Aten Extension Cables and Ports

Overview The UE250 allows users to extend the distance between the computer and USB devices up to 5m via the dynamic extension cord. USB signals transmitted through them to maintain optimal signal integrity and meet the USB 2.0 standard.





Package Contents 1x USB 2.0 Extender Cable
1x User Instructions




Features Extends the distance to your USB device up to 5m (16')
USB specification version 2.0 compliant
Fully compliant with USB Electrical and Timing Specs for USB Hubs
USB IF Approved
No power adapter required
Multiplatform support : Windows, Mac

Overview The VE066 Mini Cat 5 DVI Extender allows you to increase the distance between your DVI display and DVI source by up to 20 m using only one Cat 5e or Cat 6 cable, providing a convenient way to replace heavy and expensive DVI cables. With hot-plugging support, easily add or remove the VE066 Transmitter connected to the source or the VE066 Receiver connected to the display without having to power down the devices. Compatible with all ATEN DVI switches and DVI splitters, the VE066 Mini Cat 5 DVI Extender is a compact, convenient and economical way to extend your DVI display.





Package Contents 1x VE066T Mini Cat 5 DVI Extender (Transmitter)
1x VE066R Mini Cat 5 DVI Extender (Receiver)
1x User Instructions




Features Extends the distance between DVI source and DVI display
Uses Cat 5e cable to connect the Transmitter and Receiver units
Long distance transmission - up to 20 m*
HDCP 1.1 Compliant
Supports hot-plugging
Superior video quality - up to 1920 x 1200
Compact housing
Compatible with all ATEN DVI switches and DVI splitters
Supports LCD Screen, Plasma TV, and projectors
Perfect for Home entertainment system, Bank, Surveillance system, Outdoors multimedia display, Airport, Finance institution
Smart Video Display - Image quality is optimized based on the available resolution of the output device
Non-Powered

Overview As USB 3.0 devices are getting popular, the demand for extending the distance covered by USB devices is growing notably. ATEN’s UE350A USB 3.0 Extender Cable not only extends the distance for the USB devices up to 5 meters, but also delivers a throughput of up to 5 Gbps when used in conjunction with a USB 3.0 host and device – an astounding increase that is ten times the capability of USB 2.0.

In addition to its robust speed and transfer rate, the UE350A also provides a durable, high quality connection that harnesses the full capability of the USB 3.0 standard; at the same time, it is backwards compatible with USB 2.0 and 1.1 to ensure reliable data communication. With UE350A, extending the distance of your USB 3.0 device is quick and easy, making it an ideal addition to your USB system setups.





Package Contents 1x UE350A USB 3.0 Extender Cable




Features Extends the distance of one USB device up to 5 m (16ft)
USB 3.0, 2.0 and 1.1 compatible
Built-in USB 3.0 Hub IC – fully supports hot swapping for a variety of USB 1.1/2.0/3.0 devices
Supports USB super-speed (5 Gbps)
Plug and play – no additional software installation required
Multiplatform support – Windows and Mac
Non-powered *

Overview The UE2120 allows users to extend the distance between a computer and USB device up to 12 meters via the active extender cable. USB signals transmitted through these cables maintain optimal signal integrity and meet USB 2.0 standards.

The UE2120 features a unique lockable mechanical design that securely links the male and female ends of the USB cable, ensuring stable connection between cables. Up to 5 extender cables can be chained together, so that cable distance is increased by up to 60 meters.





Package Contents 1x 1-Port USB 2.0 Extender Cable




Features Extends the distance to your USB device(s) up to 12 meters (36’)
USB specification version 2.0 / 1.1 compliant
Plug and play - No additional driver required
Up to 5 extender cables can be chained for a distance of up to 60 meters
Lockable mechanical design for secure connection
Bus powered. No power adapter required
Multiplatform support – Windows, Mac

Overview UCE60 lets you locate your USB device or hub up to 60m (198 ft) from you computer, overcoming the typical USB cable limitation. It conditions the USB signals to communicate up to 60m using low-cost Cat 5/Cat 5e/Cat 6 cable.





Package Contents 1x Local Unit (1 ft USB Cable attached)
1x Remote Unit




Features USB 2.0 full speed compliant
Provides support for any full-speed (12Mb/s) or low-speed (1.5Mb/s) USB devices
Extends the transmission distance of a USB device up to 60m (198 ft) using Cat 5/ Cat 5e/ Cat 6 cabling
Embedded USB Transceivers prevent signal loss
Lowest cost solution for extending USB signals
No additional installation software required
LED indicates when additional external power supply needed
Multiplatform support: Windows, Mac

Overview The UE2120H allows users to extend the distance between a computer and USB device(s) up to 12 meters via the active extender hub. USB signals transmitted through these cables maintain optimal signal integrity and meet USB 2.0 standards. Up to 4 extender cables (UE2120) and 1 Extender Hub (UE2120H) can be chained together, so that cable distance is increased by up to 60 meters.



Package Contents 1x 4-Port USB 2.0 Extender Hub


Features Extends the distance to your USB device(s) up to 12 meters (36’)
4 Downstream USB 2.0 ports
USB specification version 2.0 / 1.1 compliant
Plug and play - No additional driver required
Up to 4 extender cables (UH2120) and 1 Extender Hub (UH2120H) can be chained for a distance of up to 60 meters
Bus powered. No power adapter required
Multiplatform support – Windows, Mac

Aten VE800A HDMI Extender; using Cat 5e/6 cable 40m for 1080p; 60m for 1080i (HDTV); Compliant with HDMI 1.3b

Overview The VE810 HDMI Extender extends your HDMI display up to 60 m from your HDMI source device using two Cat 5e cables. In addition, VE810 is equipped with IR signaling pass-through which allows the IR channel to control from the remote to local unit, to control the HDMI source, or from the local to remote unit, to control the display device.

For flexibility and convenience, the VE810 setup requires only one power adapter for both units. The VE810R remote unit will function without the need of an additional power adapter because it will be powered by the VE810 local unit.





Package Contents 1x VE810L (Local Unit) HDMI Extender
1x VE810R (Remote Unit) HDMI Extender
1x Power Adapter (Local Unit)
1x Mounting Kit
1x User Instructions
1x IR Receiver
1x IR Transmitter




Features Connects the local and the remote units via Cat 5e cables
HDMI (3D, Deep Color); HDCP 1.1 compliant
Superior video quality – up 1920 x 1080 at distance up to 40 m
Bi- directional IR channel for IR signal control on remote unit; IR transmission is processed one direction at a time
8 segment equalization adjustment switch optimizes display quality
Supports Dolby True HD and DTS HD Master Audio
DDC compatible
Compatible with all ATEN HDMI switches and splitters
Non-Powered (only require one power adapter)
Rack-mountable

Overview UCE260 can easily send the USB signals via Cat.5/5e/6 cable up to 60 meters (196 ft) at data rate of High Speed (480Mb/s) , Full Speed (12Mb/s) and Low Speed (1.5Mb/s). Without any configuration or software driver, this USB extender allows you to extend your USB device or hub up to 60m from your computer, which overcomes the typical USB cable limitation.





Package Contents 1x Local Unit with USB Cable
1x Remote Unit
1x Power Adapter (5V, 2.6A)
1x User Instructions




Features Supports any High-Speed (480Mb/s), full-speed (12 Mb/s) or low-speed (1.5 Mb/s) USB devices
Extends signal transmission distance of a USB devices up to 60m via a Cat 5/5e/6 cable
Includes an AC adapter to stabilize power supply
Hot-Pluggable
The most cost-effective USB extender solution
No additional software driver required

Overview The ATEN UE3310 USB 3.1 Gen1 Extender Cable allows users to extend the distance between the computer and USB devices up to 10 m. The UE3310 provides a reliable, high performance data transmission that utilizes USB 3.1 Gen1 data bandwidth up to 5Gb/s and also backward compatible with USB 2.0/1.1 standard. It’s plug and play and no additional software installation required, easy to deploy and operate on the fields.

The UE3310 provides a quick and high quality cost effective solution for all kinds of professional environments like: hospitals, factories, or business facilities.





Package Contents 1x UE3310 USB 3.1 Gen1 Extender Cable
1x AC Power Adapter
1x USB Extension Cable




Features Supports USB 3.1 Gen1 Specification (5 Gbps)
Ultra slim design and unique locker head design
Daisy-chainable, maximum distance of up to 50 m
Multiplatform support – Windows and Mac
Additional power adapter included

Overview The VE803 HDMI USB Extender extends an HDMI signal up to 60 meters from the HDMI source using two Cat 5e cables. It is capable of sending 1080i signals up to 60 meters and 1080p signals up to 40 meters.

The VE803 is equipped with USB connectors which allow you to extend any USB device between the units. The USB feature also provides support for touch panel control, allowing you to control the local HDMI source device from the remote display, or control the remote display through the local unit.

The VE803 is ideal for transportation centers, medical facilities, shopping malls or anywhere touch panel control or a kiosk is required. For flexibility and convenience, the VE803 local unit can be powered via the USB cable when connected to an appropriate source device. The VE803 is HDCP compliant, providing an easy and ideal HDMI extender solution for any application.





Package Contents 1x VE803T HDMI USB Extender
1x VE803R HDMI USB Extender
1x Power Adapter
1x USB Cable (1.8 m)
1x Mounting Kit
1x User Instructions




Features Uses two Cat 5e cables to connect the local and the remote units
Extends 1080p by 40m; extend 1080i by 60m
Superior video quality – HDTV resolutions of 480p, 720p, 1080i, 1080p (1920 x 1080), VGA, SVGA, XGA, SXGA, UXGA and WUXGA (1920 x 1200)
Supports USB touch panel
8 segment equalization adjustment switch optimizes display quality
Support Dolby True HD and DTS HD Master Audio
Built-in 8KV/15KV ESD protection
Transparent USB Support – supports all USB 2.0 full speed device (up to 12 Mbps)
Supports wide screen formats
HDMI (3D, Deep Color); HDCP compatible – signaling rates up to 2.25Gbits
Powered local unit via USB cable

Aten VE600A DVI Video Extender with Cat5 STP Cable up to 30m (with Audio Support)

Overview VE150A video extender comprises a local transmitting unit and a remote receiving unit which are connected by standard Cat 5e cables. The distance of both units can be extended up to 150m. It is ideal for factories and construction sites, or any location where the display may need to expose in a risky setting, but you want the system to be kept in a safe location.





Package Contents 1x VE150AT Video Extender (Local unit)
1x VE150AR Video Extender (Remote unit)
2x Power Adapters
1x VGA Cable (1.8m/6ft)
1x Mounting Kit
1x User Instructions




Features Uses Cat 5e cables to connect the local and remote units
Supports one local and one remote display
Long distance transmission – up to 150 m
Adjustable gain control – manually adjust signal strength to compensate for distance
Superior video quality – up to 1920x1200 (30 m);1600x1200 (100 m); 1280x1024 (150 m)
Supports VGA, XGA, SVGA, UXGA, WUXGA, and multisync monitors
Supports wide screen formats
Supports hot-plugging
Built-in 8KV/15KV ESD protection
Supports DDC for the local monitor
Easy installation
Rack Mountable
Plug-and-play – no software installation required

Overview The VE606 DVI Over Cat 5 Extender Wall Plate extends DVI and audio signals up to 60m using Cat 5e cable. It supports popular wide screen formats and ensures excellent video quality over long distance transmissions. The VE606 combination can further extend the distance or multiply sources/displays.

The VE606 can be powered at either the Transmitter or Receiver side, and uses a second Cat 5e cable to transmit the power signal. The VE606’s compact wall plate design does away with bulky cables and allows a neat and convenient installation. It is an ideal solution for function rooms, museums and any environment that requires equipment or cabling to be kept hidden from public view.





Package Contents 1x VE606T DVI Over Cat 5 Extender Wall Plate
1x VE606R DVI Over Cat 5 Extender Wall Plate
1x Terminal Block Connector
1x Power Adapter
1x User Instructions




Features Uses two Cat 5e cables to connect the local and remote units – one to transmit video and audio; and another for power*
Remotely powered from either the Transmitter or Receiver side**
Extends the distance between DVI source and DVI display
Superior video quality – up to 1920 x 1200@40m; 1280 x 1024@60m
8 segment equalization adjustment switch optimizes display quality
Supports wide screen formats
Supports hot-plugging
Decora type design is easily configurable to fit various wall plates
LED indication of power sources / connection status
Supports stereo audio
Built-in 8KV/15KV ESD protection
Easy installation
Wall mountable type for a neat and cleaner installation
Plug-and-play – no software installation required

Overview The UCE3250 4-port USB 2.0 Cat 5 Extender is a two-unit device that serves as a USB hub and a USB extender. The UCE3250 unit can connect as many as 4 USB peripherals from up to 50 meters away from your computer over a Cat 5 / 5e / 6 Ethernet cable.

The UCE3250 transmits data through signal packages with better compatibility and preserves the integrity of the data over long distances. The power supply at the remote UCE3250 unit helps provide sufficient power to any type of USB device, such as flash drives, keyboards, mice, webcams, scanners, or printers, etc.

With its durable metal housing, this high-quality USB extender provides a fast and flexible solution for industrial applications. In addition, the compact size and integrated wall mounting enables space-saving installation.





Package Contents 1x UCE3250L 4-port USB 2.0 CAT 5 Extender (Local unit)
1x UCE3250R 4-port USB 2.0 CAT 5 Extender (Remote unit)
1x USB Type-A Male to Type-B Male Cable
1x Power Adapter
1x User lnstructions




Features High-Speed USB 2.0 compliant with a data transfer rate of up to 480 Mbps
Extension distance of up to 50m over a Cat 5/5e/6 cable
Receives up to 4 USB peripherals of all types – flash drives, keyboards, mice, webcams, scanners, printers and more
Metal mechanical with wall mount design supports industrial deployment
Supports Windows®, OS X®, and Linux®
Plug- and- play

Overview The VE022 Mini Cat 5 A/V Extender allows you to extend the distance between your video/audio source and display devices by as much as 150 meters, using a Cat 5e cable, providing an easy way to replace heavy and expensive VGA cables. With hot-plugging support, you can quickly add or remove the VE022 transmitter/receiver connected to the source/display device without having to power down devices.

The VE022 Mini Cat 5 A/V Extender is a compact, convenient and economical addition to your video/audio setup.





Package Contents 1x VE022T Mini Cat 5 A/V Transmitter
1x VE022R Mini Cat 5 A/V Receiver
1x Power Adapter
1x VGA Cable (35 cm)
1x Audio Cable (40 cm)
1x Dock Mount kit
1x User Instructions
1x USB to DC Power Cord




Features Uses Cat 5e cable to extend audio and video transmission up to 150 m
Superior video quality – screen resolutions include 1920 x 1200@60Hz(30 m), 1600 x 1200@60Hz(100 m) and 1280 x 1024@60Hz(150 m)
Adjustable Gain Control lets you manually adjust signal strength to compensate for distance
Audio enabled (mono)
Convenient docking interface for mounting the VE022 on the display device
Eliminates the need for bulky VGA cables
Easy installation

Overview The VE156 VGA Over Cat 5 Extender Wall Plate extends VGA and audio signals up to 150m using Cat 5e cable. It supports popular wide screen formats and ensures excellent video quality over long distance transmissions. The VE156 combination can further extend the distance or multiply sources/displays.

The VE156 can be powered at either the Transmitter or Receiver side, and uses a second Cat 5e cable to transmit the power signal. The VE156’s compact wall plate design does away with bulky cables and allows a neat and convenient installation. It is an ideal solution for function rooms, museums and any environment that requires equipment or cabling to be kept hidden from public view.





Package Contents 1x VE156T VGA Over Cat 5 Extender Wall Plate
1x VE156R VGA Over Cat 5 Extender Wall Plate
1x Terminal Block Connector
1x Power Adapter
1x User Instructions




Features Uses two Cat 5e cables to connect the local and remote units – one to transmit video and audio; and another for power*
Remotely powered from either the Transmitter or Receiver side**
Extends the distance between VGA source and VGA display
Superior video quality – up to 1920 x 1200@60Hz (30 m), 1280 x 1024@60Hz (150m)
Adjustable Gain Control – manually adjusts signal strength to compensate for distance
Supports wide screen formats
Supports hot-plugging
Decora type design is easily configurable to fit various wall plates
LED indication of power sources / connection status
Supports stereo audio
Built-in 8KV/15KV ESD protection
Easy installation
Wall mountable type for a neat and cleaner installation
Plug-and-play – no software installation required

Overview The VE602 DVI Dual Link Extender with Audio extends your DVI display up to 60 m away from your DVI source using Cat 5e cables. The use of Cat 5e cables provides a simple and reliable connection method that takes advantage of the wiring system in most modern office buildings.

The VE602 incorporates ATEN's technology that allows A/V signals to be transmitted over one Cat 5e cable. It uses ATEN default EDID, but is able to learn and save the EDID configuration of the remote display. For dual link video signals, simply use a second Cat 5e cable.

With support for stereo audio and popular widescreen video formats, the VE602 provides crystal-clear image and sound quality for installations where remote DVI video displays are required.





Package Contents 1x VE602T DVI Dual Link Extender with Audio
1x VE602R DVI Dual Link Extender with Audio
2x Power Adapters
1x Mounting Kit
1x User Instructions




Features Extends the distance between the DVI source and DVI display device
Long distance transmission – up to 60 m
Uses Cat 5e cable to connect the local and remote units
Employs ATEN EDID technology that allows signal transmission over one Cat 5e cable
Uses a second (Sub) Cat 5e cable for dual link signals*
Supports EDID Learning – Automatically learns and saves the EDID data of the display to which the Transmitter (VE602T) is connected
Superior video quality – DVI Dual Link up to 2560 x 1600 @ 60 Hz (40 m); DVI Single Link up to 1920x1200 @ 60 Hz (40 m), 1024 x 768 @ 60 Hz (60 m)
Audio enabled
8 segment equalization adjustment switch optimizes display quality
Built-in 8KV/15KV ESD protection
Supports widescreen formats
Rack mountable

Aten VE607 Wall Plate DVI /Audio Cat 5 Extender,30M Remote Powering

Aten VE157 Wall Plate VGA /Audio Cat 5 Extender,30M Remote Powering

Overview The VE170 VGA / Audio Cat 5 Extenders, consisting of a transmitter (VE170T) and receiver (VE170R), are cost-effective and efficient solutions for sending and receiving high quality audio/video content over long distances. Simply connect the transmitter to the receiver via one Cat 5e cable, and a VGA display or projector can be located up to 300 m (1000 ft) away from the video source.

The VE170 VGA / Audio Cat 5 Extenders provides a flexible solution which is ideal for any professional A/V installation that requires multimedia content to be delivered over a long distance.





Package Contents 1x VE170T + VE170R VGA/Audio Cat 5 Extender
1x VGA/Audio Cable (1.8m)
2x Power Adapters
1x Mounting Kit
1x User instructions




Features Connects a transmitter and receiver via Cat 5e cable
Long distance transmission - up to 1920 x 1200@30m; 1024 x 768@300m
Supports one local and one remote VGA display
Long distance transmissions – up to 300 m
Adjustable Gain Control – signal strength can be manually adjusted via video gain or video compensation tuners
Audio supported (mono)
Built-in ESD protection
Rack-mountable

Overview The VE170Q package consists of a transmitter (VE170T) and receiver (VE170RQ), which includes ATEN’s patented Deskew™ technology that supports resolutions up to 1280 x 1024 @ 300 m, and features manual synchronization of the RGB signals and correction of color phase and timing errors that occur over long distances.

The VE170Q VGA / Audio Cat 5 Extenders provides a flexible solution which is ideal for any professional A/V installation that requires multimedia content to be delivered over a long distance.



Package Contents 1x VE170T + VE170RQ VGA/Audio Cat 5 Extender
1x VGA/Audio Cable (1.8m)
2x Power Adapters
1x Mounting Kit
1x User instructions


Features Connects a transmitter and receiver via Cat 5e cable
Long distance transmission - up to 1920 x 1200@150m; 1280 x 1024@300m
Supports one local and one remote VGA display
Long distance transmissions – up to 300 m
Deskew™ – automatically synchronizes the time delay of RGB signals to compensate for distance
Adjustable Gain Control – signal strength can be manually adjusted via video gain or video compensation tuners
Audio supported (mono)
Built-in ESD protection
Rack-mountable

Overview The VE801 HDMI HDBaseT-Lite Extender extends an HDMI signal up to 70m from the HDBaseT source using one Cat 5e/6/6a cable. It supports HDMI features that include 3D, Deep Color and 4K image resolutions, plus Dolby Digital 5.1, DTS HD audio and it is HDCP compatible. The VE801 all-in-one design provides an easy method for mounting the device in any location. The side panel provides slip-resistant grooves that help prevent accidental drops when installing the unit. The grooves also enhance the ability to see the LED status lights. The VE801 is perfect for digital entertainment centers or any installation that requires superior HDMI video quality to be extended for great distances.



Package Contents 1x VE801T/R HDMI HDBaseT-Lite Extender
2x Power Adapters
1x User Instructions


Features Extends HDMI signals over a single Cat 5e/6/6a cable or ATEN 2L-2910 Cat 6 cable
HDMI (3D, Deep color, 4K); HDCP 2.2 compliant
Superior video quality – up to 4K@35m (Cat 5e/6) / 40m (Cat 6a or ATEN 2L-2910 Cat 6 cable)
HDBaseT Anti-jamming – resists signal interference during high-quality video transmission using HDBaseT technology
Plug-and-play
Rack-mountable

Overview The VE601 DVI HDBaseT-Lite Extender is able to extend a DVI 1080p display up to 70 m using an Ethernet cable. This combination of ATEN and HDBaseT technology even supports sharing 1920 x 1200 media up to 40 m away, offering a simple, adaptable, and cost-effective solution for any professional A/V installation.

The VE601 DVI HDBaseT-Lite Extender is the perfect solution for professional A/V installations that require video signal interference protection, such as in medical and military installations. With its lightweight and easy-to-mount design, not to mention slip-resistant DC Jack lock mechanism, the VE601 can be installed nearly anywhere while ensuring peace of mind with its unerring reliability.



Package Contents 1x VE601T/R DVI HDBaseT-Lite Extender
2x Power Adapters
1x User Instructions


Features HDBaseT Connectivity – extends a DVI 1080p connection up to 70 meters via a single Cat 6a/ATEN 2L-2910 Cat 6 cable
DVI (3D, Deep color); HDCP 1.4 compliant
Superior video quality –1920 x 1200@35m (Cat 5e/6) / 40m (Cat 6a); 1080p@60m(Cat 5e/6) / 70m (Cat 6a)
HDBaseT Anti-Jamming – resists signal interference during video transmission using HDBaseT technology
Plug-and-play
Rack-mountable

Overview The UCE32100 is a 4-port USB 2.0 CAT 5 Extender is a two-unit device that serves as a Transmitter and a Receiver. It provides a durable, high quality connection that harnesses the full capability of the USB 2.0 standard, to ensure reliable data communication.

The UCE32100 can extend the USB transmission distance of up to 100 meters from your computer via a Cat 5 Ethernet cable. The power supply at the receiver UCE32100 unit helps provide sufficient power to any type of USB device, such as POS, flash drives, webcams, scanners, or printers, etc.

A true plug-and-play solution, the UCE32100 is compatible with all leading operating systems. With its durable metal housing, this high-quality USB extender provides a fast and flexible solution for industrial applications. In addition, the compact size with wall mounting and din rail included enables space-saving installation.



Package Contents 1x UCE32100T USB 2.0 CAT 5 Transmitter
1x UCE32100R USB 2.0 CAT 5 Receiver
1x USB 2.0 Type-A Male to Type-B Male Cable
1x Power Adapter
1x Power Cord
4x Mounting Kit
2x Din Rail
2x DC Jack Lock Kit
2x Rubber Feet Sets
1x User Instructions


Features True USB 2.0 transparent extension over CAT 5 cabling up to 100 meters
Supports all USB 2.0 devices up to 480Mbps
USB Lossless – Higher compatibility of remote USB devices
An integrated four port hub allows for extension of up to four USB devices without the need for an additional hub
Power supply for remote unit to ensure power delivery to multiple devices at once
Compact size with wall mounting and din rail included for flexible installation
DC jack lock kit included to ensure durable power adapter connection
Supports Windows®, OS X®, and Linux®
Plug-and-play

Overview The UEH4102 4-port USB 2.0 Extender over LAN incorporates patented ExtremeUSB® technology that enables users to extend beyond the standard 5 meter cable limit for USB peripheral devices.

UEH4102 provides true USB 2.0 extension at up to 480 Mbps across a Gigabit Ethernet Local Area Network (LAN). The Local and Remote units are pre-paired with each other through MAC address – no pairing action required during installation.

A true plug-and-play solution, the UEH4102 is compatible with all leading operating systems, and supports all USB peripherals, such as keyboards, mice, interactive white boards, flash drives, hard drives, audio devices, web cameras and any other USB device. The UEH4102 harnesses the full capability of the USB 2.0 standard that provides a durable, reliable and high-quality data communication.



Package Contents 1x UEH4102L 4-Port USB 2.0 Cat 5 Extender over LAN (Local unit)
1x UEH4102R 4-Port USB 2.0 Cat 5 Extender over LAN (Remote unit)
1x Power Adapter
1x USB 2.0 Type-A to Type-B Cable
1x User Instructions


Features Extends USB transmission over a Gigabit Ethernet Local Area Network (LAN)
ExtremeUSB® – supports transparent USB 2.0 signals and true plug-and-play (no software or drivers required)
Pre-paired networked configuration through MAC Address for simple installation. No pairing action required
Supports automatic connection link between Local and Remote units through DHCP
Up to 100m between extender and switch and between switches over CAT 5e/6/7 cables
Operates with all USB peripherals - flash drives, keyboards, mice, webcams, interactive whiteboards, and more
Works with all major operating systems: Windows®, OS X®, and Linux®
