Aten VE170 A/V Over Cat 5 Extender

Overview

The VE170 VGA / Audio Cat 5 Extenders, consisting of a transmitter (VE170T) and receiver (VE170R), are cost-effective and efficient solutions for sending and receiving high quality audio/video content over long distances. Simply connect the transmitter to the receiver via one Cat 5e cable, and a VGA display or projector can be located up to 300 m (1000 ft) away from the video source.

The VE170 VGA / Audio Cat 5 Extenders provides a flexible solution which is ideal for any professional A/V installation that requires multimedia content to be delivered over a long distance.

Package Contents

• 1x VE170T + VE170R VGA/Audio Cat 5 Extender
• 1x VGA/Audio Cable (1.8m)
• 2x Power Adapters
• 1x Mounting Kit
• 1x User instructions

Features

• Connects a transmitter and receiver via Cat 5e cable
• Long distance transmission - up to 1920 x 1200@30m; 1024 x 768@300m
• Supports one local and one remote VGA display
• Long distance transmissions – up to 300 m
• Adjustable Gain Control – signal strength can be manually adjusted via video gain or video compensation tuners
• Audio supported (mono)
• Built-in ESD protection
• Rack-mountable
