24 Port Cat6 Patch Panel

Product Details

High quality angled terminal block contacts accept 22-26 AWG solid core wire
Dual type terminal blocks (for Krone/110 compatible punchdown tools) and dual T568A/T568B colour coding
Cable tie mounts and cable ties supplied for cable management
Fixing screws, cage nuts and washers supplied separately

The PowerCat 6 Patch Panels are a key component of the PowerCat 6 end-to-end Solution.

Manufactured from sheet metal these panels are supplied with a robust rear cable management tray for cable strain relief and neat cable dressing. Port numbering is provided on front and rear of the panel and individual ports may be color coded for site specific network administration.

The panel features the unique DataGate Category 6 connector which includes an integral ingenious springloaded shutter that not only protects it from dust and contaminants but it also ejects improperly seated patch cords. The DataGate connector is dual color coded for either 568A or 568B wiring and supports high-speed data transmission. The product is backwards compatible with C5e systems.

Molex recommends that the full range of PowerCat 6 products are used in a system to maximize cabling performance.

Features & Advantages

Available in 1U 24 Port and 2U 48 Port density
Robust rear cable management tray
Category 6 DataGate shuttered connector
Category 6 performance when installed as an end-to-end Category 6 system
RoHS compliant
Technical Information

Jack Connector

Plastic Housing: Polycarbonate, UL94V-0 rated or equivalent
Operating Life: : Minimum 750 insertion cycles
Contact Material: Copper Alloy
Contact Plating: 1.27 micrometers Au/Ni
Contact Force: 100g minimum
Plug Retention Force: 15 lbs
IDC Connector

Plastic Housing: Polycarbonate, UL94V-0 rated or equivalent
Operating Life: Minimum 200 reterminations
Contact Material: Copper Alloy
IDC Contact Plating: Tin matte finish
Contact Force: 100g minimum
Wire Accommodation: 22-24 AWG solid
Electrical

Interface Resistance: 20 m?
Initial Contact Resistance: 2.5 m?
Insulation Resistance: >100 M?

The CE 24 Port Cat6 Patch Panel meets all the current standards for Cat6. Termination is provided on the rear in the form of Krone Style IDC punchdown connectors. The panel also comes as standard with a detachable rear cable management bar.

Comes Complete with:
4x M6 cage nuts & bolts for fixing the panel in to a cabinet, coloured black to match the panel itself.
25x 80mm cable ties to aid with cable management.
4x Self adhesive plastic label holders c/w write on paper labels
1x Sheet of pre printed numbers 1-96
1x Termination instruction sheet
Features:

Durable lacquered steel front panel.
Tested to conform to all the current ANSI/TIA/EIA 568 B.2 standards.
Gold over Nickel plated jack contacts.
Phosphor Bronze & Nickel plated IDC terminals.
IDC terminals accept 22 to 26AWG solid and stranded wires.
Accessories
(Sold Separately)

Cat6 Patch Leads IDC Punchdown Tool Cat6 Solid Cable Cat6 Modules

This Through Coupler Panel provides 24 RJ45 Cat6 Ports. RJ45 sockets on the rear allow for termination without the need for any tooling.

CE patch panels comply with the current standards for enhanced Category 6. CE Cat6 patch panels are designed to minimise deployment time and maximise connection strength.

These panels are tested to conform to all the current ANSI/TIA/EIA 568 B.2 standards.

Comes Complete with: 4 x M6 Cage nuts & bolts for fixing in to a cabinet, coloured black to match the panel itself.
24 x 80mm Cable ties to aid cable management
Features

Comes supplied with an attachable rear cable management bar and mounting screws
Supports Gigabit Ethernet
RJ45 Ports front and rear
Through Coupler
Category 6
Ports numbered 1-24
Accessories
(Sold Separately)

Cat6 Patch Leads Cat6 Modules

Excel 24 Port Patch Panel Cat6 - 1u RJ45 UTP  Unscreened Twisted Pair.

Each panel has a screen printed labelling field positioned above each port, included with the panel is a pre printed self adhesive labelling sheet - pre numbered 1- 96, for fast and easy labelling on site. Termination can be made using LSA compatible tooling, cable tie bridges are positioned between the IDC blocks to relieve cable stress.

Installation can be further enhanced by use of the rear cable management tray which is attached quickly and easily to the panel without the need for fixings (included).

Features Category 6
Labelling Options
Backward Compatible
LSA Style Termination Blocks
Performance Overview

Excel Category 6 patch panels are manufactured to provide Category 6 channel performance. A range of parameters are tested in frequency sweeps up to and including 250 MHz.
The panel is also backward compatible with Category 5 and 5e components. Accessories
(Sold Separately)

Cat6 Patch Leads IDC Punchdown Tool Cat6 Solid Cable Cat6 Modules

Excel 24 Port Patch Panel Cat6 - 1u UTP Right Angled complies with the current standards for Category 6. Ease of installation is assured with built in rear cable management at a 90 degree angle to the panel fascia. Cage nuts and mini cable ties are included with each panel.

Features Category 6
Rear cable management
Labelling Options
Backward Compatible
Cage nuts and mini cable ties included
LSA Style Termination Blocks
T568A/B Wiring Configuration
Performance Overview

Excel Category 6 Patch Panels are manufactured to and tested to the current Category 6 standards as defined by the TIA/EIA and ISO standards’ bodies. Swept frequency tests are applied to each critical performance characteristic, such as near end cross talk (NEXT) and far end cross talk (FEXT). Both Worst Case and Power Sum Test methods are applied. Actual performance exceeds the required standard by a considerable margin ensuring sufficient headroom for even the most demanding applications.

Accessories
(Sold Separately)

Cat6 Patch Leads IDC Punchdown Tool Cat6 Solid Cable Cat6 Modules

Excel Category 6 Screened Patch Panels have been designed to meet or exceed the latest ISO and TIA requirements for category 6 compliance. Ease of installation is assured with built in rear cable management at a 90° angle to the panel fascia.

Each panel has a screen printed labelling field positioned above each port, included with the panel is a pre printed self adhesive labelling sheet - pre numbered 1- 96, for fast and easy labelling on site. Termination can be made using LSA compatible tools, and cable tie bridges are positioned between the IDC blocks to relieve cable stress. Each panel consists of a number of 8 way blocks of RJ45 sockets, housed in a high quality plastic moulding.

Features Category 6
Screened
Rear cable management
Min. life 750 Insertions
Backward Compatible
Cage nuts and mini cable ties included
LSA Style Termination Blocks
T568A/B Wiring Configuration
Performance Overview

Excel Category 6 Patch Panels are manufactured to and tested to the current Category 6 standards as defined by the TIA/EIA and ISO standards’ bodies. Swept frequency tests are applied to each critical performance characteristic, such as near end cross talk (NEXT) and far end cross talk (FEXT). Both Worst Case and Power Sum Test methods are applied. Actual performance exceeds the required standard by a considerable margin ensuring sufficient headroom for even the most demanding applications.

Accessories
(Sold Separately)

Cat6 Patch Leads IDC Punchdown Tool Cat6 Solid Cable Cat6 Modules
