This server rack is built to order and therefore is non-returnable.
These transport racks meet all EIA standards and are compatible with all the major OEMs such as Dell, HP, IBM and Cisco. The 24" (610 mm) deep transport rack is for installations that require a shallow depth such as audio and video equipment. The transport racks are available in 6U & 8U heights. The transport racks are completely shock isolated. These hard cases are warranted for life to the original owner.
Perfect for servers, storage, AV equipment
High, square holed, internal, aluminium frame
Shock isolated
Removable front & rear doors
6U, 8U Heights
Universal, square mounting holes
Mounting depths of 24 or 29" (610 or 737 mm)
L shaped rack posts
Dell, HP, IBM, Cisco compatible
Heavy Duty Casters sold separately
Technical Specifications -
Rack Units
6U or 8U
Rack Mount Depth
24" (609.6 mm)
29" (737 mm)
Weight Capacity
8U: 400 lbs (181.4 kgs)
6U: 300 lbs (136 kgs)
Rack Outside Dimensions
H x W x D (without casters)
8U, 29": 26.0 x 26.0 x 41.5" (660 x 660 x 1054 mm)
6U, 29": 18.5 x 26.0 x 41.5" (470 x 660 x 1054 mm)
8U, 24": 26.0 x 26.0 x 36.0" (660 x 660 x 914 mm)
6U, 24": 18.5 x 26.0 x 36.0" (470 x 660 x 914 mm)
Hole Type
EIA 3/8" square holes
Cable Management
Multiple wire tie points
Rack Post Shape
L-Shaped rack posts
Rack Ventilation
Front and rear doors must be removed for proper ventilation
Rack Doors
Doors are removable. No tools required
Rack Casters
Heavy Duty Casters are sold separately
Casters are a tool-less design, lockable and removable
Casters add 4.5" to height (114.3 mm)
Rack Construction
Internal aluminium and steel frame - external roto-molded plastic
Assembly Notes
Ships fully assembled
