27U 600mm Wide x 600mm Deep Cabinets/Racks

Our datacel 27U 600 x 600mm Data Cabinet/Rack is a versatile 600 mm wide rack designed to accommodate a load of up to 600kg offering features that makes it suitable for a wide range of applications in the data, security, audio visual and telecommunication arenas.

Features:

Lockable/Removable Glass Front Door
Available in Grey White or Black
Lockable/Removable Steel Side and Rear Panels
19 Inch Adjustable Mounting Profiles Front and Rear
Vented Top Cover (for use with a Roof Fan Unit if necessary)
Heavy Duty Lockable Castors and Jacking Feet Included
600kg Load Capacity
Can be Bayed with or Without Side Panels (Baying Kit Included)
Swing Handle Lock fitted to glass front door and Barrel Lock fitted to rear Steel Door
Dimensions:

27U 600mm (Width) x 600mm (Depth) x 1490mm (Height)*

*Jacking Feet adds 50-80mm to height and Castors add 70mm to the height

Multiple brush strip cable entry in roof and base

Removable and Lockable Side Panels



Full height front and rear adjustable 19" profiles
19" profiles marked with U height position
Large cut out in base for cable entry


Jacking Feet and Castors can be fitted simultaneously

Please note: Cabinets with wardrobe style doors are built-to-order and therefore non-returnable.

Please note: Flatpack Prism PI floor standing cabinets are not supplied with transport castors, heavy-duty castors or jacking feet. These can be purchased separately. To add castors or jacking feet to your order, please see our range of Prism PI castors, feet and other accessories.

Please note: If a cable tray inclusive kit is selected, this will include 2 x 150mm cable trays

Prism PI Cabinet Accessory Kit Options:

Kit 1
Prism PI 27u 600mm(w) x 600mm(d) Data Cab with selected Door Options
2 x 27U 150mm Cable Trays (Black)
CE Part number: CA-PCT27150B (x2)

Kit 2
Prism PI 27u 600mm(w) x 600mm(d) Data Cab with selected Door Options
1 x 600mm x 600mm Plinth (colour will match the cabinet)
CE Part number: CA-PPL66

Kit 3
Prism PI 27u 600mm(w) x 600mm(d) Data Cab with selected Door Options
2 x 27U 150mm Cable Trays (Black)
1 x 600mm x 600mm Plinth (colour will match the cabinet)
CE Part numbers: CA-PCT27150B (x2) & CA-PPL66

Prism Data Cabinet Product Information

The PI Data enclosure range has been designed to ensure maximum rigidity and weight loading without compromising the versatility of the solution. It can be easily modified, built and de-assembled where restrictions in space are in force. The PI range is a cost effective solution suitable for any office or data centre environment, supplied with adjustable 19-inch mounting angles, transportation castors and a configurable top panel system to incorporate fan and brush entry solutions and also provides an open base design to promote trouble free installation.

Incorporating common features such as adjustable 19" mounting angles and fitted with transportation castors as standard, the PI range offers a configurable top panel system to incorporate fan and brush entry solutions and, also provides as open base design to promote trouble free installation.

Cabinets can be fitted with a range of options including side panels, solid steel doors, vented glazed doors and vented steel doors, all designed to offer the flexibility to meet everyday requirements.

Prism Data Cabinet Specifications

Cabinet Dimensions Width & Depth 600mm x 600mm 600mm x 800mm 800mm x 600mm 800mm x 800mm U Height 27u 27u 27u 27u External Height 1410mm 1410mm 1410mm 1410mm External Width 600mm 600mm 800mm 800mm External Depth 600mm 800mm 600mm 800mm Mounting Profile Width 19" 19" 19" 19" Internal Working Depth 490mm 690mm 490mm 690mm Weight of Cabinet 80kg 85kg 85kg 90kg
Mounting profile's position/s: front & rear
Construction: bolted
Front door options: glass in steel surround (lockable), mesh (lockable)
Side panels: lockable/removable, solid with vents
Cable entry: top, bottom
Ventilation: top, small vents to side panels
Removable panels: front door, rear door, side panels
Lock positions: front door, rear door, side panels
Data Cabinet Features and Benefits
Lockable/removable glass front door
Lockable/removable steel side and rear panels
19" fully adjustable mounting profiles front and rear
Vented top cover (for use with a roof fan unit if necessary)
Open base design
Raised and vented top cover with cable entry
Available in goose grey (RAL 00A05) and black (RAL 9005)
Network/cabling/broadcast
19" electronic equipment housing
Communication systems
IT systems
Vented and lockable side panels
Earth bonding kit
Full range of completing accessories
Supplied assembled or in a flat pack version
Multiple door configurations available
Configurable roof options to cater for overhead cable installations
Full range of airflow management accessories
Data Cabinet Customisation
Black or Grey (standard colours) (specific colours available or match your corporate colours - additional charges will apply)
Panels and doors can be added/removed or changed as necessary: glass front & solid rear, mesh front & rear, glass front & wardrobe rear, mesh front & wardrobe rear
Prism Data Cabinets can be supplied assembled or in a flat pack version
Accessorize with cabinet plinths and cable trays, if the cable tray inclusive kit is selected, this will include 2 x 27U 150mm cable trays
Please call our sales team on 0800 488 0000 for a quote on a custom cabinet.

Prism PI Black Cable Tray Features and Benefits
Available in multiple height and width options to suit your Prism PI cabinet
Powder coated finish in black
Prism PI Cabinet Plinth Specifications
Height: 100mm
Width: 600mm
Depth: 600mm
Construction: Welded
Prism PI Cabinet Plinth Features and Benefits
Fixed plinth
Available in grey or black (Plinth will match the colour of the cabinet ordered in the kit)
Gland plates on side and rear for cable entry
Accessories are available on the following pages:
PDU's
Shelves
Fans units
Environmental monitoring
Cable management
Other accessories
Other options and accessories:
Console drawers and KVM solutions
UPS solutions, such as APC & Emerson
A complete range of switches
Patch panels, modules and patch leads

Images for illustrative purposes only; product may differ in appearance

The RackyRax 19” Data Cabinet range delivers a practical and durable enclosure solution for structured cabling and network equipment, combining a clean, professional appearance with robust construction. Built for reliability and ease of use, these cabinets are designed to support demanding installations without the high cost typically associated with premium enclosures.

Key Features of RackyRax 19” Data Cabinets Up to 800kg load capacity (evenly distributed)
Lockable and removable perspex front door with steel surround
Lockable and removable steel rear door
Removable steel side panels for full access
Adjustable 19” mounting profiles front and rear
Ventilated top for improved airflow
Optional roof-mounted fan compatibility
Removable gland plates top and bottom for cable entry
Supplied fully assembled (flat pack available on request)
Wide range of compatible accessories available
Designed for Practical Installation Each cabinet is engineered to simplify installation and ongoing maintenance. With adjustable mounting profiles and full access through removable panels and doors, installers can quickly configure internal layouts while maintaining flexibility for future changes.

High Load Capacity Construction Built using high-quality components and assembled in the UK, RackyRax cabinets support up to 800kg of evenly distributed weight. This makes them suitable for housing dense server and networking equipment without compromising structural integrity.

Accessible and Secure Design The combination of lockable front and rear doors with removable side panels provides both security and accessibility. The perspex front door allows for quick visual inspection of equipment while maintaining controlled access to internal components.

Efficient Cable Management Multiple cable entry points ensure clean and organised routing. Removable gland plates in the roof and base, along with an open base design, allow for flexible cable management in a wide range of installation environments.

Ventilation and Cooling Options A ventilated top panel promotes passive airflow, helping to maintain optimal operating temperatures. For more demanding setups, the cabinet also supports optional roof-mounted fan units to enhance cooling performance.

Flexible Configuration Options Available in multiple U heights, the RackyRax range accommodates installations of varying scale. Whether for smaller network setups or larger infrastructure deployments, the consistent 600x600mm footprint ensures compatibility across environments.

Accessory Compatibility A full suite of accessories is available to extend functionality, including jacking feet, transport castors, shelves, and vertical cable management solutions. This allows each cabinet to be tailored to specific operational requirements.

Available Sizes and Weights The RackyRax cabinet range is available in the following configurations:

U Height Dimensions (HxWxD) Weight 12U 635 x 600 x 600 mm 28 Kg 18U 902 x 600 x 600 mm 37.8 Kg 21U 1035 x 600 x 600 mm 48 Kg 24U 1168 x 600 x 600 mm 51 Kg 27U 1302 x 600 x 600 mm 54.6 Kg 39U 1835 x 600 x 600 mm 70 Kg 42U 1968 x 600 x 600 mm 74.6 Kg 45U 2103 x 600 x 600 mm 92.3 Kg
