Neomounts TV/Monitor Ceiling Mounts

Product Information The Neomounts by Newstar ceiling mount, model FPMA-C200 is a tilt- and swivel ceiling mount for flat screens up to 40”. This mount is a great choice for space saving placement or when wall mounting and floor placement is not an option.

Neomounts by Newstar's versatile tilt (180°), rotate (360°) and swivel (180°) technology allows the mount to change to any viewing angle to fully benefit from the capabilities of the flat screen. The support is easily height adjustable from 64 to 104 centimetres. An innovative cable management conceals and routes cables from ceiling to TV. Hide your cables in the column to keep it nice and tidy.

Neomounts by Newstar FPMA-C200 has two pivot points and is suitable for screens up to 40" (102 cm). The weight capacity of this product is 20 kg. The ceiling mount is suitable for screens that meet VESA hole pattern 75x75 to 200x200mm. Different hole patterns can be covered using Neomounts by Newstar VESA adapter plates.

All installation material is included with the product.

Product Specifications Min. screen size: 10 inch
Max. screen size: 40 inch
Min. weight: 0 kg
Max. weight: 20 kg
Screens: 1
VESA pattern: 75x75, 100x100, 100x200, 200x100, 200x200 mm
VESA minimum: 75x75 mm
VESA maximum: 200x200 mm
Type: Full motion, Tilt, Rotate, Swivel
Tilt (degrees): 180°
Swivel (degrees): 180°
Rotate (degrees): 360°
Depth: 9 cm
Height: 64 - 104 cm
Height adjustment: Manual
Article number: FPMA-C200
EAN: 8717371441364
Colour: Silver
Warranty: 5 year

Product Information The NewStar FPMA-C020BLACK is a tilt- and swivel ceiling mount for flat screens up to 40” (102 cm). This mount is a great choice for space saving placement or when wall mounting and floor placement is not an option.

NewStar's versatile tilt (90°) technology allows the mount to change to any viewing angle to fully benefit from the capabilities of the flat screen. The support is easily height adjustable from 26,5 to 40 centimetres. An innovative cable management conceals and routes cables from ceiling to TV. Hide your cables in the column to keep it nice and tidy.

NewStar FPMA-C020BLACK has one pivot point and is suitable for screens up to 40" (102 cm). The weight capacity of this product is 20 kg. The ceiling mount is suitable for screens that meet VESA hole pattern 75x75 or 200x200mm. Different hole patterns can be covered using NewStar VESA adapter plates.

All installation material is included with the product.

Product Specifications Min. screen size: 10 inch
Max. screen size: 40 inch
Min. weight: 0 kg
Max. weight: 20 kg
Screens: 1
VESA pattern: 75x200, 75x75, 100x100, 100x200, 200x100, 200x200 mm
VESA minimum: 75x75 mm
VESA maximum: 200x200 mm
Type: Full motion, Tilt, Swivel
Tilt (degrees): 90°
Height: 26,5 - 40 cm
Height adjustment: Manual
Article number: FPMA-C020BLACK
EAN: 8717371445690
Colour: Black
Warranty: 5 year

Overview The Neomounts FPMA-C340DBLACK is a full motion ceiling mount for 2 flat screens up to 75". The unique tilt (10°), swivel (360°) and rotate technology (6°) allows the mount to change to the best angle for the optimal viewing position.

The ceiling mount can be easily adjusted in height from 106 to 156 cm* and has a weight capacity of 50 kg (2x). The FPMA-C340DBLACK is suitable for screens that meet VESA hole pattern 100x100 to 400x400mm. A nifty cable management systems conceals and routes cables from ceiling to screen. The mount comes with an additional decorative cover for installation on suspended ceilings.

* The Neomounts NS-EP100BLACK is an extension pole for ceiling mount models NM-C440BLACK, NM-C440DBLACK, FPMA-C340BLACK and FPMA-C340DBLACK. This pole can be used as extra extension to the pole included with the models. In this way, the height of the ceiling mounts can be increased with an extra 107,5 cm.


Specifications General Screen Size Range: 32-75 Inch

Weight Capacity (Per Screen): 50KG

Screens: 2

Compatible VESA Patterns: 100x100, 200x100, 200x200, 300x300, 400x200, 400x300, 400x400 mm

Functionality Degree of Adjustment (Tilt, Swivel, Rotate): 10o, 360o, 6o

Height: 178.5cm

Adjustment Type: Manual

Information Colour: Black

Primary Material: Steel

Warranty: 5 Years
