The Euromod system of wallplates provides a flexible and versatile method of installation. This modular system offers a wide range of wallplates and modules that allows the user to install as many or as few data or voice outlets as required. The system caters for small and large installations alike.
The Euromod Single and Double gang wallplate system is the basis of this modular approach. The single gang wallplate has a 50 x 50mm aperture and the double gang a 50 x 100mm aperture, which accepts the Euromod range of data, voice (module size 25 x 50mm) and blank modules.
Designed to offer flexibility and cost effectiveness, the user can choose to install only the number of outlets required, using the blank modules when needed to provide a professional looking finish.
Features & Advantages
Full, half and quarter blank module
Complements Euromod wall outlets and modules
Durable scratch resistant finish
The MOD-SNAP system of wallplates provides a flexible wall outlet solution allowing the fitment of as many 38.5mm x 22mm MODSNAP voice or data outlets as necessary.
The MOD-SNAP single and double gang wallplate system is the basis for this modular range. It comprises of a single gang wallplate, available with one or two apertures and a double gang wallplate with four apertures.
Any combination of voice or data modules can be fitted. In addition a blank module is available to fill in any apertures not currently required in the system. This facilitates simple and convenient future expansion. The polished face of these wallplates offers quality finish, ideal for office installations. The styling also compliments most UK style electrical power outlets.
Features & Advantages
Single gang, one or two outlets
Double gang, four outlets
Fixing screws provided
Quality polished finish
Accepted by all UK backboxes
The MOD-SNAP system of wallplates provides a flexible wall outlet solution allowing the fitment of as many 38.5mm x 22mm MODSNAP voice or data outlets as necessary.
The MOD-SNAP single and double gang wallplate system is the basis for this modular range. It comprises of a single gang wallplate, available with one or two apertures and a double gang wallplate with four apertures.
Any combination of voice or data modules can be fitted. In addition a blank module is available to fill in any apertures not currently required in the system. This facilitates simple and convenient future expansion. The polished face of these wallplates offers quality finish, ideal for office installations. The styling also compliments most UK style electrical power outlets.
Features & Advantages
Single gang, one or two outlets
Double gang, four outlets
Fixing screws provided
Quality polished finish
Accepted by all UK backboxes
The Euromod system of wallplates provides a flexible and versatile method of installation. This modular system offers a wide range of wallplates and modules that allows the user to install as many or as few data or voice outlets as required. The system caters for small and large systems alike.
The Euromod Single and Double gang wallplate system is the basis of this modular approach. The single gang wallplate has a 50 x 50mm aperature and the double gang a 50 x 100mm aperture, which accepts two (single gang) or four (double gang) of the Euromod range of data, voice or blank modules (modules have a 25 x 50mm fascia size).
The polished face of these wallplates offers a quality finish, ideal for office installations and the styling complements most UK style electrical power outlets.
Features & Advantages
50 x 50mm aperture size (single gang)
50 x 100mm aperture size (double gang)
Available with or without labelling facility
Fixing screws provided
Quality polished finish
Accepted by all UK backboxes
The MOD-SNAP system of wallplates provides a flexible wall outlet solution allowing the fitment of as many 38.5mm x 22mm MODSNAP voice or data outlets as necessary.
The MOD-SNAP single and double gang wallplate system is the basis for this modular range. It comprises of a single gang wallplate, available with one or two apertures and a double gang wallplate with four apertures.
Any combination of voice or data modules can be fitted. In addition a blank module is available to fill in any apertures not currently required in the system. This facilitates simple and convenient future expansion. The polished face of these wallplates offers quality finish, ideal for office installations. The styling also compliments most UK style electrical power outlets.
Features & Advantages
Single gang, one or two outlets
Double gang, four outlets
Fixing screws provided
Quality polished finish
Accepted by all UK backboxes
The Euromod system of wallplates provides a flexible and versatile method of installation. This modular system offers a wide range of wallplates and modules that allows the user to install as many or as few data or voice outlets as required. The system caters for small and large systems alike.
The Euromod Single and Double gang wallplate system is the basis of this modular approach. The single gang wallplate has a 50 x 50mm aperature and the double gang a 50 x 100mm aperture, which accepts two (single gang) or four (double gang) of the Euromod range of data, voice or blank modules (modules have a 25 x 50mm fascia size).
The polished face of these wallplates offers a quality finish, ideal for office installations and the styling complements most UK style electrical power outlets.
Features & Advantages
50 x 50mm aperture size (single gang)
50 x 100mm aperture size (double gang)
Available with or without labelling facility
Fixing screws provided
Quality polished finish
Accepted by all UK backboxes
The Euromod system of wallplates provides a flexible and versatile method of installation. This modular system offers a wide range of wallplates and modules that allows the user to install as many or as few data or voice outlets as required. The system caters for small and large installations alike.
The Euromod Single and Double gang wallplate system is the basis of this modular approach. The single gang wallplate has a 50 x 50mm aperture and the double gang a 50 x 100mm aperture, which accepts the Euromod range of data, voice (module size 25 x 50mm) and blank modules.
Designed to offer flexibility and cost effectiveness, the user can choose to install only the number of outlets required, using the blank modules when needed to provide a professional looking finish.
Features & Advantages
Full, half and quarter blank module
Complements Euromod wall outlets and modules
Durable scratch resistant finish
The Euromod modular system provides a flexible and versatile method of installation. This modular system offers a wide range of wallplates and modules to allow the user to install as many data outlets as required. The modules are fully assembled units featuring the Molex Connected Enterprise Solutions low profile Cat 5e RJLP connector and a 25 x 50mm fascia, shutter and spring assembly.
Molex Connected Enterprise Solutions unique patented RJLP RJ45 connector is engineered to meet the highest performance standards in the industry and offers a low profile, space saving design that enables installation in shallow backboxes and trunking.
Suitable for high speed data transmission the PowerCat RJLP RJ45 connector had been designed to meet the requirements of the Cat 5e standard which demands compliance with the PowerSum principle of measurement and test.
Features & Advantages
Cat 5e performance RJ45 RJLP connector
EIA 568B wired
Space saving low profile module
Technical Information
Jack Connector
Operating Life: Minimum 500 insertion cycles
Contact Material: Phosphor Bronze
Contact Plating: 1.25 micrometers Au/Ni
Contact Force: 100g minimum
Material: UL 94VO Thermoplastic
IDC Connector
Operating Life: Minimum 100 Reterminations
Contact Material: Phosphor Bronze
Contact Plating: Sn/Pb over Ni
Wire Accommodation: 2 x 22-26 AWG solid or stranded
The MOD-SNAP modular system provides a flexible and versatile method of installation, allowing the user the choice of installing as many data outlets as required. The modules are fully assembled units featuring the Molex Premise Networks low profile Cat 5E RJLP connector and a 25 x 38.5mm fascia (BT 6C size), shutter and spring assembly.
Molex Premise Networks unique patented RJLP RJ45 connector is engineered to meet the highest performance standards in the industry and offers a low profile, space saving design that enables installation in shallow backboxes and trunking.
Suitable for high speed data transmission the PowerCat RJLP RJ45 connector was designed to meet the requirement of the Cat 5E standard which demands compliance with the PowerSum principle of measurement and test.
Features & Advantages
RJ45 RJLP connector Category 5E
EIA 568B wired
Space saving low profile module
Labelling facility
Technical Information
Jack Connector
Operating Life: Minimum 500 insertion cycles
Contact Material: Phosphor Bronze
Contact Plating: 1.25 micrometers Au/Ni
Material: UL 94VO Thermoplastic
IDC Connector
Operating Life: Minimum 100 Reterminations
Contact Material: Phosphor Bronze
Contact Plating: Sn/Pb over Ni
Wire Accommodation: 2 x 22-26 AWG solid or stranded
A Single Gang Faceplate complete with one CE cat5e Data Module, centralised in the faceplate using blanks to enable future upgradeability to a doulble outlet. Individual port labelling is also quick and easy with standard CE outlet slide in fields incorporated into the design. IDC Termination blocks are provided on the back of each module.
Category 5e UTP modules are standard 6C size. Each shuttered module is supplied with an ID window and label.
The module is cased in a high quality ABS plastic and is suitable for mounting in a variety of plates and housings. The low profile design and its 6C size make this item ideal for floor box installations.
Features
Standard Euromod Size
Low Profile Design
Supports Gigabit Ethernet
Suitable for 22-26AWG stranded and solid wire, compatible with Krone punch down tool
The Cat5e transmission performance is in compliance with the ANSI/TIA/EIA 568 B.2 Standard
Product Overview
This is a highly durable waterproof enclosure designed to extend voice and data communications systems into damp or external environments.
Features & Benefits
Manufactured in durable polycarbonate
IP56 rated
Accepts standard 50 x 25 (mm) modules
Supplied 1x Cat5e RJ45 Modules as standard
Includes stainless steel DIN rail
UK Manufactured
Category 5e UTP modules are standard 25x50mm Euromod size. Each shuttered module is supplied with an ID window and label.
The module is cased in a high quality ABS plastic and is suitable for mounting in a variety of plates and housings due to its low profile design.
Features
Standard 25x50mm Euromod Size
Low Profile Design
Supports Gigabit Ethernet
Suitable for 22-26AWG stranded and solid wire, compatible with Krone punch down tool
The Cat5e transmission performance is in compliance with the ANSI/TIA/EIA 568 B.2 Standard
Please Note: These modules are designed to fit only into CE Faceplates found Here
Excel Screened RJ45 Cat5e Shuttered Module
Excel Category 5e RJ45 Screened modules comply with the EIA TIA Standard for enhanced Category 5. Each shuttered module is supplied with a slide label field and space above, this is allowed for use of self adhesive or further labelling if required. Termination can be made using Krone tooling, a cable tie base is positioned to the side of the IDC blocks to relieve cable stress.
Please Note: These modules are designed to fit only into Excel Faceplates found Here
Features
Screened
Supports Gigabit Ethernet
Category 5e
25 x 50mm Euromod Size
Power Sum Compliant
LSA Style Termination Blocks
Built in Slide Label System
One Piece, Snap-in Design
Integral Cable Tie Position
Simple Earthing Point
Performance Overview
Excel Category 5e Data Outlets are manufactured and tested to the current Category 5 enhanced standards as defined by the TIA and ISO standards’ bodies. Swept frequency tests are applied to each critical performance characteristic, such as near end cross talk (NEXT) and far end cross talk (FEXT). Both Worst Case and Power Sum Test methods are applied. Actual performance exceeds the required standard by a considerable margin ensuring sufficient headroom for even the most demanding applications
The Excel 3 in 1 module offers the ultimate in flexibility, space utilisation and ease of installation. The totally modular design allows the mounting of up to 3 shuttered RJ45 ports in a standard flat or bevelled single gang faceplate or up to 6 in a double gang fascia. The unique design means that you only load shuttered outlets as required, any capacity within the plate which is required for a later date is simply blanked off, providing a neat and easy to use completed installation. Individual port labelling is also quick and easy with standard Excel outlet slide in fields incorporated into the design.
Features
Category 5e compliant
High density design
Individual snap in modules
Fit standard Excel Faceplates (3 required for Single Faceplates, 6 required for Double Faceplates)
LSA compatible IDC
Individual port slide labelling system
Module dimensions 16.6(w) x 50(h) x 31.5(d) mm
Please Note: These modules are designed to fit only into Excel Faceplates found Here
Performance Overview
Excel Category 5e 3 in 1 modules are manufactured and tested to the current Category 5 enhanced standards as defined by the EIA/TIA and ISO standards’ bodies. Swept frequency tests are applied to each critical performance characteristic, such as near end cross talk (NEXT) and far end cross talk (FEXT). Both Worst Case and Power Sum Test methods are applied. Actual performance exceeds the required standard by a considerable margin ensuring sufficient headroom for even the most demanding applications.
Pre-assembled faceplates can be ordered to save installation time.
UTP RJ45 Cat5e Shuttered Module - LJ6C Size
Excel Category 5e 6C RJ45 modules comply with the standards for enhanced Category 5. Each shuttered module is supplied with a slide label field and space above, this is allowed for use of self adhesive or further labelling if required. Termination can be made using LSA compatible tooling. The low profile and 6C cut out design makes this module ideal for installations in floor box environments or shallow dado trunking
Features
Supports Gigabit Ethernet
Category 5e
6C design (22mm wide x 37mm high x 28.4mm deep)
Power Sum Compliant
LSA Style Termination Blocks
Built in Slide Label System
Performance Overview
Excel Category 5e Data Outlets are manufactured and tested to the current Category 5 enhanced standards as defined by the TIA and ISO standards’ bodies. Swept frequency tests are applied to each critical performance characteristic, such as near end cross talk (NEXT) and far end cross talk (FEXT). Both Worst Case and Power Sum Test methods are applied. Actual performance exceeds the required standard by a considerable margin ensuring sufficient headroom for even the most demanding applications
Colour: |
UTP RJ45 Cat5e Low Profile Shuttered Module
Excel Category 5e RJ45 modules comply with the EIA TIA Standard for enhanced Category 5. Each shuttered module is supplied with a slide label field and space above, this is allowed for use of self adhesive or further labelling if required. Termination can be made using Krone tooling, a cable tie base is positioned between the IDC blocks to relieve cable stress.
Please Note: These modules are designed to fit only into Excel Faceplates found Here
Features
Supports Gigabit Ethernet
Category 5e
25 x 50mm Euromod Size
Low profile Design
Power Sum Compliant
LSA Style Termination Blocks
Built in Slide Label System
One Piece, Snap-in Design
Integral Cable Tie Position
Performance Overview
Excel Category 5e Data Outlets are manufactured and tested to the current Category 5 enhanced standards as defined by the TIA and ISO standards’ bodies. Swept frequency tests are applied to each critical performance characteristic, such as near end cross talk (NEXT) and far end cross talk (FEXT). Both Worst Case and Power Sum Test methods are applied. Actual performance exceeds the required standard by a considerable margin ensuring sufficient headroom for even the most demanding applications
Excel Cat5e RJ45 modules comply with the EIA TIA Standard for enhanced Category 5. Each shuttered module is supplied with a slide label field and space above, this is allowed for use of self adhesive or further labelling if required. Termination can be made using Krone tooling, a cable tie base is positioned between the IDC blocks to relieve cable stress.
Please Note: These modules are designed to fit only into Excel Faceplates found Here
Features
Supports Gigabit Ethernet
Category 5e
25 x 50mm Euromod Size
Power Sum Compliant
LSA Style Termination Blocks
Built in Slide Label System
One Piece, Snap-in Design
Integral Cable Tie Position
Performance Overview
Excel Category 5e Data Outlets are manufactured and tested to the current Category 5 enhanced standards as defined by the TIA and ISO standards’ bodies. Swept frequency tests are applied to each critical performance characteristic, such as near end cross talk (NEXT) and far end cross talk (FEXT). Both Worst Case and Power Sum Test methods are applied. Actual performance exceeds the required standard by a considerable margin ensuring sufficient headroom for even the most demanding applications
Pre-assembled faceplates can be ordered to save installation time.
Colour: |
UTP RJ45 Cat5e 4 in 1 Module/Faceplate
A Double Gang Bevelled Faceplate complete with four Excel Data Modules. Individual port labelling is also quick and easy with standard Excel outlet slide in fields incorporated into the design
Excel Cat5e RJ45 modules comply with the EIA TIA Standard for enhanced Category 5. The shuttered module is supplied with a slide label field and space above, this is allowed for use of self adhesive or further labelling if required. Termination can be made using Krone tooling, a cable tie base is positioned between the IDC blocks to relieve cable stress.
Module Features
Supports Gigabit Ethernet
Category 5e
25 x 50mm Euromod Size
Power Sum Compliant
LSA Style Termination Blocks
Built in Slide Label System
One Piece, Snap-in Design
Integral Cable Tie Position
Performance Overview
Excel Category 5e Data Outlets are manufactured and tested to the current Category 5 enhanced standards as defined by the TIA and ISO standards’ bodies. Swept frequency tests are applied to each critical performance characteristic, such as near end cross talk (NEXT) and far end cross talk (FEXT). Both Worst Case and Power Sum Test methods are applied. Actual performance exceeds the required standard by a considerable margin ensuring sufficient headroom for even the most demanding applications
Accessories
(Sold Separately)
Cat5e Patch Leads
IDC Punchdown Tool
Cat5e Solid Cable
Cat5e Modules
The new Excel Plus surface mount boxes can be used in a wide variety of applications and provide a quick and easy method of installing up to 6 outlets to work areas. These shuttered units can be installed in desk clusters, beneath retail counters, under floors or wall mounted. They are also ideal for temporary or emergency installations
Features
Category 5e compliant
Built in labelling field
Provides convenient workstation outlet for Gigabit Ethernet applications
Supplied with cable ties and fixing kit
Lifetime Product Warranty
Available in a choice of port density
25 Year System Warranty
Shuttered outlets as standard
Performance Overview
The Excel Plus surface mount boxes are manufactured and tested to the current Category 5 enhanced standards as defined by the TIA and ISO standards’ bodies. Swept frequency tests are applied to each critical performance characteristic, such as near end cross talk (NEXT) and far end cross talk (FEXT). Both Worst Case and Power Sum Test methods are applied. Actual performance exceeds the required standard by a considerable margin ensuring sufficient headroom for even the most demanding applications.
Ports: |
UTP RJ45 Cat5e 1 in 1 Module/Faceplate
A Single Gang Bevelled Faceplate complete with one Excel Data Module, centralised in the faceplate using blanks to enable future upgradeability to a double outlet.
Excel Cat5e RJ45 modules comply with the EIA TIA Standard for enhanced Category 5. The shuttered module is supplied with a slide label field and space above, this is allowed for use of self adhesive or further labelling if required. Termination can be made using Krone tooling, a cable tie base is positioned between the IDC blocks to relieve cable stress.
Module Features
Supports Gigabit Ethernet
Category 5e
25 x 50mm Euromod Size
Power Sum Compliant
LSA Style Termination Blocks
Built in Slide Label System
One Piece, Snap-in Design
Integral Cable Tie Position
Performance Overview
Excel Category 5e Data Outlets are manufactured and tested to the current Category 5 enhanced standards as defined by the TIA and ISO standards’ bodies. Swept frequency tests are applied to each critical performance characteristic, such as near end cross talk (NEXT) and far end cross talk (FEXT). Both Worst Case and Power Sum Test methods are applied. Actual performance exceeds the required standard by a considerable margin ensuring sufficient headroom for even the most demanding applications
Accessories
(Sold Separately)
Cat5e Patch Leads
IDC Punchdown Tool
Cat5e Solid Cable
Cat5e Modules
UTP RJ45 Cat5e 3 in 1 Module/Faceplate
A Double Gang Bevelled Faceplate complete with Three Excel Data Modules, centralised in the faceplate using blanks to enable future upgradeability to a Quad outlet. Individual port labelling is also quick and easy with standard Excel outlet slide in fields incorporated into the design.
Excel Cat5e RJ45 modules comply with the EIA TIA Standard for enhanced Category 5. The shuttered module is supplied with a slide label field and space above, this is allowed for use of self adhesive or further labelling if required. Termination can be made using Krone tooling, a cable tie base is positioned between the IDC blocks to relieve cable stress.
Module Features
Supports Gigabit Ethernet
Category 5e
25 x 50mm Euromod Size
Power Sum Compliant
LSA Style Termination Blocks
Built in Slide Label System
One Piece, Snap-in Design
Integral Cable Tie Position
Performance Overview
Excel Category 5e Data Outlets are manufactured and tested to the current Category 5 enhanced standards as defined by the TIA and ISO standards’ bodies. Swept frequency tests are applied to each critical performance characteristic, such as near end cross talk (NEXT) and far end cross talk (FEXT). Both Worst Case and Power Sum Test methods are applied. Actual performance exceeds the required standard by a considerable margin ensuring sufficient headroom for even the most demanding applications
Accessories
(Sold Separately)
Cat5e Patch Leads
IDC Punchdown Tool
Cat5e Solid Cable
Cat5e Modules
UTP RJ45 Cat5e 3 in 1 Module/Faceplate
Excel Category 5e 3 in 1 sets (3 shuttered RJ45 modules complete with bevelled single gang faceplates) offer the ultimate in flexibility, space utilisation and ease of installation.
Module Features
Category 5e compliant
High density design
Individual snap in modules
LSA compatible IDC
Individual port slide labelling system
Module dimensions 16.6(w) x 50(h) x 31.5(d) mm
Performance Overview
Excel Category 5e 3 in 1 modules are manufactured and tested to the current Category 5 enhanced standards as defined by the EIA/TIA and ISO standards’ bodies. Swept frequency tests are applied to each critical performance characteristic, such as near end cross talk (NEXT) and far end cross talk (FEXT). Both Worst Case and Power Sum Test methods are applied. Actual performance exceeds the required standard by a considerable margin ensuring sufficient headroom for even the most demanding applications.
Accessories
(Sold Separately)
Cat5e Patch Leads
IDC Punchdown Tool
Cat5e Solid Cable
Cat5e Modules
Excel 100-704 CAT5e White Pre-Loaded Single Gang Bevelled Faceplate
Single Gang Bevelled Faceplate complete with two Excel Data Modules. Individual port labelling is also quick and easy with standard Excel outlet slide in fields incorporated into the design.
Excel Cat5e RJ45 modules comply with the EIA TIA Standard for enhanced Category 5. Each shuttered module is supplied with a slide label field and space above, this is allowed for use of self adhesive or further labelling if required. Termination can be made using Krone tooling, a cable tie base is positioned between the IDC blocks to relieve cable stress.
Module Features
Supports Gigabit Ethernet
Category 5e
25 x 50mm Euromod Size
Power Sum Compliant
LSA Style Termination Blocks
Built in Slide Label System
One Piece, Snap-in Design
Integral Cable Tie Position
Performance Overview
Excel Category 5e Data Outlets are manufactured and tested to the current Category 5 enhanced standards as defined by the TIA and ISO standards’ bodies. Swept frequency tests are applied to each critical performance characteristic, such as near end cross talk (NEXT) and far end cross talk (FEXT). Both Worst Case and Power Sum Test methods are applied. Actual performance exceeds the required standard by a considerable margin ensuring sufficient headroom for even the most demanding applications
Accessories
(Sold Separately)
Cat5e Patch Leads
IDC Punchdown Tool
Cat5e Solid Cable
Cat5e Modules
UTP RJ45 Cat5e 6 in 1 Module/Faceplate
Excel Category 5e 6 in 1 sets (6 shuttered RJ45 modules complete with bevelled double gang faceplates) offer the ultimate in flexibility, space utilisation and ease of installation.
Module Features
Category 5e compliant
High density design
Individual snap in modules
LSA compatible IDC
Individual port slide labelling system
Module dimensions 16.6(w) x 50(h) x 31.5(d) mm
Performance Overview
Excel Category 5e modules are manufactured and tested to the current Category 5 enhanced standards as defined by the EIA/TIA and ISO standards’ bodies. Swept frequency tests are applied to each critical performance characteristic, such as near end cross talk (NEXT) and far end cross talk (FEXT). Both Worst Case and Power Sum Test methods are applied. Actual performance exceeds the required standard by a considerable margin ensuring sufficient headroom for even the most demanding applications.
Accessories
(Sold Separately)
Cat5e Patch Leads
IDC Punchdown Tool
Cat5e Solid Cable
Cat5e Modules
- Review: The 10 Best Wireless Access Points
- Review: The Top 10 Best Ethernet Cables
- What Is An Ethernet Cable And What Does It Do?
- 10 Best CCTV Security IP Cameras For Home & Business
- Review: Best Powerline Adapters In The UK
- Celebrating 20 Years Of Comms Express!
- The Top 10 DrayTek Wireless Access Points
- Best Selling APC Products At Comms Express
- Review: Top 5 Best Performing APC Uninterruptible Power Supply Units (UPS)
- Review: Top 10 Best PDU’s
