| Product Code: | |
| Options: | |
| Qty: | |
| Unit Price: | £ |
| Part No: | FEGXP1615 |
| Manufacturer No: | GXP1615 |
| Delivery: | In Stock: Next Day |
 |
The baseline of Grandstream Basic IP phones, the GXP1615 is for a user who needs easy and streamlined access to communications. With its clear and distinct user interface and essential features and functionalities the GXP1615 is intuitive and dependable.
The GXP1615 Basic IP phone delivers a user-friendly and intuitive communication experience for users who need only essential VoIP access. Complete with 1 line, 2 call appearances and a 132x48 LCD screen, the GXP1615 is equipped for dependable phone access. The phone also offers 3 XML programmable soft keys and dual 10/100 mbps ports with PoE for a flexible user experience.
As all Grandstream IP phones do, the GXP1615 features state-of-the-art security encryption technology (SRTP and TLS). The GXP1615 supports a variety of automated provisioning options, including zero-configuration with Grandstream’s UCM series IP PBXs, encrypted XML files and TR-069, to make mass deployment extremely easy.
Features:
Basic IP Phone Comparison
 |
 |
 |
 |
|
| Model | GXP1615 | GXP1620/1625 | GXP1628 | GXP1630 |
| Lines | 2 Lines, 1 SIP Account | 2 Lines, 2 SIP Accounts | 2 Lines, 2 SIP Accounts | 3 Lines, 3 SIP Accounts |
| Conferencing | 3-Way | 3-Way | 3-Way | 4-Way |
| Phonebook Size | 500 | 500 | 500 | 500 |
| Soft Keys | 3 XML Programmable Keys | 3 XML Programmable Keys | 3 XML Programmable Keys | 3 XML Programmable Keys |
| Display | 132 x 48 Pixel LCD | 132 x 48 Pixel Back-Lit LCD | 132 x 48 Pixel Back-Lit LCD | 132 x 64 Pixel Back-Lit LCD |
| BLF/Fast-Dial Keys | No | No | 8 | 8 |
| HD Audio | No | Yes | Yes | Yes |
| Auxiliary Ports | RJ9, EHS | RJ9, EHS | RJ9, EHS | RJ9, EHS |
| PoE | Yes | GXP1620 - No GXP1625 - Yes |
Yes | Yes |
| Network Ports | 2 × 10/100 Network Ports | 2 × 10/100 Network Ports | 2 × 10/100 Network Ports | 2 × 10/100 Network Ports |
| Voice Codecs | G.729A/B, G.711u/a-law, G.726, G.722, G.723, iLBC, DTMF | |||
| Security | SIP/TLS, SRTP, AES-256, 802.1x | |||
| Provisioning | HTTP, HTTPS, TFTP, TR-069, XML | |||
| Power Supply Included | Yes | Yes | Yes | Yes |
| Buy | Buy GXP1620 | Buy | Buy | |
| Buy GXP1625 | ||||
Specifications
| Protocols/Standards | SIP RFC3261, TCP/IP/UDP, RTP/RTCP, HTTP/HTTPS, ARP/RARP, ICMP, DNS (A record, SRV, NAPTR), DHCP, PPPoE, SSH, TFTP, NTP, STUN, SIMPLE, LLDPMED, LDAP, TR-069, 802.1x, TLS, SRTP |
| Network Interfaces | Dual switched auto-sensing 10/100 Mbps Ethernet ports, integrated PoE |
| Graphic Display | 132 x 48 (2.95’’) LCD display |
| Feature Keys | 2 line keys with dual-colour LED and 1 SIP account, 3 XML programmable context sensitive soft keys, 5 (navigation, menu) keys. 13 dedicated function keys for PAGE/INTERCOM, PHONEBOOK, MESSAGE, HOME, HOLD, RECORD, MUTE, HEADSET, TRANSFER, CONFERENCE, SEND and REDIAL, SPEAKERPHONE, VOLUME |
| Voice Codecs | Support for G.711µ/a, G.722 (wide-band), G.723,G.726-32, G.729 A/B, iLBC , in-band and out-of-band DTMF (In audio, RFC2833, SIP INFO), VAD, CNG, AEC, PLC, AJB, AGC |
| Telephony Features | Hold, transfer, forward (unconditional/no-answer/busy), 3-way conferencing, call park/pickup, downloadable phone book (XML, LDAP, up to 500 items), call waiting, call history (up to 200 records), off-hook auto dial, auto answer, click-to-dial, flexible dial plan, hot desking, personalised music ringtones, server redundancy & fail-over |
| Headset Jack | RJ9 headset jack (allowing EHS with Plantronics headsets) |
| Base Stand | Yes, 2 angled positions available, wall mountable |
| QoS | Layer 2 QoS (802.1Q, 802.1P) and Layer 3 (ToS, DiffServ, MPLS) QoS |
| Security | User and administrator level access control, MD5 and MD5-sess based authentication, 256-bit AES encrypted configuration file, TLS, SRTP, HTTPS, 802.1x media access control |
| Power & Green Energy Efficiency | Universal Power Supply Input 100-240VAC 50-60Hz; Output +5VDC, 600mA |
| Physical Dimension: | 209mm (L) x 184.5mm (W) x 76.2mm (H) (with handset) Unit weight: 0.74kg; Package weight: 1.1kg |
| Package Content | GXP1615 phone, handset with cord, base stand, universal power supply, network cable, Quick Installation Guide, brochure, GPL License |
The GXP1615 Basic IP phone delivers a user-friendly and intuitive communication experience for users who need only essential VoIP access. Complete with 1 line, 2 call appearances and a 132x48 LCD screen, the GXP1615 is equipped for dependable phone access. The phone also offers 3 XML programmable soft keys and dual 10/100 mbps ports with PoE for a flexible user experience.
As all Grandstream IP phones do, the GXP1615 features state-of-the-art security encryption technology (SRTP and TLS). The GXP1615 supports a variety of automated provisioning options, including zero-configuration with Grandstream’s UCM series IP PBXs, encrypted XML files and TR-069, to make mass deployment extremely easy.
