Eaton N785-INT-SC-MM Gigabit Multimode Fiber to Ethernet Media Converter, 850 nm, 550M
scroll
to top

Eaton N785-INT-SC-MM Gigabit Multimode Fiber to Ethernet Media Converter, 850 nm, 550M

by Eaton
See more product details
Part No:FEN785-INT-SC-MM
Manufacturer No:N785-INT-SC-MM
Delivery: In Stock: 5-7 Days

/assets/images/gallery/large/1740650208FEN785-INT-SC-MM-1.jpg

Eaton N785-INT-SC-MM Gigabit Multimode Fiber to Ethernet Media Converter, 850 nm, 550M
scroll
to top
More Related Items
Click to change options
Colour:
Door:
Flat Pack:
Accessory Kit:
Apply
£531.25 Ex VAT
Qty:
Email product to a friend
X
  • Scroll to top
    Eaton N785-INT-SC-MM Gigabit Multimode Fiber to Ethernet Media Converter, 850 nm, 550M

    The N785-INT-SC-MM Gigabit Multimode Fiber to Ethernet Media Converter is a compact device which lets you extend your high-speed Ethernet connection up to 550 meters (1,804 feet) using SC multimode fiber optic cabling. Because Cat5e/6 cables are limited to only 100 meters, it is more effective to use SC multimode fiber optic cabling for greater distances.

    Use copper UTP cabling to connect one 850 nm N785-INT-SC-MM converter to your network device, such as a computer, and another converter to a network switch. The two converters are connected by a multimode fiber optic cable with SC connectors. The N785-INT-SC-MM supports 50/125 multimode cable up to 550 meters and 62.5/125 multimode cable up to 400 meters.

    Monitoring and controlling your network nodes is easy with the converter’s advanced features, such as automatic network speed sensing, full/half-duplex auto-detection and automatic MDI/MDI-X configuration. Six LEDs indicate the converter’s Ethernet network and fiber link status at a glance.

    Extends a Gigabit Ethernet Signal up to 550 m (1804 ft.) Using SC Multimode Cable

    Converts UTP copper connection to duplex fiber over long distance, then back to copper at opposite end while auto-sensing the proper speed

    Fiber optic technology more effective than Cat5e/6 over long distances

    Supports 50/125 multimode fiber optic cabling up to 550 m

    Supports 62.5/125 multimode fiber optic cabling up to 400 m

    Connection requires an N785-INT-SC-MM at both ends

    Advanced Monitoring and Control

    Supports automatic sensing of network speed

    Supports both full-duplex and half-duplex operation

    Supports automatic MDI/MDI-X configuration

    6 LEDs indicate network and fiber link status at a glance

    Plug-and-Play Operation

    No additional software or drivers required

    Compact unit sets up in minutes

    Durable metal housing designed to last

    The N785-INT-SC-MM Gigabit Multimode Fiber to Ethernet Media Converter is a compact device which lets you extend your high-speed Ethernet connection up to 550 meters (1,804 feet) using SC multimode fiber optic cabling. Because Cat5e/6 cables are limited to only 100 meters, it is more effective to use SC multimode fiber optic cabling for greater distances.

    Use copper UTP cabling to connect one 850 nm N785-INT-SC-MM converter to your network device, such as a computer, and another converter to a network switch. The two converters are connected by a multimode fiber optic cable with SC connectors. The N785-INT-SC-MM supports 50/125 multimode cable up to 550 meters and 62.5/125 multimode cable up to 400 meters.

    Monitoring and controlling your network nodes is easy with the converter’s advanced features, such as automatic network speed sensing, full/half-duplex auto-detection and automatic MDI/MDI-X configuration. Six LEDs indicate the converter’s Ethernet network and fiber link status at a glance.

    Extends a Gigabit Ethernet Signal up to 550 m (1804 ft.) Using SC Multimode Cable

    Converts UTP copper connection to duplex fiber over long distance, then back to copper at opposite end while auto-sensing the proper speed

    Fiber optic technology more effective than Cat5e/6 over long distances

    Supports 50/125 multimode fiber optic cabling up to 550 m

    Supports 62.5/125 multimode fiber optic cabling up to 400 m

    Connection requires an N785-INT-SC-MM at both ends

    Advanced Monitoring and Control

    Supports automatic sensing of network speed

    Supports both full-duplex and half-duplex operation

    Supports automatic MDI/MDI-X configuration

    6 LEDs indicate network and fiber link status at a glance

    Plug-and-Play Operation

    No additional software or drivers required

    Compact unit sets up in minutes

    Durable metal housing designed to last

    Product data is provided by Icecat, we do not warrant the accuracy of the material above.
