16U Wall Mounted Cabinets

Lande PROline 16U Wall Mount Cabinets

PROline networking enclosures/cabinets combine high quality design with superior performance. Tested with 300 kgs on the wall, 3 times the nominal weight load of 100kgs.

The design allows the cabinet to carry heavy telecom equipment, UPS and batteries in addition to standard network & IT equipment such as switches, patch panels and cables.

This product gives maximum performance on cabling and networking infrastructure, providing an economic solution using high quality fully automated production.


Key Features: • Available in heights of 7U, 9U, 12U, 16U & 20U

• 450mm and 600mm depth options

• High quality design with a rigid structure

• As standard with lockable glass front door and side panels

• Top cover with ventilation slots for option of fan installation

• Top and base have cable entry with rubber edged sliding plate (145 x 70mm)

• Rear panel has a cable gland plate

• Rear panel is used for mounting to the wall

• 19" mounting rails have U height numbering sequence

• 450mm deep supplied with 2x 19" mounting rails

• Standard paint finish of Black RAL9005 or Light Grey RAL7035

• Can also be used as a free standing cabinet with option to add castors (823415) or adj feet (823414)


Construction Main profile, framework, top/bottom cases: Multi folded automated bending technology corner profile system, resulting in a heavy duty structure with high load capacity.

The top cover and base panel have cable entry points with rubber edged sliding mechanism (w:145 x d:70 mm), allowing cabling insertion.


Rail Features The 19” rails of Lande PROline Series Wall Cabinet have automated silk-screen U numbering, from top to bottom and bottom to top. This helps when installing equipment. 19" rails are 4 fold bending for strength, 1.5 mm thickness provides high load capacities. The 19" rails are made of steel with 8-12 micron zinc plating for corrosion resistance. The 19" rails are adjustable in depth.


Additional Features PROline Wall Cabinets have a rear panel which is multifolded with 5 folds providing rigidity and high load capacity. The panel can be used as wall fixing pattern on wall. This feature provides cost efficiency on site allowing one engineer to fit a heavy enclosure to the wall.


Construction Drawings:
Additional information can be found in the Catalogue PDF file

Measurement information can be found in the

PROline 16U Rear Wall Mounting Section

All Lande PROline Wall Cabinets have the option for a rear section unit. The rear section is a heavy duty welded framed construction, 2.0 mm thick.

A PVC cable entry gland plate is provided at the wall side, to allow a cable to run through. The 19" provision, located in the rear section module, allows additional space inside (100 mm). Triangular positioning brackets for alignment and heavy load capability.


Key Features: • Available in 7U, 9U, 12U, 16U, & 20U heights

• All are 150mm deep and 600mm wide

• Heavy duty welded frame construction, 2.0mm thickness

• PVC Cable entry plate in top, base and rear

• Hasp type lock to the main cabinet

• When used with 450mm deep cabinet, the load capacity is 50kg

• When used with 600mm deep cabinet, the load capacity is 35kg


Construction Drawings:
Additional information can be found in the Catalogue PDF file

Lande PROline 16U Wall Mount Cabinets

PROline networking enclosures/cabinets combine high quality design with superior performance. Tested with 300 kgs on the wall, 3 times the nominal weight load of 100kgs.

The design allows the cabinet to carry heavy telecom equipment, UPS and batteries in addition to standard network & IT equipment such as switches, patch panels and cables.

This product gives maximum performance on cabling and networking infrastructure, providing an economic solution using high quality fully automated production.


Key Features: • Available in heights of 7U, 9U, 12U, 16U & 20U and width of 600mm

• 450mm and 600mm depth options

• High quality design with a rigid structure

• As standard with lockable glass front door and side panels

• Top cover with ventilation slots for option of fan installation

• Top and base have cable entry with rubber edged sliding plate (145 x 70mm)

• Rear panel has a cable gland plate

• Rear panel is used for mounting to the wall

• 19" mounting rails have U height numbering sequence

• 600mm deep supplied with 4x 19" mounting rails

• Standard paint finish of Black RAL9005 or Light Grey RAL7035

• Can also be used as a free standing cabinet with option to add castors (823415) or adj feet (823414)


Construction Main profile, framework, top/bottom cases: Multi folded automated bending technology corner profile system, resulting in a heavy duty structure with high load capacity.

The top cover and base panel have cable entry points with rubber edged sliding mechanism (w:145 x d:70 mm), allowing cabling insertion.


Rail Features The 19” rails of Lande PROline Series Wall Cabinet have automated silk-screen U numbering, from top to bottom and bottom to top. This helps when installing equipment. 19" rails are 4 fold bending for strength, 1.5 mm thickness provides high load capacities. The 19" rails are made of steel with 8-12 micron zinc plating for corrosion resistance. The 19" rails are adjustable in depth.


Additional Features PROline Wall Cabinets have a rear panel which is multifolded with 5 folds providing rigidity and high load capacity. The panel can be used as wall fixing pattern on wall. This feature provides cost efficiency on site allowing one engineer to fit a heavy enclosure to the wall.


Construction Drawings:
Additional information can be found in the Catalogue PDF file

Measurement information can be found in the
