Aten PG96230G 20A/16A 30-Outlet 3-Phase Switched eco PDU
ATEN PG96230 3-Phase Switched eco PDU series contains 6 x IEC 60320 C19 and 24 x IEC 60320 C13 outlets in a 0U rack enclosure.
ARM Cortex-A8 processor for flexible control methods via LAN / COM / USB / environmental sensor ports and enhanced monitoring via LCD console
Allows for connecting up to 64 PDU units with cascading
Energy-efficient relays allow operators to control large amounts of current flow for lower energy consumption
Precise kWh metering (+/-1% ) for better power consumption habits, baselines, and initiative tracking
With an ARM Cortex-A8 processor, the PG96230 series delivers flexible control methods through its LAN / COM / USB / environment sensor ports as well as powers up all connected equipment in less than 10 seconds once plugged in. For cost-saving and space-efficient setup purposes, the PG PDUs can be cascaded to connect up to 64 PDU units. As a result, these PDUs accommodate the increasing demand for power to high-density IT devices in server rooms and data centers.
In terms of hardware design, these PDUs have built-in energy-saving relays, a subtype of electromagnetic switch, to help operators control large amounts of current flow, which results in lower energy consumption compared to non-relay models incapable of energy saving.
With five colors (yellow, red, purple, blue, and green) of LCD console panel stickers available for users to choose from, differentiating between power feed settings and speeding up troubleshooting are made easier. Plus, the LCD console panel is hot-swappable and can be removed, replaced, or repaired without powering down a mission-critical connected load.
Ideal for enterprise servers, network closets, and data centers, the PG series is an intelligent power distribution and management solution that supports high-density IT applications while minimizing the overall cost.
Key Features
Each PG PDU comes with 6 x IEC 60320 C19 and 24 x IEC 60320 C13 outlets in a 0U rack enclosure
ARM Cortex-A8 processor for flexible control methods via LAN / COM / USB / environment sensor ports and enhanced monitoring via LCD console
Advantageous hardware / network specification
– 1 Gbps and 100 Mbps Ethernet ports
– Auto Ping & Reboot
– Remote Management Protocols: TCP/IP, UDP, HTTP, HTTPS, SSL, DHCP, SMTP, ARP, NTP, DNS, Auto Sense, Ping, SNMP V1&V2&V3, Telnet, Modbus (over TCP/IP), Wi-Fi, 802.11 a/b/g/n network protocols, and IPv6
– Alerts / Alarms: receives alarms via SNMP, SMTP, and syslog
– Scripting: JSON-RPC (Remote Procedure Call) protocol and Python scripting to control specified PDU unit (e.g. Switch On / Off) 1
– Security: 2-level account / password login access, and IP / MAC filter, TLS 1.2, SMTP / SMTPS protocols
– Authentication: LDAP, RADIUS, TACACS+
Expandable installation
– Allows for connecting up to 64 PDU units with cascading
– Allows for PON port connection to an ATEN's KN series KVM over IP switch for centralized management of up to 16 cascaded PDUs2
Energy-efficient relays allow operators to control large amounts of current flow for lower energy consumption
Precise kWh metering (+/-1% ) for better power consumption habits, baselines, and initiative tracking
Environment sensor port enables RJ-45 connectivity to connect or daisy-chain up to 8 environment sensors such as ATEN EA1640 for monitoring and management of temperature, humidity, airflow, differential air pressure, and leaks
Real-time LCD alert sends warnings to alert users of unusual power state
An adjustable power cord is built in to the unit capable of 90-degree rotation to allow flexible in-rack installation, resulting in better cable organization
Rotatable LCD Screen – capable of 180-degree rotation, delivering flexible in-rack installation
Secure locking enhancement prevents power cords from becoming unplugged due to vibration or human error
Supports ATEN’s eco DC (Energy & DCIM Management Web GUI) for monitoring power distribution, energy, and environmental data from PDUs and connected devices
Note:
1. To be included in a future firmware release.
2. To be included in a future firmware release.
Package Content
1 x Power Distribution Unit
1 x rack mount kit
1 x RJ-45 to DB-9 cable
1 x full-panel colored sticker
1 x user instructions
ECO DC Included free with Aten PDUs
The Eco DC energy tracking and reporting program is included at no additional cost with every ATEN PDU, providing users with valuable insights into energy consumption. This program enables real-time monitoring, detailed reporting, and efficient management of power usage, helping organizations optimize performance and reduce unnecessary energy waste—all without requiring extra investment.
Download ECO DC For Free Here
*Contact ATEN UK support for Serial Number to activate, via
[email protected]
Aten PG96330G 30A/32A 30-Outlet 3-Phase Switched eco PDU
ATEN PG96330 3-Phase Switched eco PDU series contains 6 x IEC 60320 C19 and 24 x IEC 60320 C13 outlets in a 0U rack enclosure.
ARM Cortex-A8 processor for flexible control methods via LAN / COM / USB / environmental sensor ports and enhanced monitoring via LCD console
Allows for connecting up to 64 PDU units with cascading
Energy-efficient relays allow operators to control large amounts of current flow for lower energy consumption
Precise kWh metering (+/-1% ) for better power consumption habits, baselines, and initiative tracking
With an ARM Cortex-A8 processor, the PG96330 series delivers flexible control methods through its LAN / COM / USB / environment sensor ports as well as powers up all connected equipment in less than 10 seconds once plugged in. For cost-saving and space-efficient setup purposes, the PG PDUs can be cascaded to connect up to 64 PDU units. As a result, these PDUs accommodate the increasing demand for power to high-density IT devices in server rooms and data centers.
In terms of hardware design, these PDUs have built-in energy-saving relays, a subtype of electromagnetic switch, to help operators control large amounts of current flow, which results in lower energy consumption compared to non-relay models incapable of energy saving.
Other highlights include the circuit breaker preinstalled onto the PG96330 models that support 30A / 32A current flow, which automatically switches off electricity supply to protect devices from overload or damage. With five colors (yellow, red, purple, blue, and green) of LCD console panel stickers available for users to choose from, differentiating between power feed settings and speeding up troubleshooting are made easier. Plus, the LCD console panel is hot-swappable and can be removed, replaced, or repaired without powering down a mission-critical connected load.
Ideal for enterprise servers, network closets, and data centers, the PG series is an intelligent power distribution and management solution that supports high-density IT applications while minimizing the overall cost
Key Features
Each PG PDU comes with 6 x IEC 60320 C19 and 24 x IEC 60320 C13 outlets in a 0U rack enclosure
ARM Cortex-A8 processor for flexible control methods via LAN / COM / USB / environment sensor ports and enhanced monitoring via LCD console
Advantageous hardware / network specification
– 1 Gbps and 100 Mbps Ethernet ports
– Auto Ping & Reboot
– Remote Management Protocols: TCP/IP, UDP, HTTP, HTTPS, SSL, DHCP, SMTP, ARP, NTP, DNS, Auto Sense, Ping, SNMP V1&V2&V3, Telnet, Modbus (over TCP/IP), Wi-Fi, 802.11 a/b/g/n network protocols, and IPv6
– Alerts / Alarms: receives alarms via SNMP, SMTP, and syslog
– Scripting: JSON-RPC (Remote Procedure Call) protocol and Python scripting to control specified PDU unit (e.g. Switch On / Off) 1
– Security: 2-level account / password login access, and IP / MAC filter, TLS 1.2, SMTP / SMTPS protocols
– Authentication: LDAP, RADIUS, TACACS+
Expandable installation
– Allows for connecting up to 64 PDU units with cascading
– Allows for PON port connection to an ATEN's KN series KVM over IP switch for centralized management of up to 16 cascaded PDUs2
Energy-efficient relays allow operators to control large amounts of current flow for lower energy consumption
Precise kWh metering (+/-1% ) for better power consumption habits, baselines, and initiative tracking
Environment sensor port enables RJ-45 connectivity to connect or daisy-chain up to 8 environment sensors such as ATEN EA1640 for monitoring and management of temperature, humidity, airflow, differential air pressure, and leaks
Real-time LCD alert sends warnings to alert users of unusual power state
An adjustable power cord is built in to the unit capable of 90-degree rotation to allow flexible in-rack installation, resulting in better cable organization
Rotatable LCD Screen – capable of 180-degree rotation, delivering flexible in-rack installation
Secure locking enhancement prevents power cords from becoming unplugged due to vibration or human error
Supports ATEN’s eco DC (Energy & DCIM Management Web GUI) for monitoring power distribution, energy, and environmental data from PDUs and connected devices
Note:
1. To be included in a future firmware release.
2. To be included in a future firmware release.
Package Content
1 x Power Distribution Unit
1 x rack mount kit
1 x RJ-45 to DB-9 cable
1 x full-panel colored sticker
1 x user instructions
ECO DC Included free with Aten PDUs
The Eco DC energy tracking and reporting program is included at no additional cost with every ATEN PDU, providing users with valuable insights into energy consumption. This program enables real-time monitoring, detailed reporting, and efficient management of power usage, helping organizations optimize performance and reduce unnecessary energy waste—all without requiring extra investment.
Download ECO DC For Free Here
*Contact ATEN UK support for Serial Number to activate, via
[email protected]
