40G QSFP+ to 4x 10G SFP+ Breakout Direct Attach Cable

QSFP to 4x SFP+ Splitter Cable offers IT professionals a cost-effective interconnect solution for merging 40G QSFP and 10G SFP+ enabled host adapters, switches and servers. For typical applications, users can install this splitter cable between an available QSFP port on their 40 Gigabit/s rated switch and feed up to four upstream 10GbE-SFP+ enabled switches.Each QSFP-SFP+ splitter cable features a single QSFP connector (SFF-8436) rated for 40-Gb/s on one end and (4) SFP+ connectors (SFF-8431), each rated for 10-Gb/s, on the other.

QSFP to 4 SFP+ Splitter Cables that designs and sources every subassembly in-house guaranteeing complete control over product performance, quality and consistency. Examples include our widely respected board-as-connector platform which is direct-welded to the wire and encased in a robust Zinc-Nickel backshell for superior crosstalk and EMI performance.

Features

• Connector A: (1) QSFP 40.0 Gbps Rated Connector (SFF-8436 Compliant)
• Connector B: (4) SFP+ 10.0 Gbps Rated Connectors (SFF-8431 Compliant)
• Economically Links up a QSFP port with an Upstream 10GbE-SFP+ Switch
• Protocol agnostic support of 40GbE, QDR InfiniBand, SAS & Fibre Channel
• Up to 10.3125 Gbps transfer rate per SFP+ channel (40 Gbps aggregate)
• Robust Zinc die-cast SFP+ & QSFP connectors with pull-to-release latching
• Bridge the gap between your 10G and 40G capable switches/host adapters
• Low cross-talk and pair-to-pair skew maintains signal integrity
• Fully compliant to the latest SFP+ & QSFP MSA (Multi-Source-Agreement)
• Supports all current 10-Gigabit Ethernet and 40-Gigabit Ethernet standards
• Designated form factor and electrical compliance for QDR InfiniBand
• The perfect direct attached storage splitter cable for Fibre Channel & SAS
• Enjoy a reduced power budget and lower port cost compared to optical
• Fully RoHS compliant for environmental protection

Applications

• InfiniBand SDR, DDR
• Ethernet 1G, 10G
• FibreChannel
• Rack-to-Rack, Shelf-to-Shelf Interconnect
• Networking
• Storage
• Hubs, switches, routers, servers
