| Product Code: | |
| Options: | |
| Qty: | |
| Unit Price: | £ |
| Part No: | LIN42817 |
| Manufacturer No: | 42817 |
| Delivery: | In Stock: Next Day |
 |
The Lindy USB 2.0 Active Extension Cable Slim uses built-in active electronics to extend the cable length of a USB 2.0 device by an additional 5m whilst continuing to support data transfer rates of up to 480Mbps.
With its USB A male and USB A female connector it allows Type A devices to be connected at longer distances and ensures flexible positioning. Up to 5 extension cables can be chained together to achieve a distance of 25m.
The cable's unique and slim design allows the active electronics to fit into a standard USB connector - an advantage over other active USB leads which use bulky connectors. Compatible with all USB Type A equipped computers.
Specifications
Technical Information
| Connectors | |
| Connector A | USB Type A Male |
| Connector B | USB Type A Female |
| Housing Material | Plastic |
| Connector Plating | Nickel |
| Pin Construction | Brass |
| Pin Plating | Gold |
| Power | - |
|
Dimensions (approx.) WxDxH |
USB A Male: 15x40x6mm (0.59x1.57x0.24in) USB A Female: 15x45x8mm (0.59x1.77x0.31in) |
| Cable Construction | |
| Lengths Available | 0.5m, 1m, 3m and 5m |
| Colour | Black |
| Standard | USB 2.0 |
| Jacket Diameter | 4.8mm (0.19in) |
| Jacket Material | PVC |
| Conductor Material | Tinned Copper |
| Conductor Gauge | 24AWG+28AWG |
| Type | Round |
| Shielding | AL Mylar |
| Specifications | |
| Supported Bandwidth | 480 Mbps |
| Maximum Resolution | - |
| Nominal Attenuation: | 24AWG: 93.25Ohm/km 28AWG: 237.25Ohm/km |
| Minimum Bend Radius | 48mm (1.89in) |
| Maximum Tensile Load | - |
| Transmission Medium | Twisted Pair |
| Transmission Technology | USB 2.0 |
| Operating Temperature | 0°C - 70°C |
| Storage Temperature | -10°C - 80°C |
The Lindy USB 2.0 Active Extension Cable Slim uses built-in active electronics to extend the cable length of a USB 2.0 device by an additional 5m whilst continuing to support data transfer rates of up to 480Mbps.
With its USB A male and USB A female connector it allows Type A devices to be connected at longer distances and ensures flexible positioning. Up to 5 extension cables can be chained together to achieve a distance of 25m.
The cable's unique and slim design allows the active electronics to fit into a standard USB connector - an advantage over other active USB leads which use bulky connectors. Compatible with all USB Type A equipped computers.
Specifications
Technical Information
| Connectors | |
| Connector A | USB Type A Male |
| Connector B | USB Type A Female |
| Housing Material | Plastic |
| Connector Plating | Nickel |
| Pin Construction | Brass |
| Pin Plating | Gold |
| Power | - |
|
Dimensions (approx.) WxDxH |
USB A Male: 15x40x6mm (0.59x1.57x0.24in) USB A Female: 15x45x8mm (0.59x1.77x0.31in) |
| Cable Construction | |
| Lengths Available | 0.5m, 1m, 3m and 5m |
| Colour | Black |
| Standard | USB 2.0 |
| Jacket Diameter | 4.8mm (0.19in) |
| Jacket Material | PVC |
| Conductor Material | Tinned Copper |
| Conductor Gauge | 24AWG+28AWG |
| Type | Round |
| Shielding | AL Mylar |
| Specifications | |
| Supported Bandwidth | 480 Mbps |
| Maximum Resolution | - |
| Nominal Attenuation: | 24AWG: 93.25Ohm/km 28AWG: 237.25Ohm/km |
| Minimum Bend Radius | 48mm (1.89in) |
| Maximum Tensile Load | - |
| Transmission Medium | Twisted Pair |
| Transmission Technology | USB 2.0 |
| Operating Temperature | 0°C - 70°C |
| Storage Temperature | -10°C - 80°C |
Product data is provided by Icecat, we do not warrant the accuracy of the material above.
