Blustream HMXL44ARC-KIT 4x4 HDBaseT™ CSC AV Matrix - 70m

The Blustream HMXL44ARC-KIT 4x4 HDBaseT™ CSC AV Matrix is a versatile AV distribution system designed to route four HDMI sources to four HDBaseT™ outputs with a local HDMI output. It supports 4K UHD 60Hz 4:4:4 with HDR, along with Smart Scaling to allow displays with lower resolution support to receive compatible video while maintaining full resolution on other outputs.

The Matrix also provides advanced features including simultaneous HDBaseT™/HDMI on output 1, video Smart Scaling on HDBaseT outputs and independent 14x4 audio matrix including Audio Return Channel (ARC). The HMXL44ARC includes in-built web browser interface module for control and configuration of the Matrix and RS-232 and IR pass through to enable seamless 3rd party control integration.

Key Features of BlueStream HMXL44ARC-KIT

• Advanced HDBaseT™ technology offering distribution of video and audio over a single CAT cable
• Advanced Colour Space Conversion (CSC) supports HDMI 2.0 18Gbps specification including HDR
• Features 4 x HDMI inputs which can be independently routed to 4 x HDBaseT™ outputs
• Output 1 features simultaneous HDMI and HDBaseT™ output
• Video Smart Scaling on HDBaseT™ outputs allowing a display only capable of supporting lower video resolutions (4K 60Hz 4:2:0 or 1080p) to receive 4K 60Hz 4:4:4 video content while still showing maximum original 4K UHD resolution on remaining video outputs
• Supports 4K 60Hz 4:4:4 UHD video up to 40m and 1080p video up to 70m
• 14x4 Audio Matrix independently controllable from video. Audio source inputs include:
  • 4x audio breakout from HDMI source inputs
  • 4x audio breakout from zone outputs
  • 4x ARC from zone outputs
  • 1x Optical and 1x Analogue audio input
• Supports bitstream passthrough of multichannel surround sound including object-based audio formats in line with HDMI specifications
• Web interface module for control and configuration of matrix
• Supports bi-directional IR and RS-232 on all HDBaseT™ outputs
• Control via front panel, IR, iOS / Android App, RS-232 and TCP/IP
• Supports PoC (Power over Cable) to power compatible HDBaseT™ receivers
• Supplied with Blustream IR receivers and emitters
• Advanced EDID management and HDCP 2.2 compliant
• Supplied with 4x RX70CS HDBaseT Receivers

*ARC feature supports HDMI ARC or Optical ARC
*CSC and ARC Feature compatible with RX70CS only

Flexible Installation

Slimline design with included receivers allows clean integration into professional AV setups, reducing cable clutter and simplifying installation in multi-room or multi-display environments.

Control & Integration

Supports comprehensive control methods including web interface, front panel, IR, RS-232, TCP/IP, and mobile apps. Compatible with third-party control systems, allowing seamless integration into larger AV systems.
