Our datacel 27U 800 x 1000mm server cabinet / rack is specifically designed for housing all of your companies communication requirements in a single cabinet providing adequate ventilation, security and cable management for the following equipment (typically installed):-
Servers
UPS’s
Telephone Systems
Structured Cabling
19 inch Equipment (such as Switches)
Features On Glass Door Cabinet:
Lockable/Removable Glass Front Door
Available in Grey White (RAL 9002) or Black (RAL 9004)
Lockable/Removable Steel Side and Rear Panels
19 Inch Adjustable Mounting Profiles Front and Rear
Vented Top Cover (for use with a Roof Fan Unit if necessary)
Heavy Duty Lockable Castors and Jacking Feet Included
600kg Load Capacity
Can be Bayed with or Without Side Panels (Baying Kit Included)
Swing Handle Lock fitted to glass front door and Barrel Lock fitted to rear Steel Door
Features On Mesh Door Cabinet:
Wave Design Mesh Front Door
Available in Grey White (RAL 9002) or Black (RAL 9004)
Swing Handle 2 Point Lock fitted to Front Door
Swing Handle 3 Point Lock fitted to Rear Doors
Wardrobe Style Double Mesh Rear Doors
19 Inch Adjustable Mounting Profiles Front and Rear
Vented Top Cover (for use with a Roof Fan Unit if neccessary)
Heavy Duty Lockable Castors and Jacking Feet Included
600kg Load Capacity
Can be Bayed with or Without Side Panels (Baying Kit Included)
70% Ventilation Front and Rear Doors
A range of shelves, fan trays and other accessories are also available to complete the installation of this quality cabinet.
Accessories are available on the following pages:
PDU's
Shelves
Environmental Monitoring
Cable Management
Other Accessories
Other Options and Accessories:
Console Drawers and KVM Solutions
UPS Solutions
A Complete Range of Switches
Patch Panels Modules and Patch Cables
Jacking Feet and castors can be fitted simultaneously
Multiple brush strip cable entry in roof and base
Removable Side Panels
Swing handle 2 point lock fitted to front door
High Density Cable Management
Below we have listed the most common ranges of servers, these are all compatable with our datacel cabinets. Servers are usually mounted with Chasis runners (rack) or shelves (tower)
Cisco UCS Rack servers
Dell Poweredge tower servers
Dell Poweredge rackmount servers
Fujitsu Primergy TX tower servers
Fujitsu Primergy RX rack servers
HP ProLiant BL servers
HP ProLiant DL servers
HP ProLiant ML servers
IBM System X tower servers
IBM System X rackmount servers
Lenovo tower servers
Lenovo rack servers
If you are unsure about your server fitting into our cabinets please call us on 0800 488 0000
Product Specification
U Height
27u
External Height
1490mm
External Width
800mm
External Depth
1000mm
Mounting Profile Width
19”
Max Load
600 Kg
Mounting Profiles Position/s
Front & Rear
Front Door
Mesh (Lockable), Glass (Lockable)
Construction
Bolted
Side Panels
Solid
Cable Entry
Top and Bottom
Ventilation
Passive
Removable Panels
Front Door, Rear Door, Side Panels
Lock Positions
Front Door, Rear Door, Side Panels
Colour Options
Black (RAL 9004) or Grey White (RAL 9002)
