APC Rack Air Distribution

This filter removes dust and other particles from the air before being delivered to the inlet of the rack mounted IT equipment.

Housing equipment with side-to-side airflow creates many challenges for IT and facility managers, particularly in regards to cooling. Because most enclosures are designed for a front to back airflow pattern, it is difficult to maintain ideal operating temperatures on side-to-side airflow equipment. The Rack Side Air Distribution Unit allows for greater security and organization by allowing racks to be placed adjacent to one another without impeding airflow.The Rack Side Air Distribution Unit is a 2U rack mountable air distribution product for networking equipment or servers with side-to-side airflow. It pulls in conditioned air from the front of the rack and distributes it to the side air intake of the networking equipment. This extends equipment life by providing proper inlet temperatures.This product is recommended for one or more networking products that are stacked consecutively in a rack. Rack Side Air Distribution Units may be placed above and/or below the networking equipment. Airflow pattern is user configurable via an interchangeable air turning vane. Features: Resettable circuit breakers
Dual A-B Power Inputs
Dual fans
Fan control switches
Mounting rails
Air turning vane
Resettable circuit breakers Enables a quick recovery from overload events
Dual A-B Power Inputs Draws power from the UPS for power protection with dual feeds for redundancy
Dual fans Provides fault tolerance in the event of a fan failure
Fan control switches Users can turn one or both fans on and off depending on the heat load
Mounting rails Adjustable depth allows the unit to fit APC NetShelter enclosures or other 19" EIA-310-D enclosures
Air turning vane Directs air up or down the side of the rack, supplying cool air to the inlet of side-to-side airflow equipment

The Rack Air Distribution Unit is a 2U fan unit that works with an existing precision air conditioning system to deliver cool air to the equipment contained in a rack enclosure. The Rack Air Distribution Unit connects into the raised floor and pulls supply air directly into the enclosure. This prevents the conditioned air from mixing with warmer room air before reaching the equipment. The Rack Air Distribution Unit minimizes temperature differences between the top and bottom of the enclosure. It also prevents hot exhaust air from re-circulating to the inlet of the enclosure. The product is recommended for rack enclosures with loads greater than 1.5kW and can provide airflow for loads up to 3.5kW. It is also ideal for enclosures in raised floor environments where under floor air distribution is inadequate.This Air Distribution Unit is designed for Power Dense Enclosures and Low Pressure Areas. Features: Promotes Proper Airflow
Fan guards
Dual A-B Power Inputs
Dual fans
Fan control switches
Mounting rails
Promotes Proper Airflow Helps to maintain proper rack temperatures within the enclosure by promoting top to bottom airflow movement
Fan guards A safety measure that provides protection from the fan opening by covering the inlet
Dual A-B Power Inputs Draws power from the UPS for power protection with dual feeds for redundancy
Dual fans Provides fault tolerance in the event of a fan failure
Fan control switches Users can turn one or both fans on and off depending on the heat load
Mounting rails Adjustable depth allows the unit to fit APC NetShelter enclosures or other 19" EIA-310-D enclosures

ACF126 Features APC Rack Air Removal Unit SX Ducting Kit 24 inch

Air distribution systems for power dense racks and low pressure areas

Includes : Installation Guide

Replacement ceiling tile Fits into a standard drop ceiling to provide a connection point for the ducting kit. (Not available on the 1.6kW unit).
Rack Air Distribution Features & Benefits Agility Easy to install Innovative design allows for fast, easy installation by almost anybody.
Availability Increases Airflow Provides proper intake temperatures, increasing equipment life.

ACF127 Features APC Air Removal Unit Ducting Kit 600mm

Air distribution systems for power dense racks and low pressure areas

Includes : Installation Guide

Replacement ceiling tile.
Fits into a standard drop ceiling to provide a connection point for the ducting kit. (Not available on the 1.6kW unit).
Rack Air Distribution Features & Benefits Agility Easy to install Innovative design allows for fast, easy installation by almost anybody.
Availability Increases Airflow Provides proper intake temperatures, increasing equipment life.

AR7725 Features Side Airflow Duct Kit for Cisco Nexus® 7009, 750mm Wide Enclosures

Ease of Use - Simplifies future planning by allowing side to side equipment to be placed anywhere in the data center.
Enclosure system compatible - Specifically designed to work with Netshelter Enclosures.
Increases Airflow - Provides proper intake temperatures, increasing equipment life.
Isolation of hot and cold aisle - Unique design delivers cold air to the intake and isolation of hot and cold aisle ensuring cooler intake temperatures, increasing equipment life.
Tested and Approved Solution for Cisco Nexus® 7009 - The Side Airflow Duct Kit for Nexus 7009 and NetShelter® SX Networking Enclosures have been tested and approved by Cisco® for supporting Nexus 7009 datacenter networking switches and Schneider Electric is listed as an approved vendor in the Nexus 7000 Series Site Preparation Guide.
Rack Air Distribution Features & Benefits Agility Easy to install - Innovative design allows for fast, easy installation by almost anybody.
Availability Increases Airflow - Provides proper intake temperatures, increasing equipment life.

Unique design delivers cold air to the intake and isolation of hot and cold aisle ensuring cool intake temperatures, increasing equipment life. Features: Increases Airflow
Facilitates overhead cable management
Fiber management
Ventilated
Isolation of hot and cold aisle
Ease of Use
Cable Access
Joining capability
Large cable access areas
Tested and Approved Solution for Cisco Nexus 7018
Enclosure system compatible
Increases Airflow Provides proper intake temperatures, increasing equipment life
Facilitates overhead cable management Overhead cable troughs and partitions install toollessly on the roof of the enclosure eliminating the need for ceiling mounted or underfloor mounted cable trays. Cable troughs and partitions are designed to manage both power and data cables while maintaining separation
Fiber management Supports toolless installation of AR8444 fiber spools
Ventilated Perforated front and rear doors provide ample ventilation for rack-mount equipment
Isolation of hot and cold aisle Unique design delivers cold air to the intake and isolation of hot and cold aisle ensuring cooler intake temperatures, increasing equipment life
Ease of Use Simplifies future planning by allowing side to side equipment to be placed anywhere in the data center
Cable Access Large cable access slots in the roof provides access for overhead cable egress. The bottom design allows for unobstructed cable access through a raised floor
Joining capability Enclosures include pre-installed joining hardware to join enclosures in a row and provide additional stability to the enclosure
Large cable access areas Increased cable capacity and manageability for high density cable entry/exit from the enclosure
Tested and Approved Solution for Cisco Nexus 7018 The Side Airflow Duct Kit for Nexus 7018 and NetShelter SX 1200-mm Deep Networking Enclosure have been tested and approved by Cisco for supporting Nexus 7018 datacenter networking switches and Schneider Electric is listed as an approved vendor in the Nexus 7000 Series Site Preparation Guide
Enclosure system compatible Specifically designed to work with Netshelter Enclosures

Unique design delivers cold air to the intake and isolation of hot and cold aisle ensuring cooler intake temperatures, increasing equipment life.Increased cable capacity and manageability for high density cable entry/exit from the enclosure.Overhead cable troughs and partitions install toollessly on the roof of the enclosure eliminating the need for ceiling mounted or underfloor mounted cable trays. Cable troughs and partitions are designed to manage both power and data cables while maintaining separation. Features: Increases Airflow
Facilitates overhead cable management
Fiber management
Ventilated
Isolation of hot and cold aisle
Ease of Use
Cable Access
Joining capability
Large cable access areas
Tested and Approved Solution for Cisco Nexus 7018
Enclosure system compatible
Increases Airflow Provides proper intake temperatures, increasing equipment life
Facilitates overhead cable management Overhead cable troughs and partitions install toollessly on the roof of the enclosure eliminating the need for ceiling mounted or underfloor mounted cable trays. Cable troughs and partitions are designed to manage both power and data cables while maintaining separation
Fiber management Supports toolless installation of AR8444 fiber spools
Ventilated Perforated front and rear doors provide ample ventilation for rack-mount equipment
Isolation of hot and cold aisle Unique design delivers cold air to the intake and isolation of hot and cold aisle ensuring cooler intake temperatures, increasing equipment life
Ease of Use Simplifies future planning by allowing side to side equipment to be placed anywhere in the data center
Cable Access Large cable access slots in the roof provides access for overhead cable egress. The bottom design allows for unobstructed cable access through a raised floor
Joining capability Enclosures include pre-installed joining hardware to join enclosures in a row and provide additional stability to the enclosure
Large cable access areas Increased cable capacity and manageability for high density cable entry/exit from the enclosure
Tested and Approved Solution for Cisco Nexus 7018 The Side Airflow Duct Kit for Nexus 7018 and NetShelter SX 1200-mm Deep Networking Enclosure have been tested and approved by Cisco for supporting Nexus 7018 datacenter networking switches and Schneider Electric is listed as an approved vendor in the Nexus 7000 Series Site Preparation Guide
Enclosure system compatible Specifically designed to work with Netshelter Enclosures

Vertical Exhaust Duct (VED) system for NetShelter SX is a low cost easy to install solution that mounts to the top rear of NetShelter enclosures to capture and return hot exhaust air to room cooling systems. Features: Increased capacity
Ducted Exhaust System
Efficiency
Optional sensors
Increased capacity Higher rate of heat removal allows more equipment to be installed in each rack
Ducted Exhaust System Removes hot air from the data center to prevent re-circulation and eliminate air mixing
Efficiency Increases the capacity of the air conditioner by supplying a warmer return air temperature
Optional sensors Add sensors to compatible NetBotz Appliances for monitoring temperature, humidity, fluid, vibration, dust particles, etc

Vertical Exhaust Duct (VED) system for NetShelter SX is a low cost easy to install solution that mounts to the top rear of NetShelter enclosures to capture and return hot exhaust air to room cooling systems. Features: Increased capacity
Ducted Exhaust System
Efficiency
Optional sensors
Increased capacity Higher rate of heat removal allows more equipment to be installed in each rack
Ducted Exhaust System Removes hot air from the data center to prevent re-circulation and eliminate air mixing
Efficiency Increases the capacity of the air conditioner by supplying a warmer return air temperature
Optional sensors Add sensors to compatible NetBotz Appliances for monitoring temperature, humidity, fluid, vibration, dust particles, etc

Vertical Exhaust Duct (VED) system for NetShelter SX is a low cost easy to install solution that mounts to the top rear of NetShelter enclosures to capture and return hot exhaust air to room cooling systems. Features: Increased capacity
Ducted Exhaust System
Efficiency
Optional sensors
Increased capacity Higher rate of heat removal allows more equipment to be installed in each rack
Ducted Exhaust System Removes hot air from the data center to prevent re-circulation and eliminate air mixing
Efficiency Increases the capacity of the air conditioner by supplying a warmer return air temperature
Optional sensors Add sensors to compatible NetBotz Appliances for monitoring temperature, humidity, fluid, vibration, dust particles, etc

Vertical Exhaust Duct (VED) system for NetShelter SX is a low cost easy to install solution that mounts to the top rear of NetShelter enclosures to capture and return hot exhaust air to room cooling systems. Features: Increased capacity
Ducted Exhaust System
Efficiency
Optional sensors
Increased capacity Higher rate of heat removal allows more equipment to be installed in each rack
Ducted Exhaust System Removes hot air from the data center to prevent re-circulation and eliminate air mixing
Efficiency Increases the capacity of the air conditioner by supplying a warmer return air temperature
Optional sensors Add sensors to compatible NetBotz Appliances for monitoring temperature, humidity, fluid, vibration, dust particles, etc

AR7755 Features Overhead Cable Extension 600mm Wide / Vertical Exhaust Duct Kit for SX Enclosure

Overhead Cable Extension for Vertical Exhaust Duct (VED) provides two cable routing access holes with integrated brush strips for routing data and power cabling from the rear of the enclosure to the overhead cable management system without interfering with valuable U-space.

Includes : Brush strips, Cable extension panels, Grommets

Cable access brush strip - Blocks air from escaping through holes surrounding cabling.
Efficient cable management - Organizes the routing of cables, which simplifies maintenance or future expansion.
Facilitates overhead cable management - Overhead cable troughs and partitions install toollessly on the roof of the enclosure eliminating the need for ceiling mounted or underfloor mounted cable trays. Cable troughs and partitions are designed to manage both power and data cables while maintaining separation.
Rack Air Distribution Features & Benefits Agility Easy to install - Innovative design allows for fast, easy installation by almost anybody.
Availability Increases Airflow - Provides proper intake temperatures, increasing equipment life.

AR7756 Features Overhead Cable Extension 750mm Wide / Vertical Exhaust Duct Kit for SX Enclosure

Overhead Cable Extension for Vertical Exhaust Duct (VED) provides two cable routing access holes with integrated brush strips for routing data and power cabling from the rear of the enclosure to the overhead cable management system without interfering with valuable U-space.

Includes : Brush strips, Cable extension panels, Grommets

Cable access brush strip - Blocks air from escaping through holes surrounding cabling.
Efficient cable management - Organizes the routing of cables, which simplifies maintenance or future expansion.
Facilitates overhead cable management - Overhead cable troughs and partitions install toollessly on the roof of the enclosure eliminating the need for ceiling mounted or underfloor mounted cable trays. Cable troughs and partitions are designed to manage both power and data cables while maintaining separation.
Rack Air Distribution Features & Benefits Agility Easy to install - Innovative design allows for fast, easy installation by almost anybody.
Availability Increases Airflow - Provides proper intake temperatures, increasing equipment life.

AR8207BLK Features Roof Fan Tray 208/230V 50/60HZ for NetShelter WX Enclosures

The Rack Fan Tray is a low cost solution that aids in heat removal from a Netshelter Enclosure. The system easily installs into the top of the enclosure and expels heat from the roof of the rack. Wall-mounted enclosures have the additional option of installing the rack fan tray systems in the base of the rack as well. The fan trays are designed to promote bottom to top airflow within the enclosure.

Includes : Installation Guide , Qty 1 - IEC to IEC 320 Power Cord

Fan guards - A safety measure that provides protection from the fan opening by covering the inlet.
Occupies 1U of rack space - Conserve valuable rack space in the data center.
Rack Air Distribution Features & Benefits Agility Easy to install Innovative design allows for fast, easy installation by almost anybody.
Availability Increases Airflow Provides proper intake temperatures, increasing equipment life.
The AR8207BLK fan tray can be installed in the roof, base, or both for increased ventilation within the NetShelter WX Wall-Mounted Enclosure. Each tray takes up 1U of equipment mounting space. The unit ships with two fans providing a total of 220 cfm airflow. Features: Fan guards
Occupies 1U of rack space
Fan guards A safety measure that provides protection from the fan opening by covering the inlet
Occupies 1U of rack space Conserve valuable rack space in the data center
