Cisco Meraki Outdoor Security Cameras

Cisco Meraki MV52 Cloud-Managed Smart Camera The Meraki MV52, part of the MV smart camera family, brings physical security and advanced analytics together in a powerful, ultra-longrange telephoto bullet camera. The MV52 extends visibility and safety to challenging environments where distance and detail matter.

MV52: security and intelligence MV52 has an industry-leading processor, 1TB of high-endurance local storage, and browser-based cloud management and viewing. This edge architecture minimizes physical infrastructure and software requirements, enabling faster, easier deployments and greater scalability.

With the ability to mount to walls, ceilings, or poles, and a 360-degree rotating flexible ball joint, MV52 lets you get the angle you need, anywhere. Wireless functionality and a built-in power input option make it possible to install in even the most challenging environments beyond the reach of normal Ethernet.

MV52 combines a 12°-37° field of view with 4K video resolution. This allows for high detail, even with long-distance deployments like parking lots or perimeter monitoring. It’s also useful for situations that require license plate capture or subject identification.

Using machine-learning-based computer vision, MV52 can do real-time object detection, classification, and tracking of people and vehicles to increase safety and provide useful insights into activity. These smart cameras enable physical security and business intelligence, all in a refreshingly simple package.









Highlights



Simple to use; no special software or browser plug-ins required

1TB of high-endurance on-camera storage

All-in-the-box solution minimizes physical infrastructure requirements

Long-range viewing with bullet camera form factor and 12-37° horizontal FoV

Get built-in automatic security with secure boot and signed firmware, backed by a hardware security chip

Built-in analytics like Motion Search, Motion Recap, and Motion Heatmaps

Flexible deployment options with integrated 5 GHz 802.11ac wireless

Night vision with IR illumination up to 50m (164ft)

Simplified management with Meraki cloud architecture

See more details with the 8.4MP sensor and up to 4K video resolution

In-camera machine-learning capability allows for intelligent object detection

IK10+ and IP67 rated for demanding environments

Secure video access and ensure privacy with role-based user accounts



With an unobtrusive industrial design suitable for any outdoor setting —the MV72 simplifies and streamlines the unnecessarily complex world of security cameras. By eliminating servers and video recorders, MV frees administrators to spend less time on deployment and maintenance, and more time on meeting business needs.

Features:
256GB high write endurance solid state storage
1080p video recording with H.264 encoding
IP66 (weather resistance) & IK10 rated (impact resistance)
3-9mm vari-focal lens
802.11ac wireless
Microphone for audio recording
IR illumination up to 30m or 98ft
Cloud managed with complete integration into the Meraki dashboard
Plug and play deployment with self-configuration







Anytime, Anywhere

Stream local, stream remote. View customizable
video walls from anywhere in the world using
the Meraki dashboard in a web browser.
Automatic Network Detection

The Meraki dashboard will automatically detect whether the viewing computer is in the local network or somewhere remote. Local streaming video never goes to the cloud, saving bandwidth, while remote streaming video is proxied through the cloud allowing it to be viewed from anywhere.




Built for Simplicity

MV cameras come with everything needed for a successful deployment in the box. Add cameras to a network before they even arrive, and adjust focus, aperture, and zoom settings remotely. 256GB industrial grade solid state storage on each device
1080p HD recording with H.264 encoding
IR illumination for nighttime security up to 30m (98ft)
3-9mm vari-focal lens for multipurpose deployments
3 year warranty on all hardware
IP66 and IK10 rated plus integrated heating elements for demanding environments.



Hindsight is 20/20


Laptop gone missing? Retroactively select the desk or conference table where it was last seen and the dashboard returns a list of motion events that can help lead to its recovery.


Export and Share Video Clips

Select important video segments and export from the dashboard to a shareable and downloadable link. With granular access controls, decide who has access to historical footage and exporting privileges.

Intuitive Design

Easily search historical footage using natural language processing and go from identifying an event to sharing it in just a couple of clicks. The elegant dashboard interface allows for remote management, the way it should be.




Intelligence You Can See

With built-in analytics tools, MV adds another layer of insight to your security camera deployment.

Cutting Edge Architecture

By utilizing industrial grade, high write endurance solid state storage on each camera, the MV family has removed the NVR from the equation.




Bandwidth Conscious

Use WAN bandwidth only when needed. Less than 50kbps of metadata streams to the cloud per camera when footage is not being viewed, eliminating excessive WAN usage.

Never Stop Recording

Since video is stored on the edge, cameras will
continue to record even if the network connection fails. Solid state storage allows for up to 20 days of continuous, 24/7 recording.

Cloud Managed

The Meraki cloud architecture is built for reliability, security, and scalability. Already supporting over 500,000 customer networks, it features built-in redundancy, advanced security features, and a 99.99% uptime SLA

Cisco Meraki MV72 Cloud-Managed Smart Camera The Meraki MV72 series, part of the MV smart camera family, brings physical security and advanced analytics together in a dome form factor suitable for outdoor and demanding deployments. The powerful built-in processor -- the same kind found in many of today’s smartphones -- and innovative architecture minimizes physical infrastructure as well as software requirements. MV72 not only ensures physical safety and security but provides business intelligence, all in a refreshingly simple package.

MV72: Bringing security and analytics to demanding environments As with the rest of the MV lineup, the MV72 series places high endurance storage locally on the camera, removing the Network Video Recorder (NVR) and Video Management System (VMS) from the equation. Not only does this drastically simplify both installation and scaling, but it also eliminates a major network security vulnerability in IT infrastructure.

MV72 smart cameras are equipped with an industry-leading processor, and have a 4MP sensor for recording in up to 1080P. The processor powers advanced analytics capabilities that previously required specialized software and heavy-duty hardware. Harnessing the power of machine learning for computer vision, MV72 smart cameras can do real-time object detection, classification, and tracking of people and vehicles. This compelling insight lays the foundation for more effective and efficient processes, journey pathing, and safe working practices.

MV72 series cameras are varifocal dome cameras, capable of up to 3x optical zoom. With IP67 and IK10+ rating, they are made to endure a variety of outdoor and other demanding environments. This, combined with an attractive industrial design and easy installation makes it a natural fit for deployments ranging from school yards to manufacturing, and everything in between.

Highlights

Varifocal lens, dome camera with 36-112° horizontal FoV

Secure boot and signed firmware backed by hardware security chip

IK10+ and IP67 rated for impact resistance and ingress protection

Intelligent motion indexing with search engine

Built-in motion analytics like Motion Search, Motion Recap, and Motion Heatmaps

In-camera machine learning capability for intelligent object detection

Meraki dashboard simplifies operation

Secure, encrypted control architecture and storage

Granular user access controls

Integrated 802.11ac wireless for easy upgrades from analog

IR illumination up to 30m or 98ft

Suitable for deployments of all sizes, 1-10,000+ cameras

No special software or browser plugins required



Cisco Meraki Enterprise License for the MV series Security Cameras.
Available in 1,3,5,7 and 10 year options.

Pole mount for poles with diameter between 40mm - 145mm (1.57in - 5.71in)
Can be combined with MA-MNT-MV-10: Meraki Wall Mount Arm
Supported Models: MV72
Dimensions 163.5mm L x 107.6 W mm x 34mm D
Weight 0.289kg

Wall mount for attaching camera perpendicular to mounting surface
Includes pendant cap
Supported Models: MV72
Dimensions (Wall Arm) 160mm L x 104mm W x 286 mm D
Combined Weight 0.67kg

This unique accessory converts existing low voltage (12/24V) power supplies into PoE, allowing users to upgrade from analog to IP in just one installation step. Twin power cables can be disconnected from an analog camera and connected to the two terminals within the accessory in either order. The coaxial cable from the analog camera can simply be left in the wall and will no longer be used. Instead, video data will transmit wirelessly from the camera to the viewing computer (local connection) or through the Meraki cloud (for video proxy to a remote viewing device).
