Express RJ45 Patch Lead Finder
Select requirements to view suitable RJ45 patch leads instantly from our entire range.
Reset
More Info
Our range of Cat6 RJ45 Ethernet Cable/Patch Leads and Cables including CE & Patchsee are manufactured and independently tested to conform to all the necessary EIA/TIA Cat6 Standards. We supply both Booted & SFTP Shielded Cat6 Patch Leads as well as PatchSee Leads that come with Optical Fibre Identification.
Cat6 RJ45 Ethernet Cable
ce Logo
With Strain Relief Boots

Our range of Cat6 RJ45 Ethernet Cable/Patch Leads are manufactured and tested to conform with all the necessary standards for Cat6 communications.

All Proposed Category 6 requirements as per ANSI/TIA, ISO/IEC and CENELEC EN Standards

1. ANSI/TIA-568-C.2
2. EN 50173 Channel Class E
3. IEC 61935-2 for Patch Cord
4. ISO/IEC 61156-6end Edition for Stranded Cable
RoHS Compliant for European Union Issued Directive 2002/95/EC

Features:

Guaranteed performance to 250MHz
The particular saw-tooth design of jacket towards inner can enhance the resistance of alien crosstalk
The unique design of PE cross reduces the NEXT and RL ,and provides better transmission.
Superior cable flexibility from stranded cores
Boot maintains correct bend radius to ensure maximum performance
Connector 8P8C, RJ45, 50 inch gold plating
ANSI/TIA 568 C.2 T568B pinout termination
Flame Retardancy is verified according to IEC 60332-1-2.
RoHS compliant
Each lead is made with high quality Cat6 plugs, highly flexible PVC sheath and stranded copper conductors. Between the cable and plug is a boot to provide strain relief and protection to the cable.  The low profile design of the boot means it's ideal for use in high density installations.

Applications:


10GBASE-T Ethernet
1000BASE-TX/ 1000BASE-T Gigabit Ethernet
100BASE-TX Fast Ethernet
10BASE-TX Ethernet
This range is available in a wide variety of colours and lengths up to 20mt (30mt in White).

Express View Logo
Length:
Colour:
In Stock: Next Day
£1.06
£1.27 Inc Vat
Add To Cart
Patch Leads - SFTP
With Strain Relief Boots

New to the range of our RJ45 leads are these Cat6 Shielded RJ45 Ethernet Cable/Patch Leads. With double shielding they are ideal for use when electrical interference is a problem.

Each RJ45 cable assembly comes assembled with a strain relief boot.

These leads are fully tested to comply with all Cat6 Specifications.

Express View Logo
Length:
In Stock: Next Day
£1.44
£1.73 Inc Vat
Add To Cart
Cat6 External Grade RJ45 UTP Moulded Booted Lead - Black
ce Logo

Solid conductor 4 pair U/UTP RJ45 Cat6 Ethernet Cable with External Grade LDPE outer sheath supplied in a range of length from 0.5 metre up to 50.0 metre.

Features
Supplied in 0.5mtr up to 50.0metre for the smaller jobs.
UV and Moisture Resistant Polyethylene Outer Sheath
Supports 10/100 Fast Ethernet and 10/100/1000 Gigabit Ethernet
Manufactured and tested to the ISO 11801, EN 50173 & ANSI/TIA-568-C standards

Specification
Conductor: Bare Copper 24AWG
Insulation - Thickness: MIN at any point: 0.20mm / MAX AVG: 0.24mm
Diameter: 1.03 ± 0.06mm

Jacket - LDPE - Thickness: MIN at any point: 0.45mm / MAX AVG: 0.55mm
Diameter: 5.8 ± 0.20mm

Wire: Cat6 UTP Solid 24AWG 4P (with spline)
Plug: Gold Flush YU-28

Express View Logo
Length:
In Stock: 2-3 Weeks
Was: £2.30
£2.07
£2.48 Inc Vat
Add To Cart
PatchSee Cat6 RJ45 Patch Leads
PatchSee Logo
With Optical Fibre Identification

Available in 6 lengths from 0.6 m to 4.9 m

Features

Black sheath
Grey boot to distinguish it from black booted category 5e patch cords
Part number and length printed on the boot
Compatible with colour coded PatchClips for the first level of identification
A reliable patch cord for all networks:

Conforms to EIA/TIA 568-B2.2-1 category 6
25 year guarantee for use in category 6 channels interoperable with any cabling system= quality control :  100% testing of electrical and optical properties
Test results saved onto a database
Each patch cord identified by a unique serial number
Plastic cross web unshielded (UTP) and individually foil shielded pairs (FTP)
PVC sheath for UTP cables and zero halogen (LSOH) sheath for FTP cables


How it works


Express View Logo
Length:
In Stock: Next Day
£6.62
£7.94 Inc Vat
Add To Cart
Lindy Logo

Cat.6 U/UTP PVC network cable with support for bandwidth up to 250MHz and features a snagless design with gold plated contacts for ethernet standards up to 1GBase-T.

Cat.6 cable for operating frequencies up to 250MHz. The unshielded version (U/UTP) can be used for Gigabit Ethernet thanks to the special design of the electrophysical parameters (NExT, FExT, etc.) despite the lack of shielding. These cables are manufactured and tested according to the ISO/IEC 11801 specification. The cables are packaged individually in a polybag.

The gold-plated contacts ensure reliable, corrosion-free connections over extensive periods of time. A robust snagless strain relief design prevents damage to the connector latch during installation and removal.

Features

Twisted Pair Patch Cable with RJ45 connectors
Cat.6 U/UTP, PVC
Integrated snagless connector for latch protection
Gold plated pins for better conductivity and elimination of signal loss
10 Year Warranty

Technical Specifications

Connectors Connector A RJ45 Male Connector B RJ45 Male Housing Material Polycarbonate Pin Construction Copper Alloy Pin Plating Gold plated Dimensions WxDxH
(approx.)
11.6x22.8x8.3mm
(0.46x0.90x0.33in) Cable Construction Length 0.3m, 0.5m, 1m, 2m, 3m, 5m, 7.5m, 10m, 15m, 20m and 30m Colours Grey, Black, Blue, White, Yellow, Purple, Red, Orange and Green Type Cat.6 Jacket Diameter 5.8mm (0.23in) Jacket Material PVC Conductor Material Copper Conductor Gauge 24AWG Specifications Supported Bandwidth 250MHz Nominal Attenuation 32.8dB/100m @250MHz Minimum Band Radius 69mm (2.72in) Operating Temperature -10°C - 60°C (14°F - 140°F) Storage Temperature -20°C - 75°C (-4°F - 167°F)

Express View Logo
Length:
Colour:
In Stock: Next Day
£4.00
£4.80 Inc Vat
Add To Cart
UTP Locking Network Cable
Lindy Logo

The Lindy Locking Patch Cable is the ideal Layer 1 security tool. With its unique locking feature, you can prevent the cables being accidentally disconnected. Ideal for public areas, in shops, hospitals and more, once the cables is locked it stays locked till you release them using a key.

The Lindy CAT6 RJ45 U/UTP patch leads are manufactured and tested to conform with ISO 11801 specification. The unique snagless strain relief design prevents damage to the connector latch during installation and removal. Every cable is 100% performance tested and comes with the Lindy "no surprises" guarantee.

These cables are ideal for connecting computers, hubs, switches, print servers and patch panels but are finding more and more uses in AV applications and security cameras.

Please note: This line of Locking Ethernet cables is now in clearance. We no longer stock the Key (45086) to remove these connectors. Please be advised only to purchase these cables if you already have one of our keys or if you are happy for the connection to be permanent.

Features

Lockable network cable
Gigabit Ethernet ready
Stranded core cables allowing repeated flexing without damage, prolonging the life of the cable
Key sold separately (part number 45086)
10 Year Warranty
Technical Information

U/UTP - (U) unshielded cable shielding / (UTP) Unshielded Twisted Pair
Standards: ISO/IEC 11801, EN50173, EIA/EIA 568B.2
Wiring spec: Straight through
Ethernet standard: 10GBase-T
Bandwidth: 250Mhz
Shielding: No
LS0H (Low Smoke Zero Halogen): No
Colour: Grey
Lengths available: 0.3m, 7.5m and 30m

Express View Logo
Length:
In Stock: Next Day
£6.78
£8.14 Inc Vat
Add To Cart
UTP Snagless Network Cable
Lindy Logo

Lindy CAT6 F/UTP Patch Cables are high quality F/UTP (Foiled/Unshielded Twisted Pair) Category 6 cables that are manufactured and tested to conform to ISO 11801 specification.

The cable construction consists of four unshielded twisted pairs encased in an overall foil shield that acts as a barrier preventing external EMI/RFI. It also prevents data signals from leaking out of the cable, making the cable suitable for secure installations. Gold plated contacts also help give optimum conductivity as well as resistance to tarnishing and corrosion, further boosting signal integrity and the cables overall performance and longevity.

RJ-45 connectors offer universal connectivity to computers and network components, such as routers, switch boxes, network printers, and network attached storage devices as well as being ideal for use in data centres, rack spaces, server rooms and network cabinets.

Features

Twisted Pair Patch Cable with RJ45 connectors
Cat.6 U/UTP, PVC
Integrated snagless connector for latch protection
Gold plated pins for better conductivity and elimination of signal loss
Colour: Grey
10 Year Warranty
Technical Information

F/UTP - (F) Foil cable shielding / (UTP) Unshielded Twisted Pair, also known as S/UTP
Standards: ISO/IEC 11801, EN50173-1, ANSI/TIA-568-C.2
Wiring spec: Straight through
Ethernet standard: 10/100/1000Base-T
Bandwidth: 250Mhz
Shielding: Yes
LS0H (Low Smoke Zero Halogen): No
RoHS and REACH Compliant

Express View Logo
Length:
In Stock: 5-7 Days
£3.08
£3.70 Inc Vat
Add To Cart
FTP Shielded Network Cable
Lindy Logo

Lindy's Cat.6 Patch Cables are manufactured and tested to conform with the ISO 11801 specification. A robust snagless strain relief design prevents damage to the connector latch during installation and removal. Gold plated pins ensure complete signal integrity no matter the application.

Each cable is packaged in a polybag, Cables of various colours are also available and therefore ideally suited for structured cabling in server cabinets or wall cabinets.

RJ45 connectors offer universal connectivity to computers and network components, such as routers, switches, network printers and network attached storage devices.

These cables are also ideal for use in data centres, rack spaces, server rooms and network cabinets. Additional uses include security systems and AV installations.

Features

Twisted Pair Patch Cable with RJ45 connectors
Integrated snagless connector for latch protection
Gold plated pins for better conductivity and elimination of signal loss
Cat.6 S/FTP PIMF, PVC
10 Year Warranty

Technical Information

Connectors Connector A RJ45 Male Connector B RJ45 Male Housing Material Polycarbonate Pin Construction Copper Alloy Pin Plating Gold Plated Connector Plating Nickel Dimensions WxDxH
(approx.)
11.6x22.8x8.3mm
(0.46x0.90x0.33in) Cable Construction Lengths Available 0.3m, 0.5m, 1m, 1.5m, 2m, 3m, 5m, 7.5m, 10m, 15m, 20m and 30m Colour Grey Type Cat.6 Jacket Diameter 6.2mm (0.24in) Jacket Material PVC Conductor Material Copper Conductor Gauge 27AWG Shielding Aluminium Braid Specifications Supported Bandwidth 250MHz Nominal Attenuation 250MHz @ 32.8dB/100m Minimum Band Radius 74mm (2.91in) Operating Temperature -10°C - 60°C (14°F - 140°F) Storage Temperature -20°C - 75°C (-4°F - 167°F)

Express View Logo
Length:
In Stock: Next Day
£1.76
£2.11 Inc Vat
Add To Cart
UTP Flat Network Cable
Lindy Logo

Cat.6 U/UTP flat network cable with support for bandwidth up to 250MHz and features a snagless design with gold plated contacts for ethernet standards up to 1GBase-T.

Cat.6 cable for operating frequencies up to 250MHz. The unshielded version (U/UTP) can be used for Gigabit Ethernet thanks to the special design of the electrophysical parameter (NExT, FExT, etc.) despite the lack of shielding. Designed as flat ribbon cable for use in environments with restricted or limited installation space. These cables are manufactured and tested according to the ISO/IEC 11801 specification. The cables are packaged individually in a polybag.

The gold-plated contacts ensure reliable, corrosion-free connections over extensive periods of time. A robust snagless strain relief design prevents damage to the connector latch during installation and removal.

The very flexible and thin ribbon cable construction allows the cables to be installed in restricted or limited spaces.

Features

Twisted Pair Patch Cable with RJ45 connectors
Cat.6 U/UTP, Flat
Integrated snagless connector for latch protection
Gold plated pins for better conductivity and elimination of signal loss
10 Year Warranty
Technical Specifications

Connectors Connector A RJ45 Male Connector B RJ45 Male Housing Material Polycarbonate Pin Construction Brass Pin Plating Gold plated Dimensions WxDxH
(approx.)
11.6x22.8x8.3mm
(0.46x0.90x0.33in) Cable Construction Lengths 0.3m, 1m, 2m, 3m, 5m and 10m Colour Grey Type Cat.6 Jacket Diameter 6.05mmx1.40mm (0.24x0.06in) Jacket Material PVC Conductor Material Bare Copper Conductor Gauge 32AWG Specifications Supported Bandwidth 250MHz Nominal Attenuation 35.9dB/100m @250MHz Minimum Band Radius 60mm (2.36in) Operating Temperature -10°C - 60°C (14°F - 140°F) Storage Temperature -10°C - 40°C (-14°F - 104°F)

Express View Logo
Length:
In Stock: Next Day
£1.21
£1.45 Inc Vat
Add To Cart
UTP LS0H Snagless Network Cable
Lindy Logo

The Lindy CAT6 RJ45 U/UTP LS0H patch leads are manufactured and tested to conform with ISO 11801 specification. The unique snagless strain relief design prevents damage to the connector latch during installation and removal. Every cable is 100% performance tested and comes with the Lindy "no surprises" guarantee.

These cables are ideal for connecting computers, hubs, switches, print servers and patch panels but are finding more and more uses in AV applications and security cameras.

Features

Full CAT6 specification with moulded boots and unique connector latch protection
Stranded core cables allowing repeated flexing without damage, prolonging the life of the cable
LS0H (Low Smoke Zero Halogen) cable jacket emits limited smoke and no halogen when exposed to high sources of heat
Gigabit Ethernet ready
Colour: Grey
10 Year Warranty
Technical Information

U/UTP - (U) Unshielded cable shielding / (UTP) Unsheilded Twisted Pair
Standards: ISO/IEC 11801, EN50173, EIA/EIA 568B.2
Wiring spec: Straight through
Ethernet standard: 10GBase-T
Bandwidth: 250Mhz
Shielding: No
LS0H (Low Smoke Zero Halogen): Yes

Express View Logo
Length:
In Stock: 5-7 Days
£2.25
£2.70 Inc Vat
Add To Cart
UTP Solid Patch Cable
Lindy Logo

Lindy CAT6 F/UTP Solid Patch Cable are high quality F/UTP (Foiled/Unshielded Twisted Pair) Category 6 cables that are manufactured and tested to conform to ISO 11801 specification.

This Lindy patch cable has a rigid (solid) core to provide greater effectiveness when applied over larger distances, ideal for use with Lindy CAT6 and CAT5 AV extenders. This patch cable is also backwards compatible with other CAT5 and CAT5e products. This cable’s construction consists of four unshielded twisted pairs encased in an overall foil shield that acts as a barrier preventing external EMI/RFI.

It also prevents data signals from leaking out of the cable, making the cable suitable for secure installations. Gold plated contacts also help give optimum conductivity as well as resistance to tarnishing and corrosion, further boosting signal integrity and the cables overall performance and longevity.

RJ-45 connectors offer universal connectivity to computers and network components, such as routers, switch boxes, network printers, and network attached storage devices as well as being ideal for use in data centres, rack spaces, server rooms and network cabinets.

Features

Full CAT6 specification with moulded boots and connector latch protection
Rigid (solid) core for greater effectiveness over larger distances
Backwards compatible with CAT5 and CAT5e products
Gigabit Ethernet Ready
10 Year Warranty
Technical Specifications

Connectors Connector A RJ45 Male Connector B RJ45 Male Housing Material Metal Pin Construction 8P8C Pin Plating 3µm Gold Plated Dimensions WxDxH
(approx.)
11.6x21.3x9.3mm
(0.46x0.84x0.37in) Cable Construction Lengths Available 10m, 20m, 30m, 40m, 50m, 75m and 100m Colour Grey Type Cat.6 Jacket Diameter 6.2mm (0.24in) Jacket Material PVC Conductor Material Bare Copper Conductor Gauge 24AWG Shielding Foil Wiring 1:1 Technical Information Supported Bandwidth 250MHz Nominal Attenuation 250MHz @ 32.8dB/100m Minimum Bend Radius 49mm (1.93in) Operating Temperature -10°C - 60°C (14°F - 140°F) Storage Temperature -20°C - 70°C (-4°F - 158°F) Humidity 10% - 85% RH (Non-Condensing)

Express View Logo
Length:
In Stock: Next Day
£17.50
£21.00 Inc Vat
Add To Cart
FTP Network Cable
Lindy Logo

Cat.6 S/FTP Flat network cable with support for bandwidth up to 250MHz and features a snagless design with gold plated contacts for ethernet standards up to 1GBase-T.

Cat.6 cable for operating frequencies up to 250MHz in shielded version with braid as overall shield and foil shield for the individual wire pairs (S/FTP). Cat.6 cables are widespread throughout the professional sector.

They are ideal for Gigabit Ethernet or AV extension applications. These cables are manufactured and tested according to the ISO/IEC 11801 specification. A robust snagless strain relief design prevents damage to the connector latch during installation and removal.

The gold-plated contacts ensure reliable, corrosion-free connections over extensive periods of time. A robust snagless strain relief design prevents damage to the connector latch during installation and removal.

The halogen-free sheath material of the LSZH cable makes the product suitable for use in public spaces with its low smoke emission and elimination of toxic halogen emissions.

Features

Cat.6 S/FTP PIMF, LSZH
Twisted Pair Patch Cable with RJ45 connectors
Integrated snagless connector for latch protection
Gold plated pins for better conductivity and elimination of signal loss
10 Year Warranty
Technical Information

Connectors Connector A RJ45 Male Connector B RJ45 Male Housing Material Polycarbonate Pin Construction Brass Pin Plating Gold Plated Connector Plating Nickel Dimensions WxDxH
(approx.)
11.6x21.5x8.3mm
(0.46x0.85x0.33in) Cable Construction Lengths Available 0.3m, 0.5m, 1m, 2m, 3m, 5m and 10m Colour Grey Type Cat.6 Jacket Diameter 6.2mm (0.24in) Jacket Material PVC Conductor Material Copper Conductor Gauge 26AWG Shielding Aluminium / Polyester Specifications Supported Bandwidth 250MHz Nominal Attenuation 250MHz @ 38.3dB/100m Minimum Band Radius 18.6mm (0.74in) Operating Temperature -25°C - 60°C (43°F - 140°F) Storage Temperature -25°C - 60°C (-43°F - 140°F)

Express View Logo
Length:
In Stock: Next Day
£3.13
£3.76 Inc Vat
Add To Cart
StarTech Cat6 Ethernet Cable - Cat6 Gigabit Ethernet Wire
StarTech.com Logo

100% copper for outstanding value

Get the highest value for your cable investment with StarTech Cat 6 cables, each one manufactured using high-quality copper conductors.

24-gauge wire for high-performance network connections

Ensure high-performance capability for your demanding Ethernet applications, such as Power-over-Ethernet, using cables that include 24 AWG copper.

50-micron gold connectors provide peak conductivity

Rely on our RJ45 connectors to deliver optimum conductivity while eliminating signal loss due to oxidation or corrosion.

Lifetime Warranty

We back all our cables with a lifetime warranty.

Applications

Designed for use with Gigabit networks
Patches from hub to distribution panel
Connects workstation to wall outlet
Other Features

Wire Gauge 24 AWG Conductor Type Stranded Copper Number of Conductors 4 pair UTP Cable Rating CAT6 - 650 MHz Cable Jacket Material PVC - Polyvinyl Chloride Connector Plating Gold Fire Rating CMG Rated (General Purpose) Cable Type Snagless Colour Black, Blue, Green, Grey, Orange, Purple, Red, White and Yellow

Express View Logo
Length:
Colour:
In Stock: Next Day
£4.45
£5.34 Inc Vat
Add To Cart
StarTech 1m Cat6 Patch Cable - Shielded (SFTP)
StarTech.com Logo

Our shielded Cat6 cables ensure fast and dependable Gigabit network connections by protecting against electromagnetic interference (EMI/RFI) and noise. The result is a fast and safe network.

Plus, the RJ45 connectors are both snagless and molded to prevent damage to the connector clips and the cable. This helps to avoid accidental disconnections and decreases in network performance.

Available in a variety of lengths and colours, our shielded Cat6 cables help you complete your network solutions, allowing you to organize your cable runs and identify network connections.

Applications

Connect PoE-enabled devices to Gigabit networks
Connect between computers, hubs, switches, print servers and patch panels
Connect a workstation to an RJ45 wall outlet
Deliver data, voice and video over Gigabit networks
Technical Specification

Number of Conductors 4 Pair SFTP Cable Jacket Material PVC - Polyvinyl Chloride Fire Rating CMG Rated (General Purpose) Cable Type Shielded Snag-less Wiring Standard TIA/EIA-568-B.1-2001 T568B Cable Rating CAT6 - 500 MHz Wire Gauge 26 AWG (0.404 mm) Conductor Type Stranded Copper Colours Black. Grey and Blue.

Express View Logo
Length:
Colour:
In Stock: Next Day
£5.28
£6.34 Inc Vat
Add To Cart
StarTech C6PATCH50GR 50ft Cat6 Ethernet Cable - Grey CAT 6 Gigabit
StarTech.com Logo

100% copper for outstanding value

Get the highest value for your cable investment with StarTech Cat 6 cables, each one manufactured using high-quality copper conductors.

24-gauge wire for high-performance network connections

Ensure high-performance capability for your demanding Ethernet applications, such as Power-over-Ethernet, using cables that include 24 AWG copper.

50-micron gold connectors provide peak conductivity

Rely on our RJ45 connectors to deliver optimum conductivity while eliminating signal loss due to oxidation or corrosion.

Lifetime Warranty

We back all our cables with a lifetime warranty.

Applications

Designed for use with Gigabit networks
Patches from hub to distribution panel
Connects workstation to wall outlet
Other Features

Wire Gauge 24 AWG Conductor Type Stranded Copper Number of Conductors 4 pair UTP Cable Rating CAT6 - 650 MHz Cable Jacket Material PVC - Polyvinyl Chloride Fire Rating CMG Rated (General Purpose) Cable Type Molded Colour Grey

Express View Logo
In Stock: Next Day
£13.03
£15.64 Inc Vat
Add To Cart
Other Ranges Available
Cat5e RJ45 Ethernet Cable/Patch Leads & Cables
Cat5e RJ45 Ethernet Cable/Patch Leads & Cables
View Range
Cat6A RJ45 Patch Leads & Cables
Cat6A RJ45 Ethernet Cable/Patch Leads & Cables
View Range
PatchSee Leads
PatchSee RJ45 Patch Leads & Cables
View Range
Cat5e RJ45 Neutrik etherCON Patch Leads & Cables
Cat5e RJ45 Neutrik etherCON Shielded Patch Leads & Cables
View Range
Join Our Mailing List
Social Links
  • Apply for Credit
