Excel Cat6A Solid Cable

Excel solid Cat6a cable U/UTP 23AWG LSOH CPR Euroclass B2ca designed and manufactured to meet and exceed the ISO, CENELEC and TIA standards and supplied on 500m reels. Excel Cat 6A U/UTP Cable takes the performance capabilities of copper infrastructure to new levels. This delivers Class EA/ Augmented Category 6 link performance over distances of up 90 metres which supports the applications including 10GBASE?T, 10 Gigabit Ethernet.

To keep ahead of the ever-increasing expansion of network infrastructure and the growing need to save space in existing containment, Excel Networking Solutions is pleased to introduce a new reduced-size Category 6A U/UTP cable, which features one of the smallest diameters available in the market today at 7mm. A weight of 48g per meter allows more cable to be placed in containment and reduces the overall floor weight of any installation.

Its unique design overcomes the barriers of U/UTP when it comes to the CPR fire rating and performance. In smaller diameter cables, the use of a non-metallic but reflective barrier tape increases the performance of the cable and acts as a heat barrier, which reduces the combustibility of the cable giving a higher resilience to fire and decreasing the burn rate.

Features and Benefits

Cat6a 23AWG Copper Cable
U/UTP No Overall Screening
No Conductor Screening
Outer sheath colour Ice Blue
Reaction-to-fire class according to EN 13501-6: B2ca
Smoke development class according to EN 13501-6: s1a
Product specifications for these products can be found in the Documentation tab

Excel Dual screened Cat6a cable S/FTP LSOH CPR Euroclass Dca with individual foil wrapped pairs and overall foil wrap and braided screening supplied on 500m Reel. Excel Cat 6A fully screened (S/FTP) Cable takes the performance capabilities of copper infrastructure to new levels. This delivers Class EA/ Augmented Category 6 link performance over distances of up 90 metres which supports the applications including 10GBASE-T, 10 Gigabit Ethernet.

Each cable consists of four pairs which are individually wrapped with a high quality, strong, aluminium/polyester foil tape providing screening for each pair. The individual pairs are set to different lay lengths to ensure optimum performance. These are then wrapped in another, overall foil and an overall braid screening.

Features and Benefits

Dual Cat6a Copper Cable
S/FTP Overall Screening
Foil Screen per pair
Outer sheath colour White
Reaction-to-fire class according to EN 13501-6: Dca
Smoke development class according to EN 13501-6: s2
Product specifications for these products can be found in the Documentation tab

Excel solid Cat6A cable individually screened full U/FTP LSOH CPR Euroclass B2ca designed and manufactured to meet and exceed the ISO, CENELEC and TIA standards and supplied on 305 m boxes. Excel Cat6A fully screened (U/FTP) cable takes the performance capabilities of copper infrastructure to new levels.

This delivers Class EA/Augmented Category 6 link performance over distances of up 90 metres which supports the applications including 10GBASE-T, 10 Gigabit Ethernet.

Each cable consists of four pairs which are individually wrapped with a high quality, strong, aluminium/polyester foil tape providing screening for each pair.

The individual pairs are set to different lay lengths to ensure optimum performance.

Features and Benefits

Cat6a Solid Copper Cable
U/FTP no overall screening
Foil screen per pair
Outer sheath colour Ice Blue
Reaction-to-fire class according to EN 13501-6: B2ca
Smoke development class according to EN 13501-6: s1a

Excel Dual Cat6a cable individually screened full U/FTP LSOH CPR Euroclass Dca designed and manufactured to meet and exceed the ISO, CENELEC and TIA standards and supplied on 500m reels. Excel Cat 6A fully screened (U/FTP) Cable takes the performance capabilities of copper infrastructure to new levels. This delivers Class EA/ Augmented Category 6 link performance over distances of up 90 metres which supports the applications including 10GBASE-T, 10 Gigabit Ethernet.

Each cable consists of four pairs which are individually wrapped with a high quality, strong, aluminium/polyester foil tape providing screening for each pair.

The individual pairs are set to different lay lengths to ensure optimum performance.

Features and Benefits

Cat6a Solid Copper Cable
U/FTP No Overall Screening
Foil Screen per pair
Outer sheath colour Ice Blue
Reaction-to-fire class according to EN 13501-6: Dca
Smoke development class according to EN 13501-6: s2
Product specifications for these products can be found in the Documentation tab

Excel screened Cat6a cable S/FTP LSOH CPR Euroclass B2ca with individual foil wrapped pairs and overall foil wrap and braided screening supplied on 500m Reel. Excel Cat 6A fully screened (S/FTP) Cable takes the performance capabilities of copper infrastructure to new levels. This delivers Class EA/ Augmented Category 6 link performance over distances of up 90 metres which supports the applications including 10GBASE-T, 10 Gigabit Ethernet.

Each cable consists of four pairs which are individually wrapped with a high quality, strong, aluminium/polyester foil tape providing screening for each pair. The individual pairs are set to different lay lengths to ensure optimum performance. These are then wrapped in another, overall foil and an overall braid screening.

Features and Benefits

Cat6a Solid Copper Cable
S/FTP Overall Screening
Foil screen per pair
Outer sheath colour white
Reaction-to-fire class according to EN 13501-6: B2ca
Smoke development class according to EN 13501-6: s1a
Product specifications for these products can be found in the Documentation tab

Excel solid Cat6A cable individually screened full U/FTP LSOH CPR Euroclass B2ca designed and manufactured to meet and exceed the ISO, CENELEC and TIA standards and supplied on 305 m boxes. Excel Cat6A fully screened (U/FTP) cable takes the performance capabilities of copper infrastructure to new levels.

This delivers Class EA/Augmented Category 6 link performance over distances of up 90 metres which supports the applications including 10GBASE-T, 10 Gigabit Ethernet. Each cable consists of four pairs which are individually wrapped with a high quality, strong, aluminium/polyester foil tape providing screening for each pair.

The individual pairs are set to different lay lengths to ensure optimum performance.

Features and Benefits

Cat6a Solid Copper Cable
U/FTP no overall screening
Foil screen per pair
Outer sheath colour white
Reaction-to-fire class according to EN 13501-6: B2ca
Smoke development class according to EN 13501-6: s1a
Product specifications for these products can be found in the Documentation tab

Excel solid Cat6A cable individually screened full U/FTP LSOH CPR Euroclass B2ca designed and manufactured to meet and exceed the ISO, CENELEC and TIA standards and supplied on 500 m Reel. Excel Cat6A fully screened (U/FTP) cable takes the performance capabilities of copper infrastructure to new levels.

This delivers Class EA/Augmented Category 6 link performance over distances of up 90 metres which supports the applications including 10GBASE-T, 10 Gigabit Ethernet.

Each cable consists of four pairs which are individually wrapped with a high quality, strong, aluminium/polyester foil tape providing screening for each pair.

The individual pairs are set to different lay lengths to ensure optimum performance.

Features and Benefits

Cat6a Solid Copper Cable
U/FTP no overall screening
Foil screen per pair
Outer sheath colour Ice Blue
Reaction-to-fire class according to EN 13501-6: B2ca
Smoke development class according to EN 13501-6: s1a

Excel solid Cat6a cable screened U/FTP LSOH S-Foil CPR Euroclass Dca designed and manufactured to meet and exceed the ISO, CENELEC and TIA standards and supplied on 500m reels. Excel Cat 6A screened (U/FTP) Cable takes the performance capabilities of copper infrastructure to new levels.

Each cable consists of two sets of two pairs are wrapped together in an "S" configuration with high quality, strong, aluminium/polyester foil tape providing screening for each pair. The "S" Foil configuration ensures separation of the pairs that ensures the performance.

The individual pairs are set to different lay lengths to ensure optimum performance.

Features and Benefits

Cat6A solid copper cable
U/FTP no overall screening
S-Foil screened pairs
Outer sheath colour white
Reaction-to-fire class according to EN 13501-6: Dca
Smoke development class according to EN 13501-6: s2
Product specifications for these products can be found in the Documentation tab

Excel Dual Cat6a cable screened U/FTP LSOH S-Foil CPR Euroclass Dca designed and manufactured to meet and exceed the ISO, CENELEC and TIA standards and supplied on 500m reels. Excel Cat 6A Screened (U/FTP) Cable takes the performance capabilities of copper infrastructure to new levels. This delivers Class EA/ Augmented Category 6 link performance over distances of up 90 metres which supports the applications including 10GBASE-T, 10 Gigabit Ethernet.

Each cable consists of two sets of two pairs are wrapped together in an "S" configuration with high quality, strong, aluminium/polyester foil tape providing screening for each pair. The "S" Foil configuration ensures separation of the pairs that ensures the performance and is manufactured as a Dual Cable.

The individual pairs are set to different lay lengths to ensure optimum performance.

Features and Benefits

Cat6a Solid Copper Cable
U/FTP No Overall Screening
S Foil Screened Pairs
Outer sheath colour Ice Blue
Reaction-to-fire class according to EN 13501-6: Dca
Smoke development class according to EN 13501-6: s2
Product specifications for these products can be found in the Documentation tab

Excel Dual Cat6a cable individually screened full F/FTP LSOH CPR Euroclass Dca designed and manufactured to meet and exceed the ISO, CENELEC and TIA standards and supplied on 500m reel. Excel Cat 6A fully screened (F/FTP) Cable takes the performance capabilities of copper infrastructure to new levels. This delivers Class EA/ Augmented Category 6 link performance over distances of up 90 metres which supports the applications including 10GBASE-T, 10 Gigabit Ethernet.

Each cable consists of four pairs which are individually wrapped with a high quality, strong, aluminium/polyester foil tape providing screening for each pair.

The individual pairs are set to different lay lengths to ensure optimum performance. These are then wrapped in another overall foil.

Features and Benefits

Dual Cat6a Copper Cable
F/FTP Overall Foil Screen
Foil Screen per pair
Outer sheath colour Ice Blue
Reaction-to-fire class according to EN 13501-6: Dca
Smoke development class according to EN 13501-6: s2
Product specifications for these products can be found in the Documentation tab

Excel screened Cat6a cable S/FTP LSOH CPR Euroclass Dca with individual foil wrapped pairs and overall foil wrap and braided screening supplied on 500m Reel. Excel Cat 6A fully screened (S/FTP) Cable takes the performance capabilities of copper infrastructure to new levels. This delivers Class EA/ Augmented Category 6 link performance over distances of up 90 metres which supports the applications including 10GBASE-T, 10 Gigabit Ethernet.

Each cable consists of four pairs which are individually wrapped with a high quality, strong, aluminium/polyester foil tape providing screening for each pair. The individual pairs are set to different lay lengths to ensure optimum performance. These are then wrapped in another, overall foil and an overall braid screening.

Features and Benefits

Cat6A solid copper cable
S/FTP Overall Screening
Foil Screen per pair
Reaction-to-fire class according to EN 13501-6: Dca
Smoke development class according to EN 13501-6: s2
Product specifications for these products can be found in the Documentation tab

Excel Category 6a – Augmented Category 6 – cables, and associated connectors, take the performance capabilities of copper infrastructure to new levels. Designed to the current ISO and EIA/TIA standards for Class EA augmented Category 6a performance these products are intended to deliver reliable, high network performance over link distances of upto 90 metres, including support of emerging applications such as 10GBase-T, 10 Gigabit Ethernet.

Each cable consists of two 2 pair sub units which are wrapped in a figure of 8 style covering of high quality, strong, aluminium/polyester foil tape providing an individual screen for each pair but also a quick and easy to install overall design. These sub units are then cabled together, with the pairs set to different lay lengths to ensure optimum performance, an overall 360 degree foil tape screen plus drain wire is applied to provide further immunity to outside noise and to mitigate any risk of alien cross talk.

Excel Category 6a cables are jacketed in an Ice Blue low smoke zero halogen (LSZH) compound compliant with flame retardant standards as defined in IEC 60332-1, and smoke emission standards IEC61034. Supplied on 500 metre plywood drums, each cable has a print legend identifying the specification, part code and sequential metre marking which counts down from 500 metres to 1 metre, on each drum to reduce waste.

Specified to 500MHz
Category 6a compliant
Suitable for 10 Gigabit, 10GBase-T, Ethernet applications
Individual and overall foil screen
Compact, but robust, design
Innovative screening design, reduces install time
Low Smoke Zero Halogen Outer Sheath
CPR compliant to Dca
Material & Construction Conductor Materials Cu, bare Size 23 AWG Insulation Materials Foam PE Colour Blue/White Orange/White Green/White Brown/White Jacket Materials LSOH (Copolymer, thermoplastic) Diameter Nominal 6.9mm Colour Ice Blue or Orange Construction F/FTP No. of Cores 8 Conductor category Class 1 = Solid Reaction-to-fire class according to EN 13501-6 Dca Category 6A (IEC) Overall screening Foil Conductor screening Foil



Accessories
(sold Separately)

Tools

Universal Stripping Tool IDC Punchdown Tool

Networking

Keystone Jack Patch Panels Cat6a Modules

Excel Cat6A Cable Unscreened U/UTP - Ice Blue, and associated connectors, take the performance capabilities of copper infrastructure to new levels. Designed to the current ISO EN and TIA standards for Class EA / Category 6A performance these products are intended to deliver reliable, high network performance over link distances of up to 90 metres and channels up to 100m, including applications such as 10GBASE-T, 10 Gigabit Ethernet.

Each cable consists of 4 unscreened twisted pairs which are formed around a specifically designed X filler, manufactured from lightweight flexible polyethelene. The use of a X filler to separate and maintain the position of conductors within high frequency unscreened cable designs has become standard practice following their introduction into Category 6 cables some years ago. By controlling - and making consistent - the spacing and positioning of each pair in relation to the others within the cable performance levels can be assured and issues such as crosstalk within and between cables can be addressed.

The term ‘Alien Crosstalk’ refers to the influence on the signal from a source external to the jacket sheath. i.e. it is the crosstalk from the other Category 6A cables. Whereas the Category 6 cables are circular, with the central X filler used in the Excel Category 6A creates an oval shape. There is an overall twist along the length of cable. The oval shape, twisting along the length of the cable, forces air gaps between adjacent cables within any bundles. These resulting air gaps drastically reduce the risks of Alien Crosstalk. The risks are further mitigated by following good installation practices.

Excel Category 6a cables are jacketed in an Ice Blue low smoke zero halogen (LSZH) compound compliant with flame retardant standards as defined in IEC 60332-1, and smoke emission standards IEC61034. Supplied on 500 metre plywood drums, each cable has a print legend identifying the specification, part code and sequential metre marking which counts down from 500 metres to 1 metre, on each drum to reduce waste.

Features: Specified to 500MHz
Category 6A compliant
Suitable for 10GBASE-T, 10 Gigabit Ethernet Applications
Compact, but robust, design
Low Smoke Zero Halogen Outer Sheath
Sequential metre markings
Supports Power Over Ethernet (POE) Plus
CPR Compliant to Dca
Performance Overview

Excel Category 6A cables are designed, manufactured and tested in accordance with the ISO, EN and TIA standards for Category 6A. As such they are suitable for the support of high speed enterprise LAN and datacenter applications such as 10 Gigabit Ethernet. The use of a purposely designed X filler together with the unique oval shape of the cable ensure that correctly installed systems are immune to performance concerns sometimes found in high speed, high frequency copper cable networks. Cables designed in this way act against Alien Crosstalk..

Material & Construction Conductor Materials Cu, bare Size 23 AWG Insulation Materials Foam PE Colour Blue/White Orange/White Green/White Brown/White Jacket Materials LSOH (Copolymer, thermoplastic) Diameter Nominal 8.3mm Colour Ice Blue Construction U/UTP No. of Cores 8 Conductor category Class 1 = Solid Reaction-to-fire class according to EN 13501-6 Dca Category 6A (IEC) Overall screening None Conductor screening None Accessories
(sold Separately)

Tools

Universal Stripping Tool IDC Punchdown Tool Networking

Keystone Jack Patch Panels Cat6a Modules

Excel Category 6A – Augmented Category 6 – cables, and associated connectors, take the performance capabilities of copper infrastructure to new levels. The cable has been designed to exceed the ISO/IEC, TIA and CENELEC for Category 6A/Augmented Category 6 component requirements. This delivers Class EA/ Augmented Category 6 link performance over distances of up 90 metres which supports the applications including 10GBASE-T, 10 Gigabit Ethernet.

Each cable consists of 4 pairs individually wrapped in a covering of high quality, strong, aluminium/polyester foil tape providing an individual screen for each pair. These sub units are then cabled together, with the pairs set to different lay lengths to ensure optimum performance.

Excel Category 6A cables are jacketed in an Ice Blue low smoke zero halogen (LSOH) compound compliant with flame retardant standards as defined in IEC 60332-1, and smoke emission standards IEC61034. Supplied on 500 metre plywood drums or in a 305 metre box, each cable has a print legend identifying the specification, part code and sequential metre marking which counts down from 500 or 305 metres to 1 metre respectively.

Features: Specified to 500MHz
Category 6A compliant
Suitable for 10GBASE-T, 10 Gigabit Ethernet Applications
"S" foil screen
Compact, but robust, design
Low Smoke Zero Halogen Outer Sheath
Sequential metre markings
Supports Power Over Ethernet (POE) Plus
CPR Compliant to Dca
Performance Overview

Excel Category 6A cables are designed, manufactured and tested in accordance with the ISO and TIA standards for Cat 6A. As such they are suitable for the support of high speed enterprise LAN and data centre applications such as 10 Gigabit Ethernet. The use of high quality foil tape screens in the design of this cable ensure that correctly installed systems are immune to performance concerns sometimes found in high speed, high frequency copper cable networks. Cables designed with pair and overall screening such as this act against Alien Crosstalk, the inducement of noise from one 4 pair cable to an adjoining (or number of adjoining cables) as well as protecting against from signal loss though emissions and enabling immunity from disturbance’s which could potentially be received from external sources such as other cables or electronic devices.

Material & Construction Conductor Materials Cu, bare Size 23 AWG Insulation Materials Foam PE Colour Blue/White Orange/White Green/White Brown/White Jacket Materials LSOH (Copolymer, thermoplastic) Diameter Nominal 6.7mm Colour Ice Blue Construction U/FTP No. of Cores 8 Conductor category Class 1 = Solid Reaction-to-fire class according to EN 13501-6 Dca Category 6A (IEC) Overall screening None Conductor screening Foil

Accessories
(sold Separately)

Tools

Universal Stripping Tool IDC Punchdown Tool

Networking

Keystone Jack Patch Panels Cat6a Modules

Cat6A Cable - Solid conductor 4 pair U/FTP cable with low smoke zero halogen outer sheath, CRP Rating Class B2ca

Each cable consists of 4 pairs individually wrapped in a covering of high quality, strong, aluminium/polyester foil tape providing an individual screen for each pair. These are twisted together to form 4 pairs with varying lay lengths.

The printing detail on the sheath, includes the cables part number, specification details and a 305-0 reverse metre marking within each box supplied, allowing for quick and easy measurement of cable installed and the amount remaining within the box.


Product Features



305 metres in an easy to pull box


Available in Ice Blue


CPR Compliant to B2ca Standard – Classification B2ca, s1, d1, a1


Manufactured and tested to the ANSI/TIA, ISO/IEC, and EN Standards


Fire Test according to IEC 60332-1-2 and EN 50399, EN 61034-2, EN 60754-2


Sequential reverse metre markings (305-0)


Solid Copper Cores

Product Specification



Construction and Characteristics

Conductor

Material/Size

Bare Copper / 23AWG

Insulation

Material

PE

Thickness

Nominal: 0.385mm

Diameter

Nominal: 1.32mm

Colours

Blue/White

Orange/White

Green/White

Brown/White

Unaged Elongation

Min. 100%

Unaged Tensile Strength

Min.0.816 Kgf/mm²

Screen

Material

Individual Foil and without overall braid screened.

Material

Stranded tinned copper drain wire

Jacket

Material

LS0H

Thickness

Nominal: 0.5mm

Diameter

Nominal: 7.1mm

Colour

Ice Blue

Unaged Elongation

Min. 125%

Unaged Tensile Strength

Min. 0.918Kgf/mm²

Aging at 100°C for 168hrs

Min. elongation retention: 70%

Min. tensile strength retention: 70%

Electrical Performances

Dielectric Strength of Insulation

1500 V dc/2 Seconds

Insulation Resistance Test

Min. 5000 M?/Km

Conductor Resistance

Max. 9.38 ?/100m at 20°C

Resistance Unbalance

Max. 2%

Capacitance Unbalance

Max. 160 pF/100m

Mutual Capacitance

Max. 5600 pF/100m

Impedance

1~100MHz

100? ± 15%

100~250MHz

100? ± 22%

251~500MHz

100? ± 25%

Attenuation & Near End Cross Talk

Frequency
(MHz)

Attenuation
(dB), Max.

NEXT
(dB), Min.

PSNEXT
(dB), Min.

1MHz

1.9*

65.0*

62.0*

10MHz

5.5*

57.8*

55.5*

100MHz

18.0*

41.8*

39.9*

200MHz

26.1*

36.9*

34.3*

250MHz

29.5*

35.3*

32.7*

300MHz

32.7*

34.0*

31.4*

400MHz

38.4*

29.9*

27.1*

500MHz

43.8*

26.7*

23.8*
