| Part No: | SB-8856VNN3361 |
| Manufacturer No: | 8856VNN3361 |
| Delivery: | In Stock: 2-3 Weeks |
 |
The Schleifenbauer 8856VNN3361 is a custom-engineered PDU designed to support large-scale IT infrastructure with precision and control. Featuring 48 power outlets in a compact double-horizontal frame, it enables seamless deployment in high-density racks without compromising airflow or space. With optional remote monitoring and outlet-level switching, it offers the insight and flexibility needed for modern power management strategies.
Constructed from black aluminum with stainless steel covers, rated at IP20 for protection in standard environments.
Toolless mount buttons support fast installation with designated bracket positions.
Three-phase power input rated at 32 A, 230/400V - 50Hz, ensures reliable high-capacity operation.
Equipped with 12 x IEC 60320 C19 and 36 x IEC 60320 C13 outlets to accommodate a wide range of device connections.
Includes six hydraulic-magnetic 16A breakers to safeguard connected equipment from overloads and faults.
*For complete specifications please see the documentation tab above.
Starting April 2025, Schleifenbauer is introducing the PDU 5.0, a cutting-edge Power Distribution Unit (PDU) crafted through collaboration with over 40 data centre operators. This next-generation PDU, paired with EnerTree software, is designed to address the unique challenges of modern data centres. Perfectly suited for the high demands of Artificial Intelligence (AI), High-Performance Computing (HPC), and Machine Learning (ML), the PDU 5.0 provides enhanced energy management and performance optimisation. With this solution, data centres can expect reliable, scalable power distribution, advanced monitoring, and seamless adaptability to the evolving digital landscape.
The PDU 5.0 by Schleifenbauer streams live data from the PDU, offering real-time monitoring of power usage and environmental factors. This provides instant access to critical data, allowing you to respond immediately to changes and prevent potential issues, contributing to a more stable and reliable IT environment.
With the ability to manage up to 100 PDUs through a single IP address, the PDU 5.0 minimises network management complexity. This saves time and reduces operational costs, enabling data centre managers to work more efficiently.
The integrated LED ring provides a quick visual status display of the PDU, allowing administrators to instantly understand the PDU's status and detect any alerts or issues. This feature makes routine checks faster and simpler.
Using the Rack PDU Display app and NFC technology, you can easily access PDU data without the need for a physical display on the PDU itself. This adds flexibility, eliminates a vulnerable component, and allows for secure, rapid local access to PDU measurement data.
With encryption and specific access settings, the PDU 5.0 ensures secure data exchange within your data centre, keeping sensitive information well-protected.
The PDU 5.0 comes equipped with EnerTree software, enabling advanced energy management with monitoring, reporting, and alert features.
The software supports various devices, including third-party PDUs, UPS systems, cooling equipment, and sensors, making it an all-in-one solution for data centre managers.
