Excel Cat6A Cable S/FTP PE External SWA Fca 500m Black

Engineered for maximum resilience in extreme conditions, the Excel Cat6A S/FTP Armoured External Grade Cable delivers robust network performance in demanding environments such as marine vessels, offshore platforms, and industrial sites. This heavy-duty solution combines multiple layers of screening, shielding, and armouring to ensure reliable data transmission while maintaining mechanical protection from external elements.

Key Features:

• Class EA (Augmented Cat6A) compliant – supports 10GBASE?T, 10 Gigabit Ethernet
• 23AWG solid conductors with foam PE insulation for high signal integrity
• Individually screened pairs with AL/Mylar foil and drain wire
• Overall aluminium magnesium wire braiding for complete S/FTP shielding
• Galvanized steel wire braiding armour provides mechanical protection
• External-grade PE outer jacket with LSZH inner layer
• 500m drums for large-scale deployment
• Compatible with Metal Gland item 750-095 for grounding and bonding at entry points

Durable Construction for Extreme Applications

Designed for harsh installation environments, the cable’s structure incorporates multiple layers of foil shielding and wire braiding to defend against EMI and maintain data integrity. The steel wire braid armour adds vital mechanical protection, making it suitable for marine and offshore deployments.

Optimized Performance Architecture

Each of the four twisted pairs is wrapped with aluminum/polyester foil, ensuring both separation and protection. Differentiated lay lengths further minimize crosstalk, guaranteeing consistent Cat6A performance up to 90 meters for bandwidth-heavy applications.

External Grade, Internal Compliance

While built for the outside, the cable maintains compliance with international standards including ISO, CENELEC, and TIA. The inner LSZH layer provides additional safety, reducing smoke and toxicity in enclosed areas.

Secure Building Entry Point

The cable is compatible with Metal Gland item 750-095 to facilitate proper bonding of the steel wire armour when transitioning into internal infrastructure, ensuring safe and standards-compliant installations.
