Intel SAS Cables

Cable for 2U x8 systems to support SAS/SATA drives in front drive bay.

(1) 180 mm cable, connects SAS ROC module Mini SAS HD connector to HSBP Mini SAS HD Port 0-3 connector
(1) 250 mm cable, connects SAS ROC module Mini SAS HD connector to HSBP Mini SAS HD Port 4-7 connector

Cable for 1U and 2U systems to connect ROC modules.

(1) 385 mm cable, connects ROC module Mini SAS HD connector (LS) to HSBP Mini SAS HD connector (VT)
(2) 140 mm cable, connects ROC module Mini SAS HD connector (RS) to HSBP Mini SAS HD connector (RA)
