DrayTek Vigor 2766 Series Routers

The Ideal SoHo Wi-Fi 6 & VPN Router for G.Fast, VDSL and Gigabit Fibre


The Vigor 2766ax is DrayTek’s G.Fast / VDSL and Ethernet router that is ideal for Small Office and Home Office networks. Featuring powerful Firewall and Content Filtering, configurable Quality of Service, and an array of VPN capabilities, with the performance to make full use of FTTP Fibre Broadband.

Incorporating Wi-Fi 6 features, the Vigor 2766ax routers provide a reliable, highly integrated and reliable network solution for SoHo environments.


G.Fast, VDSL and Ethernet Router

Connect the Vigor 2766 to Ultrafast G.Fast or Superfast VDSL2+ FTTC with the integrated DSL Modem, or connect to Virgin Media Cable and Ultrafast FTTP with the Ethernet WAN port Powerful SoHo VPN Router

Connect remote locations with 2 VPN tunnels for Remote Dial-In User Teleworker and Dial-Out LAN to LAN VPN. Up to 150Mbps IPsec performance, with SSL and OpenVPN support.   Wi-Fi 6 - AX3000 Performance

Wi-Fi 6 wireless provides gigabit Wi-Fi with reliable throughput. Ideal for time-sensitive video conferencing, low latency gaming and handling 4K Ultra-HD streaming, without buffering. Hardware NAT & Routing with Hardware QoS

The accelerator supports up to 4k NAT and routing connections. With acceleration enabled, Vigor2766's firewall performance can reach 940Mbps, while still meeting high expectation of QoS quality. You may easily prioritize business critical apps, and always keep VoIP in 1st priority.   Packed With Features

Configure DrayTek's rich feature set to fit your network with Route Policy, Quality of Service, VPN Matcher, DrayDDNS and more. VigorACS Central Management

Use the VigorACS central management platform to manage, monitor and configure the Vigor 2766 series routers remotely across multiple locations.


DrayTek Vigor 2766 Series Diagram




Key Specifications

G.Fast (Ultrafast Fibre), VDSL2 (Superfast Fibre), ADSL2+ and Ethernet Router with Failover
Up to 940Mbps Firewall Throughput for Ethernet WAN
4 Gigabit LAN Ports
AX3000 - 11ax Dual Band Wireless
4 LAN Subnets with VLANs (Port-based / 802.1q)
SPI Firewall and Content Filtering
Up to 150Mbps IPsec VPN Throughput
2 Dial-Out LAN-to-LAN or Remote Teleworker VPN Tunnels
DrayTek SSL VPN and OpenVPN support
Optional VigorCare Available
Can be centrally Managed by VigorACS

The DrayTek Vigor 2767ax-4G is a fibre-ready VDSL router with integrated 4G/LTE, designed to deliver secure, high-speed, and resilient connectivity for small businesses, home offices, and SME environments. Powered by DrayOS 5, it combines VDSL2/ADSL2+ support, a 2.5GbE WAN/LAN interface, Wi-Fi 6 performance, and dual-SIM 4G failover to provide a dependable gateway for both fixed and mobile broadband services.

Key Features of DrayTek Vigor 2767ax-4G VDSL2/ADSL2+ modem with dedicated DSL WAN interface
2.5GbE switchable WAN/LAN port for FTTP services
Integrated 4G/LTE modem with dual SIM and eSIM support
Wi-Fi 6 (AX3000) wireless performance
Up to 2.3Gbps firewall throughput
Support for up to 16 VPN tunnels with WireGuard, OpenVPN and IPsec
SPI firewall with Web Content Filtering and URL/IP reputation
3x Gigabit LAN + 1x 2.5GbE LAN with VLAN and QoS support
VDSL, Fibre & 4G Connectivity Dedicated VDSL2/ADSL2+ WAN, a 2.5GbE WAN/LAN port for FTTP, and integrated 4G/LTE with dual SIM and eSIM support provide flexible primary or backup Internet options.

Benefits: Reliable multi-WAN connectivity. Automatic failover for continuous network access.

Wi-Fi 6 AX3000 Performance High-efficiency Wi-Fi 6 wireless delivers gigabit-class speeds with improved capacity for video conferencing, 4K streaming, cloud applications, and low-latency gaming.

Benefits: Stronger wireless coverage. Smooth performance across multiple connected devices.

High-Performance VPN & Security Supports up to 16 VPN tunnels with WireGuard, OpenVPN and IPsec, backed by an SPI firewall, Web Content Filtering, URL/IP reputation, and Threat Protection Lite.

Benefits: Secure remote access for teams. Strong protection against online threats.

2.5GbE Multi-Gigabit Capability With up to 2.3Gbps firewall throughput and a 2.5GbE interface, the router is ready for high-speed fibre services and bandwidth-intensive workloads.

Benefits: Make full use of fibre broadband. Supports demanding business and multimedia applications.

Flexible LAN & VLAN Support 3x Gigabit LAN ports and 1x 2.5GbE LAN port allow direct connection of PCs, servers, and NAS devices, with VLAN support to segment traffic across up to four networks.

Benefits: Separate guest and business traffic. Improve traffic control and service quality.

Intelligent Traffic Management Integrated QoS and bandwidth management tools prioritise critical applications such as VoIP and video calls while keeping background traffic under control.

Benefits: Consistent performance for key applications. Better overall network stability.

I/O Diagram
