Eizo Photography, Design & Media Monitors

With 4K UHD (3840 x 2160), a spacious 27-inch screen, and USB Type-C connectivity, this monitor facilitates a detail-oriented, comfortable, and streamlined workflow ideal for any creative field. Whether it be photography, video editing, or design, this monitor gives you everything you need to keep imagination flowing.

4K UHD Resolution

The ColorEdge CS2740 is the first CS series monitor to implement 4K UHD resolution (3840 x 2160), which is four times the size of Full HD. The remarkable detail ensures that high resolution photos and other content are displayed crisply. The 27-inch screen provides ample space for easily displaying Full HD content in full with enough space to show toolbars, palettes, and other windows or applications simultaneously. This makes the monitor versatile for photos, video editing, design, and other types of creative work up to 4K.

High Pixel Density for Smooth Display

A conventional monitor displays in Full HD with just 96 ppi. The ColorEdge CS2740 boasts a pixel density nearly twice that at an incredible 164 ppi for 4K image display that has never looked smoother. Alphanumeric characters and contours are distinguished with excellent sharpness so you can check even the finest details without needing to zoom in.

Single Cable Connection with USB Type-C

The ColorEdge CS2740 features USB Type-C connectivity with 60 W power delivery. With a single USB Type-C cable you can display video, transmit USB signals, and supply power to a connected device such as a smartphone or notebook PC. Simply plug in and get creative without worrying about additional cable clutter.

10-Bit Simultaneous Display

Using the DisplayPort or HDMI inputs, the monitor offers 10-bit simultaneous display* from a 16-bit look-up-table (LUT) which means it can show more than one billion colors simultaneously. This is 64 times more colors than you get with 8-bit display, resulting in smooth color gradations and reduced Delta-E between two adjacent colors.

Multiple Inputs

The ColorEdge CS2740 is equipped with HDMI and DisplayPort inputs. In addition to USB Type-C, it also has a USB Type-B and four USB Type-A ports.

The Eizo CG2700S is a 27-inch ColorEdge monitor with a 2560 x 1440 WQHD resolution and IPS wide-gamut panel, providing a detailed workspace for photography, video editing, colour grading, graphics and print work. It supports 10-bit display from a 16-bit LUT, with 1.07 billion colours, 400 cd/m² brightness and a 1600:1 contrast ratio for accurate image reproduction. :contentReference[oaicite:0]{index=0}

Key Features of Eizo CG2700S 27-inch IPS wide-gamut LCD panel
2560 x 1440 WQHD resolution
10-bit display with a 16-bit LUT
1.07 billion display colours
400 cd/m² typical maximum brightness
1600:1 typical contrast ratio
Built-in calibration sensor for automatic self-calibration
USB Type-C with up to 92 W Power Delivery
DisplayPort and HDMI inputs
Integrated USB hub with four downstream ports
RJ-45 Gigabit LAN connection
Supplied monitor hood for controlled viewing conditions
Dive Straight into Your Creativity This flagship 27-inch monitor marks a new generation of ColorEdge with a new exterior design. With 2K WQHD (2560 x 1440) resolution, 400 cd/m2 high brightness, and HDR gamma support, the monitor reproduces content in remarkable detail. USB Type-C connectivity provides a streamlined experience so professionals in video editing, game development, photography, and more can focus on creating.

The ColorEdge CG2700S is one of the flagship models for the latest generation of ColorEdge color management monitors. It features HDR gamma support, USB Type-C connectivity, a built-in calibration sensor, and a new cabinet design.

2K WQHD Resolution The ColorEdge CG2700S displays at 2K WQHD (2560 x 1440) resolution. The 27-inch screen provides ample space for displaying Full HD content in full with enough space to show toolbars, palettes, and other windows or applications. This makes the monitor versatile for video editing, 3DCG creation, game development, photography, and other creative fields. EIZO also offers a 4K UHD (3840 x 2160) model with the ColorEdge CG2700X for creators focused on 4K content.

Single Cable Connection with USB Type-C The ColorEdge CG2700S features USB Type-C connectivity that allows you to display video, transmit USB signals, and supply power to a connected device such as a tablet or notebook PC. This convenient multi-purpose connectivity makes it faster and easier to connect when moving between workstations or working remotely.

Power Delivery The ColorEdge CG2700S reliably charges a MacBook Pro or other high-end laptops with 92 W power delivery. This eliminates the need for a laptop's bulky power supply unit, freeing up space in your bag and on the desk.

Stable Network Connection While many modern laptops are not equipped with a dedicated LAN port, the monitor has one directly built in for stable wired connection. Connecting a laptop via USB Type-C provides access to the network through the monitor for sharing creative assets and files, carrying out post production work remotely, and enables network-based color management via ColorNavigator Network.

Built-In Sensor to Automate Your Workflow ColorEdge were the first monitors in the world to have a built-in calibration sensor for color critical applications. The built-in sensor can be set to calibrate the monitor automatically at designated times. This eliminates the need for a third-party calibration device and ensures your screen stays color-accurate. In addition, the sensor swings onto the screen, taking up minimal space and allowing you to continue working even during calibration.

ColorNavigator 7 Color Management Software A monitor needs to be calibrated at regular intervals to maintain color accuracy. EIZO's proprietary ColorNavigator 7 software provides an intuitive and highly precise solution to color management. It allows you to schedule automatic recalibration, calibrate all color modes simultaneously, and conduct correlation with external sensors to match the studio's internal color management framework. Calibration information is saved to the monitor instead of the operating system so users do not have to recalibrate even when using a different PC.

ColorNavigator Network Color Management Software ColorNavigator Network provides centralized quality control (QC) of ColorEdge monitors for studios, printing houses, and other enterprises with multiple creators and editors who work on shared projects. With NetAgent or ColorNavigator 7 installed on the workstation, administrators can manage multiple ColorEdge monitors via web browser enabling quality control even from remote locations. ColorNavigator Network is hosted on a secure cloud server to free you from the initial investment and running costs of providing your own server.

Vivid Colors Reproduced to Industry Standards The monitor's wide color gamut faithfully reproduces 98% of the DCI-P3 standard used in digital cinema and supports the BT.2020 standard used in broadcasting. In addition, it covers 99% of the Adobe RGB color space so images shot in Adobe RGB will be displayed correctly. It also covers almost the entire ISO-coated and US web-coated CMYK color spaces used in printing.

3D LUT for Accurate Color Display The monitor uses a 3D LUT which adjusts colors individually on an RGB cubic table. With the supported ColorNavigator 7 software’s emulation function, creators can check how content will appear to their audience. The 3D LUT also improves the monitor's additive color mixture (combination of RGB), which is a key factor in its ability to display neutral gray tones.

10-Bit Simultaneous Display Using the DisplayPort or HDMI input, the ColorEdge monitor offers 10-bit simultaneous display* from a 16-bit look-up-table (LUT) which means it can show more than one billion colors simultaneously. This is 64 times more colors than you get with 8-bit display, resulting in smooth color gradations and reduced Delta-E between two adjacent colors.

Broadcast and Cinema Presets Preset modes for DCI-P3, BT.709, and BT.2020 ensure you can work in the appropriate color spaces and gamma values. In addition, preset modes for PQ (DCI and BT.2100) and HLG (BT.2100) are available for viewing HDR content. With the built-in calibration sensor, you can conveniently adjust or maintain the brightness setting for each preset.

HDR Gamma Support The ColorEdge CG2700S features a high brightness level of 400 cd/m2. It supports HLG (hybrid log-gamma) and the PQ (perceptual quantization) curve for displaying and editing HDR (high dynamic range) video content. The optimized gamma curves render images to appear more true to how the human eye perceives the real world compared to SDR (standard dynamic range). This ensures professional creators can reliably display HDR content for editing and color grading.

Luminance Warning The monitor includes a function that shows the areas of the image that cannot be displayed correctly at the current brightness settings. These areas are marked in yellow or magenta and can be viewed for brightness levels of 300, 500, 1000, and 4000 cd/m2.

Automatic Color Settings To ensure color settings stay consistent throughout production, the monitor includes a Sync Signal function which automatically adjusts the monitor's settings, such as input range and input color format, according to the video signal.

Adjusted at the Factory for Smooth Color Gradations The gamma level for each ColorEdge monitor is adjusted at the factory by measuring the R, G, and B gamma values from 0 - 255, then using the monitor's 16-bit look-up-table (LUT) to select the 256 most appropriate tones and achieve the desired value. This ensures the smoothest color gradations in your images.

Stable Color in Just 3 Minutes A typical monitor takes 30 minutes or more for its brightness, chromaticity, and tone characteristics to stabilize. It takes a mere 3 minutes. Whether you are working in a studio or taking the monitor with you on location, you get reliable color display soon after turning the monitor on.

Stable Display Using Industry-First AI The color and brightness of an LCD monitor can shift due to changes in ambient temperature and the temperature of the monitor itself. ColorEdge CG Series monitors are equipped with a temperature sensor for accurately measuring the temperature inside the monitor, as well as estimating the temperature of the surrounding environment.

With this temperature sensing and estimation technology, the monitor adjusts in real-time so gradations, color, brightness, and other characteristics continue to be displayed accurately. Furthermore, EIZO uses AI (artificial intelligence)* in the estimation algorithm of the CG2700S so it can distinguish between various temperature changing patterns to calculate even more accurate correction.

Uniformity Across the Screen LCD monitors commonly exhibit fluctuations in brightness and chromaticity across the screen, affecting color accuracy. To counter this, ColorEdge monitors are equipped with EIZO's patented digital uniformity equalizer (DUE) technology which corrects deviations in every tone across the screen to ensure stable display.

Punched Metal Design The ColorEdge CG2700S's sleek, new design incorporates punched metal on the back side that allows for more airflow, keeping the monitor cool without a noisy fan. A carrying handle on the back of the monitor allows you to easily move it to other locations.

Light Shielding Hood The ColorEdge CG2700X comes bundled with a light shielding hood that effectively prevents glare on the screen caused by ambient lighting. The hood is newly designed to be lightweight and easily attaches to the monitor magnetically without needing to connect separate parts.

Ergonomic Stand Adjust the screen to the most comfortable angle and reposition it to show your work to a colleague or client. The monitor comes with a versatile stand that offers height, tilt, and swivel adjustments. The stand is also equipped with a quick release that allows you to easily remove the screen from the stand with a single touch.

The Eizo CG2400S is a 24.1-inch ColorEdge monitor with a 1920 x 1200 WUXGA resolution and 16:10 aspect ratio, providing a spacious vertical workspace for photography, video editing, colour grading, graphics and print production. Its wide-gamut IPS panel displays 1.07 billion colours through 10-bit processing and a 16-bit LUT, with 99% Adobe RGB and 98% DCI-P3 coverage.

Key Features of Eizo CG2400S 24.1-inch IPS wide-gamut display
1920 x 1200 WUXGA resolution
16:10 aspect ratio
94 ppi pixel density
1.07 billion colours with 10-bit display
278 trillion colour tones with 16-bit LUT
400 cd/m² typical maximum brightness
1800:1 typical contrast ratio
Built-in calibration sensor
Digital Uniformity Equalizer
Brightness stabilization
WUXGA Resolution The 24.1-inch IPS display provides a native resolution of 1920 x 1200 pixels with a 16:10 aspect ratio. The additional vertical space compared with Full HD provides room for tool panels and other controls while keeping more of the working image visible.

Wide-Gamut Colour Reproduction The wide-gamut IPS panel covers 99% of the Adobe RGB colour space and 98% of DCI-P3. It also provides 100% coverage of Rec.709, EBU, SMPTE-C and sRGB, supporting accurate colour reproduction across photography, video and print workflows.

10-Bit Display and 16-Bit LUT The monitor supports 10-bit display with 1.07 billion colours and uses a 16-bit look-up table containing 278 trillion colour tones. This combination provides detailed colour processing and smooth transitions between subtle shades.

HDR Film Production HLG and PQ gamma modes support HDR video workflows, with preset modes for HDR content including PQ and HLG EOTF settings. The monitor provides a typical maximum brightness of 400 cd/m² and a typical contrast ratio of 1800:1.

Built-In Calibration Sensor The integrated calibration sensor allows automatic recalibration at scheduled intervals. Calibration can take place while the monitor is in use or while the connected computer is switched off, helping maintain consistent colour reproduction without requiring a separate calibration device for routine calibration.

USB Type-C Connectivity USB Type-C provides DisplayPort Alt Mode for video transmission, USB data connectivity and up to 70 W Power Delivery for a connected notebook or mobile device. A single cable can therefore carry the display signal, connect the USB hub and provide charging power.

DisplayPort and HDMI Alongside USB Type-C, the monitor provides DisplayPort and HDMI inputs for connection to computers and compatible video equipment. The interfaces support the monitor's WUXGA resolution and 10-bit display capability.

Digital Uniformity Equalizer The Digital Uniformity Equalizer helps maintain consistent brightness and colour characteristics across the panel. This supports accurate image evaluation when working across different areas of the screen.

Professional Colour Presets Preset modes include BT.2020, BT.709, DCI-P3, PQ_DCI-P3, HLG_BT.2100, Adobe RGB and sRGB. These modes provide convenient starting points for different colour spaces and HDR production requirements.

FograCert Softproof Monitor The monitor has received FograCert Softproof Monitor certification based on ISO 12646 requirements. This certification confirms its suitability for colour-critical softproofing applications in print-related workflows.

USB Hub The integrated USB hub provides two USB 5Gbps Type-A downstream ports and two USB 2.0 Type-A downstream ports. A USB Type-B upstream connection is also available alongside the USB Type-C upstream connection.

Factory Colour Adjustment Factory adjustment of colour characteristics provides consistent image reproduction from the outset. The monitor also supports hardware calibration for adjustment of brightness, white point and gamma characteristics.

Ergonomic Stand The stand provides 155 mm of height adjustment and 344° of swivel adjustment, along with tilt and pivot functions. A 100 x 100 mm VESA mounting pattern is also available for compatible mounting systems.

Recycled Materials The monitor housing contains more than 85% recycled plastic. Its packaging uses molded pulp made from recycled cardboard and newspaper, while the included cables are packaged without plastic bags.

Light-Shielding Hood A light-shielding hood is included to help reduce reflections and the effect of surrounding light on the screen during colour-critical work. This is particularly useful in controlled photography, editing and print environments.

Professional Applications The monitor is suitable for photography, image editing and retouching, video editing, post-production and colour grading, design, illustration, printing, fine art printing, and textile and fashion workflows.

The Eizo CS2400R is a 24.1-inch ColorEdge monitor with a 1920 x 1200 WUXGA resolution and 16:10 aspect ratio, providing a practical workspace for photography, image editing, retouching, design, creation and illustration. Its IPS panel supports 10-bit display from a 16-bit LUT with 278 trillion colour tones and provides 100% sRGB coverage for accurate colour reproduction.

Key Features of Eizo CS2400R 1920 x 1200 WUXGA resolution
16:10 aspect ratio
94 ppi pixel density
1.07 billion colours with 10-bit display
278 trillion colour tones with 16-bit LUT
300 cd/m² typical maximum brightness
1000:1 typical contrast ratio
14 ms typical grey-to-grey response time
DisplayPort and HDMI inputs
Two USB 5Gbps downstream ports
Two USB 2.0 downstream ports
Hardware calibration support
Digital Uniformity Equalizer
Gamut Clipping function
WUXGA Resolution The 24.1-inch IPS panel provides a native resolution of 1920 x 1200 pixels with a 16:10 aspect ratio. The additional vertical workspace compared with a 16:9 Full HD display provides more room for image-editing tools, palettes and application controls while keeping the working area visible.

Accurate sRGB Colour Reproduction The monitor covers 100% of the sRGB and Rec.709 colour spaces, providing accurate colour reproduction for photography, image editing, retouching, design and illustration. Its colour characteristics are suited to workflows where consistent colour representation is important.

10-Bit Display and 16-Bit LUT The display supports 10-bit colour with 1.07 billion colours and uses a 16-bit look-up table containing 278 trillion colour tones. This high-resolution colour processing provides smooth gradations and detailed transitions between shades.

USB Type-C Connectivity USB Type-C supports DisplayPort Alt Mode for video transmission, USB data communication and up to 70 W Power Delivery. A compatible notebook can therefore use a single cable for the display signal, USB hub connection and charging.

DisplayPort and HDMI DisplayPort and HDMI inputs provide additional options for connecting computers and compatible video sources. Both digital interfaces support 10-bit display, allowing the monitor to reproduce its full colour depth when paired with suitable source hardware and software.

Hardware Calibration The monitor supports hardware calibration for adjusting brightness, white point and gamma characteristics. ColorNavigator software can be used for regular recalibration and for creating individual calibration targets according to the requirements of the workflow.

Factory Calibration Report Each monitor is supplied with an individual calibration report documenting its factory calibration. This provides recorded colour measurements for the individual display and supports consistent setup for colour-sensitive applications.

Digital Uniformity Equalizer The Digital Uniformity Equalizer helps maintain consistent brightness and colour characteristics across the display area. This is useful when evaluating images where uniform reproduction from one part of the screen to another is important.

Gamut Clipping The Gamut Clipping function provides control over how colours outside the selected colour space are displayed. This gives users an additional method for checking colour reproduction when working with images intended for specific output conditions.

USB Hub The integrated USB hub provides two USB 5Gbps downstream ports and two USB 2.0 downstream ports for compatible peripherals. The monitor can therefore act as a central connection point for accessories attached to the workstation.

Wide Viewing Angles The IPS panel provides typical horizontal and vertical viewing angles of 178 degrees. This allows images to remain clearly visible when viewed away from the centre of the screen.

Automatic Signal Recognition Automatic signal input recognition detects connected video sources and selects the appropriate input. The monitor also provides adjustment options for colour temperature, gamma, colour tone, saturation, input range and other display characteristics.

Ergonomic Stand The stand provides 155 mm of height adjustment, 344 degrees of swivel and 90 degrees of pivot adjustment. Tilt adjustment is also available, while the 100 x 100 mm VESA mounting pattern provides compatibility with suitable mounting systems.

The Eizo CS2731 is a 27-inch ColorEdge monitor with a 2560 x 1440 Quad HD resolution and 16:9 aspect ratio, providing a detailed workspace for photography, video, graphics, image editing, retouching, design, creation and illustration. Its IPS wide-gamut panel displays up to 1.07 billion colours from a 16-bit look-up table containing 278 trillion colour tones, with more than 99% Adobe RGB, more than 95% DCI-P3 and 100% sRGB coverage. USB Type-C connectivity supports DisplayPort Alt Mode, USB data and up to 60 W Power Delivery, while DisplayPort, HDMI and DVI-D inputs provide flexible connection options.

Key Features of Eizo CS2731 2560 x 1440 Quad HD resolution
16:9 aspect ratio
109 ppi pixel density
1.07 billion colours with 10-bit display
278 trillion colour tones with 16-bit look-up table
100% sRGB coverage
350 cd/m² typical brightness
1000:1 typical contrast ratio
10 ms typical grey-to-grey response time
DisplayPort, HDMI and DVI-D inputs
Four USB downstream ports: two USB 5Gbps and two USB 2.0
Hardware calibration for brightness and luminance characteristics
Digital Uniformity Equalizer for homogeneity correction
Gamut Clipping and automatic signal input recognition
Quad HD Resolution The 2560 x 1440 resolution provides a detailed working area across the 27-inch screen. With a 16:9 aspect ratio and 109 ppi pixel density, the monitor provides space for detailed images, editing tools and creative applications.

Wide-Gamut Colour Reproduction The IPS wide-gamut panel covers more than 99% of the Adobe RGB colour space, more than 95% of DCI-P3 and 100% of sRGB. These colour spaces make the monitor suitable for photography, image editing, video and graphics work where accurate colour representation is important.

10-Bit Display and 16-Bit LUT The display can reproduce approximately 1.07 billion colours through a 10-bit signal, while its 16-bit look-up table provides a palette of 278 trillion colour tones. This allows subtle gradations to be represented across images and other visual content.

USB Type-C Connectivity The USB Type-C connection supports DisplayPort Alt Mode for video transmission, USB communication and up to 60 W Power Delivery. This allows compatible notebooks and other devices to connect to the monitor while receiving power through the same connection.

Multiple Video Inputs DisplayPort, HDMI and DVI-D inputs provide several connection options for computers and other video sources. The monitor supports digital video signals across its range of input interfaces.

Hardware Calibration Hardware calibration provides control over brightness and luminance characteristics directly within the monitor. Adobe RGB and sRGB preset modes are available, with additional memory spaces available through calibration.

Digital Uniformity Equalizer The Digital Uniformity Equalizer provides homogeneity correction across the screen. This helps maintain consistent image presentation over the display area for colour-focused workflows.

USB Hub The integrated USB hub provides two USB 5Gbps Type-A ports and two USB 2.0 Type-A ports. These connections allow compatible peripherals and accessories to be connected directly through the monitor.

Gamut Clipping Gamut Clipping is included among the monitor's colour management functions. Automatic signal input recognition also detects connected video sources and selects the appropriate input.

Ergonomic Stand The adjustable stand provides 155 mm of height adjustment, 344° of swivel and forward or backward tilt adjustment. The screen can also rotate into portrait orientation, while 100 x 100 mm VESA mounting support allows alternative mounting arrangements.

Creative Workflows The monitor is suited to photography, video and graphics applications, including image editing, retouching, design, creation, illustration and textile or fashion work. Its wide colour gamut, calibration functions and detailed Quad HD resolution support colour-focused creative tasks.

The Eizo FLT-BK is a 23.8-inch FlexScan monitor with a 1920 x 1080 Full HD resolution and 16:9 aspect ratio, providing a practical display for office and professional working environments. Its IPS panel delivers 16.77 million colours, 250 cd/m² typical brightness, a 1000:1 contrast ratio and 178° viewing angles. USB Type-C connectivity provides DisplayPort Alt Mode, USB data and up to 60 W Power Delivery, while the integrated arm offers flexible positioning and contributes to the monitor's compact footprint.

Key Features of Eizo FLT-BK 1920 x 1080 Full HD resolution
16:9 aspect ratio
16.77 million colours with 8-bit display
250 cd/m² typical brightness
1000:1 typical contrast ratio
5 ms typical grey-to-grey response time
178° horizontal and vertical viewing angles
USB Type-C DisplayPort Alt Mode input
USB Type-C docking with up to 60 W Power Delivery
USB 5Gbps Type-C downstream connection with up to 15 W output
sRGB, Eco, Paper, Movie and DICOM preset modes
Auto EcoView automatic brightness adjustment
Full HD Display The 1920 x 1080 Full HD resolution provides a 16:9 workspace suited to everyday office applications, documents, web content and general computer use. The 23.8-inch screen provides a viewable image area of 527 x 296.5 mm.

IPS Panel The IPS panel provides 178° horizontal and vertical viewing angles, allowing content to remain clearly visible from different positions in front of the screen. With 16.77 million colours and 250 cd/m² typical brightness, it provides a clear display for office applications.

USB Type-C Docking The USB Type-C connection combines DisplayPort Alt Mode video transmission with USB connectivity and up to 60 W Power Delivery. A compatible notebook can connect to the monitor through a single cable for display, data and charging.

USB Connectivity The monitor provides a USB 5Gbps Type-C downstream connection capable of supplying up to 15 W. This allows compatible peripherals and mobile devices to be connected directly to the display.

Flexible Monitor Arm The black FLT-BK model includes an integrated arm that allows the screen to be positioned for different working arrangements. The stand supports 180° rotation and 40° forward and backward tilt, providing flexibility when arranging the display.

Low Power Consumption The monitor has a typical power consumption of only 6 W, while power consumption in power save mode is 0.27 W. Its Eco preset combines automatic brightness adjustment with additional power-saving functions for lower energy use during everyday operation.

Preset Display Modes Preset modes include sRGB, Eco, Paper, Movie and DICOM, alongside two manually stored user settings. These modes allow the display characteristics to be changed according to the type of content being viewed.

Automatic Brightness Control Auto EcoView uses ambient light information to adjust screen brightness automatically. This helps maintain a comfortable viewing level as lighting conditions around the workstation change.

Compact Construction The monitor has a slim display profile measuring 24.4 mm in depth without the stand and weighs 2.4 kg without the stand. Its lightweight construction makes it suitable for modern workspaces where desk space and equipment weight are important considerations.

VESA Mounting The display supports a 100 x 100 mm VESA mounting pattern when used with the optional adapter plate. This provides an alternative mounting option for compatible monitor arms and brackets.

The Eizo EV2490-BK is a 23.8-inch FlexScan monitor with a 1920 x 1080 Full HD resolution and 16:9 aspect ratio, providing a practical display for office work, home working and professional applications. Its IPS panel delivers 16.7 million colours, 250 cd/m² typical brightness, a 1000:1 contrast ratio and 178° horizontal and vertical viewing angles. USB Type-C connectivity combines DisplayPort video, USB data and up to 70 W Power Delivery, while the integrated LAN connection and KVM functionality allow the monitor to serve as a central workstation hub.

Key Features of Eizo EV2490-BK 1920 x 1080 Full HD resolution
16:9 aspect ratio
93 ppi pixel density
16.7 million colours with 8-bit display
1.06 billion colour tones with 10-bit look-up table
250 cd/m² typical brightness
5 ms typical grey-to-grey response time
USB Type-C DisplayPort Alt Mode input
USB 5Gbps connectivity
Three USB Type-A and one USB Type-C downstream ports
DisplayPort and HDMI inputs
RJ-45 network connection
Integrated KVM switch
USB-C daisy-chain support for multi-monitor setups
Built-in speakers
Automatic signal input recognition
Auto EcoView and EcoView functions
Full HD IPS Display The 1920 x 1080 Full HD resolution provides a 16:9 workspace for documents, applications, web content and general office tasks. The IPS panel maintains consistent image presentation across a broad 178° horizontal and vertical viewing range.

USB Type-C Docking USB Type-C provides DisplayPort Alt Mode video, USB data and up to 70 W Power Delivery through a single connection. A compatible laptop can therefore connect to the display while receiving power and accessing connected peripherals.

Network Connectivity The integrated RJ-45 connection allows compatible computers connected through USB-C to access a wired network through the monitor. This reduces the number of separate connections required at the workstation.

Integrated KVM Switch The built-in KVM switch allows connected computers to share the monitor's USB peripherals. This is useful for workstations where users need to switch between multiple computers while retaining access to connected keyboard, mouse and other USB devices.

Daisy-Chain Support The USB-C ports support daisy chaining, allowing multiple compatible monitors to be connected from a computer using a single upstream connection. This can help reduce cable clutter in multi-display workstations.

USB Hub The monitor includes three USB Type-A downstream ports and one USB Type-C downstream port using USB 5Gbps connectivity. The USB Type-C downstream port can also provide up to 15 W of charging power for compatible devices.

Built-In Speakers Integrated speakers provide audio output directly from the monitor, while a 3.5 mm stereo headphone output is available for private listening. Audio can be received through the USB-C, DisplayPort or HDMI connections.

Preset Display Modes The monitor includes sRGB, Paper, Movie and DICOM preset modes, together with two manual memory locations. These modes allow the display characteristics to be adjusted according to different types of content and working requirements.

Auto EcoView Auto EcoView adjusts screen brightness according to the ambient lighting conditions around the monitor. EcoView functions also provide controls for managing power consumption during everyday operation.

Ergonomic Stand The adjustable stand provides 191.2 mm of height adjustment, 344° of swivel and tilt from 5° forwards to 35° backwards. The display can also pivot between portrait and landscape orientations, allowing the screen position to be adapted to different workstations.

VESA Mounting A 100 x 100 mm VESA mounting pattern provides compatibility with suitable monitor arms and mounting brackets. This allows the display to be positioned using alternative mounting equipment where required.

Office and Home Working The monitor is suitable for office environments, home offices, finance applications and general professional computing. Its USB-C docking, network connection, KVM switch and multiple USB ports provide a central connection point for compatible workstations.

The Eizo EV2490-WT is a 23.8-inch FlexScan monitor with a 1920 x 1080 Full HD resolution and 16:9 aspect ratio, providing a practical display for office work, home working and professional applications. Its IPS panel supports 16.7 million colours, 250 cd/m² typical brightness, a 1000:1 contrast ratio and 178° horizontal and vertical viewing angles. USB Type-C connectivity combines DisplayPort video, USB data and up to 70 W Power Delivery, while the integrated RJ-45 connection, KVM switch and USB hub provide a central connection point for compatible workstations. The white finish gives the monitor a light appearance suitable for a range of office environments.

Key Features of Eizo EV2490-WT 1920 x 1080 Full HD resolution
16:9 aspect ratio
93 ppi pixel density
16.7 million colours with 8-bit display
1.06 billion colour tones with 10-bit look-up table
1000:1 typical contrast ratio
5 ms typical grey-to-grey response time
USB Type-C with DisplayPort Alt Mode
USB 5Gbps connectivity
DisplayPort and HDMI inputs
USB-C output for daisy-chain connections
RJ-45 network connection
Integrated KVM switch
Built-in speakers
3.5 mm stereo headphone output
Automatic signal input recognition
Auto EcoView and EcoView Index
Full HD IPS Display The 1920 x 1080 Full HD resolution provides a 16:9 workspace for documents, applications, web content and general office tasks. The IPS panel provides consistent image presentation across a broad 178° horizontal and vertical viewing range.

USB Type-C Docking The USB Type-C connection supports DisplayPort Alt Mode, USB communication and up to 70 W Power Delivery. A compatible laptop can connect to the monitor through one cable while receiving power and accessing connected USB peripherals.

Network Connection The integrated RJ-45 connection provides wired network access for a compatible computer connected through the monitor. This allows the display to act as a convenient connection point for workstations using USB-C docking.

Integrated KVM Switch The built-in KVM switch allows compatible computers to share connected USB peripherals through the monitor. This makes it possible to switch between computers while retaining access to a connected keyboard, mouse and other USB devices.

Daisy-Chain Connectivity The USB Type-C output supports daisy-chain connections for compatible multi-monitor configurations. This can simplify cabling when several displays are used together in a workstation.

USB Hub The integrated USB hub provides three USB Type-A downstream ports and one USB Type-C downstream port using USB 5Gbps connectivity. The USB Type-C downstream connection can provide up to 15 W of power to compatible devices.

Built-In Speakers Integrated speakers provide audio playback directly from the monitor, while the 3.5 mm stereo headphone output provides a connection for headphones or other compatible audio equipment. Audio can be supplied through USB-C, DisplayPort or HDMI.

Preset Display Modes The monitor includes sRGB, Paper, Movie and DICOM preset modes, along with two manual memory locations. These modes provide different display settings for various types of content and working environments.

Auto EcoView Auto EcoView automatically adjusts screen brightness according to ambient lighting conditions. EcoView functions also provide controls for managing display power consumption during everyday use.

Ergonomic Stand The stand provides 191.2 mm of height adjustment, 344° of swivel and tilt from 5° forwards to 35° backwards. The display can also pivot between portrait and landscape orientations for different working positions.

VESA Mounting The 100 x 100 mm VESA mounting pattern supports compatible monitor arms and brackets. This provides an alternative mounting option for workstations requiring a different display position.

Office and Home Working The monitor is suitable for office environments, home offices, finance applications and general professional computing. USB-C docking, wired networking, KVM functionality, multiple USB ports and daisy-chain support provide useful connectivity for modern workstations.

The Eizo EV2740X-BK is a 27-inch FlexScan monitor with a 3840 x 2160 4K UHD resolution and 16:9 aspect ratio, providing a detailed workspace for office applications, CAD, video surveillance, finance and other professional tasks. Its IPS panel offers 163 ppi, 350 cd/m² typical brightness, a 2000:1 typical contrast ratio and 178° viewing angles, with 100% sRGB coverage for consistent colour reproduction.

Key Features of Eizo EV2740X-BK 16:9 aspect ratio with 163 ppi pixel density
16.7 million displayed colours
More than 1.06 billion colour tones with 14-bit look-up table
100% sRGB colour space coverage
350 cd/m² typical brightness
2000:1 typical contrast ratio
5 ms grey-to-grey response time
USB Type-C with DisplayPort Alt Mode
DisplayPort input with HDCP 1.3/2.3
Two HDMI inputs with HDCP 1.4/2.3
Integrated RJ-45 Gigabit Ethernet connection
Picture-by-Picture functionality
Built-in 2.0 W + 2.0 W stereo speakers
Auto EcoView and EcoView Index functions
Flicker-free viewing
DICOM tone curve support
Automatic signal input recognition
4K UHD Resolution The 3840 x 2160 4K UHD resolution provides four times the pixel count of Full HD, giving applications, text and graphics a high level of detail across the 27-inch screen. The 163 ppi pixel density helps produce fine text and clearly defined visual content, making the monitor suitable for office work, CAD, video applications and other detailed workloads.

IPS Display Panel The IPS panel provides 178° horizontal and vertical viewing angles, allowing content to remain consistent when viewed away from the centre of the screen. With 350 cd/m² typical brightness, a 2000:1 typical contrast ratio and 100% sRGB coverage, the display provides clear images and consistent colour for everyday professional use.

USB Type-C Docking The USB Type-C connection carries DisplayPort video and USB data while providing up to 94 W of Power Delivery to a compatible computer. This allows a single cable connection to handle display output, data communication and notebook charging from the monitor.

Network Connectivity An integrated RJ-45 connection provides Gigabit Ethernet connectivity through the monitor. The network interface supports 10BASE-T, 100BASE-TX and 1000BASE-T standards, allowing a compatible computer connected through USB Type-C to access a wired network through the display.

Integrated KVM Switch The integrated KVM switch allows connected computers to share the monitor's keyboard and mouse peripherals. This provides a convenient way to work between multiple systems while using the same display and USB-connected input devices.

Picture-by-Picture Picture-by-Picture functionality allows content from different signal sources to be displayed simultaneously. This can be useful when comparing information from two connected computers or working with multiple sources on the same screen.

USB Hub and Connections The monitor provides USB 5Gbps connectivity through three USB Type-A downstream ports and one USB Type-C downstream port. The Type-C downstream connection also supports up to 15 W charging, while DisplayPort, two HDMI inputs and USB Type-C provide several options for connecting computers and other equipment.

Audio and Speakers Audio can be received through USB Type-C, DisplayPort or HDMI connections. The monitor includes built-in stereo speakers rated at 2 W per channel, along with separate 3.5 mm stereo headphone and line-out connections.

Display Presets and Viewing Functions Preset modes include sRGB, Paper, Movie and DICOM, alongside two manual memory locations. Auto EcoView, EcoView Index, Overdrive, automatic input recognition and flicker-free operation provide additional display and viewing controls for different working conditions.

Ergonomic FlexStand The FlexStand provides 195 mm of height adjustment, 90° swivel movement, clockwise pivot rotation and tilt from 5° forwards to 35° backwards. These adjustment options allow the screen position to be changed for different desk setups and viewing preferences.

VESA Mounting The monitor supports a 100 x 100 mm VESA mounting pattern, providing compatibility with suitable monitor arms, wall mounts and other mounting systems. The stand can also be removed when an alternative mounting method is required.

The Eizo EV2740X-WT is a 27-inch FlexScan monitor with a 3840 x 2160 4K UHD resolution and 16:9 aspect ratio, providing a detailed workspace for office applications, CAD, finance, video surveillance and control room tasks. Its IPS panel offers 163 ppi, 350 cd/m² typical brightness, a 2000:1 typical contrast ratio and 178° horizontal and vertical viewing angles.

USB Type-C supports DisplayPort Alt Mode, USB data and up to 94 W Power Delivery, while DisplayPort and two HDMI inputs provide additional connectivity. Integrated RJ-45 networking, a KVM switch, USB hub and Picture-by-Picture functionality allow the monitor to support a streamlined workstation setup, while the white finish provides an alternative appearance for professional and home working environments.

Key Features of Eizo EV2740X-WT 163 ppi pixel density
16.7 million colours with 8-bit signal input
More than 1.06 billion colour tones with 14-bit LUT
2000:1 typical contrast ratio
5 ms typical grey-to-grey response time
USB Type-C docking with DisplayPort Alt Mode
DisplayPort input with HDCP 1.3/2.3
Two HDMI inputs with HDCP 1.4/2.3
USB 5Gbps hub
Three USB Type-A downstream ports
One USB Type-C downstream port with 15 W charging
Integrated RJ-45 Gigabit Ethernet
Integrated KVM switch
Picture-by-Picture functionality
Built-in 2 W + 2 W stereo speakers
Auto EcoView and EcoView Index
Flicker-free operation
Automatic signal input recognition
4K UHD Resolution The 3840 x 2160 4K UHD resolution provides four times the pixel count of Full HD, allowing more information to be displayed across the 27-inch screen. With a 163 ppi pixel density, text, graphics and application interfaces can appear highly detailed, making the monitor suitable for office work, CAD, video applications and other tasks requiring a large amount of on-screen information.

IPS Panel The IPS panel provides 178° horizontal and vertical viewing angles for consistent image visibility across the screen. A typical brightness of 350 cd/m² and 2000:1 contrast ratio provide clear presentation of text, graphics and images, while the sRGB colour space supports consistent colour reproduction for everyday professional applications.

USB Type-C Docking The USB Type-C connection combines DisplayPort video transmission and USB data with up to 94 W of Power Delivery. A compatible notebook can therefore connect to the monitor using a single cable for display output, peripheral communication and charging.

Network Connectivity An integrated RJ-45 port provides Gigabit Ethernet connectivity through the monitor. The network interface supports 10BASE-T, 100BASE-TX and 1000BASE-T, allowing a compatible computer connected through the monitor to use a wired network connection.

Integrated KVM Switch The integrated KVM switch allows compatible computers to share connected keyboard and mouse peripherals. This makes it possible to move between systems while retaining the same monitor and USB-connected input devices.

Picture-by-Picture Picture-by-Picture functionality allows signals from different sources to be displayed simultaneously on the screen. This can be useful for comparing information from two computers or monitoring separate sources without repeatedly changing inputs.

USB Hub and Connections The monitor includes a USB 5Gbps hub with three USB Type-A downstream ports and one USB Type-C downstream port. The USB Type-C downstream connection provides up to 15 W charging, while the display accepts video through USB Type-C, DisplayPort and two HDMI inputs.

Audio and Speakers Audio signals can be received through USB Type-C, DisplayPort and HDMI connections. Built-in stereo speakers provide 2 W per channel, while two 3.5 mm stereo jacks provide separate headphone and line-out connections.

Display Modes and Viewing Functions The monitor provides sRGB, Paper, Movie and DICOM preset modes alongside two manual memory locations. DICOM tone curve support, Auto EcoView, EcoView Index, Overdrive, automatic signal recognition and flicker-free operation provide additional controls for different viewing requirements.

Ergonomic FlexStand The FlexStand provides 195 mm of height adjustment, 90° swivel movement, clockwise pivot rotation and tilt from 5° forwards to 35° backwards. These adjustment options allow the display to be positioned according to the user's desk arrangement and viewing preference.

VESA Mounting A 100 x 100 mm VESA mounting pattern provides compatibility with suitable monitor arms, wall mounts and other mounting systems. The stand can be removed when an alternative mounting arrangement is required.

The Eizo EV3240X-BK is a 31.5-inch FlexScan monitor with a 3840 x 2160 4K UHD resolution and 16:9 aspect ratio, providing a spacious workspace for office applications, CAD, finance, video surveillance and control room environments. Its IPS panel delivers 140 ppi, 350 cd/m² typical brightness, a 2000:1 typical contrast ratio and 178° horizontal and vertical viewing angles.

USB Type-C connectivity supports DisplayPort Alt Mode, USB data and up to 94 W Power Delivery, while DisplayPort and two HDMI inputs provide additional display connections. Integrated Gigabit Ethernet, a KVM switch, USB hub and Picture-by-Picture and Picture-in-Picture functions allow the monitor to accommodate a wide range of workstation setups.

Key Features of Eizo EV3240X-BK 16.7 million displayed colours
More than 1.06 billion colour tones with 14-bit look-up table
sRGB colour space
2000:1 typical contrast ratio
5 ms typical grey-to-grey response time
USB Type-C with DisplayPort Alt Mode
Two HDMI inputs
USB 5Gbps hub
Three USB Type-A downstream ports
One USB Type-C downstream port with 15 W charging
Integrated RJ-45 Gigabit Ethernet
Integrated KVM switch
Picture-by-Picture functionality
Built-in 2 W + 2 W stereo speakers
Auto EcoView and EcoView Index
Overdrive function
Flicker-free operation
Automatic signal input recognition
4K UHD Resolution The 3840 x 2160 4K UHD resolution provides four times the pixel count of Full HD, giving users a large area for displaying applications, documents and other content simultaneously. With 140 ppi across the 31.5-inch panel, text, icons and graphics are presented with a high level of detail for office, CAD and video applications.

IPS Display Panel The IPS panel provides 178° horizontal and vertical viewing angles, helping maintain consistent image visibility across the wide screen. A typical brightness of 350 cd/m² and 2000:1 contrast ratio provide clear text, graphics and images, while the sRGB colour space supports consistent colour presentation.

USB Type-C Docking The USB Type-C connection combines DisplayPort video, USB data and Power Delivery of up to 94 W. A compatible notebook can connect to the monitor with a single cable for display output, peripheral communication and charging.

Gigabit Ethernet An integrated RJ-45 connection provides 1000BASE-T Gigabit Ethernet through the monitor. When a compatible computer is connected through USB Type-C, the network connection can provide wired Ethernet access without requiring a separate network adapter at the workstation.

KVM Switch The integrated KVM switch allows compatible computers to share connected USB keyboard and mouse peripherals. This makes it possible to move between systems while retaining the same display and input devices.

Picture-by-Picture and Picture-in-Picture Picture-by-Picture and Picture-in-Picture functions allow content from multiple connected sources to be viewed at the same time. These modes can be useful for comparing information, monitoring different systems or working with separate computers from one display.

USB Hub and Connectivity The USB hub provides USB 5Gbps connectivity through three USB Type-A downstream ports and one USB Type-C downstream port. The Type-C downstream connection supports up to 15 W charging, while the monitor accepts video signals through USB Type-C, DisplayPort and two HDMI inputs.

Audio and Speakers Audio can be received through USB Type-C, DisplayPort and HDMI connections. Integrated stereo speakers provide 2 W per channel, while separate 3.5 mm stereo connections are available for headphones and line-out audio.

Display Presets and Viewing Functions The monitor provides User1, User2, sRGB, Paper, Movie and DICOM preset modes. DICOM tone curve support, Auto EcoView, EcoView Index, Overdrive, automatic signal input recognition and flicker-free operation provide additional display controls for different working conditions.

Ergonomic FlexStand The FlexStand provides 195 mm of height adjustment, 90° swivel movement, 90° clockwise pivot rotation and tilt from 5° forwards to 35° backwards. These adjustments allow the display to be positioned for different desk layouts and viewing preferences.

VESA Mounting A 100 x 100 mm VESA mounting pattern provides compatibility with suitable monitor arms, wall mounts and other mounting systems. The FlexStand is removable when an alternative mounting arrangement is required.

The Eizo EV3450XC-BK is a 34.1-inch FlexScan ultrawide monitor with a 3440 x 1440 UWQHD resolution, 21:9 aspect ratio and 3800 mm curvature radius. Its IPS panel provides 109 ppi, 300 cd/m² typical brightness, a 1000:1 typical contrast ratio and 178° horizontal and vertical viewing angles. USB Type-C docking supports DisplayPort Alt Mode, USB data and up to 94 W Power Delivery, while DisplayPort and two HDMI inputs provide flexible connectivity.

The monitor also incorporates a 5-megapixel webcam with Windows Hello support, an integrated microphone with active noise cancellation, Gigabit Ethernet, a KVM switch, Picture-by-Picture functionality and stereo speakers, making it suitable for office work, home working, CAD, finance and video conferencing.

Key Features of Eizo EV3450XC-BK 3800 mm screen curvature radius
16.7 million displayed colours
More than 1.06 billion colour tones with 14-bit LUT
sRGB colour space
USB Type-C docking with DisplayPort Alt Mode
DisplayPort input
Two HDMI inputs
USB 5Gbps hub
Two USB Type-A downstream ports
One USB Type-C downstream port with 15 W charging
Integrated RJ-45 Gigabit Ethernet
Integrated KVM switch
5-megapixel integrated webcam
Privacy shutter for webcam
Built-in microphone with active noise cancellation
Picture-by-Picture functionality
Ultrawide UWQHD Display The 3440 x 1440 UWQHD resolution provides a broad working area across the 21:9 screen. The ultrawide format allows multiple application windows to be positioned side by side, providing a practical workspace for documents, spreadsheets, communications and other professional applications.

Curved IPS Panel The IPS panel features a 3800 mm curvature radius that brings the outer areas of the ultrawide screen closer to the user's field of view. With 178° horizontal and vertical viewing angles, 300 cd/m² typical brightness and a 1000:1 typical contrast ratio, the display provides clear and consistent viewing across the screen.

USB Type-C Docking The USB Type-C connection carries DisplayPort video and USB data while providing up to 94 W of Power Delivery. A compatible notebook can use one cable for display output, peripheral connectivity and charging, helping reduce the number of cables required at the workstation.

Integrated Webcam The built-in 5-megapixel webcam provides video for online meetings and collaboration. It features an approximately 80° viewing angle, a physical privacy shutter, status LED and an integrated IR sensor that supports Windows Hello-compatible authentication.

Noise-Cancelling Microphone The frame-integrated microphone uses active noise cancellation to help reduce unwanted background sounds during video calls. Combined with the integrated webcam and speakers, it provides a convenient setup for web meetings without requiring separate desktop video and audio equipment.

Gigabit Ethernet The integrated RJ-45 connection provides 1000BASE-T Gigabit Ethernet through the monitor. A compatible computer connected through USB Type-C can use the monitor as a wired network connection, providing an additional workstation connectivity option.

KVM Switch The integrated KVM switch allows compatible computers to share connected keyboard and mouse peripherals. This enables users to operate multiple systems while retaining the same monitor and USB-connected input devices.

Picture-by-Picture Picture-by-Picture functionality allows two video signals to be displayed simultaneously. Three predefined layouts provide different arrangements for viewing content from separate computers or signal sources on the same ultrawide screen.

USB Hub and Connections The USB 5Gbps hub includes two USB Type-A downstream ports and one USB Type-C downstream port with up to 15 W charging. Display inputs consist of USB Type-C, DisplayPort and two HDMI connections, providing several options for computers and other video sources.

Audio and Stereo Speakers The monitor receives audio through USB Type-C, DisplayPort and HDMI connections. Two integrated 4 W speakers provide stereo sound, while a 3.5 mm stereo headphone output is available for private listening.

Display Modes and Eye Care The display provides User1, User2, sRGB, Paper, Movie and DICOM preset modes. Auto EcoView automatically adjusts brightness according to ambient lighting, while EcoView Index, EcoView Optimizer, Overdrive and flicker-free operation provide additional viewing controls.

Ergonomic FlexStand The FlexStand provides 195 mm of height adjustment, 90° swivel movement and tilt from 5° forwards to 35° backwards. These adjustment options allow the ultrawide display to be positioned according to the user's desk layout and preferred viewing position.

VESA Mounting The monitor supports a 100 x 100 mm VESA mounting pattern for compatible monitor arms and mounting systems. The FlexStand can be removed when an alternative mounting arrangement is required.

The Eizo EV3450XC-WT is a 34.1-inch FlexScan ultrawide monitor with a 3440 x 1440 UWQHD resolution and 21:9 aspect ratio, providing a broad workspace for office applications, CAD, finance, home working and professional multitasking. Its curved IPS panel has a 3800 mm bending radius, 109 ppi pixel density, 300 cd/m² typical brightness, a 1000:1 typical contrast ratio and 178° horizontal and vertical viewing angles.

Key Features of Eizo EV3450XC-WT 3800 mm screen bending radius
109 ppi pixel density
16.7 million colours with 8-bit signal input
More than 1.06 billion colour tones with 14-bit LUT
USB Type-C docking with DisplayPort Alt Mode
DisplayPort input with HDCP 1.3/2.3
Two HDMI inputs with HDCP 1.4/2.3
USB 5Gbps hub
Two USB Type-A downstream ports
One USB Type-C downstream port with 15 W charging
Integrated RJ-45 Gigabit Ethernet
Integrated KVM switch
5-megapixel integrated webcam
Webcam privacy shutter and status LED
Picture-by-Picture functionality
UWQHD Ultrawide Display The 3440 x 1440 UWQHD resolution provides a wide working area across the 21:9 display. The ultrawide format allows multiple application windows to be arranged side by side, giving users room to work with documents, spreadsheets, communications and other content without relying on a second monitor.

Curved IPS Panel The IPS panel uses a 3800 mm bending radius to provide a curved viewing surface across the 34.1-inch screen. The 178° horizontal and vertical viewing angles help maintain consistent visibility, while 300 cd/m² typical brightness and a 1000:1 typical contrast ratio provide clear presentation of text, graphics and images.

USB Type-C Docking The USB Type-C connection carries DisplayPort video and USB data while providing up to 94 W of Power Delivery. A compatible notebook can use a single cable for display output, peripheral connectivity and charging, reducing the number of separate connections required at the workstation.

Integrated Webcam The built-in 5-megapixel webcam provides video for online meetings and collaboration. It has an approximately 80° viewing angle, privacy shutter and status LED, while the integrated IR sensor supports Windows Hello-compatible authentication.

Noise-Cancelling Microphone The frame-integrated microphone uses active noise cancelling to help reduce unwanted background sounds during video calls. Together with the integrated webcam and speakers, it provides a convenient audio and video setup for online meetings and remote collaboration.

Gigabit Ethernet The integrated RJ-45 connection provides 1000BASE-T Gigabit Ethernet through the monitor. A compatible computer connected through USB Type-C can use the display as a wired network connection, adding network access to the monitor's docking functions.

Integrated KVM Switch The integrated KVM switch allows compatible computers to share connected keyboard and mouse peripherals. This makes it possible to operate multiple systems while using the same display and USB-connected input devices.

Picture-by-Picture Picture-by-Picture functionality allows content from separate signal sources to be displayed simultaneously. Three predefined layouts provide different arrangements for viewing information from multiple computers or video sources on the same ultrawide screen.

USB Hub and Connections The USB 5Gbps hub provides two USB Type-A downstream ports and one USB Type-C downstream port with up to 15 W charging. Video inputs include USB Type-C, DisplayPort and two HDMI connections, giving the monitor several options for connecting computers and other devices.

Audio and Stereo Speakers Audio can be received through USB Type-C, DisplayPort and HDMI connections. Two integrated 4 W speakers provide stereo audio, while a 3.5 mm stereo jack provides an option for connecting headphones.

Display Modes and Eye Care The monitor provides two manual memory locations together with sRGB, Paper, Movie and DICOM preset modes. DICOM tone curve support, Auto EcoView, EcoView Index, EcoView Optimizer, Overdrive and flicker-free operation provide additional controls for different viewing conditions.

Ergonomic FlexStand The FlexStand provides 195 mm of height adjustment, 90° swivel movement and tilt from 5° forwards to 35° backwards. These adjustments allow the ultrawide display to be positioned according to the user's desk arrangement and preferred viewing position.

VESA Mounting The monitor supports a 100 x 100 mm VESA mounting pattern for compatible monitor arms and mounting systems. The FlexStand can be removed when an alternative mounting arrangement is required.

White Finish The white cabinet and stand provide an alternative finish for office workstations, home offices, CAD environments, finance departments and other professional settings. The matching white finish gives the monitor a consistent appearance across the cabinet and stand.

The Eizo EV4340X-WT is a 42.5-inch FlexScan monitor with a 3840 x 2160 4K UHD resolution and 16:9 aspect ratio, providing a spacious viewing area for control rooms, trading environments, CAD, finance, video surveillance and professional multitasking. Its IPS panel delivers 16.77 million colours, 104 ppi pixel density, 350 cd/m² typical brightness, a 1000:1 contrast ratio and 178° horizontal and vertical viewing angles. Integrated LAN connectivity, KVM functionality, Picture-by-Picture, Picture-in-Picture and built-in speakers make it suitable for workstation and multi-source applications.

Key Features of Eizo EV4340X-WT 16.77 million colours with 8-bit display support
5 ms gray-to-gray response time
178° horizontal and vertical viewing angles
USB Type-C with DisplayPort Alt Mode and up to 94 W Power Delivery
DisplayPort and two HDMI inputs
USB 5Gbps hub with two USB-A ports and one USB-C port
Integrated 1000BASE-T RJ-45 LAN adapter
KVM switch functionality
Picture-by-Picture with 2, 3 or 4 sources
4K UHD Display The 3840 x 2160 4K UHD resolution provides four times the pixel count of Full HD, giving the large 42.5-inch screen enough detail for displaying multiple application windows, charts, documents and monitoring information. The 16:9 format and 104 ppi density provide a practical balance between screen size and image definition.

IPS Panel The IPS panel uses LED backlighting and provides 178° horizontal and vertical viewing angles. With 350 cd/m² typical brightness, a 1000:1 contrast ratio and a 5 ms gray-to-gray response time, the monitor delivers clear text, graphics and video across its large viewing area.

USB Type-C Docking USB Type-C combines DisplayPort Alt Mode, USB data transfer and Power Delivery in a single connection. Up to 94 W of power can be supplied to a connected laptop, while the monitor can also provide access to its integrated USB hub and network connection.

Video Connections The monitor provides USB Type-C, DisplayPort and two HDMI inputs, allowing several computers or video sources to be connected at the same time. HDCP support is provided across the digital video inputs for compatible protected content.

Multi-Source Viewing Picture-by-Picture supports simultaneous display from two, three or four signal sources, while Picture-in-Picture allows an additional source to be shown within the main image. These functions make the large screen useful for monitoring several systems without requiring multiple physical displays.

KVM and Network Connectivity An integrated KVM switch allows compatible computers to share connected USB peripherals through the monitor. The built-in 1000BASE-T RJ-45 connection can provide network access through the USB Type-C docking connection, helping reduce the number of separate connections required at the workstation.

USB Hub and Audio The USB hub includes two USB 5Gbps Type-A downstream ports and one USB 5Gbps Type-C downstream port with up to 15 W current output. Integrated 4 W + 4 W speakers provide stereo audio, while a stereo mini-jack is available for headphone output.

Display Modes and Eye Care Preset modes include User 1, User 2, sRGB, Paper, Movie and DICOM. Auto EcoView adjusts brightness according to surrounding lighting conditions, while additional viewing functions include automatic signal input recognition, Overdrive and flicker-free operation.

White Finish The EV4340X-WT variant has a white housing and is supplied with a removable stand. The large screen format makes it suitable for control rooms, finance workstations, video surveillance environments, CAD applications and other settings where a broad 4K workspace is useful.

The Eizo EV2740S-BK is a 27-inch FlexScan monitor with a 3840 x 2160 4K UHD resolution and 16:9 aspect ratio, providing a detailed workspace for office applications, CAD, finance, control rooms and home working. Its IPS panel delivers 16.7 million colours, 163 ppi pixel density, 350 cd/m² typical brightness, a 1000:1 contrast ratio and 178° horizontal and vertical viewing angles.

Key Features of Eizo EV2740S-BK 16.7 million colours with 8-bit display support
1.06 billion colour tones through a 10-bit look-up table
sRGB colour space
6 ms gray-to-gray response time
USB Type-C with DisplayPort Alt Mode and up to 70 W Power Delivery
DisplayPort and HDMI inputs
USB 5Gbps hub with four USB Type-A downstream ports
Picture-by-Picture functionality
Auto EcoView, EcoView Index and EcoView Optimizer
sRGB, Paper, Movie and DICOM preset modes
Flicker-free operation and Overdrive
Automatic signal input recognition
4K UHD Resolution The 3840 x 2160 4K UHD resolution provides a high level of detail across the 27-inch display. With 163 pixels per inch, the screen is suited to text-heavy office work, CAD drawings, spreadsheets, graphics and other applications where fine image detail is important.

IPS Display Panel The IPS panel uses LED backlighting and provides 178° horizontal and vertical viewing angles. A typical brightness of 350 cd/m² and 1000:1 contrast ratio provide clear presentation of documents, graphics and video, while the 6 ms gray-to-gray response time supports smooth changes between images.

Colour Reproduction The display supports 16.7 million colours through an 8-bit signal path and incorporates a 10-bit look-up table capable of handling approximately 1.06 billion colour tones. The sRGB colour space and adjustable colour settings provide flexibility for everyday office, graphics and content applications.

USB Type-C Docking USB Type-C combines DisplayPort Alt Mode, USB data and Power Delivery through a single connection. The monitor can supply up to 70 W to a compatible connected computer, while its USB hub provides access to additional peripherals.

Video Connections The monitor provides USB Type-C, DisplayPort and HDMI inputs, allowing it to connect to a range of computers and video sources. HDCP support is provided through the digital inputs, and automatic signal input recognition helps select an active source.

USB Hub and Audio Four USB 5Gbps Type-A downstream ports provide connections for peripherals such as keyboards, mice and storage devices. Integrated 1 W + 1 W stereo speakers provide audio playback, with audio signals supported through USB Type-C, DisplayPort and HDMI.

Display Modes and Eye Care Preset modes include sRGB, Paper, Movie and DICOM, alongside two manual memory locations. Auto EcoView, EcoView Index and EcoView Optimizer provide brightness and energy-management functions, while flicker-free operation and Overdrive support comfortable viewing and responsive image changes.

Ergonomic Stand The supplied stand provides 169 mm of height adjustment, 344° swivel, 5° forward and 35° backward tilt, plus clockwise and anti-clockwise pivot rotation between landscape and portrait orientation. A 100 x 100 mm VESA mounting pattern is also available for compatible mounting systems.

The Eizo EV2720S-BK is a 27-inch FlexScan monitor with a 2560 x 1440 WQHD resolution and 16:9 aspect ratio, providing a spacious workspace for office applications, home working, CAD, finance and control room environments. Its IPS panel delivers 16.7 million colours, 109 ppi pixel density, 350 cd/m² typical brightness, a 1500:1 contrast ratio and 178° horizontal and vertical viewing angles.

Key Features of Eizo EV2720S-BK 16.7 million colours with 8-bit signal support
1.06 billion colour tones through a 10-bit look-up table
sRGB colour space
350 cd/m² typical brightness
1500:1 typical contrast ratio
5 ms gray-to-gray response time
USB Type-C with DisplayPort Alt Mode and up to 70 W Power Delivery
DisplayPort and HDMI inputs
Four USB 5Gbps Type-A downstream ports
Picture-by-Picture functionality
Built-in 1 W + 1 W stereo speakers
Auto EcoView, EcoView Index and EcoView Optimizer
sRGB, Paper, Movie and DICOM preset modes
Flicker-free operation and Overdrive
Automatic signal input recognition
WQHD Resolution The 2560 x 1440 WQHD resolution provides 1.8 times the workspace of a conventional 1920 x 1080 Full HD display. On the 27-inch screen, the 109 ppi pixel density provides detailed text and graphics while leaving room for several application windows to be displayed together.

IPS Display Panel The IPS panel uses LED backlighting and provides 178° horizontal and vertical viewing angles. With a typical brightness of 350 cd/m², a 1500:1 contrast ratio and a 5 ms gray-to-gray response time, the monitor provides clear presentation of documents, graphics and moving images.

Colour Reproduction The display supports 16.7 million colours through an 8-bit signal path and incorporates a 10-bit look-up table capable of handling approximately 1.06 billion colour tones. The sRGB colour space and adjustable white point and gamma settings provide flexibility for different viewing requirements.

USB Type-C Docking USB Type-C combines DisplayPort Alt Mode, USB data and Power Delivery through one connection. The monitor can supply up to 70 W to a compatible laptop or other connected computer, reducing the number of separate cables needed at the workstation.

Display Connections The monitor provides USB Type-C, DisplayPort and HDMI inputs for connecting computers and other compatible video sources. HDCP support is available across the digital inputs, while automatic signal input recognition helps select an active connection.

USB Hub and Audio Four USB 5Gbps Type-A downstream ports provide convenient connections for keyboards, mice, storage devices and other peripherals. Integrated 1 W + 1 W stereo speakers provide audio playback, with sound available through USB Type-C, DisplayPort and HDMI. A 3.5 mm stereo headphone output is also included.

Picture-by-Picture Picture-by-Picture allows content from different signal sources to be displayed simultaneously. This can be useful when comparing information from separate computers or when working with multiple systems from a single monitor.

Display Modes and Eye Care Preset modes include sRGB, Paper, Movie and DICOM, along with two manual memory locations. Auto EcoView adjusts screen brightness according to ambient lighting, while EcoView Index and EcoView Optimizer provide additional energy-management functions. Flicker-free operation and Overdrive are also supported.

Ergonomic FlexStand The supplied stand provides a 169 mm height adjustment range, 344° swivel and 5° forward to 35° backward tilt. The display can also pivot between landscape and portrait orientations, allowing the screen position to be adapted to different working arrangements.

VESA Mounting and Black Finish A 100 x 100 mm VESA mounting pattern provides compatibility with suitable monitor arms and mounting brackets. The black housing gives the monitor a professional appearance suitable for office, home and workstation environments.

The Eizo EV2720S-WT is a 27-inch FlexScan monitor with a 2560 x 1440 WQHD resolution and 16:9 aspect ratio, providing a spacious workspace for office applications, home working, CAD, finance and control room environments. Its IPS panel delivers 16.7 million colours, 109 ppi pixel density, 350 cd/m² typical brightness, a 1500:1 contrast ratio and 178° horizontal and vertical viewing angles. The monitor also features four USB downstream ports, Picture-by-Picture functionality, integrated stereo speakers and a versatile stand with height, swivel, tilt and pivot adjustment.

Key Features of Eizo EV2720S-WT 16.7 million colours with 8-bit signal support
1.06 billion colour tones through a 10-bit look-up table
sRGB colour space
5 ms gray-to-gray response time
USB Type-C with DisplayPort Alt Mode and up to 70 W Power Delivery
DisplayPort and HDMI inputs
Four USB 5Gbps Type-A downstream ports
Picture-by-Picture functionality
Built-in 1 W + 1 W stereo speakers
Auto EcoView, EcoView Index and EcoView Optimizer
sRGB, Paper, Movie and DICOM preset modes
Flicker-free operation and Overdrive
Automatic signal input recognition
WQHD Resolution The 2560 x 1440 WQHD resolution provides 1.8 times the screen area of a conventional 1920 x 1080 Full HD display. The 27-inch panel and 109 ppi pixel density provide detailed text and graphics while giving users room to view multiple windows together.

IPS Display Panel The IPS panel uses LED backlighting and provides 178° horizontal and vertical viewing angles. A typical brightness of 350 cd/m² and 1500:1 contrast ratio provide clear presentation of documents, graphics and video, while the 5 ms gray-to-gray response time supports fast image transitions.

Colour Reproduction The monitor displays up to 16.7 million colours through an 8-bit signal path and uses a 10-bit look-up table capable of handling approximately 1.06 billion colour tones. The sRGB colour space and adjustable colour settings provide flexibility for everyday office and professional applications.

USB Type-C Docking USB Type-C combines DisplayPort Alt Mode, USB data and Power Delivery through a single cable. Up to 70 W can be supplied to a compatible laptop or computer, while connected peripherals can use the monitor's integrated USB hub.

Display Connections The monitor provides USB Type-C, DisplayPort and HDMI inputs for connecting computers and other compatible video sources. HDCP support is available through the digital inputs, and automatic signal input recognition helps select an active source.

USB Hub and Audio Four USB 5Gbps Type-A downstream ports provide connections for keyboards, mice, storage devices and other peripherals. Integrated 1 W + 1 W stereo speakers provide audio playback, while a 3.5 mm stereo jack is available for audio output.

Picture-by-Picture Picture-by-Picture allows content from two compatible signal sources to be displayed simultaneously. This can be useful when comparing information from separate computers or when working with multiple systems from one screen.

Display Modes and Eye Care Preset modes include sRGB, Paper, Movie and DICOM, with two manual memory locations also available. Auto EcoView adjusts brightness according to ambient lighting, while EcoView Index and EcoView Optimizer provide additional energy-management functions. Flicker-free operation, Overdrive and an anti-glare surface support comfortable viewing during extended use.

Ergonomic FlexStand The supplied stand provides 169 mm of continuous height adjustment, 344° swivel and 5° forward to 35° backward tilt. The display can also rotate clockwise and anti-clockwise for portrait or landscape positioning, allowing the screen to be adjusted to different working arrangements.

VESA Mounting and White Finish A 100 x 100 mm VESA mounting pattern provides compatibility with suitable monitor arms and mounting brackets. The white housing is complemented by matching white cables, providing a consistent appearance for office and home workspaces.

The Eizo EV2400R-BK is a 23.8-inch FlexScan monitor with a 1920 x 1080 Full HD resolution and 16:9 aspect ratio, providing a practical display for office work, home working, control rooms and everyday professional applications. Its IPS panel delivers 16.7 million colours, 93 ppi pixel density, 350 cd/m² typical brightness, a 1500:1 contrast ratio and 178° horizontal and vertical viewing angles.

The monitor supports a 100 Hz refresh rate for smoother scrolling and window movement, while DisplayPort and HDMI inputs provide flexible connectivity. Four USB downstream ports, built-in stereo speakers, automatic brightness adjustment and an ergonomic stand with height, tilt, swivel and pivot adjustment add functionality for modern workspaces.

Key Features of Eizo EV2400R-BK 16.7 million colours with 8-bit display support
350 cd/m² typical brightness and 1500:1 contrast ratio
100 Hz maximum refresh rate for smoother screen movement
DisplayPort and HDMI video inputs
Four USB downstream ports, including two USB 5Gbps and two USB 2.0 ports
Built-in 1 W + 1 W stereo speakers
sRGB, Eco, Paper, Movie and DICOM display modes
Auto EcoView, EcoView Index and EcoView Optimizer functions
Full HD Display The 1920 x 1080 Full HD resolution provides a clear 16:9 viewing area suitable for office applications, documents, web content and everyday multimedia use. The 93 ppi pixel density provides detailed text and graphics across the 23.8-inch screen.

IPS Panel The IPS panel provides 16.7 million colours, 350 cd/m² typical brightness and a 1500:1 typical contrast ratio. Its 178° horizontal and vertical viewing angles help maintain consistent image visibility and colour reproduction when viewing the display from different positions.

100 Hz Refresh Rate The monitor supports a maximum refresh rate of 100 Hz, providing smoother movement when scrolling through documents, browsing websites or moving application windows. This is particularly useful during extended periods of everyday computer use.

Display Connections DisplayPort and HDMI inputs provide straightforward connection options for compatible desktop computers, laptops and other video sources. The monitor also supports audio input through DisplayPort and HDMI.

USB Hub The integrated USB hub provides four downstream Type-A ports, including two USB 5Gbps ports and two USB 2.0 ports. This allows compatible peripherals such as keyboards, mice and other USB devices to be connected directly to the monitor.

Display Modes and Eye Care The monitor includes sRGB, Eco, Paper, Movie and DICOM display modes together with two manual memory locations. Auto EcoView adjusts screen brightness according to ambient lighting, while flicker-free operation, Overdrive and EcoView functions provide additional viewing and power-management options.

Integrated Stereo Speakers Built-in 1 W + 1 W stereo speakers provide audio playback without requiring separate desktop speakers. Audio can be supplied through the DisplayPort or HDMI connection for convenient use with compatible computers and media sources.

Ergonomic Stand The stand provides continuous height adjustment through a 140 mm range, along with 5° forward and 35° backward tilt and 344° swivel. The display can also rotate clockwise or anti-clockwise between landscape and portrait orientation for different working requirements.

Anti-Glare Screen The LED-backlit IPS panel features an anti-glare surface that diffuses reflected light to reduce distracting reflections. This helps provide a clearer view of the screen in different office lighting conditions.

Energy-Efficient Operation The monitor has typical power consumption of approximately 8 W, with a maximum consumption of 43 W when operating at maximum brightness with all signal inputs and USB ports in use. Standby consumption is approximately 0.37 W, while power consumption with the power switch off is 0 W.

VESA Mounting VESA 100 x 100 mm mounting compatibility allows the monitor to be installed on a suitable mounting arm or bracket. This provides an alternative to the supplied ergonomic stand for workstation configurations requiring different positioning.

The Eizo EV2400R-WT is a 23.8-inch FlexScan monitor with a 1920 x 1080 Full HD resolution and 16:9 aspect ratio, providing a practical display for office work, home working, control rooms and everyday professional applications. Its IPS panel delivers 16.7 million colours, 93 ppi pixel density, 350 cd/m² typical brightness, a 1500:1 contrast ratio and 178° horizontal and vertical viewing angles. The 100 Hz refresh rate supports smoother scrolling and window movement, while DisplayPort and HDMI inputs provide flexible connectivity.

Key Features of Eizo EV2400R-WT 16.7 million colours with 10-bit look-up table supporting 1.06 billion colour tones
350 cd/m² typical brightness and 1500:1 contrast ratio
100 Hz maximum refresh rate for smoother scrolling and movement
DisplayPort and HDMI digital video inputs
Four USB Type-A downstream ports, including two USB 5Gbps and two USB 2.0 ports
Built-in 2 W stereo speakers
Auto EcoView, EcoView Index and EcoView Optimizer functions
sRGB, Eco, Paper, Movie and DICOM display modes
Height, tilt, swivel and pivot adjustment
Integrated power supply and energy efficiency class B
Full HD IPS Display The 23.8-inch IPS panel provides a 1920 x 1080 Full HD resolution in a 16:9 format. With 93 ppi pixel density, 350 cd/m² typical brightness and a 1500:1 contrast ratio, the display provides clear text, detailed graphics and stable image reproduction. The 178° horizontal and vertical viewing angles help maintain consistent colours and contrast when viewing the screen from different positions.

100 Hz Refresh Rate A maximum refresh rate of 100 Hz allows scrolling, cursor movement and window transitions to appear smoother than on a conventional 60 Hz display. This makes the monitor suitable for regular office applications, browsing, document work and other everyday computer tasks.

Display Connectivity DisplayPort and HDMI inputs provide digital video connectivity for compatible computers and other sources. The monitor supports RGB and YUV signals, while HDCP support allows compatible protected content to be displayed.

USB Hub Four USB Type-A downstream ports provide convenient access for peripherals. Two ports support USB 5Gbps while the remaining two use USB 2.0, allowing devices such as keyboards, mice and other accessories to be connected directly to the monitor.

Display Modes and Eye Care The monitor includes sRGB, Eco, Paper, Movie and DICOM modes, along with Auto EcoView, EcoView Index and EcoView Optimizer functions. Overdrive and flicker-free operation are also provided for comfortable everyday viewing, while automatic signal recognition simplifies switching between connected sources.

Integrated Stereo Speakers Built-in stereo speakers provide 1 W per channel for basic audio playback without requiring separate desktop speakers. Audio can be supplied through the DisplayPort or HDMI connection.

Ergonomic Stand The stand provides height adjustment, tilt, swivel and pivot rotation, allowing the display to be positioned for different desk layouts and viewing preferences. The monitor can be adjusted through a 140 mm height range, swivelled up to 344°, tilted from 5° forward to 35° backward and rotated for portrait orientation.

VESA Mounting VESA 100 x 100 mm mounting compatibility provides an alternative to the supplied stand for users who require a monitor arm, wall mount or other compatible mounting system.

The Eizo S2134-BK is a 21.3-inch FlexScan monitor with a 1600 x 1200 UXGA resolution and 4:3 aspect ratio, providing a spacious square-format display for office work, finance applications, control systems and other professional desktop tasks.

Its IPS panel uses LED backlighting and delivers 16.7 million colours, 500 cd/m² typical brightness, an 1800:1 contrast ratio and 178° horizontal and vertical viewing angles. DisplayPort, DVI-D and D-Sub inputs support digital and analogue computer connections, while two USB downstream ports, automatic brightness control and an adjustable stand add practical functionality for different workstation environments.

Key Features of Eizo S2134-BK 4:3 aspect ratio with 94 ppi pixel density
16.7 million colours with 10-bit look-up table supporting 1.06 billion colour tones
178° horizontal and vertical viewing angles
6 ms typical grey-to-grey response time
DisplayPort, DVI-D and D-Sub video inputs
HDCP 1.3 support through DisplayPort and HDCP 1.4 through DVI-D
Two USB 2.0 Type-A downstream ports and one USB Type-B upstream port
Auto EcoView, EcoView Index and EcoView Optimizer functions
sRGB, Paper, Movie and DICOM display modes
Overdrive and flicker-free operation
Automatic signal input recognition
UXGA 4:3 Display The 21.3-inch display provides a 1600 x 1200 UXGA resolution with a 4:3 aspect ratio and a visible image area of 432 x 324 mm. The square-format screen provides additional vertical workspace compared with many widescreen monitors, making it suitable for applications where information needs to remain visible with less scrolling.

IPS Panel The IPS panel delivers 16.7 million colours and supports a colour palette of up to 1.06 billion colour tones through its 10-bit look-up table. With 500 cd/m² typical brightness and an 1800:1 contrast ratio, the display provides strong image visibility, while 178° horizontal and vertical viewing angles help maintain consistent images from different viewing positions.

Digital and Analogue Inputs DisplayPort and DVI-D provide digital video connections, while the D-Sub mini 15-pin input supports analogue sources. DisplayPort supports HDCP 1.3 and DVI-D supports HDCP 1.4. Automatic signal input recognition makes it easier to switch between connected sources.

USB Connectivity A USB 2.0 Type-B upstream connection links the monitor to a computer, while two USB 2.0 Type-A downstream ports provide convenient connections for compatible peripherals. The downstream ports can supply up to 500 mA per port when the USB upstream connection is active.

Display Modes and Eye Comfort The monitor includes two manual memory locations together with sRGB, Paper, Movie and DICOM modes. Auto EcoView adjusts screen brightness according to ambient lighting, while EcoView Index and EcoView Optimizer provide additional energy-saving functions. Overdrive and flicker-free operation are also supported.

Automatic Image Adjustment When using an analogue signal, the Self Adjustment function automatically adjusts the image to help suppress flicker and drift. This provides a more consistent image when connecting computers through the D-Sub input.

Ergonomic Stand The supplied stand provides 82 mm of height adjustment together with tilt, swivel and pivot functions. The display can tilt from 0° forwards to 40° backwards, swivel through 70° and rotate clockwise between landscape and portrait orientations.

VESA Mounting A 100 x 100 mm VESA mounting pattern allows the display to be installed on a compatible monitor arm, wall mount or other mounting system when the supplied stand is not required.

Energy-Efficient Operation The monitor has a typical power consumption of 13 W and a maximum consumption of 42 W when operating at maximum brightness with all signal inputs and USB ports in use. Standby consumption is rated at 0.5 W, while power consumption reaches 0 W when the power switch is turned off. The monitor has an energy efficiency class C rating.
