Cisco QSFP-H40G-ACU7M Compatible 7m 40G QSFP+ to QSFP+ Direct Attach Cable Twinax - 40GbE QSFP+ Copper DAC 40 Gbps Low Power Active Transceiver Module DAC Firepower ASR1000 ASR9000
Copper QSFP+ Cable | 40 Gbps | Active DAC | Lifetime Warranty
The QSFPH40GACU7 is a Cisco QSFP-H40G-ACU7M compatible direct-attach copper QSFP+ cable that’s designed, programmed and tested to work with Cisco® brand compatible switches and routers and complies with MSA industry standards.
This Active Twinax copper cable supports 40 Gigabit Ethernet applications connected through QSFP+ (Mini-GBIC) ports. This copper QSFP+ cable is hot-swappable, making upgrades and replacements seamless by minimizing network disruptions.
Designed for high-speed performance, this low-power, low-latency QSFP+ cable is a cost-effective alternative to fiber-optic cable assemblies, supporting short-distance applications such as point-to-point in-rack network switch or server connections.
Technical details | |
Jacket material | Polyvinyl chloride (PVC) |
Cable length | 7 m |
Sustainability certificates | RoHS |
Input impedance | 100 |
Features | |
Connector 1 | QSFP+ |
Connector 2 | QSFP+ |
Data transfer rate | 40000 Mbit/s |
Certification | CE, FCC |
Product colour | Black |
Connector 2 gender | Male |
Connector 1 gender | Male |
AWG wire size | 24 |
Operational conditions | |
Operating temperature (T-T) | 0 - 70 °C |
Storage temperature (T-T) | -40 - 80 °C |
Weight & dimensions | |
Cable length | 7 m |
Width | 14 mm |
Depth | 7000 mm |
Height | 12 mm |
Weight | 451 g |
Logistics data | |
Master (outer) case width | 33.4 cm |
Master (outer) case length | 63.8 cm |
Master (outer) case height | 28.2 cm |
Products per master (outer) case | 20 pc(s) |
Full specification and details can be found in the PDF file
