coverage, it supports connections up to 5 km, making it perfect for large outdoor areas. Simplify deployment with auto-pairing and agile LED indicators.

802.11ac for up to 867 Mbps on the 5 GHz wireless data rate.

Ideal for long-range wireless transmission up to 5 km.

Auto-pairing and agile LEDs for efficient deployment.

3× Gigabit Ethernet ports for more high-speed IP camera connections.

Supports Omada SDN for remote and centralized management.

IP65 weatherproof enclosure and 6kV lightning protection ensure all-weather suitability.

Supports Passive PoE for flexible deployment

The EAP683 LR is a high-performance AX6000 Ceiling Mount WiFi 6 Access Point, delivering blazing speeds of up to 5952 Mbps. Seamlessly manage advanced features like Omada Mesh and Seamless Roaming via the Omada SDN platform, powered conveniently by PoE+.

Features

Up to 5952 Mbps WiFi 6 Speeds: 1148 Mbps on 2.4 GHz + 4804 Mbps on 5 GHz†
Supports WiFi 6 technologies, such as HE160, 1024-QAM, etc.‡
Integrates with Omada SDN platform for centralized management.
Advanced Features: Omada Mesh, Seamless Roaming, and more.§
PoE+ Powered: Supports both 802.3at PoE+ and DC (adapter included).
What's in the box

Specifications

Standards Wireless Standards: IEEE 802.11ax/ac/n/g/b/a

WiFi Speeds 5 GHz: Up to 4804 Mbps
2.4 GHz: Up to 1148 Mbps

WiFi Capacity Concurrent Clients: 512

Security Wireless Security: Captive Portal Authentication, Access Control, Wireless MAC Address Filtering, Wireless Isolation Between Clients, SSID to VLAN Mapping, Rogue AP Detection, 802.1X Support, WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise

Ethernet Ports 1× 2.5 Gigabit PoE+ Port

Dimensions (W×D×H) 8.7 × 8.7 × 1.3 in (220 × 220 × 32.5 mm)

*For complete specification see the documentation tab above

The Omada EAP110 by TP-Link provides a business-class wireless network solution that’s flexible, manageable, secure, and easy-to-deploy. Featuring cloud access, Omada Cloud Controller OC200 or Omada Software Controller allow users to centrally manage the entire Omada networks in the remote site. And the intuitive Omada app makes network management incredibly convenient. Omada EAPs also feature captive portal and advanced RF management functions, which make them ideal for demanding, high-traffic environments such as campuses, hotels, malls and offices..

Free cloud centralised management and Omada app for ultra convenience and easy management


Supports passive PoE for convenient installation up to 100 metres


Simple mounting design for easy attachment to a wall or ceiling


Secure guest network along with multiple authentication options (SMS/Facebook Wi-Fi/ Voucher, etc.) and abundant wireless security technologies


Enterprise class Wi-Fi security help to decrease network security threats


Multi-SSID divides multiple wireless networks for different user types


Supports management VLAN for an enhanced network management


Flexible Placement Easy mounting design & PoE

The EAP’s elegant appearance and easy mounting design with chassis make it easy to be integrated seamlessly into any wall or ceiling surface to blend in with most interior decorations. EAP110 supports Passive PoE to make deployment effortless and flexible.



Free Cloud Centralised Management - Anytime, Anywhere Omada Cloud Controller OC200 and Omada Software Controller make it easy to manage and monitor the whole Omada network in real-time, while cloud service enables remote and secure access no matter where you find yourself.



Easy Management with the Omada App Follow configuration instructions on the free Omada app to get set up in minutes. Omada lets you configure settings, monitor the network status and manage clients, all from the convenience of a smart phone or tablet..



Guest Network with Facebook and SMS Support Captive portal helps maintain only authorised guests to use the network, presenting devices with a convenient, user-friendly authentication method to grant Wi-Fi access. The addition of SMS and Facebook authentication simplifies the captive portal even further to simplify connectivity and boost your business.





Meet the New OC200 Cloud Controller The OC200 Omada Cloud Controller is dedicated to provide centralised management for the whole Omada network.

Omada Cloud Controller

OC200



  Model Omada EAP225-wall Omada EAP245v3 Omada EAP225v3 Omada EAP115 Omada EAP110 Product Name AC1200 Wireless MUMIMO Wall Plate Access Point AC1750 Wireless MU-MIMO Gigabit Ceiling Mount Access Point AC1350 Wireless MU-MIMO Gigabit Ceiling Mount Access Point 300Mbps Wireless N Access Point 300Mbps Wireless N Access Point Speed 2.4GHz : 300Mbps
5GHz : 867Mbps 2.4GHz : 450Mbps
5GHz : 1300Mbps 2.4GHz : 450Mbps
5GHz : 867Mbps 2.4GHz : 300Mbps 2.4GHz : 300Mbps Ethernet Port 4 × 10/100Mbps Port 2 × Gigabit Port 1 × Gigabit Port 1 × 10/100Mbps Port 1 × 10/100Mbps Port Power Supply 802.3af/at PoE + 802.3af & 48V Passive PoE 802.3af & 24V Passive PoE 802.3af & 9V/0.6A DC 24v Passive PoE Internal Antennas 2.4GHz:2×2.3dBi
5GHz: 2×4dBi 2.4GHz: 3×3.5dBi
5GHz: 3×4dBi 2.4GHz: 3×4dBi
5GHz: 2×5dBi 2×4dBi 2×4dBi   Buy Buy Buy Buy Buy

The Omada EAP115-wall by TP-Link provides a business-class wireless network solution that’s flexible, manageable, secure, and easy-to-deploy. Featuring cloud access, Omada Cloud Controller OC200 or Omada Software Controller allow users to centrally manage the entire Omada networks in the remote site. And the intuitive Omada app makes network management incredibly convenient. Omada EAPs also feature captive portal and advanced RF management functions, which make them ideal for demanding, high-traffic environments such as campuses, hotels, shopping centres and offices..

Easy-mount construction allows installation into any standard EU-type data wall-box


Compact, low-profile design fits discreetly with any existing interior style


Free cloud centralised management and Omada app for ultra convenience and easy management


Supports Power over Ethernet (802.3af) for convenient and affordable installation


Enterprise class Wi-Fi security helps to decrease network security threats


Captive portal provides one convenient method of authentication for Wi-Fi guests


Supports management VLAN for an enhanced network management


Perfectly Formed The EAP115-Wall would blend seamlessly into any business setting with a refined, minimalist appearance. A slimline design includes casing that’s just 11 mm in thickness.



Effortless Deployment With 802.3af Power over Ethernet supported there’s no need for additional wiring. Simply plug in existing Ethernet cables and you’re ready to go.



Complete Wireless Coverage An EAP in each room guarantees a strong wireless signal and allows guests to enjoy their own private Wi-Fi network.



Free Cloud Centralised Management - Anytime, Anywhere Omada Cloud Controller OC200 and Omada Software Controller make it easy to manage and monitor the whole Omada network in real-time, while cloud service enables remote and secure access no matter where you find yourself.



Easy Management with the Omada App Follow configuration instructions on the free Omada app to get set up in minutes. Omada lets you configure settings, monitor the network status and manage clients, all from the convenience of a smart phone or tablet..



Meet the New OC200 Cloud Controller The OC200 Omada Cloud Controller is dedicated to provide centralised management for the whole Omada network.

Omada Cloud Controller

OC200



  Model Omada EAP225-wall Omada EAP115-wall Omada EAP225v3 Omada EAP115 Omada EAP110 Product Name AC1200 Wireless MUMIMO Wall Plate Access Point 300Mbps Wireless N Wall Plate Access Point AC1350 Wireless MU-MIMO Gigabit Ceiling Mount Access Point 300Mbps Wireless N Access Point 300Mbps Wireless N Access Point Speed 2.4GHz : 300Mbps
5GHz : 867Mbps 2.4GHz : 450Mbps 2.4GHz : 450Mbps
5GHz : 867Mbps 2.4GHz : 300Mbps 2.4GHz : 300Mbps Ethernet Port 4 × 10/100Mbps Port 2 × 10/100Mbps Port 1 × Gigabit Port 1 × 10/100Mbps Port 1 × 10/100Mbps Port Power Supply 802.3af/at PoE + 802.3af 802.3af & 24V Passive PoE 802.3af & 9V/0.6A DC 24v Passive PoE Internal Antennas 2.4GHz:2×2.3dBi
5GHz: 2×4dBi 2×1.8dBi 2.4GHz: 3×4dBi
5GHz: 2×5dBi 2×4dBi 2×4dBi   Buy Buy Buy Buy Buy

The Omada EAP225 by TP-Link provides a business-class wireless network solution that’s flexible, manageable, secure, and easy-to-deploy. Featuring cloud access, Omada Cloud Controller OC200 or Omada Software Controller allow users to centrally manage the entire Omada networks in the remote site. And the intuitive Omada app makes network management incredibly convenient. Omada EAPs also feature captive portal and advanced RF management functions, which make them ideal for demanding, high-traffic environments such as campuses, hotels, shopping centres and offices.

Simultaneous 450Mbps on 2.4GHz and 867Mbps on 5GHz totals 1317Mbps Wi-Fi speeds


Supports Seamless Roaming so even video streams and voice calls are unaffected as users move between locations


Free cloud centralised management and Omada app for ultra convenience and easy management


Compatibility with 802.3af and Passive PoE (PoE adpater included) support makes deployment effortless and flexible


Secure guest network along with multiple authentication options (SMS/Facebook Wi-Fi/ Voucher, etc.) and abundant wireless security technologies.


Band Steering Automatically moves dual band devices onto the wider 5GHz band for faster connections


MU-MIMO means access points simultaneously transfer data with multiple devices, speeding up connections


Beamforming concentrates signal towards where you need it most, providing a fast and stable Wi-Fi experience


Schedules can be set so access points automatically reboot and Wi-Fi turns on/off at the times you choose






An Affordable Scalable Business Wi-Fi Solution 802.11ac MU-MIMO Wi-Fi Solution

Build and manage a scalable Wi-Fi network for your business with the Omada business class solution, tailored to handle the power of hundreds of TP-LINK EAPs at an affordable cost.







Superior Wi-Fi Speeds with MU-MIMO Technology Outfitted with the latest 802.11ac Wave 2 MU-MIMO technology, the EAP225 easily delivers dual-band Wi-Fi speeds of up to 1350 Mbps to multiple devices at the same time.





Free Cloud Centralised Management - Anytime, Anywhere Omada Cloud Controller OC200 and Omada Software Controller make it easy to manage and monitor the whole Omada network in real-time, while cloud service enables remote and secure access no matter where you find yourself.







Easy Management with the Omada App Follow configuration instructions on the free Omada app to get set up in minutes. Omada lets you configure settings, monitor the network status and manage clients, all from the convenience of a smart phone or tablet..







Guest Network with Facebook and SMS Support Captive portal helps maintain only authorised guests to use the network, presenting devices with a convenient, user-friendly authentication method to grant Wi-Fi access. The addition of SMS and Facebook authentication simplifies the captive portal even further to simplify connectivity and boost your business.







Timesaving and Flexible Deployment The Omada EAP225 is designed for easy installation on any wall or ceiling. The Power over Ethernet (PoE) function allows your network cables to carry electrical power so you minimise on cable clutter. It’s one more hardwiring hassle you don’t have to worry about when operating your centralised management system.







Meet the New OC200 Cloud Controller The OC200 Omada Cloud Controller is dedicated to provide centralised management for the whole Omada network.

Omada Cloud Controller

OC200









  Model Omada EAP225-wall Omada EAP245 v3 Omada EAP225 v3 Omada EAP115 Omada EAP110 Product Name AC1200 Wireless MUMIMO Wall Plate Access Point AC1750 Wireless MU-MIMO Gigabit Ceiling Mount Access Point AC1350 Wireless MU-MIMO Gigabit Ceiling Mount Access Point 300Mbps Wireless N Access Point 300Mbps Wireless N Access Point Speed 2.4GHz : 300Mbps
5GHz : 867Mbps 2.4GHz : 450Mbps
5GHz : 1300Mbps 2.4GHz : 450Mbps
5GHz : 867Mbps 2.4GHz : 300Mbps 2.4GHz : 300Mbps Ethernet Port 4 × 10/100Mbps Port 2 × Gigabit Port 1 × Gigabit Port 1 × 10/100Mbps Port 1 × 10/100Mbps Port Power Supply 802.3af/at PoE + 802.3af & 48V Passive PoE 802.3af & 24V Passive PoE 802.3af & 9V/0.6A DC 24v Passive PoE Internal Antennas 2.4GHz:2×2.3dBi
5GHz: 2×4dBi 2.4GHz: 3×3.5dBi
5GHz: 3×4dBi 2.4GHz: 3×4dBi
5GHz: 2×5dBi 2×4dBi 2×4dBi   Buy Buy Buy Buy Buy

EAP230-Wall is designed to meet every network need in environments with numerous separated rooms, like hotels, offices, and dormitories. A device in each room ensures an exclusive, high-speed Wi-Fi connection for every user.


Product Features



Fast Dual-Band Wi-Fi: Simultaneous 300 Mbps on 2.4 GHz and 867 Mbps on 5 GHz totals 1,167 Mbps Wi-Fi speeds with MU-MIMO.†


Gigabit Ports: 2 Gigabit Ethernet ports (1× uplink + 1× downlink).


Integrated into Omada SDN: Zero-Touch Provisioning (ZTP)‡, Centralized Cloud Management, and Intelligent Monitoring.


Centralized Management: Cloud access and Omada app for ultra convenience and easy management.


Private Connection for Every Room: Designed to meet every network need in environments with numerous separated rooms, like hotels, offices, and dormitories.


Elegant Appearance: Unprecedented thin design with just 11 mm, the same size and shape as a light switch or power outlet faceplate to fit perfectly in any room.


Easy Installation and PoE Support: Easy-mount construction, compatible with 86 mm & EU standard junction box, and 802.3af/at PoE support.


Secure Guest Network: Along with multiple authentication options (SMS/Facebook Wi-Fi/ Voucher, etc.) and abundant wireless security technologies.





MU-MIMO + Dual-Band: Faster Connection for More Devices


802.11ac wave 2 technology allows multiple users to access the internet at the same time. Speeds up to 1200 Mbps and 2.4 GHz and 5 GHz wireless bands deliver simultaneous high-speed internet access to various devices.










Seamlessly Blends with any Décor


The same size and shape as a light switch or power outlet faceplate to fit in perfectly in any room.












High-Speed Gigabit Port


Equipped with a Gigabit port to deliver the fastest possible wired transmission.












Effortless Deployment with Power over Ethernet



802.3af/802.3at PoE support means there’s no need for extra wiring. Plug in existing Ethernet cables to transmit both power and data to your APs.








Omada SDN - Smarter Cloud Solution for Business Networking




Omada Software Defined Networking (SDN) platform integrates network devices including access points, switches and gateways, guaranteeing powerful business network with higher efficiency, higher security, and higher reliability.




Easy Management with the Omada App




Follow configuration instructions on the free Omada app to get set up in minutes. Omada lets you configure settings, monitor the network status and manage clients, all from the convenience of a smart phone or tablet.

TP-Link AC1200 Wall Plate Dual-Band Wi-Fi Access Point (EAP235-Wall)The TP-Link EAP235-Wall is a wireless MU-MIMO Gigabit wall plate access point which enables multiple users to access the Internet simultaneously, which largely boosts up your network speed of up to 1,200 Mbps. Capable of transmitting in both 2.4 GHz and 5 GHz wireless band, it provides greater compatibility to connect varieties of devices. With 802.3af/802.3at Power over Ethernet supported there’s no need to install additional wiring in the building. Simply plug in existing Ethernet cables and you’re ready to go.

TP-Link EAP235-Wall Key Features

Fast Dual-Band Wi-Fi: Simultaneous 300 Mbps on 2.4 GHz and 867 Mbps on 5 GHz totals 1,167 Mbps Wi-Fi speeds with MU-MIMO.
Four Gigabit Ports: 4 Gigabit Ethernet ports (1× uplink + 3× downlink), with one downlink port supporting PoE pass-through to provide power for wired device.
Integrated into Omada SDN: Zero-Touch Provisioning (ZTP)‡, Centralised Cloud Management, and Intelligent Monitoring.
Centralised Management: Cloud access and Omada app for ultra convenience and easy management.
Elegant Appearance: Ultra slimmest and conspicuous design blends into hotel rooms, hospitals, offices, dormitories and any other environments.
Easy Installation and PoE Support: Easy-mount construction, compatible with 86 mm & EU & US standard junction box, and 802.3af/at PoE support.
Secure Guest Network: Along with multiple authentication options (SMS/Facebook Wi-Fi/ Voucher, etc.) and abundant wireless security technologies.
Advanced Wireless Tech: Optimize network performance with MU-MIMO, Band Steering, and Beamforming technologies.
TP-Link EAP235-Wall - Technical Specifications

Hardware FeaturesInterface:
- Uplink: 1× 10/100/1000 Mbps Ethernet Port
- Downlink: 3× 10/100/1000 Mbps Ethernet Ports (One port supports PoE OUT. The PoE OUT feature requires 802.3at PoE+ input and the maximum output is 13 W.)
Physical Security Lock: Yes
Button: Reset
Power Supply: 802.3af/802.3at PoE
Power Consumption: 9.8 watts /24.4 watts (PoE Out Included)
Dimensions: 143 × 86 × 20 mm (5.6 × 3.4 × 0.8 in)
Antenna Type: 2 Dual-Band Antennas
- 2.4 GHz: 2× 4 dBi
- 5 GHz: 2× 4 dBi
Mounting: Wall Plate Mounting
Wireless FeaturesWireless Standards: IEEE 802.11a/b/g/n/ac
Frequency: 2.4 GHz and 5 GHz
Signal Rate:
- 5 GHz: Up to 867 Mbps
- 2.4 GHz: Up to 300 Mbps
Wireless Functions:
- 16 SSIDs (Up to 8 SSIDs on each band)
- Enable/Disable Wireless Radio
- Automatic Channel Assignment
- Transmit Power Control (Adjust Transmit Power on dBm)
- QoS(WMM)
- MU-MIMO
- Band Steering
- Load Balance
- Beamforming
- Rate Limit
- Reboot Schedule
- Wireless Schedule
- Wireless Statistics based on SSID/AP/Client
Wireless Security:
- Captive Portal Authentication
- Access Control
- Wireless Mac Address Filtering
- Wireless Isolation Between Clients
- SSID to VLAN Mapping
- Local LAN port based VLAN
- Rogue AP Detection
- 802.1X Support
- 64/128/152-bit WEP / WPA / WPA2-Enterprise, WPA-PSK / WPA2-PSK
Transmission Power:
- CE:<20 dBm(2.4 GHz, EIRP), <23 dBm(5 GHz, EIRP)
- FCC:<21 dBm (2.4 GHz), <21 dBm (5 GHz)
ManagementOmada App: Yes
Centralised Management:
- Omada Cloud-Based Controller
- Omada Hardware Controller (OC300)
- Omada Hardware Controller (OC200)
- Omada Software Controller
Cloud Access: Yes (Through OC300, OC200, Omada Cloud-Based Controller, or Omada Software Controller)
Email Alerts: Yes
LED ON/OFF Control: Yes
Management MAC Access Control: Yes
SNMP: v1, v2c
System Logging Local/Remote Syslog: Local/Remote Syslog
SSH: Yes
Web-based Management: HTTP/HTTPS
L3 Management: Yes
Multi-site Management: Yes
Management VLAN: Yes
OtherCertification: CE, FCC, RoHS
Package Contents:
- Omada AC1200 Wireless MU-MIMO Gigabit Wall Plate Access Point EAP235-Wall
- Mounting Screw
- Installation Guide
System Requirements: Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10
Environment:
- Operating Temperature: 0–40 ? (32–104 ?)
- Storage Temperature: -40–70 ? (-40–158 ?)
- Operating Humidity: 10–90% RH non-condensing
- Storage Humidity: 5–90% RH non-condensing

Product Features Superior WiFi 6 Speeds: Simultaneous 574 Mbps on 2.4 GHz and 1201 Mbps on 5 GHz totals 1775 Mbps Wi-Fi speeds.**

High-Performance Connectivity: Guarantee higher network efficiency and lower latency.

Four Gigabit Ports: 4 Gigabit Ethernet ports (1× uplink + 3× downlink), with one downlink port supporting PoE pass-through to provide power for wired device.‡

Centralized Management: Integrates into Omada SDN for cloud access and remote management.

Secure Guest Network: Along with multiple authentication options (SMS/Facebook Wi-Fi/ Voucher, etc.) and abundant wireless security technologies.†

Easy Installation and PoE Support: Easy-to-install design, compatible with 86 mm & EU & US standard junction box, and 802.3af/at PoE support.

Seamless Integrated into Omada SDN Platform The Omada Software Defined Networking (SDN) platform integrates network devices including access points, switches, and routers to provide 100% centralized cloud management and create a highly scalable network—all controlled from a single interface.

Easy Management with the Omada App Follow the configuration instructions on the free Omada app to get set up in minutes. Omada lets you configure settings, monitor the network status and manage clients, all from the convenience of a smart phone or tablet.

AX1800 Ceiling Mount WiFi 6 Access Point

Upgrade to WiFi 6, Power up Your Business




Key Features • Ultra-Fast WiFi 6 Speeds: Simultaneous 574 Mbps on 2.4 GHz and 1201 Mbps on 5 GHz totals 1775 Mbps Wi-Fi speeds.

• High-Efficiency WiFi 6: More connected devices can enjoy faster speeds.

• Centralized Cloud Management: Manage the whole network locally or from the cloud via web UI or Omada app.

• Seamless Roaming: Even video streams and voice calls are unaffected as users move between locations.

• Omada Mesh: Enables wireless connectivity between access points for extended range and flexible deployment.

• PoE+ Powered: Supports both Power over Ethernet (802.3at) and DC power supply for flexible installations.

• Secure Guest Network: Along with multiple authentication options (SMS/Facebook Wi-Fi/ Voucher, etc.) and abundant wireless security technologies.













Superior WiFi 6 Speeds Upgrade to WiFi 6 with speeds up to 1775 Mbps brings 50% faster speeds than WiFi 5. Every application feels more fluid with drastically improved Wi-Fi speeds.






Higher Efficiency for More Devices WiFi 6 features such as OFDMA and MU-MIMO handle multiple clients across congested environments such as typical office spaces, lodging, and small clinics. Enjoy faster speeds on more devices with less lag.






Seamless Integration into Omada SDN Platform The Omada Software Defined Networking (SDN) platform integrates network devices including access points, switches, and routers to provide 100% centralized cloud management and create a highly scalable network—all controlled from a single interface.






Easy Deployment & Higher Performance by Omada Mesh Easy Pairing, Less Wiring

With Mesh technology, Omada EAPs save you from extra wires by wirelessly extending your WiFi signal further and more flexibly to hard-to-wire areas.






Optimized Network Performance Intelligent self-organization optimizes the best path between EAPs while self-healing ensures you stay online even when one AP is disrupted.






Always Stay Smooth with Fast Roaming Ensures customers to enjoy uninterrupted streaming when moving around by switching clients automatically to the access points with the optimal signal.






Easy to Mount with Refined Industrial Design Step 1. Push up

Step 2. Simply rotate to lock






Boosted Network Security and Efficiency Secure Guest Network with Up to 16 SSIDs

Guest network access provides enhanced security to guests. Different SSIDs also enable flexible access management.

Guest Network with Facebook Wi-Fi and SMS Login

Captive portal (including SMS, Facebook Wi-Fi, Voucher) and 802.1x authentication help maintain authorized guests to use the network. Boost your business with a customized marketing page.

WPA3 for Worry-Free Open Public Networks

With advanced enterprise security, WPA3 provides more data security for previously unsecured and open WiFi hotspots.

Band Steering

Automatically moves dual band devices onto the wider 5GHz band for faster connections.

Load Balance

Ensures large numbers of users have smooth network experiences in high-density business networks

Airtime Fairness

Increases average network throughput in heavily congested environments

The Omada EAP245 by TP-Link provides a business-class wireless network solution that’s flexible, manageable, secure, and easy-to-deploy. Featuring cloud access, Omada Cloud Controller OC200 or Omada Software Controller allow users to centrally manage the entire Omada networks in the remote site. And the intuitive Omada app makes network management incredibly convenient. Omada EAPs also feature captive portal and advanced RF management functions, which make them ideal for demanding, high-traffic environments such as campuses, hotels, shopping centres and offices..

Simultaneous 450Mbps on 2.4GHz and 1300Mbps on 5GHz totals 1750Mbps Wi-Fi speeds


Supports Seamless Roaming so even video streams and voice calls are unaffected as users move between locations


Free cloud centralised management and Omada app for ultra convenience and easy management


Support Power over Ethernet (802.3at) for convenient and affordable installation


Secure guest network along with multiple authentication options (SMS/Facebook Wi-Fi/ Voucher, etc.) and abundant wireless security technologies.


Band Steering Automatically moves dual band devices onto the wider 5GHz band for faster connections


MU-MIMO means access points simultaneously transfer data with multiple devices, speeding up connections


Beamforming concentrates signal towards where you need it most, providing a fast and stable Wi-Fi experience


Load balance ensures large numbers of users have smooth network experiences in high density business networks


An Elite Business Scalable Business Wi-Fi Solution AC1750 802.11ac MU-MIMO Wi-Fi Solution

Build and manage a scalable Wi-Fi network for your business with the Omada business class solution, tailored to handle the power of hundreds of TP-LINK EAPs at an affordable cost.



Superior Wi-Fi Speeds and Performance QCA enterprise class chipsets, dedicated high-power amplifier and professional antenna along with the latest generation 802.11ac Wave 2 MU-MIMO technology, ensure superior 1750 Mbps Wi-Fi speeds and long-range coverage over 2.4GHz and 5GHz wireless bands.

Free Cloud Centralised Management - Anytime, Anywhere Omada Cloud Controller OC200 and Omada Software Controller make it easy to manage and monitor the whole Omada network in real-time, while cloud service enables remote and secure access no matter where you find yourself.



Easy Management with the Omada App Follow configuration instructions on the free Omada app to get set up in minutes. Omada lets you configure settings, monitor the network status and manage clients, all from the convenience of a smart phone or tablet..



Guest Network with Facebook and SMS Support Captive portal helps maintain only authorised guests to use the network, presenting devices with a convenient, user-friendly authentication method to grant Wi-Fi access. The addition of SMS and Facebook authentication simplifies the captive portal even further to simplify connectivity and boost your business.



Multiple PoE Options for Easy Installation EAP245 supports both 802.3at PoE and Passive PoE power supply, can be either powered by a PoE switch or the provided PoE adapter. The addition of elegant appearance and simple mounting design for easy attachment to a wall or ceiling further makes deployment effortless and flexible.

Meet the New OC200 Cloud Controller The OC200 Omada Cloud Controller is dedicated to provide centralised management for the whole Omada network.

Omada Cloud Controller

OC200



  Model Omada EAP225-wall Omada EAP245v3 Omada EAP225v3 Omada EAP115 Omada EAP110 Product Name AC1200 Wireless MUMIMO Wall Plate Access Point AC1750 Wireless MU-MIMO Gigabit Ceiling Mount Access Point AC1350 Wireless MU-MIMO Gigabit Ceiling Mount Access Point 300Mbps Wireless N Access Point 300Mbps Wireless N Access Point Speed 2.4GHz : 300Mbps
5GHz : 867Mbps 2.4GHz : 450Mbps
5GHz : 1300Mbps 2.4GHz : 450Mbps
5GHz : 867Mbps 2.4GHz : 300Mbps 2.4GHz : 300Mbps Ethernet Port 4 × 10/100Mbps Port 2 × Gigabit Port 1 × Gigabit Port 1 × 10/100Mbps Port 1 × 10/100Mbps Port Power Supply 802.3af/at PoE + 802.3af & 48V Passive PoE 802.3af & 24V Passive PoE 802.3af & 9V/0.6A DC 24v Passive PoE Internal Antennas 2.4GHz:2×2.3dBi
5GHz: 2×4dBi 2.4GHz: 3×3.5dBi
5GHz: 3×4dBi 2.4GHz: 3×4dBi
5GHz: 2×5dBi 2×4dBi 2×4dBi   Buy Buy Buy Buy Buy

AX3000 Ceiling Mount WiFi 6 Access Point



Key Features: • Ultra-Fast WiFi 6 Speeds: Simultaneous 574 Mbps on 2.4 GHz and 2402 Mbps on 5 GHz totals 2976 Mbps WiFi speeds.

• High-Efficiency WiFi 6: More connected devices can enjoy faster speeds.

• Centralized Cloud Management: Omada SDN integration manages the whole network locally or from the cloud via web UI or Omada app.

• 160 MHz Channel: Double the data at peak transmission times on a single stream with HE160.

• Seamless Roaming: Video streams and voice calls are unaffected as users move between locations

• Omada Mesh: Enables wireless connectivity between access points for extended range and flexible deployment.

• PoE+ Powered: Supports both 802.3at PoE+ and DC (adapter included) power supply for flexible installations.

• Ultra-Slim Design: 160 mm × 33.6 mm elegant design brings more agility.




The New Slimline Business WiFi 6 AX3000 Ceiling Mount WiFi 6 Access Point









AX3000 WiFi 6 Speed
2402 Mbps on 5 GHz + 574 Mbps on 2.4 GHz



High-Efficiency WiFi 6
More connected devices can enjoy faster speeds



Centralized Cloud Management
Manage the whole network locally or from the cloud



160 MHz Channel
Double the data at peak transmission times on a single stream with HE160



Auto Channel Selection and Power Adjustment
Optimize overall performance by reducing WiFi interference



Omada Mesh Technology
More flexible and convenient wireless deployment



Seamless Roaming
Uninterrupted streaming when moving between APs



Ultra-Slim Design
160 mm × 33.6 mm elegant design brings more agility



PoE+ Powered
Supports both DC (adapter included) and 802.3at PoE+ for flexible installations



Designed for Business Environments Requiring High-Performance WiFi Hospitality High-quality and full coverage Guest WiFi


Education High-security WiFi to connect more devices


Shopping Mall Seamless marketing WiFi coverage to boost business


Office Stable, seamless, and high-security WiFi coverage


Meeting Room Faster streaming, downloading, video conferencing, and more







Power up Your Business with New-Era Business WiFi 6 WiFi 6 brings faster speeds, lower lag, less interference, and higher capacity.



1024 QAM
25% more data encoded at one time



Long OFDM Symbol
11% faster speed



HE160
Double the data at peak transmission times on a single stream











Higher Efficiency for More Devices Wi-Fi 6 features such as OFDMA and MU-MIMO handle multiple clients across congested environments like typical office spaces, lodging, and hospitals. Enjoy faster speeds on more devices with less lag. as typical office spaces, lodging, and small clinics. Enjoy faster speeds on more devices with less lag.











Seamless Integration into Omada SDN The Omada Software Defined Networking (SDN) platform integrates network devices including access points, switches, and routers to provide 100% centralized cloud management and create a highly scalable network—all controlled from a single interface.



Hardware, Software, or Cloud-Based Controllers



Centralized Cloud Management



Intelligent Monitoring



Zero-Touch Provisioning (ZTP)












Auto Channel Selection and Power Adjustment to Optimize Overall Performance Provides powerful wireless performance while significantly reducing WiFi interference by automatically adjusting the channel settings and transmission power levels of neighboring APs in the same network












Easy Deployment & Higher Performance by Omada Mesh Easy Pairing, Less Wiring

With Mesh technology, Omada EAPs save you from extra wires by wirelessly extending your WiFi signal further and more flexibly to hard-to-wire areas.












Optimized Network Performance Intelligent self-organization optimizes the best path between EAPs while self-healing ensures you stay online even when one AP is disrupted.












Always Stay Smooth with Fast Roaming Ensures customers to enjoy uninterrupted streaming when moving around by switching clients automatically to the access points with the optimal signal.












Ultra-Slim Design Brings More Agility Exceptional performance with compact design ensures simple WiFi installation while saving space. The elegant appearance makes EAP653 perfectly blend into any modern office, hotel, classroom, or café.












Easy to Mount with Refined Industrial Design

1. Push up.



2. Rotate to lock.






Security Secure Guest Network with Up to 16 SSIDs Guest network access provides enhanced security to guests. Different SSIDs also enable flexible access management.




Boost Business with Facebook WiFi and SMS Login Captive portal (including SMS, Facebook Wi-Fi, Voucher) and 802.1x authentication help maintain authorized guests to use the network. Boost your business with a customized marketing page.




WPA3 for Worry-Free Open Public Networks With advanced enterprise security, WPA3 provides more data security for previously unsecured and open WiFi hotspots.








Efficiency Band Steering Automatically moves dual band devices onto the wider 5GHz band for faster connections.




Load Balance Ensures large numbers of users have smooth network experiences in high-density business networks




Airtime Fairness Increases average network throughput in heavily congested environments

Professional AC1750 WiFi Solution for High-Density Environments AC1750 Wireless MU-MIMO Gigabit Ceiling Mount Access Point



Features

Fast Dual-Band Wi-Fi: Simultaneous 450 Mbps on 2.4 GHz and 1300 Mbps on 5 GHz totals 1750 Mbps Wi-Fi speeds
High-Density Connectivity: MU-MIMO, Load Balance, and professional antennas improve capacity in high-density environments to connect more devices simultaneously.
Integrated into Omada SDN: Supports Zero-Touch Provisioning (ZTP), Centralized Cloud Management, and Intelligent Monitoring.
Centralized Management: Cloud access and Omada app for ultra convenience and easy management.
Seamless Roaming: Even video streams and voice calls are unaffected as users move between locations.
PoE Support: Supports both standard 802.3af/at and Passive PoE (PoE adapter included) for flexible installations.
Secure Guest Network: Along with multiple authentication options (SMS/Facebook Wi-Fi/ Voucher, etc.) and abundant wireless security technologies.



Connect More Devices in Dense Environments

With enterprise-class performance, EAP265 HD is designed to meet the challenging goal of increased capacity by up to 3 times in dense environments compared to standard AC EAP without high-density capability. MU-MIMO and professional antennas help to deliver reliable WiFi to more devices simultaneously, leveraging multi-user experience like never before.





Premium Dual-Band Speeds with Long Range Coverage

Supported 802.11ac Wave2 technology, EAP265 HD provides boosted Wi-Fi speeds up 1750 Mbps for more devices in high-dense environments. Dedicated high-power antennas with Beamforming ensure long range coverage over the 2.4 GHz and 5 GHz band. Advanced wireless technologies like Load Balance, Band Steering, and Airtime Fairness optimize the whole network performance and improve efficiency.




Seamless Roaming

802.11k/v roaming switches clients automatically to the AP with the optimal signal with a seamless transition when moving. This allows sensitive applications like VoIP and video conferences to go uninterrupted.




Secure Guest Network with Facebook Wi-Fi and SMS Login

Guest Network provides elevated secure access to guests sharing your Wi-Fi network, with captive portal helping maintain only authorized guests to use the network. The addition of SMS and Facebook authentication simplifies the captive portal even further to simplify connectivity and power up your business.




Multiple PoE Options for Easy Installation

EAP265 HD supports both 802.3af PoE and Passive PoE power supply, can be either powered by a PoE switch or the provided PoE adapter. The addition of elegant appearance and simple mounting design for easy attachment to a wall or ceiling further makes deployment effortless and flexible.




Easy Management with the Omada App

Follow configuration instructions on the free Omada app to get set up in minutes. Omada lets you configure settings, monitor the network status and manage clients, all from the convenience of a smart phone or tablet.

AX3000 Wall Plate WiFi 6 Access Point

Match Your Room with AX3000 WiFi 6




Key Features • Blazing-Fast AX3000 WiFi 6 Speeds: Simultaneous 574 Mbps on 2.4 GHz and 2402 Mbps on 5 GHz totals 2976 Mbps WiFi speeds.

• Higher Network Efficiency: Deliver data to more devices at the same time with less lag.

• Complete In-Room WiFi Coverage: Guaranteed strong signals and corner-to-corner WiFi coverage.

• Gigabit Port: Connect wired devices with one downlink gigabit port.

• Centralized Cloud Management: Integrates into Omada SDN for cloud access and remote management.

• Secure Guest Network: Implement multiple authentication options (SMS/Facebook Wi-Fi/ Voucher) packed with high-quality wireless security technologies.

• Easy Installation and PoE Support: Easy-to-install design, compatible with 86 mm & EU standard junction box, and 802.3af/at PoE support.




AX3000 WiFi 6 Speed
2402 Mbps on 5 GHz + 574 Mbps on 2.4 GHz

High-Efficiency WiFi 6
More connected devices can enjoy faster speeds

Centralized Cloud Management
Manage the whole network locally or from the cloud





160 MHz Channel
Double the data at peak transmission times on a single stream with HE160

Enhanced Security
With guest networks, Captive Portal, and WPA3 encryption

Seamless Roaming
Uninterrupted streaming when moving between APs





Two Gigabit Ports
One downlink and one uplink for fast wired connection

802.3af/at PoE Support
Flexible and convenient deployment

Quick, Simplified Installation
Compatible with 86 mm & EU standard junction box





Dedicated Complete, Private WiFi Network in Each Room Hospitality

Room-by-room connection with elegant appearance

Dormitory

Stable wireless and wired connections

Apartment

Private and secure network access for every family

Villa

Whole-home WiFi coverage with seamless roaming

Meeting Room

Faster streaming, downloading, video conferencing, and everything to satisfy your needs




Quick, Simplified Installation With an easy-to-install design, there is no need to bring someone in to install our EAP.




Lightning-Fast AX3000 WiFi 6 Speeds WiFi 6 brings faster speeds, lower lag, less interference, and higher capacity. Enjoy more than twice the speed of WiFi 5 with new-era business WiFi 6 with speeds up to 2976 Mbps.






Better User Experience with High-Performance WiFi 6 Connectivity The latest WiFi 6 features and advanced wireless techniques guarantee higher network efficiency and lower latency.






More than Speed, Security Matters Safeguard your network against brute force attack and snooping with WPA3 enterprise-grade security protection, portal authentication, and segregated guest networks.

Secure Guest Network with Up to 16 SSIDs

Guest networks provide enhanced security. Different SSIDs also enable flexible access management.

Boost Business with Facebook WiFi and SMS Login

Captive portals (including SMS, Facebook WiFi, Voucher) and 802.1x authentication ensure authorized guests can access the network. Boost your business with a customized marketing page.

WPA3 for Worry-Free Open Public Networks

WPA3 provides more data security for previously unsecured and open WiFi hotspots with advanced enterprise security.




Gigabit Ports to Bridge Network The gigabit downlink port allows to connect wired device to the gigabit network.






Effortless Deployment with PoE Powered With 802.3af/802.3at PoE support, there’s no need for more wiring. Plug it into the existing Ethernet cables, and you’re ready.






Auto Channel Selection and Power Adjustment to Optimize Overall Performance Provides powerful wireless performance while significantly reducing WiFi interference by automatically adjusting the channel settings and transmission power levels of neighboring APs in the same network.






Seamless Integration into Omada SDN The Omada Software Defined Networking (SDN) platform integrates network devices including access points, switches, and routers to provide 100% centralized cloud management and create a highly scalable network—all controlled from a single interface.






Easy Management with the Omada App Follow configuration instructions on the Omada app to get set up in minutes. Omada lets you configure settings, monitor the network status, and manage clients, all from the convenience of your mobile device.

AX3000 Ceiling Mount WiFi 6 Access Point

The New Slimline Business WiFi 6.




Key Features • Ultra-Fast WiFi 6 Speeds: Simultaneous 574 Mbps on 2.4 GHz and 2402 Mbps on 5 GHz totals 2976 Mbps WiFi speeds.

• High-Efficiency WiFi 6: More connected devices can enjoy faster speeds.

• Centralized Cloud Management: Omada SDN integration manages the whole network locally or from the cloud via web UI or Omada app.

• 160 MHz Channel: Double the data at peak transmission times on a single stream with HE160.

• Seamless Roaming: Video streams and voice calls are unaffected as users move between locations.

• Omada Mesh: Enables wireless connectivity between access points for extended range and flexible deployment.

• PoE+ Powered: Supports both 802.3at PoE+ and DC (adapter included) power supply for flexible installations.

• Ultra-Slim Design: 160 mm × 33.6 mm elegant design brings more agility.




AX3000 WiFi 6 Speed
2402 Mbps on 5 GHz + 574 Mbps on 2.4 GHz

High-Efficiency WiFi 6
More connected devices can enjoy faster speeds

Centralized Cloud Management
Manage the whole network locally or from the cloud





160 MHz Channel
Double the data at peak transmission times on a single stream with HE160

Auto Channel Selection and Power Adjustment
Optimize overall performance by reducing WiFi interference

Omada Mesh Technology
More flexible and convenient wireless deployment





Seamless Roaming
Uninterrupted streaming when moving between APs

Ultra-Slim Design
160 mm × 33.6 mm elegant design brings more agility

PoE+ Powered
Supports both DC (adapter included) and 802.3at PoE+ for flexible installations





Designed for Business Environments Requiring High-Performance WiFi Hospitality

High-quality and full coverage Guest WiFi

Education

High-security WiFi to connect more devices

Shopping Mall

Seamless marketing WiFi coverage to boost business

Office

Stable, seamless, and high-security WiFi coverage

Meeting Room

Faster streaming, downloading, video conferencing, and more




Lightning-Fast AX3000 WiFi 6 Speeds New-era business WiFi 6 with speeds up to 2976 Mbps brings more than twice the speed of WiFi 5.† Every application feels more fluid with drastically improved WiFi speeds.






Higher Efficiency for More Devices WiFi 6 features such as OFDMA and MU-MIMO handle multiple clients across congested environments like typical office spaces, lodging, and hospitals. Enjoy faster speeds on more devices with less lag.






Seamless Integration into Omada SDN The Omada Software Defined Networking (SDN) platform integrates network devices, including access points, switches, and routers. It provides 100% centralized cloud management and creates a highly scalable network controlled from a single interface.






Auto Channel Selection and Power Adjustment to Optimize Overall Performance Provides powerful wireless performance while significantly reducing WiFi interference by automatically adjusting the channel settings and transmission power levels of neighboring APs in the same network.






Easy Deployment & Higher Performance by Omada Mesh Easy Pairing, Less Wiring

With Mesh technology, Omada EAPs save you from extra wires by wirelessly extending your WiFi signal further and more flexibly to hard-to-wire areas.



Optimized Network Performance

Intelligent self-organization optimizes the best path between EAPs while self-healing ensures you stay online even when one AP is disrupted.






Always Stay Smooth with Fast Roaming Ensures customers to enjoy uninterrupted streaming when moving around by switching clients automatically to the access points with the optimal signal.






Ultra-Slim Design Brings More Agility Exceptional performance with compact design ensures simple WiFi installation while saving space. The elegant appearance makes EAP650 perfectly blend into any modern office, hotel, classroom, or café.






Easy to Mount with Refined Industrial Design 1. Push up

2. Rotate to lock






Boosted Network Security and Efficiency Secure Guest Network with Up to 16 SSIDs

Guest network access provides enhanced security to guests. Different SSIDs also enable flexible access management.

Boost Business with Facebook WiFi and SMS Login

Captive portal (including SMS, Facebook Wi-Fi, Voucher) and 802.1x authentication help maintain authorized guests to use the network. Boost your business with a customized marketing page

WPA3 for Worry-Free Open Public Networks

With advanced enterprise security, WPA3 provides more data security for previously unsecured and open WiFi hotspots.

Band Steering

Automatically moves dual band devices onto the wider 5GHz band for faster connections.

Load Balance

Ensures large numbers of users have smooth network experiences in high-density business networks

Airtime Fairness

Increases average network throughput in heavily congested environments

AX1800 Ceiling Mount WiFi 6 Access Point

High Performing AX1800 Wireless for High-Density Environments


Features & Benefits: Ultra-Fast WiFi 6 Speeds: Simultaneous 574 Mbps on 2.4 GHz and 1201 Mbps on 5 GHz totals 1775 Mbps Wi-Fi speeds

High-Density Connectivity: 4× increased capacity to connect more devices simultaneously.

Integrated into Omada SDN: Zero-Touch Provisioning (ZTP)§, Centralized Cloud Management, and Intelligent Monitoring.

Centralized Management: Cloud access and Omada app for ultra convenience and easy management.

Ultra-Slim Design: 160 mm × 33.6 mm elegant design brings more agility.

Seamless Roaming: Even video streams and voice calls are unaffected as users move between locations.

Omada Mesh: Enables wireless connectivity between access points for extended range and flexible deployment.

PoE+ Powered: Supports DC (adapter included), 802.3at PoE+, and Passive PoE for flexible installations.

Secure Guest Network: Along with multiple authentication options (SMS/Facebook Wi-Fi/ Voucher, etc.) and abundant wireless security technologies.

Auto Channel Selection and Power Adjustment: Optimize overall performance by reducing WiFi interference.

Optimized WiFi Performance: With Portal Authentication, MU-MIMO, Band Steering, Airtime Fairness, and Load Balance.




Hospitality
High Quality and Full Coverage Wi-Fi



Restaurant
Full Wi-Fi Coverage in High-Density Environment



Shopping Mall
Social Marketing for O2O



Meeting Room
Wireless and Wired Connections for dense usage



Railway Station
High-Density Wi-Fi


High-Density Connectivity with 4× Increased Capacity OFDMA and MU-MIMO increase network capacity by up to 4× versus Wi-Fi 5 (802.11ac) in high-density environments to connect more devices simultaneously. Leverage multi-user capabilities and upgrade your business like never before.


Advanced Wi-Fi Speed with 4 Spatial Streams The Omada Wi-Fi 6 Access Point features the latest 802.11ax technologies like 1024 QAM and Long OFDM Symbol, which allows the EAP to boost overall speeds up to 1775 Mbps (1201 Mbps on a 5 GHz band and 574 Mbps on a 2.4 GHz band). With 4 spatial streams, multi-user throughput is incredibly increased to drive more applications.


Seamless Integration into Omada SDN The Omada Software Defined Networking (SDN) platform integrates network devices, including access points, switches, and routers. It provides 100% centralized cloud management and creates a highly scalable network controlled from a single interface.


Auto Channel Selection and Power Adjustment to Optimize Overall Performance Provides powerful wireless performance while significantly reducing WiFi interference by automatically adjusting the channel settings and transmission power levels of neighboring APs in the same network.


Easy Deployment & Higher Performance by Omada Mesh Easy Pairing, Less Wiring

With Mesh technology, Omada EAPs save you from extra wires by wirelessly extending your WiFi signal further and more flexibly to hard-to-wire areas.

Optimized Network Performance

Intelligent self-organization optimizes the best path between EAPs while self-healing ensures you stay online even when one AP is disrupted.


Stay Smooth with Seamless Roaming 802.11k/v roaming switches clients automatically to the AP with the optimal signal with a seamless transition when moving?. This allows sensitive applications like VoIP and video conferences to go uninterrupted.


Ultra-Slim Design Brings More Agility Exceptional performance with compact design ensures simple WiFi installation while saving space. The elegant appearance makes EAP620 HD perfectly blend into any modern office, hotel, classroom, or café.


Easy to Mount with Refined Industrial Design 1. Push up

2. Rotate to lock


Secure Guest Network with Up to 16 SSIDs
Guest network access provides enhanced security to guests. Different SSIDs also enable flexible access management.

Boost Business with Facebook WiFi and SMS Login
Captive portal (including SMS, Facebook WiFi, Voucher) and 802.1x authentication help ensure that only authorized users have network access. Boost your business with a customized marketing page.

  WPA3 for Worry-Free Open Public Networks
With advanced enterprise security, WPA3 provides more data security for previously unsecured and open WiFi hotspots.

Band Steering
Automatically moves dual band devices onto the wider 5GHz band for faster connections.

  Load Balance
Ensures large numbers of users have smooth network experiences in high-density business networks.

Airtime Fairness
Increases average network throughput in heavily congested environments.

  Full specification and details can be found in the Product Datasheet PDF file

The OMADA CLOUD(3-YEAR) is a hassle-free solution for centralized management of Omada access points, switches, and routers. Experience seamless deployment, remote accessibility, and real-time insights without the need for additional hardware investment.

Features

Existing entirely in the cloud.
No additional hardware controller investment and installation on customer premises.
Centralized management for unlimited Omada access points, JetStream switches, and SafeStream routers.*
Cloud access to manage from anywhere, anytime.
Supports Zero-Touch Provisioning for efficient deployment and reduces the overall cost of deployment, operation, and maintenance.
The Omada app for convenient management.
The easy-to-use dashboard makes it easy to see your real-time network status and check network usage and traffic distribution.
Specifications

Omada App
Centralized Management Unlimited centralized management scale
Centrally manage Omada access points, JetStream switches, and SafeStream routers

Cloud Access
L3 Management
Multi-site Management
Zero-Touch Provisioning
Management Features Automatic Device Discovery
Batch Configuration
Batch Firmware Upgrading
Intelligent Network Monitoring
Abnormal Event Warnings
Unified Configuration
Reboot Schedule
Captive Portal Configuration

*For complete specification see the documentation tab above

The OMADA CLOUD(5-YEAR) is a hassle-free solution for centralized management of Omada access points, switches, and routers. Experience seamless deployment, remote accessibility, and real-time insights without the need for additional hardware investment.

Features

Existing entirely in the cloud.
No additional hardware controller investment and installation on customer premises.
Centralized management for unlimited Omada access points, JetStream switches, and SafeStream routers.*
Cloud access to manage from anywhere, anytime.
Supports Zero-Touch Provisioning for efficient deployment and reduces the overall cost of deployment, operation, and maintenance.
The Omada app for convenient management.
The easy-to-use dashboard makes it easy to see your real-time network status and check network usage and traffic distribution.
Specifications

Omada App
Centralized Management Unlimited centralized management scale
Centrally manage Omada access points, JetStream switches, and SafeStream routers

Cloud Access
L3 Management
Multi-site Management
Zero-Touch Provisioning
Management Features Automatic Device Discovery
Batch Configuration
Batch Firmware Upgrading
Intelligent Network Monitoring
Abnormal Event Warnings
Unified Configuration
Reboot Schedule
Captive Portal Configuration

*For complete specification see the documentation tab above

High-End Business WiFi 6 to Power Up Your Business

AX5400 Ceiling Mount Wi-Fi 6 Access Point

AX5400 WiFi 6 Speed: 4804 Mbps on 5 GHz; 574 Mbps on 2.4 GHz

High-Efficiency WiFi 6: More connected devices can enjoy faster speeds

Centralized Cloud Management: Manage the whole network locally or from the cloud

2.5GE Wired Performance: Boosts overall throughput with a 2.5 Gbps Ethernet port

160 MHz Channel: Double the data at peak transmission times on a single stream with HE160

Auto Channel Selection and Power Adjustment: Optimize overall performance by reducing WiFi interference

Omada Mesh Technology: More flexible and convenient wireless deployment§

Seamless Roaming: Uninterrupted streaming when moving between APs§

PoE+ Powered: Supports both DC (adapter not included) and 802.3at PoE+ for flexible installations



Designed for Business Environments Requiring High-Performance WiFi

Hospitality: High-quality and full coverage Guest WiFi

Education: High-security WiFi to connect more devices

Shopping Mall: Seamless marketing WiFi coverage to boost business

Office: Stable, seamless, and high-security WiFi coverage

Meeting Room: Faster streaming, downloading, video conferencing, and more



High-End Business Wi-Fi 6 Bring Real Power to Your Business

WiFi 6 brings faster speeds, lower lag, less interference, and higher capacity.


Blazing-Fast AX5400 Wi-Fi 6 Speeds

High-end business WiFi 6 with speeds up to 5378 Mbps brings 2.6-time speeds than WiFi 5.


Seamless Integration into Omada SDN

The Omada Software Defined Networking (SDN) platform integrates network devices including access points, switches, and routers to provide 100% centralized cloud management and create a highly scalable network—all controlled from a single interface.



Easy Deployment & Higher Performance by Omada Mesh

Easy Pairing, Less Wiring

With Mesh technology, Omada EAPs save you from extra wires by wirelessly extending your WiFi signal further and more flexibly to hard-to-wire areas.

Optimized Network Performance

Intelligent self-organization optimizes the best path between EAPs while self-healing ensures you stay online even when one AP is disrupted.

Always Stay Smooth with Fast Roaming

Ensures customers to enjoy uninterrupted streaming when moving around by switching clients automatically to the access points with the optimal signal.

Boosted Network Security and Efficiency

Secure Guest Network with Up to 16 SSIDs
Guest network access provides enhanced security to guests. Different SSIDs also enable flexible access management.

Boost Business with SMS Login: Captive portal (including SMS and Voucher) and 802.1x authentication help maintain authorized guests to use the network.

Boost your business with a customized marketing page.

WPA3 for Worry-Free Open Public Networks: With advanced enterprise security, WPA3 provides more data security for previously unsecured and open WiFi hotspots.

Band Steering: Automatically moves dual band devices onto the wider 5GHz band for faster connections.

Load Balance: Ensures large numbers of users have smooth network experiences in high-density business networks

Airtime Fairness: Increases average network throughput in heavily congested environments

Centralized Management

The Omada hardware controller (OC400) for the Omada Software Defined Networking (SDN) platform, supports centralized management for up to 1,000 Omada access points, 200 Omada switches, and 100 Omada routers.* Enjoy cloud service with no license fees with the use of OC400.

Centralized Management: for up to 1,000 Omada access points, 200 Omada switches, and 100 Omada routers.

2× 10GE SFP+ Slots, 4× GE RJ45 Ports, and 2× USB 3.0 Ports.

Redundant power supplies offer a reliable networking architecture.

Free cloud access with the Omada app or Web UI from anywhere, anytime.

On-premises manages to locally monitor and manage devices.

The easy-to-use dashboard and real-time network topology make network monitoring easy.

Batch and multi-site management benefit network maintenance.

TP-Link EAP683 UR AX6000 Ceiling Mount WiFi 6 Access Point you can get up to 5952 Mbps WiFi 6 speeds, offering 1148 Mbps on 2.4 GHz and 4804 Mbps on 5 GHz. Equipped with 4×4 MIMO dual-band internal antennas, it delivers ultra-range wireless coverage with high transmission power. Enjoy cutting-edge WiFi 6 technologies like HE160 and 1024-QAM for enhanced performance.

Up to 5952 Mbps WiFi 6 Speeds: 1148 Mbps on 2.4 GHz + 4804 Mbps on 5 GHz

Ultra-range wireless coverage by 4×4 MIMO dual-band internal antennas with high transmission power.

Supports WiFi 6 technologies, such as HE160, 1024-QAM, etc.

Integrates with the Omada SDN platform for centralized management.

Advanced Features: Omada Mesh, Seamless Roaming, and more.

PoE+ Powered: Supports both 802.3at PoE+ and DC.

Next-Gen AXE11000 Enterprise Wireless for High-Density Environments Ultra-Fast Wi-Fi 6 Speeds - Simultaneous 4804 Mbps on 6 GHz, 4804 Mbps on 5 GHz, and 1148 Mbps on 2.4 GHz for 10.8 Gbps WiFi speeds.
High-Density Connectivity up to 2000 Clients - Improves WiFi performance in dense environments with OFDMA, MU-MIMO, and BSS Coloring.
160 MHz Bandwidth Channel - Double the data at peak transmission times on a single stream with HE160.
Smart Antennas - Professional antennas with high-power amplifiers provide strong wireless coverage in high-density environments.
PoE++ Support - Supports Power over Ethernet (802.3bt) for convenient deployment and installation.
Integrated into Omada SDN - Supports Zero-Touch Provisioning (ZTP), Centralized Cloud Management, and Intelligent Monitoring.
Centralized Management - Cloud access and the Omada app offer ultra convenience and easy management.
Designed for Business Environments in Heavy WiFi Areas

Ultra-Fast AXE11000 WiFi 6 Speeds

High-end business WiFi 6 with speeds up to 10.8 Gbps brings 5.3x faster speeds than WiFi 5.

Higher Efficiency for More Devices and Scenarios

OFDMA and Uplink & Downlink MU-MIMO increase network capacity by up to 4x versus WiFi 5 (802.11ac) in high-density environments to connect more devices simultaneously. Leverage multi-user capabilities and upgrade your business like never before.

Experience the Peak of WiFi with Smart Antennas

Improve performance, lower interference, and extend coverage for user-heavy scenarios through TP-Link Smart Antenna technology. Equipped with an ingenious 6 GHz/5 GHz/2.4 GHz antenna array, EAP690E HD automatically selects the optimal antennas to cover all terminal devices via intelligent algorithms, delivering lag-free and superb WiFi experiences.

Reliable Business Networks with Intelligent Power Supply

With the intelligent power supply feature of EAP690E HD, the PoE switch can act as a backup power source. Intelligent power supply automatically and smoothly powers EAP690E HD when the DC adapter is accidentally disconnected, delivering a reliable and safe business network experience.

Seamless Integration into Omada SDN

The Omada Software Defined Networking (SDN) platform integrates network devices including access points, switches, and routers to provide 100% centralized cloud management and create a highly scalable network-all controlled from a single interface. Experience total control at your fingertips.

Auto Channel Selection and Power Adjustment to Optimize Overall Performance

Provides powerful wireless performance that significantly reduces WiFi interference by automatically adjusting the channel settings and transmission power levels of neighboring APs in the same network

Easy Deployment & Higher Performance by Omada Mesh

Easy Pairing, Less Wiring

With Mesh technology, Omada APs save you from redundant wires by wirelessly extending your WiFi signal farther and more flexibly to hard-to-wire areas.

Optimized Network Performance

Intelligent self-organization optimizes the best path between APs, while self-healing ensures your devices stay online even when one AP is disrupted.

Omada provides a business-class wireless network solution that’s flexible, manageable, secure, and easy-to-deploy. Featuring cloud access, Omada Cloud Controller OC200 or Omada Software Controller allow users to centrally manage the entire Omada networks in the remote site. And the intuitive Omada app makes network management incredibly convenient. Omada EAPs also feature captive portal and advanced RF management functions, which make them ideal for demanding, high-traffic environments such as campuses, hotels, shopping centres and offices.

Professional centralised management for Wi-Fi network


Free cloud access to manage from anywhere, anytime


PoE (802.3af/802.3at) supported for easy installation


Industry leading hardware design with powerful chipset, durable metal casing, and USB port for auto backup


Omada App for a convenient management


Secure guest network with multiple login options(Facebook Wi-Fi, SMS login, Vourcher)


Dedicated In Network Centralised Management

The OC200 Omada Cloud Controller dedicated to provide centralised management for the whole Omada network. Monitor statistics in real-time, view a graphical analysis of network traffic, create a captive portal, upgrade and reboot your system, and easily scale your network to boost your business.

No PC/server is needed Reliability and Security Cloud Access for ultra convenience

Free Cloud Centralised Management - Anytime, Anywhere

Omada Cloud Controller OC200 and Omada Software Controller make it easy to manage and monitor the whole Omada network in real-time, while cloud service enables remote and secure access no matter where you find yourself.



Even More Convenient with Omada App

Remotely access and configure the OC200 from the convenience of your smartphone, wherever you are in the world.



Guest Network with Facebook and SMS Support

Visitors have access to secure Wi-Fi with captive portal and wireless isolation technology. Newly added SMS authentication simplifies the connection process, while Facebook authentication raises the social media profile of your business.

Centralized Management for Access Points, Switches, and Gateways

OC300, the hardware controller for the Omada Software Defined Networking (SDN) platform, provides 100% centralized management of access points, switches, and gateways—all controlled from a single interface.


Product Features
Centralized management for up to 500 Omada access points, JetStream switches, and SafeStream routers.


Cloud access to manage from anywhere, anytime.


Locally monitor and manage devices with the ultimate security and stability.


The Omada app for convenient management.


Industry-leading hardware design with a powerful chipset, durable metal casing, and USB 3.0 port for auto backup.


Batch management, multi-site management, and remote firmware updates benefit network maintenance.


The easy-to-use dashboard makes it easy to see your real-time network status and check network usage and traffic distribution.


Network topology helps IT admins quickly see and troubleshoot connections at a glance.

Industry-Leading Hardware Design

Equipped with an advanced design and the latest chipset, OC300 has enough processing power to support the massive management of your business network. Rackmount/desktop design benefits easier and flexible installation.



Batch Management, Multi-Site Management, and Remote Firmware Updates

Improve network maintenance without needing to configure on-site or manage devices one by one.



Powerful Scheduling

Maintain your network easily with more agile and effective processing. No manual tasks required.



Hybrid Cloud for Maximum Convenience

Featuring hybrid cloud technology, the Omada Hardware Controller OC300 allows you to remotely control the whole network wherever you are in the world with cloud access. Locally manage devices with the ultimate security and stability.


Easy and Intelligent Network Monitoring

The easy-to-use dashboard makes it easy to see your real-time network status; check network usage and traffic distribution; receive network condition logs, abnormal event warnings, and notifications; or even track key data for better business results. Network topology helps IT admins quickly see and troubleshoot connections at a glance.

Match Your Room with AX3000 WiFi 6 Blazing-Fast AX3000 WiFi 6 Speeds - Simultaneous 574 Mbps on 2.4 GHz and 2402 Mbps on 5 GHz totals 2976 Mbps WiFi speeds.
Higher Network Efficiency - Deliver data to more devices at the same time with less lag.
Complete In-Room WiFi Coverage - Guaranteed strong signals and corner-to-corner WiFi coverage.
Multiple Gigabit Ports - Connect multiple devices with three downlink gigabit ports, one with PoE pass-through.
Centralized Cloud Management - Integrates into Omada SDN for cloud access and remote management.
Secure Guest Network - Implement multiple authentication options (SMS/Facebook Wi-Fi/ Voucher) packed with high-quality wireless security technologies.
Easy Installation and PoE Support - Easy-to-install design, compatible with 86 mm & EU & US standard junction box, and 802.3af/at PoE support.
Lightning-Fast AX3000 WiFi 6 Speeds

WiFi 6 brings faster speeds, lower lag, less interference, and higher capacity. Enjoy more than twice the speed of WiFi 5 with new-era business WiFi 6 with speeds up to 2976 Mbps.

Better User Experience with High-Performance - WiFi 6 Connectivity

The latest WiFi 6 features and advanced wireless techniques guarantee higher network efficiency and lower latency.

More than Speed, Security Matters

Safeguard your network against brute force attack and snooping with WPA3 enterprise-grade security protection, portal authentication, and segregated guest networks.

Full Gigabit Ports to Bridge Network

Wired devices like VoIP phones can be powered with no need for extra electrical cables. The four data ports (1 uplink + 3 downlinks) transfer data at multiple gigabits, allowing you to connect several devices to your gigabits network. One of the downlink ports offers PoE pass-through to eliminate the need for that extra power port.

Effortless Deployment with PoE Powered

With 802.3af/802.3at PoE support, there's no need for more wiring. Plug it into the existing Ethernet cables, and you're ready.

Quick, Simplified Installation

With an easy-to-install design, there is no need to bring someone in to install our EAP.

Auto Channel Selection and Power Adjustment to Optimize Overall Performance

Provides powerful wireless performance while significantly reducing WiFi interference by automatically adjusting the channel settings and transmission power levels of neighboring APs in the same network

Seamless Integration into Omada SDN

The Omada Software Defined Networking (SDN) platform integrates network devices including access points, switches, and routers to provide 100% centralized cloud management and create a highly scalable network—all controlled from a single interface.

AX1800 Indoor/Outdoor WiFi 6 Access Point

Performance-Driven WiFi 6 for Demanding Outdoor Environments




Key Features • Superior WiFi 6 Speeds: Delivers dual-band speeds of up to 1.8 Gbps powered by the latest WiFi 6 technology

• Higher Network Efficiency: Enjoy faster speeds on more devices with less lag via OFDMA and MU-MIMO

• Long-Range Coverage: Dedicated high-power amplifier and professional antennas with IP67 weatherproof enclosure

• Omada Mesh Technology: Enables wireless connectivity between access points for extended range and flexible deployment

• Stay Smooth with Fast Roaming: Users can enjoy seamless streaming across the property with their devices switching effortlessly between access points

• Centralized Cloud Management: Integrates into Omada SDN for cloud access and remote management





Dual-Band WiFi 6 Connectivity Powered by the latest WiFi 6 technology, the AP delivers speeds of up to 1.8 Gbps, providing higher data rates on both 5 GHz and 2.4 GHz bands for demanding multi-user scenarios, such as outdoor swimming pools, cafés, and amusement parks.






Long-Range Coverage Professional antennas equipped with high-power amplifiers utilize WiFi 6 technology to provide strong and expansive wireless coverage to various outdoor environments. The maximum range reaches up to 200 meters over 2.4 GHz band and 300 meters over 5 GHz band.






Connect Numerous Devices OFDMA and MU-MIMO greatly improve multi-user efficiency to provide simultaneous connections for dozens of clients in large open areas.






Seamless Integration into Omada SDN Platform The Omada Software Defined Networking (SDN) platform integrates network devices including access points, switches, and routers to provide 100% centralized cloud management and create a highly scalable network—all controlled from a single interface.






Easy Deployment & Higher Performance by Omada Mesh Easy Pairing, Less Wiring

With Mesh technology, Omada EAPs save you from extra wires by wirelessly extending your WiFi signal further and more flexibly to hard-to-wire areas.



Optimized Network Performance

Intelligent self-organization optimizes the best path between EAPs while self-healing ensures you stay online even when one AP is disrupted.






Always Stay Smooth with Fast Roaming Ensures customers enjoy uninterrupted streaming when moving around by switching clients automatically to the access points with the optimal signal.






IP67 Weatherproof Enclosure for Outdoor Environments EAP610-Outdoor is totally resistant to dust ingress, shock, vibration, and moisture, withstanding the most extreme environments.






Versatile Mounting Solutions Our mounting kits provide flexible installation, whether inside or outside.






Multiple PoE Options for Easy Installation The AP supports both 802.3at PoE+ and Passive PoE power supply. It can be either powered by a PoE switch or the provided PoE adapter for convenient deployment.






Easy Management with the Omada App Follow the configuration instructions on the free Omada app to get set up in minutes. Omada lets you configure settings, monitor the network status and manage clients, all from the convenience of a smart phone or tablet.

AX5400 Ceiling Mount WiFi 6 Access Point



Key Features: • Blazing-Fast WiFi 6 Speeds: Simultaneous 574 Mbps on 2.4 GHz and 4804 Mbps on 5 GHz totals 5378 Mbps WiFi speeds.

• High-Efficiency WiFi 6: More connected devices can enjoy faster speeds.

• Centralized Cloud Management: Omada SDN integration manages the whole network locally or from the cloud via web UI or Omada app.

• 160 MHz Channel: Double the data at peak transmission times on a single stream with HE160.

• Seamless Roaming: Video streams and voice calls are unaffected as users move between locations

• Omada Mesh: Enables wireless connectivity between access points for extended range and flexible deployment.

• PoE+ Powered: Supports both 802.3at PoE+ and DC (adapter included) power supply for flexible installations.




High-End Business WiFi 6 to Power Up Your Business AX5400 Ceiling Mount Wi-Fi 6 Access Point










AX5400 WiFi 6 Speed
4804 Mbps on 5 GHz + 574 Mbps on 2.4 GHz



High-Efficiency WiFi 6
More connected devices can enjoy faster speeds



Centralized Cloud Management
Manage the whole network locally or from the cloud



2.5GE Wired Performance
Boosts overall throughput with a 2.5 Gbps Ethernet port



160 MHz Channel
Double the data at peak transmission times on a single stream with HE160



Auto Channel Selection and Power Adjustment
Optimize overall performance by reducing WiFi interference



Omada Mesh Technology
More flexible and convenient wireless deployment



Seamless Roaming
Uninterrupted streaming when moving between APs



PoE+ Powered
Supports both DC (adapter included) and 802.3at PoE+ for flexible installations




Designed for Business Environments Requiring High-Performance WiFi Hospitality High-quality and full coverage Guest WiFi


Education High-security WiFi to connect more devices


Shopping Mall Seamless marketing WiFi coverage to boost business


Office Stable, seamless, and high-security WiFi coverage


Meeting Room Faster streaming, downloading, video conferencing, and more







Blazing-Fast AX5400 Wi-Fi 6 Speeds High-end business WiFi 6 with speeds up to 5378 Mbps brings 2.6-time speeds than WiFi 5.



1024 QAM
25% more data encoded at one time



Long OFDM Symbol
11% faster speed



HE160
Double the data at peak transmission times on a single stream











Higher Efficiency for More Devices Wi-Fi 6 features such as OFDMA and MU-MIMO handle multiple clients across congested environments like typical office spaces, lodging, and hospitals. Enjoy faster speeds on more devices with less lag. as typical office spaces, lodging, and small clinics. Enjoy faster speeds on more devices with less lag.











Seamless Integration into Omada SDN The Omada Software Defined Networking (SDN) platform integrates network devices including access points, switches, and routers to provide 100% centralized cloud management and create a highly scalable network—all controlled from a single interface.



Hardware, Software, or Cloud-Based Controllers



Centralized Cloud Management



Intelligent Monitoring



Zero-Touch Provisioning (ZTP)












Auto Channel Selection and Power Adjustment to Optimize Overall Performance Provides powerful wireless performance while significantly reducing WiFi interference by automatically adjusting the channel settings and transmission power levels of neighboring APs in the same network












Easy Deployment & Higher Performance by Omada Mesh Easy Pairing, Less Wiring

With Mesh technology, Omada EAPs save you from extra wires by wirelessly extending your WiFi signal further and more flexibly to hard-to-wire areas.












Optimized Network Performance Intelligent self-organization optimizes the best path between EAPs while self-healing ensures you stay online even when one AP is disrupted.












Always Stay Smooth with Fast Roaming Ensures customers to enjoy uninterrupted streaming when moving around by switching clients automatically to the access points with the optimal signal.












Easy to Mount with Refined Industrial Design

1. Push up.



2. Rotate to lock.






Security Secure Guest Network with Up to 16 SSIDs Guest network access provides enhanced security to guests. Different SSIDs also enable flexible access management.




Boost Business with Facebook WiFi and SMS Login Captive portal (including SMS, Facebook Wi-Fi, Voucher) and 802.1x authentication help maintain authorized guests to use the network. Boost your business with a customized marketing page.




WPA3 for Worry-Free Open Public Networks With advanced enterprise security, WPA3 provides more data security for previously unsecured and open WiFi hotspots.








Efficiency Band Steering Automatically moves dual band devices onto the wider 5GHz band for faster connections.




Load Balance Ensures large numbers of users have smooth network experiences in high-density business networks




Airtime Fairness Increases average network throughput in heavily congested environments

Product Features Superior WiFi 6 Speeds: Delivers dual band speeds of up to 3 Gbps powered by the latest WiFi 6 technology.

Higher Network Efficiency: Enjoy faster speeds on more devices with less lag with OFDMA and MU-MIMO.

160 MHz Bandwidth Channel: Double the data at peak transmission times on a single stream with HE160.

Long-Range Coverage: Dedicated high-power amplifier and professional antennas with an IP67 weatherproof enclosure.

Omada Mesh Technology: Enables wireless connectivity between access points for extended range and flexible deployment

Stay Smooth with Seamless Roaming: Users can enjoy seamless streaming across the property with their devices switching effortlessly between access points.

PoE Powered: : Supports both 802.3at PoE+ and Passive PoE (adapter included) power supply for flexible installation.

Centralized Cloud Management: Omada SDN integration manages the whole network locally or from the cloud via web UI or the Omada app.

Overview Long-Range Coverage Professional antennas equipped with high-power amplifiers utilize WiFi 6 technology to provide strong and expansive wireless coverage to various outdoor environments.

Experience the Peak of WiFi 6 with Smart Antennas TP-Link Smart Antenna technology brings lower interference, longer coverage, and higher performance. EAP650-Outdoor is equipped with horizontally polarized antennas and vertically polarized antennas, while its intelligent algorithms automatically select the optimal antennas to ensure the peak WiFi experience ideal for outdoor applications.

Flexible Deployment with Omada Mesh and PoE Support Less Wiring with Mesh With Mesh technology, Omada EAPs save you from extra wires by wirelessly extending your WiFi signal further and more flexibly to hard-to-wire areas

Powered with PoE+ Switch Powered and connected by an 802.3at PoE+ switch using one single cable for convenient deployment.

Powered with Passive PoE Powered and connected by the provided passive PoE adapter using one single cable, ideal for home WiFi deployment.

Always Stay Smooth with Seamless Roaming Ensures customers enjoy uninterrupted streaming when moving around by switching clients automatically to the access points with the optimal signal.

IP67 Weatherproof Enclosure for Outdoor Environments EAP650-Outdoor is totally resistant to dust ingress, shock, vibration, and moisture, withstanding the most extreme environments.
6: Completely dust-tight. No ingress of dust.
7: Protection against full immersion in water up to 1 meter deep for half an hour

Versatile Mounting Solutions Our mounting kits provide flexible installation, whether inside or outside

Seamless Integration into the Omada SDN Platform The Omada Software Defined Networking (SDN) platform integrates network devices including access points, switches, and routers to provide 100% centralized cloud management and create a highly scalable network—all controlled from a single interface.

Hassle-Free Cloud or On-Premises Controllers Centralized Cloud Management Intelligent Monitoring Zero-Touch Provisioning (ZTP) Easy Management with the Omada Follow the configuration instructions on the free Omada app to get set up in minutes. Omada lets you configure settings, monitor the network status and manage clients, all from the convenience of a phone or tablet.

The TP-Link EAP660 HD AX3600 Dual Band Multi-Gigabit Ceiling Mount Access Point provides ultra-high performing enterprise wireless for high-density environments



Product Features

Ultra-Fast Wi-Fi 6 Speeds: Simultaneous 1148 Mbps on 2.4 GHz and 2402 Mbps on 5 GHz totals 3550 Mbps Wi-Fi speeds.


High-Density Connectivity: 4x increased capacity to connect more devices simultaneously.


Integrated into Omada SDN: Zero-Touch Provisioning (ZTP), Centralized Cloud Management, and Intelligent Monitoring.


Centralized Management: Cloud access and Omada app for ultra convenience and easy management.


2.5G Port: A 2.5 Gbps Ethernet port boosts total internet throughput.


Seamless Roaming: Even video streams and voice calls are unaffected as users move between locations.


PoE+ Support: Supports Power over Ethernet (802.3at) for convenient deployment and installation.


Secure Guest Network: Along with multiple authentication options (SMS/Facebook Wi-Fi/ Voucher, etc.) and abundant wireless security technologies.

High-Density Connectivity with 4× Increased Capacity

OFDMA* and Uplink & Downlink MU-MIMO** increase network capacity by up to 4× versus Wi-Fi 5 (802.11ac) in high-density environments to connect more devices simultaneously. Leverage multi-user capabilities and upgrade your business like never before.


Blazing Fast Speed with 8 Spatial Streams

The Omada Wi-Fi 6 Access Point features the latest 802.11ax technologies like 1024 QAM and Long OFDM Symbol, which allows the EAP to boost overall speeds up to 3550 Mbps (2402 Mbps on a 5 GHz band and 1148 Mbps on a 2.4 GHz band)†. With 8 spatial streams, multi-user throughput is incredibly increased to drive more applications.


Omada SDN - Smarter Cloud Solution for Business Networking

Omada Software Defined Networking (SDN) platform integrates network devices including access points, switches and gateways, guaranteeing powerful business network with higher efficiency, higher security, and higher reliability.


Optimized Wired Performance with 2.5 GE PoE+ Port

Armed with a 2.5 Gigabit Ethernet Port, the EAP660 HD delivers exceptional multi-gigabit performance to support the insatiable demand for better and faster Wi-Fi. Compatibility with standard 802.3at PoE is ideal for flexible deployment.


Seamless Roaming

802.11k/v roaming switches clients automatically to the AP with the optimal signal with a seamless transition when moving. This allows sensitive applications like VoIP and video conferences to go uninterrupted.


Secure Guest Network with Facebook Wi-Fi and SMS Login

Guest Network provides elevated secure access to guests sharing your Wi-Fi network, with captive portal helping maintain only authorized guests to use the network. The addition of SMS and Facebook authentication simplifies the captive portal even further to simplify connectivity and power up your business.

Omada provides a business-class wireless network solution that’s flexible, manageable, secure, and easy-to-deploy. Featuring cloud access, Omada Cloud Controller OC200 or Omada Software Controller allow users to centrally manage the entire Omada networks in the remote site. And the intuitive Omada app makes network management incredibly convenient. Omada EAPs also feature captive portal and advanced RF management functions, which make them ideal for demanding, high-traffic environments such as campuses, hotels, shopping centres and offices..

Simultaneous 450Mbps on 2.4GHz and 1300Mbps on 5GHz totals 1750Mbps Wi-Fi speeds


Supports Seamless Roaming so even video streams and voice calls are unaffected as users move between locations


Free cloud centralised management and Omada app for ultra convenience and easy management


Support Power over Ethernet (802.3at) for convenient and affordable installation


Secure guest network along with multiple authentication options (SMS/Facebook Wi-Fi/ Voucher, etc.) and abundant wireless security technologies.


Band Steering Automatically moves dual band devices onto the wider 5GHz band for faster connections


MU-MIMO means access points simultaneously transfer data with multiple devices, speeding up connections


Beamforming concentrates signal towards where you need it most, providing a fast and stable Wi-Fi experience


Load balance ensures large numbers of users have smooth network experiences in high density business networks




An Elite Business Scalable Business Wi-Fi Solution AC1750 802.11ac MU-MIMO Wi-Fi Solution

Build and manage a scalable Wi-Fi network for your business with the Omada business class solution, tailored to handle the power of hundreds of TP-LINK EAPs at an affordable cost.







Superior Wi-Fi Speeds and Performance QCA enterprise class chipsets, dedicated high-power amplifier and professional antenna along with the latest generation 802.11ac Wave 2 MU-MIMO technology, ensure superior 1750 Mbps Wi-Fi speeds and long-range coverage over 2.4GHz and 5GHz wireless bands.



Free Cloud Centralised Management - Anytime, Anywhere Omada Cloud Controller OC200 and Omada Software Controller make it easy to manage and monitor the whole Omada network in real-time, while cloud service enables remote and secure access no matter where you find yourself.





Easy Management with the Omada App Follow configuration instructions on the free Omada app to get set up in minutes. Omada lets you configure settings, monitor the network status and manage clients, all from the convenience of a smart phone or tablet..





Guest Network with Facebook and SMS Support Captive portal helps maintain only authorised guests to use the network, presenting devices with a convenient, user-friendly authentication method to grant Wi-Fi access. The addition of SMS and Facebook authentication simplifies the captive portal even further to simplify connectivity and boost your business.







Multiple PoE Options for Easy Installation EAP245 supports both 802.3at PoE and Passive PoE power supply, can be either powered by a PoE switch or the provided PoE adapter. The addition of elegant appearance and simple mounting design for easy attachment to a wall or ceiling further makes deployment effortless and flexible.



  Model Omada EAP225-wall Omada EAP245v3 Omada EAP225v3 Omada EAP115 Omada EAP110 Product Name AC1200 Wireless MUMIMO Wall Plate Access Point AC1750 Wireless MU-MIMO Gigabit Ceiling Mount Access Point AC1350 Wireless MU-MIMO Gigabit Ceiling Mount Access Point 300Mbps Wireless N Access Point 300Mbps Wireless N Access Point Speed 2.4GHz : 300Mbps
5GHz : 867Mbps 2.4GHz : 450Mbps
5GHz : 1300Mbps 2.4GHz : 450Mbps
5GHz : 867Mbps 2.4GHz : 300Mbps 2.4GHz : 300Mbps Ethernet Port 4 × 10/100Mbps Port 2 × Gigabit Port 1 × Gigabit Port 1 × 10/100Mbps Port 1 × 10/100Mbps Port Power Supply 802.3af/at PoE + 802.3af & 48V Passive PoE 802.3af & 24V Passive PoE 802.3af & 9V/0.6A DC 24v Passive PoE Internal Antennas 2.4GHz:2×2.3dBi
5GHz: 2×4dBi 2.4GHz: 3×3.5dBi
5GHz: 3×4dBi 2.4GHz: 3×4dBi
5GHz: 2×5dBi 2×4dBi 2×4dBi

Ultra-Thin Enterprise WiFi 7 Access Point

- Next-Gen WiFi 7
- Wi-Fi Speeds up to 9214 Mbps
- Multi-Link Operation (MLO)
- 1× 2.5G RJ45 Port
- PoE Power
- Ultra-Thin Design
- Centralized Cloud Management
- Omada Mesh Technology

Ultra-Thin Design for Flexible Deployment
The overall design of EAP772 utilizes a thinner circular arc with a groove around the top cover, fitting closer to various installation surfaces such as ceilings. The compact internal hardware layout and heat-dissipating design ensure high performance with a sharp aesthetic.

Boosted Network Security

- Secure Guest Network with up to 24 SSIDs
- Boost Your Business with SMS Login
- WPA3 for Worry-Free Open Public Networks
- Rogue AP Detection

TP-Link Omada AX1800. 2.4 GHz, 5 GHz, Maximum data transfer rate: 1201 Mbit/s. Security algorithms: SNMP, SNMPv2, SNMPv3, SSH, WPA-Personal, WPA2-Personal, WPA3-Personal. Ethernet LAN data rates: 1000 Mbit/s. Product colour: White

Long Distance Starts with External Antennas
Two detachable external antennas for 5 GHz and 2.4 GHz provide optimal coverage and greater flexibility for your network.

Ideal for High-Density Outdoor Scenes
OFDMA and MU-MIMO provide simultaneous connections for dozens of clients in large open areas.
Equipped with an IP67 weatherproof enclosure, our EAP625-Outdoor HD withstands the most extreme environments.

Flexible Deployment with Omada Mesh and PoE Support

- Less Wiring with Omada Mesh
- Powered with PoE+ Switch
- Powered with Passive PoE
