The HPE Networking Instant On JL813A 1830 24G 12p Class4 PoE 2SFP Switch is a cost-effective, smart-managed switch designed to meet the evolving networking needs of small businesses. This switch offers reliable and high-speed connectivity, making it ideal for environments with growing bandwidth demands.
Key Features:
24 RJ-45 Autosensing Ports: 10/100/1000 ports for versatile device connectivity.
12 PoE+ Compliant Ports: Class 4 PoE with a 195W power budget, ideal for powering access points, cameras, and VoIP phones.
2 SFP Ports: 1G fiber ports for high-speed uplinks.
Smart-Managed Layer 2 Ethernet: Provides essential network management capabilities.
Flexible Management Options: Easily deploy and manage the switch using Instant On cloud management via mobile app or web portal, or through the local web GUI.
Integrated Security Features: Protect your business data with advanced security features like VLANs, automatic Denial-of-Service protection, and Global Storm Control.
Energy Efficiency: Features like Energy Efficient Ethernet (IEEE 802.3az), auto-port shutdown, and fanless design help reduce power consumption and operating costs.
Enhanced User Experience:Mobile App: The HPE Networking Instant On mobile app allows for easy setup, management, and monitoring of your network devices. Cloud-based access enables remote management from anywhere.
High Performance: Dedicated SFP fiber ports eliminate traffic bottlenecks, providing higher uplink bandwidth and performance across longer distances.
Versatile Deployment: Suitable for rack-mountable, cabinet mount, table top, and wall mountable installations.
Technical Specifications:I/O Ports and Slots:
24 RJ-45 autosensing 10/100/1000 ports.
12 PoE+ compliant ports with a 195W power budget.
2 SFP fiber ports for high-speed uplinks.
Form Factor: Rack-mountable design for efficient space utilization.
The HPE Networking Instant On JL813A 1830 24G 12p Class4 PoE 2SFP Switch is an excellent choice for small businesses seeking a reliable, high-performance, and affordable networking solution. Its advanced features and flexible connectivity options make it suitable for a wide range of applications and environments
Product Specification
Gigabit Copper Ports
24; Class 4 (ports 1 -12)
Uplinks
2 SFP 1GbE ports
Dimensions
253.0(D) x 443.0(W) x 43.9(H) mm
Weight
7.65 lb (3.47 kg)
Throughput (Mpps)
38.68 Mpps
Switching capacity
52 Gbps
Reliability MTBF (years)
96.6
Maximum power rating
100-127V: 244.6W
200-220V: 237.2W
Warranty
Limited Lifetime Warranty
Perfect For:
Home Office
Coffee Shop
Tech Start-Ups
Dental Offices
Aruba Instant On 1830 has all the features you need right out of the box
Power over Ethernet (PoE) support
The 1830 Switch Series is ready to deploy in 8-, 24-, and 48-port for non-PoE and Class 4 PoE models. Up to 30 W PoE power delivery is available for Class 4 PoE devices. With PoE and non-PoE ports supported in the same PoE model, these switches are ideal for the most cost-efficient environments.
Flexible management options
Easily deploy and manage 1830 switches using two management modes - Instant On cloud management (access via mobile app and/or web portal) or the local web GUI.
Integrated security features
Prevent unauthorized access and protect your business data with advanced security features like VLANs, automatic Denial-of-service protection, Global Storm Control, TPM (Trusted Platform module) based security and more.
Optimal energy efficiency
Cut operating costs and reduce your environmental footprint with 1830 switches. Energy Efficient Ethernet (IEEE 802.3az), auto-port shutdown, energy-efficient cooling support and fanless design all help maintain operating temperatures, reducing excess noise and power consumption.
SFP fibre connectivity
Two (2) and four (4) dedicated 1G SFP fiber ports on 24- and 48-port models respectively eliminate traffic bottlenecks across your network. Fiber connectivity provides higher uplink bandwidth and performance across longer distances than copper cabling can support.
PoE Powered Device (PD) enabled
Simplify deployments in hard-to-wire areas by the PD powered 8-port non-PoE model that can be powered from an external PoE switch or an external injector, offering greater flexibility for space-constrained environments by eliminating the need for additional power outlets and wiring.
This Model Includes:
Limited Lifetime Warranty
24/7 Phone/Chat Support
Instant On Community
