100G QSFP28 to QSFP28 Direct Attach Cable - Passive

100G QSFP28 to QSFP28 Passive Copper Cable assemblies are suitable for very short distances and offer a highly cost-effective way to establish a 100-Gigabit link between QSFP+ ports of QSFP+ switches within racks and across adjacent racks. These cables are used for 100GbE and lnfniband standards, to maximize performance.

QSFP+ are designed to meet emerging data center and high performance computing application needs for a high density cabling interconnect system capable of delivering an aggregate data bandwidth of 100Gb/s. This interconnect system is fully compliant with existing industry standard specifications such as the QSFP MSA and IBTA (lnfiniBand Trade Association). The QSFP+ cables support the bandwidth transmission requirements as defined by IEEE 802.3ba (100 Gb/s) and lnfiniband QDR ( 4x25 Gb/s per channel) specifications.

Features

• Connector A: 1 x QSFP28 1 00Gbps Data Rate (SFF-8665 Compliant)
• Connector B: 1x QSFP28 100Gbps Data Rate (SFF-8665 Compliant)
• 4-Channel Full-Duplex Passive Copper Cable Transceiver
• Support data rates: 25.78Gb/s (per channel)
• IEEE 802.3bj 100GEBASE-CR4
• 12C based two-wire serial interface for easy control and monitoring
• Low cross-talk and pair-to-pair skew maintains signal integrity
• Enjoy a reduced power budget and lower port cost compared to optical
• Operating temperature: 0-70°C
• Fully RoHS compliant for environmental protection

Applications

• 100 Gigabit Ethernet
• Fiber Channel over Ethernet
• Data storage and communication industry
• Switch/ router/ HBA
• Data Center networking
