TP-Link TL-SM331T 1000BASE-T RJ45 SFP Module

The TL-SM331T is a 1000BASE-T RJ45 SFP Module featuring Plug and play, high speed connection and a durable metal casing aswell as high compatability with various optic fibre equipment from different vendors.

Features

• Support 1000BASE-T Operation in Host Systems
• Support TX Disable function
• For 100m* Reach Over UTP Cat 5e or above Cable
• Hot-Pluggable SFP Footprint Features
• Commercial Product Operating Temperature Range: 0-70°C
• Compliant with IEEE Std 802.3-2002
• Fully Metallic Enclosure for Low EMI
• Low Power Dissipation (0.5 W Typical, 0.8 W Max)

Specifications

• Contents
• 1000BASE-T RJ45 SFP Module TL-SM331T
• Installation Guide
• Hardware Features
• Hot Swappable
• Dimensions (W*D*H)
• 2.7*0.5*0.5 in (67.4*13.75*13.8 mm)
• Tranceiver
• Standards and Protocols: IEEE 802.3-2002
• Power Supply: 3.3V
• Max. Cable Length: 100m* (Cat 5e or above)
• Data Rate: 1.25 Gbps
• Port Type: 1× 1000 Mbps RJ45 Port
• Safety & Emission: FCC, CE
• Operating Temperature: 0–70 ? (32–158 ?)
• Storage Temperature: -40–85 ? (-40–185 ?)
