Speedway Splice Tray Kit for 24 Heatshrink Splice Protectors

Overview

Introducing the revolutionary new Speedway splice tray with unrivalled ease of use and flexibility.

Featuring a unique external fibre pathway and pivoting splice holder arrangement this tray redefines the concept of splice management, combining fibre management and splicing control in one product.

Due to its accommodating internal dimensions, the Speedway splice tray is able to comfortably hold 24 splices with either heat-shrink or crimp German-style splice protectors with up to 900µm buffered fibres.

Features

• Unique external fibre pathway allows easy storage of excess fibre and multi-directional routing of entry and exit fibres
• The spacious interior maintains 30mm fibre bend radius and allows storage of either 250µm or 900µm buffered fibre
• Internal management allows multiple fibre routing options including cross over
• Pivoting splice holders allow uninterrupted control of fibre prior to splicing and during rework
• Built-in fibre pick can be used to withdraw individual fibres and can be stored in the tray after use
• Will hold up to 24 splices with either heat-shrink or crimp style splice protectors
• Supplied with tray hinge to maintain access to splices with stacked trays
• Transparent clip in lid supplied with every tray
• Cable tie points to secure fibre on entry and exit
• Mountable via central hole, DIN style holes or double-sided foam adhesive pad
