Tripp Lite SR Accessories - Cooling

Tripp Lite's SRXFAN3U SmartRack Panel-mount Triple Fan Accessory (for use with SmartRacks) is ideal for increasing the ventilation of SmartRacks, enclosures and server cabinets. The unit features (3) 4-in.-208-240V fans mounted in a 3U panel and includes mounting hardware.

Key Features Tripp Lite's SRXFAN3U SmartRack Panel-mount Triple Fan Accessory (for use with SmartRacks) is ideal for increasing the ventilation of SmartRacks, enclosures and server cabinets
Unit features (3) 4-in.-208-240V fans mounted in a 3U panel
Includes mounting hardware

This Package Includes Fan unit with C14 power inlet and required mounting hardware. User-supplied cord required.

Tripp Lite's SmartRack SRXFANROOF is ideal for increasing the ventilation in all rack enclosure server cabinets. The unit features (6) 208-240V high performance fans mounted in a roof panel, and includes toolless mounting hardware. Built-in cable access holes for routing of cables through fan roof panel. Supports 208-240V 50/60 Hz AC input.
COMPATIBLE SMARTRACK ENCLOSURES - SR25UB, SR25UBKD, SR25UBSP1, SR25UBTAA, SR42UB, SR42UBCL, SR42UBEXP, SR42UBG, SR42UBKD, SR42UBSP1, SR42UBTAA, SR48UB, SR48UBCL, SR48UBEXP, SR48UBSP1, SR42UBTAA, and other Tripp Lite SmartRack enclosures that specify the use of this accessory.

Key Features Ideal for increasing the ventilation in all rack enclosure server cabinets
Features (6) 208-240V high performance fans mounted in a roof panel
Includes toolless mounting hardware
Built-in cable access holes for routing of cables through fan roof panel
Supports 208-240V 50/60 Hz AC input
Compatible SmartRack Enclosures: SR25UB, SR25UBKD, SR25UBSP1, SR25UBTAA, SR42UB, SR42UBCL, SR42UBEXP, SR42UBG, SR42UBKD, SR42UBSP1, SR42UBTAA, SR48UB, SR48UBCL, SR48UBEXP, SR48UBSP1, SR42UBTAA, and other Tripp Lite SmartRack enclosures that specify the use of this accessory

This Package Includes SRXFANROOF 208-240V 50/60Hz fan roof
Tooless mounting hardware
6 inch C14 inlet dongle (user-supplied input cord required)

he SRFILTER comes prefabricated and ready to install in standard 48U rack enclosures on the inside of the door. Vertical hook-and-loop strips will need to be trimmed accordingly to accommodate 45U, 42U and 25U enclosures. When a filter becomes dirty or worn from use, be sure to replace it. The pieces can remain attached to the door with no need for replacement.

Key Features Prevents dust and particle buildup on equipment installed in standard SmartRack enclosure
Facilitates hot-aisle / cold-aisle data center configurations
Comes ready to install in our standard 48U racks
Vertical hook-and-loop strips must be trimmed accordingly to accommodate 45U, 42U and 25U enclosures

This Package Includes 20" (l) x 1.5" (w) horizontal hook-and-loop strips (3 pieces)
40" (l) x 1.5" (w) vertical hook-and-loop strips (4 pieces)
7/8" diameter circular hook-and-loop pieces (12 pieces)
Filter (1 piece)

The SRSWITCHDUCT is a rackmount, ducting kit that pulls air in from the front of the rack and directs is to the side intake on equipment such as network switches. Each duct is 2U tall, with one above and one below the mounted equipment. Foam baffling is included to create a hot air exhaust pathway to prevent hot air from recirculating back to the cold aisle side of the rack.

Key Features Two intake scoop duct to direct airflow
Adjustable depth universal equipment mounting rails to hold the piece of equipment being cooled
Foam baffling to segregate hot and cold aisles

This Package Includes Top and bottom air scoop duct
Foam hot air recirculation prevention strips
Metal hot aisle duct baffle
Universal equipment support rails
All mounting hardware
Owner's Manual

The SRTHERMDUCT Thermal Duct Kit can change a standard SmartRack 42-48U enclosure into a sealed passive cooling structure that allows heat built up inside a rack to be directed up and into the facility CRAC / HVAC return air system.

Key Features Improves cooling efficiency of standard Tripp Lite rack enclosures
Adjustable roof-mount thermal duct connects to HVAC return air system
Included gaskets and panels help seal enclosure for proper airflow management through thermal duct
Compatible with standard 42-48U SmartRack Enclosures

This Package Includes Height-adjustable roof-mount thermal duct
Roof-mount cable access panel
Enclosure bottom
Door gasket seals
(16) Magnetic vinyl sheet rear door seals
(4) M8 screws
(4) M4 screws
(16) M4 nuts
Owner's manual

SmartRack Magnetic Vinyl Kit for Rack Airflow Management

Passive airflow containment kit blocks vented panels of an EIA-standard 19 in. rack enclosure to prevent cool air from escaping and help connected equipment last longer and operate more efficiently

Features

6 magnetic panels attach to vented rack doors and side panels
Traps cool air inside rack for maximum cooling efficiency
Seals tightly to eliminate hot spots that can harm equipment
Covers a standard 48U rack door perforation pattern
Compatible with all Tripp Lite SmartRack enclosures
5-year limited warranty







The SRCOOLMVKIT SmartRack® Magnetic Vinyl Kit consists of six panels that attach magnetically to the vented front door, rear door or side panel of your floor or wall-mount rack enclosure. By blocking perforated areas, cool air is trapped inside the rack cabinet, and hot spots that can damage connected equipment are eliminated. Operating at a cooler temperature allows your sensitive rack equipment to last longer and work more efficiently. With four 16.9 x 18.8-inch and two 16.9 x 5.2-inch magnetic vinyl panels, the SRCOOLMVKIT can cover an EIA-standard 19-inch 48U rack door perforation pattern. It is compatible with all SmartRack enclosures.






Traps Cool Air Inside SmartRack Enclosure for Maximum Cooling Efficiency 6 magnetic panels attach to vented rack doors and side panels
Blocks perforated areas to prevent cool air from escaping
Seals tightly to eliminate hot spots that can harm equipment
Covers up to a standard 48U rack door perforation pattern
Compatible with all Tripp Lite SmartRack enclosures



Package Includes

(4) Magnetic vinyl panels, 16.9 x 18.8 in.
(2) Magnetic vinyl panels, 16.9 x 5.2 in



Overview UPC Code 037332255037 Product Type Airflow Management Accessories Type Airflow Management Cooling Cooling Type Passive Physical Shipping Dimensions (height x width x depth) 1.52 x 48.01 x 52.07 cm Shipping Weight 3.18 kg Full specification and details can be found in the

Wall-Mount Roof Fan Kit - Dual 230V High-Performance Fans, 210 CFM, 3 ft. (0.91 m) Cord, C14 Input

Increases airflow inside wall-mount rack enclosures to keep equipment cool, boost system performance and avoid costly downtime

Features

Cools rack equipment to boost system performance and avoid costly downtime
High-performance 5 in. 230V fans draw warm air up through rack at 210 CFM
50 dB sound rating ensures quiet operation—about as loud as your refrigerator
Includes hardware for mounting inside or outside standard 19 in. rack cabinets
3-ft. (0.91 m) power cord with C14 input connects to conveniently located AC outlet
2-year limited warranty









Increase Ventilation Inside Your Wall-Mount Rack Enclosures and Server Cabinets Tripp Lite’s SRXFANWM SmartRack® Wall-Mount Roof Fan Kit is an ideal accessory for maintaining a constant flow of air within your rack enclosures and server cabinets. Better airflow keeps your valuable rack components cool, helps boost system performance and avoids costly equipment failures that can lead to downtime, damage and data loss.






Powerful 230V Fans Provide Proper Cooling Two durable five-inch 230V fans mount inside or outside the cabinet to draw hot exhaust air out and facilitate equipment cooling. The high-performance fans circulate air at 210 cubic feet per minute (CFM) and do so quietly at about 50 decibels—about as loud as your refrigerator.






Compatible with Tripp Lite SmartRack Wall-Mount Enclosures The SRXFANWM comes fully assembled and ready to mount to your rack cabinet with the included hardware. Compatible racks include SRW6U, SRW9U, SRW10US, SR12UB, SRW12U, SRW12US, SRW12US33, SRW12USG, SRW18US, SRW26US and other Tripp Lite SmartRack enclosures that specify the use of this accessory. The three-foot AC power cord features a C14 input plug that connects to a conveniently located wall outlet, surge protector or PDU.




Typical Applications

Draw warm air away from rack-mounted equipment to boost system performance, prevent costly downtime and extend operating life



Package Includes

(2) 230V high-performance fans
(2) Fan guards
Rack-mounting hardware
Owner’s manual



System Requirements

SRW6U, SRW9U, SRW10US, SR12UB, SRW12U, SRW12US, SRW12US33, SRW12USG, SRW18US, SRW26US and other Tripp Lite SmartRack enclosures that specify the use of this accessory



Overview UPC Code 037332243195 Product Type Fan Kit Accessories Type Fan Kit Input Nominal Input Voltage(s) Supported 230V AC Nominal Input Voltage Description 230V 50 Hz Input Plug Features C14 Input Cord Length 0.91 m Cooling Cooling Type Passive Physical Shipping Weight 1.77 kg Unit Dimensions (height x width x depth) Por Ventilador 13.21 x 13.21 x 4.1 cm Full specification and details can be found in the
