Product Code: | |
Options: | |
Qty: | |
Unit Price: | £ |
If you wish to enquire about this product please contact us on
0800 488 0000
3/4 COMP BOX STD + UN7113 + UP651/UP751
357 x 257 x 83mm pre-wired floor box with 3m tap-off. 1 x 2 gang standard.
• Feed: 3m STD Tap-Off Unfused
• Grey Trim and Lid
• Pre-wired with 13A Twin Socket
• Reversible Lid
• Accepts carpets or tiles up to 6mm
UPW400 | UPW410 | |
Compartment | 3 compartment | 4 compartment |
Pack | 1 | 1 |
Variation | Standard | Standard |
Colour | Silver | Silver |
Dimensions | Floor Aperture 322mm x 222mm Carpet tile 305mm x 170mm Trim 358mm x 258mm |
Floor Aperture 322mm x 222mm Carpet tile 305mm x 170mm Trim 358mm x 258mm |
Materials | Galvanised steel base, Polypropylene lid & trim, Zinc plated steel load plate. | Galvanised steel base, Polypropylene lid & trim, Zinc plated steel load plate. |
Compliance / Standards | CE & UKCA Marked Low Voltage Directive 2014/35/EU The Electrical Equipment (Safety) Regulations 2016 BS 7671:2018 BS EN 61534-22:2014 BS 1363-2:2016+A1:2018 |
CE & UKCA Marked Low Voltage Directive 2014/35/EU The Electrical Equipment (Safety) Regulations 2016 BS 7671:2018 BS EN 61534-22:2014 BS 1363-2:2016+A1:2018 |
Rated voltage (Un) | 230 volts | 230 volts |
Operating voltage range | 50 – 253V | 50 – 253V |
Rated load current | 13 Amps | 13 Amps |
Full specification and details for the UPW400 can be found in the UPW400 Product Datasheet PDF file
Full specification and details for UPW410 can be found in the UPW410 Product Datasheet PDF file
Additional details can be found in the Product Catalogue PDF file
