Product Code: | |
Options: | |
Qty: | |
Unit Price: | £ |
Part No: | MOD4IN1-QTM |
Delivery: | In Stock: Next Day |
![]() |
UTP RJ45 Cat5e 4 in 1 Module/Faceplate
A Double Gang Bevelled Faceplate complete with four Excel Data Modules. Individual port labelling is also quick and easy with standard Excel outlet slide in fields incorporated into the design
Excel Cat5e RJ45 modules comply with the EIA TIA Standard for enhanced Category 5. The shuttered module is supplied with a slide label field and space above, this is allowed for use of self adhesive or further labelling if required. Termination can be made using Krone tooling, a cable tie base is positioned between the IDC blocks to relieve cable stress.
Module FeaturesPerformance Overview
Excel Category 5e Data Outlets are manufactured and tested to the current Category 5 enhanced standards as defined by the TIA and ISO standards’ bodies. Swept frequency tests are applied to each critical performance characteristic, such as near end cross talk (NEXT) and far end cross talk (FEXT). Both Worst Case and Power Sum Test methods are applied. Actual performance exceeds the required standard by a considerable margin ensuring sufficient headroom for even the most demanding applications
To complement the extensive range of single piece modules, the range has been expanded with the introduction of the keystone jack. Ideal for the user with a preference for a jack and shutter install these independently verified outlets offer exceptional performance and fast reliable installation with either LSA or 110 style tooling. A choice of colours are offered to suit the required housing, White jacks for the shutter, and Black for the patch frame. The patch panel frame offers great flexibility either through part loading to suit the installations and manage cost or for pre-terminated requirements, allowing terminated jacks to be snapped into place quickly and easily.
