| Product Code: | |
| Options: | |
| Qty: | |
| Unit Price: | £ |
| Part No: | FEMC112CS |
| Manufacturer No: | MC112CS |
| Delivery: | In Stock: Next Day |
 |
The MC112CS is a media converter designed to convert 100BASE-FX fibre to 100Base-TX copper media or vice versa. Adopting WDM technology, MC112CS takes only one fibre cable to transmit and receive data, which will save half cabling cost for you. Designed under IEEE 802.3u 10/100Base-TX and 100Base-FX standards, the MC112CS is designed for use with single-mode fibre cable utilising the SC-Type connector. The MC112CS supports longwave (LX) laser specification at a full wire speed forwarding rate. It works at 1310nm on transferring data and at 1550nm on receiving data. So the other end device to cooperate with the MC112CS should work at 1550nm on transferring data and at 1310nm on receiving data. Another TP-LINK’s media converter MC111CS is just one of the examples to cooperate with MC112CS.
Other features of this module include the ability to be used as a stand alone device (no chassis required), Auto MDI/MDI-X for TX port, Auto negotiation of duplex mode on TX port, and front panel status LEDs. The MC112CS will transmit at extended fiber optic distances utilising single-mode fibre up to 20 kilometres.
| MC200CM v4 |
MC210CS v4 |
MC220L v4 |
MC100CM v5 |
MC110CS v6 |
MC111CS v5 |
MC112CS v5 |
||
| Standards | IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z | IEEE 802.3i, IEEE 802.3u | ||||||
| Interface | 1 1000Mbps SC port 1 10/100/1000Mbps RJ45 port | 1 SFP port 1 10/100/1000 Mbps RJ45 port | 1 100Mbps SC port 10/100Mbps RJ45 port | |||||
| Transmission Distance | 0.55km (50/125um), 0.22km (62.5/125um) | 15km | Depends on the inserting SFP module | 2km | 20km | |||
| Transmission Media | Multi-mode Fibre, TP | Single-mode Fibre, TP | Multi/ Single-mode Fibre, TP | Multi-mode Fibre, TP | Single-mode Fibre, TP | |||
| Wave Length | 850nm | 1310nm | Depend on used SFP module | 1310nm | 1310nm | 1550nmTX 1310nmRX |
1310nmTX 1550nmRX |
|
| Dimensions | 3.7 × 2.9 × 1.1 in. (94.5 × 73.0 × 27.0 mm) |
|||||||
| Environment | Operating Temperature: 0°C to 40°C (32°F to 104°F) Storage Temperature: -40°C to 70°C (-40°F to 158°F) Operating Humidity: 10% to 90% non-condensing Storage Humidity: 5% to 90% non-condensing |
|||||||
| Power Supply | 9V/0.6A | |||||||
| Max Power Consumption | 1.66W | 1.8W | 1.7W | 2.4W | 2.4W | 1.49W | 1.44W | |
| Certifications | CE, FCC | |||||||
The MC112CS is a media converter designed to convert 100BASE-FX fibre to 100Base-TX copper media or vice versa. Adopting WDM technology, MC112CS takes only one fibre cable to transmit and receive data, which will save half cabling cost for you. Designed under IEEE 802.3u 10/100Base-TX and 100Base-FX standards, the MC112CS is designed for use with single-mode fibre cable utilising the SC-Type connector. The MC112CS supports longwave (LX) laser specification at a full wire speed forwarding rate. It works at 1310nm on transferring data and at 1550nm on receiving data. So the other end device to cooperate with the MC112CS should work at 1550nm on transferring data and at 1310nm on receiving data. Another TP-LINK’s media converter MC111CS is just one of the examples to cooperate with MC112CS.
Other features of this module include the ability to be used as a stand alone device (no chassis required), Auto MDI/MDI-X for TX port, Auto negotiation of duplex mode on TX port, and front panel status LEDs. The MC112CS will transmit at extended fiber optic distances utilising single-mode fibre up to 20 kilometres.
| MC200CM v4 |
MC210CS v4 |
MC220L v4 |
MC100CM v5 |
MC110CS v6 |
MC111CS v5 |
MC112CS v5 |
||
| Standards | IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z | IEEE 802.3i, IEEE 802.3u | ||||||
| Interface | 1 1000Mbps SC port 1 10/100/1000Mbps RJ45 port | 1 SFP port 1 10/100/1000 Mbps RJ45 port | 1 100Mbps SC port 10/100Mbps RJ45 port | |||||
| Transmission Distance | 0.55km (50/125um), 0.22km (62.5/125um) | 15km | Depends on the inserting SFP module | 2km | 20km | |||
| Transmission Media | Multi-mode Fibre, TP | Single-mode Fibre, TP | Multi/ Single-mode Fibre, TP | Multi-mode Fibre, TP | Single-mode Fibre, TP | |||
| Wave Length | 850nm | 1310nm | Depend on used SFP module | 1310nm | 1310nm | 1550nmTX 1310nmRX |
1310nmTX 1550nmRX |
|
| Dimensions | 3.7 × 2.9 × 1.1 in. (94.5 × 73.0 × 27.0 mm) |
|||||||
| Environment | Operating Temperature: 0°C to 40°C (32°F to 104°F) Storage Temperature: -40°C to 70°C (-40°F to 158°F) Operating Humidity: 10% to 90% non-condensing Storage Humidity: 5% to 90% non-condensing |
|||||||
| Power Supply | 9V/0.6A | |||||||
| Max Power Consumption | 1.66W | 1.8W | 1.7W | 2.4W | 2.4W | 1.49W | 1.44W | |
| Certifications | CE, FCC | |||||||
Other features of this module include the ability to be used as a stand alone device (no chassis required), Auto MDI/MDI-X for TX port, Auto negotiation of duplex mode on TX port, and front panel status LEDs. The MC112CS will transmit at extended fibre optic distances utilising single-mode fibre up to 20 kilometres.
