12U Floor Standing Cabinets

APC Netshelter Soundproof Racks


When there's no space, budget, or time to build a traditional server closet, APC NetShelter™ Soundproof Racks offer a cost-effective alternative. Conveniently deploy servers and networking equipment in this elegant, quiet, all-in-one IT rack. Its sturdy, fan-cooled design makes it perfect for more dense IT gear.

This server-room-in-a-box comes with everything you need to replace a basic IT closet - security, cooling, power, and cable management. Just add IT gear. With APC NetShelter Soundproof Racks, you can regain valuable space and standardize across multiple sites.

Avoid noise Complaints
Loud servers are reduced to normal office background (18.5 dBA reduction) with soundproof cabinet lining while also keeping them cool. Simply set the rack thermostat, and “whisper quiet” cabinet fans will remove excess heat, preventing noisy server fans from turning on.

Keep equipment Cool
Fans in the cabinet rear extract hot air out of the rack and draw cool ambient air in through the front. Each fan module provides 1.2kW of efficient cooling without requiring costly dedicated air conditioning. See tips below for best performance.

Key Features:

Ideal for bank branches, retail spaces, offices, healthcare facilities, and classrooms
New! 2x dynamic load strength, thermostat-control, cable management, and UL certification
Engineered to be stronger and smarter without dedicated IT staff
2x more dynamic strength
Fans controlled by thermostat
Integrated cable manager
UL certification
Specifications:

Rack enclosure
Main Input Voltage: 100...230 V
Number of rack unit: 12U
Provided equipment: Casters
Height: 785 mm
Depth: 1130.4 mm
Colour: Maple
Mounting preference: No preference
Maximum mounting depth: 0.83 m
Rack width: 19"
Input: Network frequency 50/60 Hz
Standards: EIA-310D
Number of Units in Package: 1
Package 1 Weight: 108.8 kg
Output connection type: 4 IEC 60320 C13
Number of cables: 1
Width: 750 mm
Net weight: 114 kg
Mounting mode: Not rack-mountable
Mounting position: Vertical
Minimum mounting depth: 0.69 m
Permanent permissible load: 840 kg static
Output PDU type: Basic
Packing Units: Unit Type of Package 1 PCE
Package 1 Height: 89.9 cm
Package 1 Length: 120 cm
Package 1 Width: 82 cm
Contractual warranty: 2 Years

The 12U 600mm Wide x 600mm Deep PI Data enclosure/cabinet has been designed to ensure maximum rigidity and weight loading without compromising the versatility of the solution. It can be easily modified, built and de-assembled where restrictions in space are in force.

The PI range is a cost effective solution suitable for any office or data centre environment, supplied with adjustable 19 inch mounting angles, transportation castors and a configurable top panel system to incorporate fan and brush entry solutions and also provides an open base design to promote trouble free installation.

Typical Applications

Networking / Cabling / Broadcast.
19 inch Electronic Equipment Housing
Communication Systems
IT Systems
Features:

12U 600x600mm (height 750mm)
Weight - 40kg
Lockable/Removable Glass Front Door
Lockable/Removable Steel Side and Rear Panels
19 inch Adjustable Mounting Profiles Front and Rear
Vented Top Cover (for use with a Roof Fan Unit if necessary)
Open Base Design
Raised and vented top cover with cable entry
Comes with a set of transport castors (non-load bearing) for placement only
Available in Goose Grey (RAL 00A05) and Black (RAL 9005)
All Racks can be customised in the following ways:

Specific Colours (Match them to your corporate colours)
Panels and doors can be added/removed or changed as necessary
Please call our sales team on 0800 488 0000 for a quote on a custom cabinet.

Accessories are available on the following pages:

PDU's
Shelves
Fans Units
Environmental Monitoring
Cable Management
Other Accessories
Other Options and Accessories:

Console Drawers and KVM Solutions
UPS Solutions, such as APC, Tripp Lite & Eaton
A Complete Range of Switches
Patch Panels, Modules and Patch Leads



Multiple Cable Access Points



Slam Latch Locking Mechanism



Quick Release Hinge System Provides
Maximum Space During Installation

The 12U 600mm Wide x 600mm Deep PI Data enclosure/cabinet has been designed to ensure maximum rigidity and weight loading without compromising the versatility of the solution. It can be easily modified, built and de-assembled where restrictions in space are in force.

The PI range is a cost effective solution suitable for any office or data centre environment, supplied with adjustable 19 inch mounting angles, a configurable top panel system to incorporate fan and brush entry solutions and also provides an open base design to promote trouble free installation.

Typical Applications

Networking / Cabling / Broadcast.
19 inch Electronic Equipment Housing
Communication Systems
IT Systems
Features:

12U 600x600mm (height 720mm)
Weight - 40kg
Supplied Flat Packed
Open Base Design
Lockable/Removable Glass Front Door
Lockable/Removable Steel Side and Rear Panels
19 inch Adjustable Mounting Profiles Front and Rear
Vented Top Cover (for use with a Roof Fan Unit if necessary)
Comes with a set of transport castors (non-load bearing) for placement only
Raised and vented top cover with cable entry
Available in Goose Grey (RAL 00A05) and Black (RAL 9005)
All Racks can be customised in the following ways:

Specific Colours (Match them to your corporate colours)
Panels and doors can be added/removed or changed as necessary
Please call our sales team on 0800 488 0000 for a quote on a custom cabinet.

Accessories are available on the following pages:

PDU's
Shelves
Fans Units
Environmental Monitoring
Cable Management
Other Accessories
Other Options and Accessories:

Console Drawers and KVM Solutions
UPS Solutions, such as APC, Tripp Lite & Eaton
A Complete Range of Switches
Patch Panels, Modules and Patch Leads



Multiple Cable Access Points



Slam Latch Locking Mechanism



Quick Release Hinge System Provides
Maximum Space During Installation

The 12U 600mm Wide x 800mm Deep PI Data enclosure/cabinet has been designed to ensure maximum rigidity and weight loading without compromising the versatility of the solution. It can be easily modified, built and de-assembled where restrictions in space are in force.

The PI range is a cost effective solution suitable for any office or data centre environment, supplied with adjustable 19 inch mounting angles, transportation castors and a configurable top panel system to incorporate fan and brush entry solutions and also provides an open base design to promote trouble free installation.

Typical Applications

Networking / Cabling / Broadcast.
19 inch Electronic Equipment Housing
Communication Systems
IT Systems
Features:

12U 600x800mm (height 720mm)
Weight - 45kg
Lockable/Removable Glass Front Door
Lockable/Removable Steel Side and Rear Panels
19 inch Adjustable Mounting Profiles Front and Rear
Vented Top Cover (for use with a Roof Fan Unit if necessary)
Open Base Design
Raised and vented top cover with cable entry
Comes with a set of transport castors (non-load bearing) for placement only
Available in Goose Grey (RAL 00A05) and Black (RAL 9005)
All Racks can be customised in the following ways:

Specific Colours (Match them to your corporate colours)
Panels and doors can be added/removed or changed as necessary
Please call our sales team on 0800 488 0000 for a quote on a custom cabinet.

Accessories are available on the following pages:

PDU's
Shelves
Fans Units
Environmental Monitoring
Cable Management
Other Accessories
Other Options and Accessories:

Console Drawers and KVM Solutions
UPS Solutions, such as APC, Tripp Lite & Eaton
A Complete Range of Switches
Patch Panels, Modules and Patch Leads



Multiple Cable Access Points



Slam Latch Locking Mechanism



Quick Release Hinge System Provides
Maximum Space During Installation

The 12U 600mm Wide x 800mm Deep PI Data enclosure/cabinet has been designed to ensure maximum rigidity and weight loading without compromising the versatility of the solution. It can be easily modified, built and de-assembled where restrictions in space are in force.

The PI range is a cost effective solution suitable for any office or data centre environment, supplied with adjustable 19 inch mounting angles, a configurable top panel system to incorporate fan and brush entry solutions and also provides an open base design to promote trouble free installation.

Typical Applications

Networking / Cabling / Broadcast.
19 inch Electronic Equipment Housing
Communication Systems
IT Systems
Features:

12U 600x800mm (height 720mm)
Weight - 45kg
Supplied Flat Packed
Lockable/Removable Glass Front Door
Lockable/Removable Steel Side and Rear Panels
19 inch Adjustable Mounting Profiles Front and Rear
Vented Top Cover (for use with a Roof Fan Unit if necessary)
Open Base Design
Raised and vented top cover with cable entry
Available in Goose Grey (RAL 00A05) and Black (RAL 9005)
All Racks can be customised in the following ways:

Specific Colours (Match them to your corporate colours)
Panels and doors can be added/removed or changed as necessary
Please call our sales team on 0800 488 0000 for a quote on a custom cabinet.

Accessories are available on the following pages:

PDU's
Shelves
Fans Units
Environmental Monitoring
Cable Management
Other Accessories
Other Options and Accessories:

Console Drawers and KVM Solutions
UPS Solutions, such as APC, Tripp Lite & Eaton
A Complete Range of Switches
Patch Panels, Modules and Patch Leads



Multiple Cable Access Points



Slam Latch Locking Mechanism



Quick Release Hinge System Provides
Maximum Space During Installation

Please note: These products are built-to-order and therefore non-returnable.

Please note: Flatpack Prism PI floor standing cabinets are not supplied with transport castors, heavy-duty castors or jacking feet. These can be purchased separately. To add castors or jacking feet to your order, please see our range of Prism PI castors, feet and other accessories.

Please note: If a cable tray inclusive kit is selected, this will include 2 x 150mm cable trays

Prism PI Server Rack/Cabinet Accessory Kit Options:

Kit 1
Prism PI 12u 600mm(w) x 1000mm(d) Server Cabinet with Mesh Doors
2 x 12u 150mm Cable Trays (Black)
CE Part number: CA-PCT12150B (x2)

Kit 2
Prism PI 12u 600mm(w) x 1000mm(d) Server Cabinet with Mesh Doors
1 x 600mm x 1000mm Plinth (colour will match the cabinet)
CE Part number: CA-PPL610G

Kit 3
Prism PI 12u 600mm(w) x 1000mm(d) Server Cabinet with Mesh Doors
2 x 12u 150mm Cable Trays (Black)
1 x 600mm x 1000mm Plinth (colour will match the cabinet)
CE Part numbers: CA-PCT12150B (x2) & CA-PPL610G

Prism Server Cabinet Product Information

Prism's 12U 600 x 1000mm PI Server Rack is manufactured from 2mm steel, allowing it to accommodate all of today’s data centre requirements and this additional grade of material allows static loading of 750kg to be used. The internal mounting profiles have been designed to accommodate all of today’s server manufacturers products and with the use of the mid profiles supplied, a number of different depths of products can be accommodated within the one enclosure.

Prism Data Cabinet Specifications

Cabinet Dimensions Width & Depth 600mm x 1000mm U Height 12u External Height 750mm External Width 600mm External Depth 1000mm Mounting Profile Width 19" Internal Working Depth 890mm
Mounting profile's position/s: front & rear
Construction: bolted
Front door: mesh
Side panels: lockable/removable, solid with vents
Cable entry: top, bottom
Ventilation: top, small vents to side panels
Lock positions: front door, rear door, side panels
Server Cabinet Features and Benefits
Lever latch lock with 3-point locking system
Lockable front and rear metal door with 64% airflow mesh (standard)
Lockable side panels with high and low-level venting
19" ‘vendor neutral’ fully adjustable mounting profiles front and rear
Raised and vented top cover (for use with a roof fan unit if necessary) with cable entry
Open base design with plate options to maintain security
Comes with a set of transport castors (non-load bearing) for placement only (not included with flatpack version)
Available in goose grey (RAL 00A05) and black (RAL 9005)
Data centres/communication rooms
19” server equipment housing
Communication systems
Structured cabling/multi-vendor installations
Mid-style multiple depth mounting profiles
Vertical cable management (800mm wide only)
Earth bonding kit
Full range of completing accessories
Supplied assembled or in a flat pack version
Configurable roof options to cater for overhead cable installations
Full range of airflow management accessories
High density power and cooling options
Server Cabinet Customisation
Black or Grey (standard colours) (specific colours available or match your corporate colours - additional charges will apply)
Panels and doors can be added/removed or changed as necessary
Prism Data Cabinets can be supplied assembled or in a flat pack version
Accessorize with cabinet plinths and cable trays, if the cable tray inclusive kit is selected, this will include 2 x 12U 150mm cable trays
Please call our sales team on 0800 488 0000 for a quote on a custom cabinet.

Prism PI Black Cable Tray Features and Benefits
Available in multiple height and width options to suit your Prism PI cabinet
Powder coated finish in black
Prism PI Cabinet Plinth Specifications
Height: 100mm
Width: 600mm
Depth: 1000mm
Construction: Welded
Prism PI Cabinet Plinth Features and Benefits
Fixed plinth
Available in grey or black (Plinth will match the colour of the cabinet ordered in the kit)
Gland plates on side and rear for cable entry
Retractable stabilising arms with grab handles for use with telescopic equipment
Accessories are available on the following pages:
PDU's
Shelves
Fans units
Environmental monitoring
Cable management
Other accessories
Other options and accessories:
Console drawers and KVM solutions
UPS solutions, such as APC & Emerson
A complete range of switches
Patch panels, modules and patch leads

Ideal for data centers and IT environments that need a secure, mid-depth and heavy-duty rack enclosure cabinet capable of supporting up to 1,000 lbs. of equipment in a full 12U of rack space.

Premium SmartRack mid-depth enclosure cabinet


12U of rack space; 1,000-lb. load capacity


Depth of 33" allow for standard server installation


Locking, reversible front/rear doors and locking, removable side panels


Casters and leveling feet


Meets all enclosure requirements towards PCI DSS (Payment Card Industry Data Security Standard) compliance


Unit Dimensions (hwd / cm) 63.75 x 60 x 85.09















Key Features Simple Installation: Compatible with all standard 19-inch rack equipment and is designed to simplify equipment installation. It features front and rear pairs of vertical rails with square mounting holes. The rails are adjustable in quarter-inch increments to accommodate equipment depths from 3 to 32.5 inches.The rails feature square mounting holes and are capable of supporting up to 1,000 lbs. of equipment with included installation hardware. The top and bottom panels are also provided with ports for cable routing. Each rack space within the enclosure is numbered for easy reference.

Secure Equipment Access: Designed to provide a safe, secure installation solution for up to 1,000 lbs. of mission-critical rackmount equipment. It features a locking, reversible front/rear doors and locking, removable side panels. This prevents unauthorized access to installed equipment while making it easy for authorized personnel to perform inspections, maintenance and equipment replacement.

Convection Cooling: The top and bottom panels are furnished with vents designed to help remove warm air from the enclosure and draw in cool air by convection. The panels also support installation of standard user-supplied case fans (Tripp Lite SRFANWM).

Vented Top and Bottom Panels with Cable Cutouts: The top and bottom panels are furnished with vents designed to help remove warm air from the enclosure and draw in cool air by convection. They also support installation of standard user-supplied case fans.

Casters for Mobility: Comes with an accessory caster kit consisting of 4 casters and all required installation hardware. With the casters installed, the SR12UB can easily be maneuvered into the desired location, and then secured in place by adjusting the unit’s levelers. Note: the casters are intended for minor position adjustments within the final installation area only and are not designed for moving the enclosure over long distances.


This Package Includes SmartRack 12U Mid-Depth Rack Enclosure Cabinet
(36) M6 screws
(36) M6 cage nuts
(36) M6 washers
SRACASTER kit (includes 4 casters)
(2) keys
Owner's Manual

RackyRax 19” Data Cabinets combine all the features of a premium data cabinet including the aesthetically pleasing design, without the price-point to match.

The Data Cabinets are available in various configurations and are supplied fully assembled or flat packed. Each cabinet utilises a ventilated top and four 19” adjustable front and rear mounting posts. The cabinets feature lift-off sides and a lockable door for maximum access to the internal equipment, with cable access in the base for convenient routing of network cables. The side panels can be fitted with cabinet locks. The cabinet frameworks are finished in black with a Perspex lockable front door

Each Cabinet is assembled in the UK using the highest quality components and boast an impressive load rating of up to 800kg (evenly distributed). The RackyRax range of Data Cabinets has been designed ensure easy installation and maintenance

Cable access can be made through removable gland plates in the roof or through the open base.

Each RackyRax Cabinet is supplied fully assembled and ready to go

Images for illustration purposes only

Features



800kg loading capacity (evenly distributed)
Lockable/removable perspex front door with steel surround
Lockable/removable steel rear door
Removable steel side panels
Adjustable 19" mounting profiles front and rear
Removable gland plates top and bottom for cable access
A full range of accessories are available to complement the cabinet including jacking feet, transport castors, shelves and vertical cable trays
Technical Specification

Cabinet Availability U Height Size (HxWxD) Weight 12U 635x600x600 mm 28 Kg 18U 902x600x600 mm mm 37.8 kg 21U 1035x600x600 mm 48 Kg 24U 1168x600x600 mm 51 Kg 27U 1302x600x600 mm 54.6 Kg 39U 1835x600x600 mm 70 Kg 42U 1968x600x600 mm 74.6 Kg 45U 2103x600x600 mm 92.3 Kg Cabinet Specs Cable Entry Top & Bottom Depth 600mm Internal Working Depth 480mm Mounting Profiles 19" Adjustable Front & Rear Side Panels Removable Width 600mm Manufacturer RackyRax

RackyRax 19” Data Cabinets combine all the features of a premium data cabinet including the aesthetically pleasing design, without the price-point to match.

The Data Cabinets are available in various configurations and are supplied fully assembled or flat packed. Each cabinet utilises a ventilated top and four 19” adjustable front and rear mounting posts. The cabinets feature lift-off sides and a lockable door for maximum access to the internal equipment, with cable access in the base for convenient routing of network cables. The side panels can be fitted with cabinet locks. The cabinet frameworks are finished in black with a Perspex lockable front door

Each Cabinet is assembled in the UK using the highest quality components and boast an impressive load rating of up to 800kg (evenly distributed). The RackyRax range of Data Cabinets has been designed ensure easy installation and maintenance

Cable access can be made through removable gland plates in the roof or through the open base.

Each RackyRax Cabinet is supplied fully assembled and ready to go

Images shown for illustration purposes only

Features



800kg loading capacity (evenly distributed)
Lockable/removable perspex front door with steel surround
Lockable/removable steel rear door
Removable steel side panels
Adjustable 19" mounting profiles front and rear
Removable gland plates top and bottom for cable access
A full range of accessories are available to complement the cabinet including jacking feet, transport castors, shelves and vertical cable trays
Technical Specification

Cabinet Availability U Height Size (HxWxD) Weight 12U 635x600x800 mm 33 Kg 18U 902x600x800 mm 55 kg 21U 1035x600x800 mm 54.6 Kg 24U 1168x600x800 mm 56 Kg 27U 1302x600x800 mm 60 Kg 39U 1835x600x800 mm 78 Kg 42U 1968x600x800 mm 87 Kg 45U 2103x600x800 mm 92.2 Kg Cabinet Specs Cable Entry Top & Bottom Depth 800mm Internal Working Depth 680mm Mounting Profiles 19" Adjustable Front & Rear Side Panels Removable Width 600mm Manufacturer RackyRax

RackyRax 19” Data Cabinets combine all the features of a premium data cabinet including the aesthetically pleasing design, without the price-point to match.

The Data Cabinets are available in various configurations and are supplied fully assembled or flat packed. Each cabinet utilises a ventilated top and four 19” adjustable front and rear mounting posts. The cabinets feature lift-off sides and a lockable door for maximum access to the internal equipment, with cable access in the base for convenient routing of network cables. The side panels can be fitted with cabinet locks. The cabinet frameworks are finished in black with a Perspex lockable front door

Each Cabinet is assembled in the UK using the highest quality components and boast an impressive load rating of up to 800kg (evenly distributed). The RackyRax range of Data Cabinets has been designed ensure easy installation and maintenance

Cable access can be made through removable gland plates in the roof or through the open base.

Each RackyRax Cabinet is supplied fully assembled and ready to go

Images for illustration purposes only

Features



800kg loading capacity (evenly distributed)
Lockable/removable perspex front door with steel surround
Lockable/removable steel rear door
Removable steel side panels
Adjustable 19" mounting profiles front and rear
Removable gland plates top and bottom for cable access
A full range of accessories are available to complement the cabinet including jacking feet, transport castors, shelves and vertical cable trays
Technical Specification

Cabinet Availability U Height Size (HxWxD) Weight 12U 635x800x800 mm 28.2 Kg 18U 902x800x800 mm 42.3 kg 21U 1035x800x800 mm 49.3 Kg 24U 1168x800x800 mm 56.4 Kg 27U 1302x800x800 mm 63.4 Kg 39U 1835x800x800 mm 91.6 Kg 42U 1968x800x800 mm 98.8 Kg 45U 2103x800x800 mm 105.7 Kg Cabinet Specs Cable Entry Top & Bottom Depth 800mm Internal Working Depth 680mm Mounting Profiles 19" Adjustable Front & Rear Side Panels Removable Width 800mm Manufacturer RackyRax

Racky Rax Server Cabinets have been designed to offer the optimum housing for servers and networking hardware. Mesh front and rear doors plus a vented roof add up to offer maximum ventilation.

The cabinets are fitted with quick release front and rear perforated doors (approximately 60% open), fitted with lockable swing handles. The side panels can be fitted with cabinet locks. The large floor aperture gives maximum cable access, plus there is cabling access in the top. All apertures are fitted with blanking plates as standard.

These 600 wide cabinets have additional cable access next to the rack profiles to allow easy routing of cables from the front to the rear of the cabinet. These Server Cabinets are available in various configurations and are supplied fully assembled on a pallet, but all cabinets can be easily dismantled if required. The high quality attractive black finish ensures the cabinet will complement high specification office environments.

Conforms to the following standards: IEC 297-2, DIN 41494-7, DIN 41491-1, BS 5850/3192

A full range of cabinet accessories are available including; wall mounting frames, PDUs, fixed shelves, telescopic shelves, castors, cage nuts, baying kits, roof mounting fan units and plinths

Images for illustration purposes only

Features



Fully removable steel sides
Design allows for maximum ventilation
Lockable doors front and rear
Adjustable 19” mounting profiles front and rear
800 kg static load capacity
Supplied fully assembled
Technical Specification

Cabinet Availability U Height Size (HxWxD) Weight (in Kg) 12U 625x600x1000 mm 26.4 Kg 18U 889x600x1000 mm 39.6 Kg 21U 1025x600x1000 mm 46.2 Kg 24U 1155x600x1000 mm 52.8 Kg 27U 1348x600x1000 mm 59.4 Kg 39U 1882x600x1000 mm 85.8 Kg 42U 2015x800x800 mm 92 Kg 45U 2091x800x800 mm 99 Kg

Racky Rax Server Cabinets have been designed to offer the optimum housing for servers and networking hardware. Mesh front and rear doors plus a vented roof add up to offer maximum ventilation.

The cabinets are fitted with quick release front and rear perforated doors (approximately 60% open), fitted with lockable swing handles. The side panels can be fitted with cabinet locks. The large floor aperture gives maximum cable access, plus there is cabling access in the top. All apertures are fitted with blanking plates as standard.

These 800 wide cabinets have additional cable access next to the rack profiles to allow easy routing of cables from the front to the rear of the cabinet. These Server Cabinets are available in various configurations and are supplied fully assembled on a pallet, but all cabinets can be easily dismantled if required. The high quality attractive black finish ensures the cabinet will complement high specification office environments.

Each Server Cabinet is assembled in the UK using the highest quality components and boast an impressive load rating of up to 800kg (evenly distributed). The RackyRax range of Data Cabinets has been designed ensure easy installation and maintenance

Conforms to the following standards: IEC 297-2, DIN 41494-7, DIN 41491-1, BS 5850/3192

A full range of cabinet accessories are available including; wall mounting frames, PDUs, fixed shelves, telescopic shelves, castors, cage nuts, baying kits, roof mounting fan units and plinths

Images for illustration purposes only

Features



Fully removable steel sides
Design allows for maximum ventilation
Lockable/Removable doors front and rear
Removable gland plates top and bottom for cable access
Adjustable 19” mounting profiles front and rear
800 kg static load capacity
Supplied fully assembled
Technical Specification

Cabinet Availability U Height Size (HxWxD) Weight (in Kg) 12U 635x800x1000 mm 55.6 Kg 18U 902x800x1000 mm 68.2 Kg 21U 1035x600x1000 mm 71 Kg 24U 1180x800x1000 mm 73.8 Kg 27U 1302x800x1000 mm 77.6 Kg 39U 1835x800x1000 mm 104 Kg 42U 1968x800x800 mm 116.8 Kg 45U 2103x800x800 mm 118.6 Kg

Soundproof Micro Data Center Server Rack for Office and Sensitive Location Deployment

The EDGE-3 soundproof MDC is an exceptional range of enclosures with a combination of noise reduction and air-cooled thermal performance. The EDGE-3 is a superior alternative to a costly data and communications room, by allowing the deployment of servers and network equipment directly in the office and requires less than 1m² of valuable floor space.

It allows for localized on premise computing in populated or more sensitive locations - especially where there might be a concern of server noise being a distraction or breaching ECC working noise guidelines.

The EDGE-3 is an excellent all round 19” data, comms and server cabinet, with adjustable front and rear mounting angles and 6 cable entry ports. Reducing energy bills is always desirable but expecting a standard server cabinet to assist in this aspect is virtually impossible.

Key features

Cost-Effective & Green, server rooms are costly to build and run whereas EDGE-3 offer a fraction of the running costs and minimal initial investment
Cool, innovative air-flow design for effective thermal dissipation of 11.5kW
Soundproof, reduce equipment noise up to 28.5dBA (99.9%) of IT noise
Lockable, security features keep your equipment safe
Easy to Deploy, just plug and go
Expandable, when you need extra capacity, just add another EDGE-3
Portable, easily relocated to another room or building
Specifications

Number of doors 2 Type of ventilation Active Dimensions (WxHxD) 780mm x 720mm x 1100mm Number of rack units (RU) 12 With roof plate Yes With earthing Yes With front door Yes Front door material Steel Front door locking system Two-point Rear door material Steel Side panels included Yes Material Steel Type of surface Powder coated Available Colours Black or Grey RAL-number 9005 (black)
7035 (grey) IP-rating IP44 Application Server Rack

Lande Outdoor IP65 12U Cabinets

Based on the application areas, the corrosive agents, humidity effects, salty environmental effects in seaports Lande OD series enclosures constructed from different corrosive resistance reaction level materials.


Key Features: • This IP65 Outdoor Cabinet range provides a high quality design, with a welded construction for strength and corrosion protection

• This Cabinet is suitable for using within a wide range of markets to protect your equipment from the elements

• Ideal for housing equipment used in data and networking, telecoms, FTTx Communications, industrial and transportation

• IP65 Protection Level (EN60529), Polyurethane infused sealing system

• NEMA-250 classifications 3, 3S, 4, 4X, 5, 12, 12K, 13

• Standard Material (Hot Dip Pre Galv DX51 D+275gr/m, zinc plated)

• Double layer structure

• Insulation material between external and internal layers

• Gland plate supplied with 2x PG21 and 1x PG48 gland and 2x 28mm PVC blind caps

• Spare blank gland plate included

• All enclosures with a hinged canopy roof

• Hidden ventilation louvres to allow hot air discharge through the roof

• Refer to fan system parts 829606 and 829607

• Plinth 200mm high with front and rear access panel

• Polyester outdoor paint Light Grey RAL7035 as standard

• Option for Anti-graffiti and insul-paint, Signal White RAL9003 Polyurethane finish

• We can also offer in Stainless Steel Grades 430, 304 & 316

• Contact us for details on lead time and supply options


Construction Details: Front side has inner door, which is lockable provides additional security and additional protection especially for dust entry once main door is not locked.

The cabinet can be equipped with mechanical or magnet door sensors on demand.


Construction Drawings (Width: 600 mm / Depth: 650 mm): 1.
FRONT DOOR EXTERNAL SKIN

2.
LOCKING SYSTEM 3 POINT WK2 Antivandalism Certified

  3.
FRONT DOOR INNER SKIN

4.
INTERNAL COVER / DOOR

  5.
SIDE INNER SKIN

6.
VENTILATION CHANNEL

  7.
MOUNTING RAILS 19"

8.
MAIN BODY WELDED

  9.
PLINTH H200 mm

10.
PLINTH ACCESS WINDOW

  11.
FAN UNIT HOUSING

12.
ROOF CANOPY- 2 INCLINED INNER FIXING SCREWS- 2 HINGES and CANOPY STOPPER MECHANISM

  13.
REAR MOUNTING PLATE with DIN RAIL

14.
REAR INNER SKIN

  15.
GLAND PLATE WITH PG GLAND / GLAND PLATE PLAIN





Construction Drawings (Width: 600 mm / Depth: 800 mm): 1.
FRONT & REAR DOOR EXTERNAL SKIN

2.
FRONT & REAR DOOR INNER SKIN

  3.
LOCKING SYSTEM 3 POINT WK2 Antivandalism Certified

4.
FRONT & REAR INTERNAL COVER DOOR

  5.
SIDE INNER SKIN

6.
VENTILATION CHANNEL

  7.
MOUNTING RAILS 19"

8.
MAIN BODY WELDED

  9.
PLINTH H200 mm

10.
PLINTH ACCESS WINDOW

  11.
FAN UNIT HOUSING

12.
ROOF CANOPY- 4 INCLINED INNER FIXING SCREWS- NO HINGE / NO CANOPY STOPPER MECHANISM

  13.
GLAND PLATE WITH PG GLAND / GLAND PLATE PLAIN





Additional information can be found in the Catalogue PDF file

Drawing information can be found in the 600x650 Cabinet PDF file

Drawing information can be found in the 600x800 Cabinet PDF file

Lande 12U IP55 Safebox-B

This Lande range of IP55 Wall Mounting Cabinets are designed for use within industrial applications, warehouses and outdoor areas to provide protection against dust and water ingress, (rain, slush, snow). With the addition of a fan & filter integration, this area of the enclosure provides IP54 protection.

The SAFEBOX-B IP55 Outdoor Cabinets are designed for industrial applications. Based on EN 60529 provided IP55 protection class against dust and water ingress. With fan and filter integration, enclosure provides IP54 protection against dust and water. Enclosure provides protection against extraneous objects (things that might fall in, dust carried by wind) and water (rain, slush, snow, blush) which might damage the internal equipment.


Key Features: • Monoblock welded construction, with polyester type powder coating (RAL7035 Light Grey)

• Size - 12U, width 600mm and depth 450mm or 600mm

• 12U models contain 2 single point locking system. The lock systems accommodate a central cylinder lock which unlocks with a cylindrical key

• All models fitted with 1 set of 19" mounting rails

• As standard, the base of the cabinet is equipped with a filtered air inlet

• The base of the cabinet is equipped with 4x PG21 cable entry compatible blind plugs

• Top part is also filtered for passive ventilation and hot air exhaust. As required these filters can be replaced with a thermostat switched single fan

• All models have a roof canopy with gasket for dust and liquid protection

• Wall mounted brackets are included. Note that mounting screws are not, as this is subject to the site mounting area

• A single earth grounding cable between the main body and door is included

• Metal front door with IP55 sealing gasket

• Maximum load capacity is upto 300kg mounted on the wall, or 800kg on the ground

• Accessories include, rear mounting plates, fans plus options for pole mounting and plinths if siting on the ground


Installation:
Installation information can be found in the Installation Guide PDF file
