CE Patch Panels

CE patch panels comply with the current standards for enhanced Category 5e. CE 5e patch panels are designed to minimise deployment time and maximise connection strength. Each panel offers a choice of labelling systems to include both labelling fields with writable surface and separate identification strips are provided to allow further labelling where required.

Comes Complete with:
4 x M6 Cage nuts & bolts for fixing in to a cabinet, coloured black to match the panel itself.
4 x Cable management rings.
5 x 150mm Cable ties to aid cable management
4 x Self adhesive plastic label holders c/w write on paper labels
1 x Sheet of pre printed numbers 1 to 96
1 x Termination instruction sheet
Features:

Durable lacquered steel front panel.
Conforms to ANSI/EIA/TIA, ISO/IEC11801 and EN50173 Category 5e standard, FCC part 68 requirements.
Gold over Nickel plated jack contacts.
Phosphor Bronze & Nickel plated IDC terminals.
IDC terminals accept 22 to 26AWG solid and stranded wires.
Accessories
(Sold Separately)

Cat5e Patch Leads IDC Punchdown Tool Cat5e Solid Cable Cat5e Modules

This Through Coupler Panel provides 24 RJ45 Cat5e Ports. RJ45 sockets on the rear allow for termination without the need for any tooling.

CE patch panels comply with the current standards for enhanced Category 5e. CE 5e patch panels are designed to minimise deployment time and maximise connection strength.

These panels are tested to confirm to all the current ANSI/TIA/EIA 568 B.2 standards.

Comes Complete with: 4 x M6 Cage nuts & bolts for fixing in to a cabinet, coloured black to match the panel itself.
24 x 80mm Cable ties to aid cable management
Features

Comes supplied with an attachable rear cable management bar and mounting screws
Supports Gigabit Ethernet
RJ45 Ports front and rear
Through Coupler
Category 5e
Ports numbered 1-24
Accessories
(Sold Separately)

Cat5e Patch Leads Cat5e Modules

The design of this innovative right angled patch panel makes installation simple with the IDC termination blocks at 90 degrees to the panel. With built in cable management to the rear installtions can be kept clean and tidy.

CE patch panels comply with the current standards for enhanced Category 5e. CE 5e patch panels are designed to minimise deployment time and maximise connection strength. Each panel offers a choice of labelling systems to include both labelling fields with writable surface and separate identification strips are provided to allow further labelling where required.

Features:

Cable management system built into the rear
Durable lacquered steel front panel.
Conforms to ANSI/EIA/TIA, ISO/IEC11801 and EN50173 Category 5e standard, FCC part 68 requirements.
Gold over Nickel plated jack contacts.
Phosphor Bronze & Nickel plated IDC terminals.
IDC terminals accept 22 to 26AWG solid and stranded wires.
Accessories
(Sold Separately)

Cat5e Patch Leads IDC Punchdown Tool Cat5e Solid Cable Cat5e Modules

CE patch panels comply with the current standards for enhanced Category 5e. CE 5e patch panels are designed to minimise deployment time and maximise connection strength.

Comes Complete with:
4 x M6 Cage nuts & bolts for fixing in to a cabinet, coloured black to match the panel itself.
24 x 80mm Cable ties to aid cable management
Features:

2u 19 Inch Rackmount Panel
Durable lacquered steel front panel.
Conforms to ANSI/EIA/TIA, ISO/IEC11801 and EN50173 Category 5e standard, FCC part 68 requirements.
Gold over Nickel plated jack contacts.
Phosphor Bronze & Nickel plated IDC terminals.
IDC terminals accept 22 to 26AWG solid and stranded wires.
Accessories
(Sold Separately)

Cat5e Patch Leads IDC Punchdown Tool Cat5e Solid Cable Cat5e Modules

CE patch panels comply with the current standards for enhanced Category 5e. CE 5e patch panels are designed to minimise deployment time and maximise connection strength.

Comes Complete with:
4 x M6 Cage nuts & bolts for fixing in to a cabinet, coloured black to match the panel itself.
24 x 80mm Cable ties to aid cable management
Features:

1u High Density Design
Durable lacquered steel front panel.
Conforms to ANSI/EIA/TIA, ISO/IEC11801 and EN50173 Category 5e standard, FCC part 68 requirements.
Gold over Nickel plated jack contacts.
Phosphor Bronze & Nickel plated IDC terminals.
IDC terminals accept 22 to 26AWG solid and stranded wires.
Accessories
(Sold Separately)

Cat5e Patch Leads IDC Punchdown Tool Cat5e Solid Cable Cat5e Modules

The CE 24 Port Cat6 Patch Panel meets all the current standards for Cat6. Termination is provided on the rear in the form of Krone Style IDC punchdown connectors. The panel also comes as standard with a detachable rear cable management bar.

Comes Complete with:
4x M6 cage nuts & bolts for fixing the panel in to a cabinet, coloured black to match the panel itself.
25x 80mm cable ties to aid with cable management.
4x Self adhesive plastic label holders c/w write on paper labels
1x Sheet of pre printed numbers 1-96
1x Termination instruction sheet
Features:

Durable lacquered steel front panel.
Tested to conform to all the current ANSI/TIA/EIA 568 B.2 standards.
Gold over Nickel plated jack contacts.
Phosphor Bronze & Nickel plated IDC terminals.
IDC terminals accept 22 to 26AWG solid and stranded wires.
Accessories
(Sold Separately)

Cat6 Patch Leads IDC Punchdown Tool Cat6 Solid Cable Cat6 Modules

The CE 48 Port Cat6 Patch Panel meets all the current standards for Cat6. Termination is provided on the rear in the form of Krone Style IDC punchdown connectors.

Comes Complete with:
4 x M6 Cage nuts & bolts for fixing in to a cabinet, coloured black to match the panel itself.
24 x 80mm Cable ties to aid cable management
Features:

Durable lacquered steel front panel.
Tested to conform to all the current ANSI/TIA/EIA 568 B.2 standards.
Gold over Nickel plated jack contacts.
Phosphor Bronze & Nickel plated IDC terminals.
IDC terminals accept 22 to 26AWG solid and stranded wires.
Accessories
(Sold Separately)

Cat6 Patch Leads IDC Punchdown Tool Cat6 Solid Cable Cat6 Modules

The CE 48 Port Cat6 Patch Panel meets all the current standards for Cat6. Termination is provided on the rear in the form of Krone Style IDC punchdown connectors.

Comes Complete with:
4 x M6 Cage nuts & bolts for fixing in to a cabinet, coloured black to match the panel itself.
24 x 80mm Cable ties to aid cable management
Features:

1u High Density Design
Durable lacquered steel front panel.
Tested to conform to all the current ANSI/TIA/EIA 568 B.2 standards.
Gold over Nickel plated jack contacts.
Phosphor Bronze & Nickel plated IDC terminals.
IDC terminals accept 22 to 26AWG solid and stranded wires.
Accessories
(Sold Separately)

Cat6 Patch Leads IDC Punchdown Tool Cat6 Solid Cable Cat6 Modules

48 Port 2U category 5e Through Coupler Patch Panels offers RJ45 to RJ45 jack connectivity between the front and rear of the patch panel. The patch panel is ideal for providing a cross connect for network equipment with the simple fitting of patch cords rather than switch link looms.

Each panel has the port number screen printed below the port with an area to add the port identification above. The design lends itself for the easy application of a bespoke engraved label above and below the ports to suit the installation requirement. Cage nuts and machine screws are included with each panel.

This Through Coupler Panel provides 24 RJ45 Cat6 Ports. RJ45 sockets on the rear allow for termination without the need for any tooling.

CE patch panels comply with the current standards for enhanced Category 6. CE Cat6 patch panels are designed to minimise deployment time and maximise connection strength.

These panels are tested to conform to all the current ANSI/TIA/EIA 568 B.2 standards.

Comes Complete with: 4 x M6 Cage nuts & bolts for fixing in to a cabinet, coloured black to match the panel itself.
24 x 80mm Cable ties to aid cable management
Features

Comes supplied with an attachable rear cable management bar and mounting screws
Supports Gigabit Ethernet
RJ45 Ports front and rear
Through Coupler
Category 6
Ports numbered 1-24
Accessories
(Sold Separately)

Cat6 Patch Leads Cat6 Modules

These Category 6 Through Coupler Patch Panels comply with the EIA TIA Standard for Category 6 and are available in a choice of port density.

Each panel offers a choice of labelling with the option to use the screen printed fields on the panel facia or the slide label system which is enclosed with each panel. Ease of installation is assured with ample rear cable management positions.

Features:

• Independently verified to Category 6 standard
• Choice of Port Density
• Choice of Labelling System
• Lifetime Product Warranty
