IBM Server Rails

The 1URAIL-IBM-336 replaces the IBM rail kit. This rail kit allows the IBM X336 to be installed into most 4Post and 2Post racks. Common installation issues such as obstructions are easily resolved with the 1URAIL-IBM-336. In circumstances where the original IBM rails have been lost or damaged, the 1URAIL-IBM-336 provides an economical solution to replace the OEM rail kit.

Features

IBM x336 compatible

Alternative to OEM slide rails
Fixed (non-sliding) rail
Supports upright/side post shapes such as "C", "Z" and other shapes
Allows IBM xSeries 1U servers to mount in various non-standard racks
Mounts in any rack

Square, round, threaded holes
2Post version available (CA-URSI3361)
This kit also supports shallow racks without cable management
Technical Specifications

Rail OEM

IBM

Server Compatibility

IBM xSeries 336. IBM rails not required

Rack Type

4Post Standard 19" racks
Meets EIA-310 requirements
Use reducer brackets for 23" and 24" racks
2Post - center mount
2Post - flush mount

Rack Type

4Post, 2Post

Hole Type

Compatible with the industry standard 3/8" square hole racks
Cage nuts included for square hole mounting
Compatible with all standard round (non-threaded) holes
Compatible with all standard threads including 10-32, 12-24 and Metric M6

Rail Type

Fixed (non-sliding)

Rack Units

1U

Mounting Depth Range

2Post center or flush: 2" - 8" (51 - 203 mm)
4Post: 15 7/8" - 34 1/4" (403 - 870 mm)

Included Hardware

10-32 and 12-24 screws supplied
Cage nuts provided for square hole racks

Finish

Zinc plated

Tech Notes

Threaded front flange mates with the IBM thumb screws (M4x0.7 threads)
Rack flange type standard "L" shaped uprights or non-standard "C", "Z" and "?" shapes

Assembly Notes

4Post - requires a Phillips screwdriver for installation.
2Post - requires a Phillips & straight screwdriver for installation.

IBM x345, x346, x365, x3650 Slide Rails

This rail kit allows the specified IBM servers to be installed into most 4Post server racks. This rail kit is available with or without a cable management arm. If you have the IBM cable management arm that came with the IBM rail kit, you can use that CMA with this rail kit.

Fits 4Post, 2Post cabinets

Adjustable mounting depth of 22.5 - 31" (572 - 787 mm)
Supports upright shapes C, Z and other shapes
Fits square, round, threaded holes
2Post center mount requires additional P/N: CA-URS2P2U
2Post flush mount requires additional P/N: CA-URS4U3 Mounts up to 2 servers
Sliding rackmount for:

IBM x345
IBM x346
IBM x365
IBM x3650 M1
Rail OEM

IBM

Server Compatibility

IBM x345, x346, x365, x3650
NOTE: This kit does not work with the x3650 M2, x3850 (Call for support on these servers)

Rack Type

4Post server racks
2Post server racks using the CA-URS2P2U

Rack Type

4Post

Hole Type

Compatible with the industry standard 3/8" (10 mm) square hole racks
Compatible with all standard round (non-threaded) holes
Compatible with all standard threads including 10-32, 12-24 and metric M6

Rail Type

Ball bearing slide rails

Rack Units

2U

Mounting Depth Range

22.5" to 31" (610 mm to 787 mm)
19" to 34.5" (508 to 864 mm) with -EXT kit
Contact RackSolutions for solutions outside the listed depth range

Cable Management

Fully articulated cable management arm with Kit P/N: 2URAIL-IBM-345-CMA

Included Hardware

12-24 pan head screws
12-24 cage nuts
10-32 pan head screws
10-32 cage nuts

Tech Notes

The 2URAIL-IBM-345 rail kit is compatible with the IBM cable management arm that comes with the server. Therefore, a CMA is not included in the base kit. If you do not have the original IBM CMA, order the 2URAIL-IBM-345-CMA

Assembly Notes

Phillips head screwdriver required
