3 Compartment Floor Boxes

Raised floor boxes

Accessory plate options available 185mm x 76mm
Cable management at exit
Low profile 80mm
Easy grip recessed lifting handle
Compact design 266mm  x 212mm
20mm & 25mm knock-outs
Tough galvanised lid insert
Raised floor boxes are used to connect the sub-floor to the desk via the raised floor itself, power and data are separated into compartments and fed out under a purpose built lid. Custom accessory plates can be made to order, such as red power plates used to distinguish separate power supplies.

Fixing brackets and floor template are supplied with each unit.

Floor Box Accessories

Blanking Plate
Solid plate to fit 3 compartment floor box
Plate size 76mm x 185mm

Floor Box Accessories

Euromod plate

2 x Euro 50mm x 50mm frames (complete)
To fit 3 compartment floor boxes
Fits up to 4 x 25x50mm Modules
Plate size 76mm x 185mm

Floor Box Accessories

High density, 3 way power outlet


Features

High density design
Unswitched
To fit 3 compartment floor boxes
Plate Size 76mm x 185mm

Floor Box Accessories

Twin switched UK twin earth power plate

Features

Switched
Dual earth as standard
To fit 3 compartment floor boxes
Plate size 76mm x 185mm

Floor Box Accessories

High density plate allowing up to 4 RJ45 LJ6C outlets to be mounted

Features

4 x Apertures 22mm x 37mm
Suits standard LJ6C modules
To fit 3 compartment floor boxes
Plate size 76mm x 185mm

Floor Box Accessories

High density plate allowing up to 6 RJ45 LJ6C outlets to be mounted

Features

6 x Apertures 22mm x 37mm
Suits standard LJ6C modules
To fit 3 compartment floor boxes
Plate size 76mm x 185mm
