    Excel Cat7A Cable S/FTP Eca LS0H 500m Reel - Yellow
    500mt Drum - Low Smoke Zero Halogen

    The Excel Category 7A Screened S/FTP LSOH Cable is designed and manufactured to meet and exceed the ISO, CENELEC and TIA standards. This delivers Class FA link and channel performance supporting all applications detailed and proposed within the standards. This superior performance cable is ETL Component Verified.

    Each cable consists of 4 pairs individually wrapped in a covering of high quality, strong, aluminium/polyester foil tape providing an individual screen for each pair. These sub units are then cabled together, with the pairs set to different lay lengths to nsure optimum performance, an overall braid screen is applied to provide further immunity to outside noise and to mitigate any risk of alien cross talk.

    Excel Category 7A cables are jacketed in a yellow low smoke zero halogen (LSOH) flame retardant compound. Supplied on 500 metre plywood drums, each cable has a print legend identifying the specification, part code and sequential.

    • Category 7A compliant
    • Specified to 1000MHz
    • Individual foil pairs with overall braid screen
    • Supplied on 500m reels
    • Low Smoke Zero Halogen Jacket
    • High Performance Design
    • CPR Compliant to Eca
    Material & Construction
    Conductor Materials Cu, bare
    Size 23 AWG
    Insulation Materials Foam-Skin-PE
    Colour Blue/White
    Jacket Materials LSOH (Copolymer, thermoplastic)
    Diameter Nominal 7.8mm
    Colour Yellow
    Construction S/FTP
    No. of Cores 8
    Conductor category Class 1 = Solid
    Reaction-to-fire class according to EN 13501-6 Eca
    Category 7A (IEC)
    Overall screening Braiding
    Conductor screening Foil
