USB 3.0 SATA Hard Drive Duplicator & Eraser Dock - Standalone 2.5/3.5in HDD & SSD Eraser and Cloner
Clone a 2.5in/3.5in SATA drive without a host computer connection, or dock the drives over USB 3.0 for easy access
The SATDOCK2REU3 USB 3.0 Standalone Duplicator and Eraser Dock lets you connect your 2.5in/3.5in SATA HDDs or SSDs through SuperSpeed USB 3.0, with the ability to swap drives in and out as needed. The dock also functions as a standalone drive duplicator and eraser – an efficient and versatile solution for external drive management.
Featuring standalone Sector by Sector hard drive duplication with built-in LED progress bar, and support for 2 drive single pass over writing the SATDOCK22EU3 is a user-friendly all-in-one solution for any application requiring hard drive duplication or erasing.
With support for SATA I/II/III, and large capacity drives (tested up to 4TB) this HDD/SSD docking station is compatible with virtually any SATA hard drive, and greatly increases the storage/backup capabilities of your computer.
Extend the value of this hard drive docking station further with the addition of our SATA to IDE Hard Drive Adapter (SAT2IDEADP), allowing easy insertion of any 2.5 or 3.5in. IDE hard drive into a SATA hard drive dock.
The SATDOCK2REU3 is backed by a 2-year StarTech.com warranty and free lifetime technical support.
Top view:
Applications:
System administrators who need quick access to drives for imaging
Data Archiving
Technicians who regularly test or benchmark different hard drives and need to swap between them
Forensic investigators who require disk sector imaging/cloning to create an exact replica of a source drive onto a different drive
Professionals who require identical backups for when data integrity is crucial, such as data recovery
Cloning hard drives that contain hidden partitions, that some software disk cloning programs may skip
IT administrators that wish to quickly clear/erase a drive in preparation for use in other applications
Data recovery specialists who need quick access to drives to recover/retrieve data
Features:
Supports 2.5in and 3.5in form factor SATA hard drives (HDD) and solid state drives (SSD)
Standalone Sector-by-Sector hard drive duplication
Stand alone single pass overwrite erase
SuperSpeed USB 3.0 compliant host interface, with up to 5 Gbps of data bandwidth
High Speed USB 2.0 compliant host interface, with transfer rates up to 480Mbps
Supports SATA revision I/II/III (1.5/3.0/6.0 Gbps) drives
Plug-and-Play and Hot-Swap compatible
Universal Power Adapter (NA/UK/EU)
Built-in LED progress bar
The StarTech.com Advantage:
Quickly copy hard drives, with standalone sector by sector HDD/SSD duplication
Securely erase up to two drives simultaneously, with Single Pass HDD overwriting
Hassle-free access to drive data, with hot-swappable top slot-loading dock design that supports both 2.5in and 3.5in HDD/SSDs
Technical details
Product type
HDD/SSD duplicator
Chipset
Prolific - PL2775
LED indicators
HDD, Link, Power
USB connector type
USB Type-B
Plug and Play
Yes
Maximum supported storage capacity
4 TB
Number of simultaneous copies
1 copies
Interface
USB 3.2 Gen 1 (3.1 Gen 1)
Duplicator operating modes
Copy, Erase
Transfer rate
11 GB/min
Product colour
Black
Sustainability certificates
RoHS
Hard drive
SSD support
Yes
Supported HDD sizes
2.5, 3.5"
Power
Output voltage
12 V
Output current
3 A
Input current
1.2 A
AC input voltage
110 - 240 V
Power plug type
Type M
Operational conditions
Storage temperature (T-T)
-10 - 95 °C
Operating temperature (T-T)
0 - 85 °C
Operating relative humidity (H-H)
5 - 90 %
Weight & dimensions
Width
103 mm
Depth
128 mm
Height
62 mm
Weight
424 g
Packaging data
Package width
165 mm
Package length
195 mm
Package height
130 mm
Package weight
885 g
Manual
Yes
AC adapter included
Yes
Cables included
AC, USB
Full specification and details can be found in the
eSATA / USB 3.0 Hard Drive Duplicator Dock – Standalone HDD Cloner with SATA 6Gbps for fast-speed duplication
Clone a 2.5in/3.5in SATA drive without a host computer connection, or dock the drives over USB 3.0 or eSATA for easy access
The SDOCK2U33RE Dual 2.5/3.5" SATA HDD/SSD duplicator dock lets you duplicate/clone an existing hard drive without the use of a host computer system -- or dock and swap drives from your desktop or laptop computer simultaneously, using a single USB or eSATA port.
Versatile Features
The SDOCK2U33RE offers convenient dual-function performance. As a hard drive duplicator, the SDOCK2U33RE lets you create an exact sector-by-sector clone from one hard drive to another, including partitions and boot sector information -- ensuring data integrity and consistency for sensitive operations, such as data recovery. As an external hard drive dock the SDOCK2U33RE lets you connect your drives through either eSATA or USB, with each drive slot individually supporting high capacity 2.5/3.5" hard drives or solid state drives, tested up to 4 TB.
Fast Performance
With support for SATA III (6 Gbps) you can maximize efficiency with duplication speeds up to 22 GB per minute, and eSATA docking speeds up to 6 Gbps. The Dock can also be connected through USB 3.0 with UASP for transfer speeds up 5 Gbps (70% faster than conventional USB 3.0). See our UASP testing results below for further details.
Hassle-free Operation
With push button operation and plug-and play installation, the duplicator dock has been specially designed for hassle-free operation. The SDOCK2U33RE lets you quickly dock your hard drives or start duplicating hard drives with the push of a button. Plus, the built-in LED progress bar saves you time by letting you easily monitor the entire duplication process, so you'll know exactly when it's time to start your next operation.
For added compatibility with different drive types in duplication and docking applications, the SDOCK2U33RE supports the use of various drive adapters. The below list of StarTech.com adapters have been specifically tested, to ensure compatibility with this drive duplicator:
SATA to 2.5in or 3.5in IDE Drive Adapter - SAT2IDEADP
2.5in SATA to Mini SATA SSD Adapter - SAT2MSAT25
M.2 SSD to 2.5in SATA Adapter - SAT32M225
Improved Performance with UASP
UASP is supported in Windows 8, Mac OSX (10.8 or above), and Linux. In testing, UASP performs with a 70% faster read speed and 40% faster write speed over traditional USB 3.0 at peak performance.
At the same peak in testing UASP also shows an 80% reduction in required processor resources.
Testing results were obtained using an Intel® Ivy Bridge system, a UASP-enabled StarTech.com Enclosure, and a SATA III solid state drive.
SDOCK2U33RE is backed by a StarTech.com 2-year warranty and free lifetime technical support.
Front View:
1. Power button and LED
2. PC/Copy Mode button and LED
3. Start Duplication button
4. HDD1/HDD2 Activity LED indicators
5. Duplication LED Progress bar
6. Hard drive #1 slot (Destination for Duplication)
7. Hard drive #2 slot (Source for Duplication)
8. Hard drive #1 eject button
9. Hard drive #2 eject button
Rear View:
1. eSATA port
2. USB 3.0 port
3. Power adapter port
Applications:
Disc sector imaging/cloning to create an exact replica of a source drive onto a different drive
Create identical backups for system builds that require the same drive image
Quickly access or swap bare hard drives for easy data backup/recovery
Features:
Standalone sector-by-sector hard drive duplication with speeds up to 22GB per minute
Supports both 2.5" and 3.5" form factor hard drives (HDD) and solid state drives (SSD)
eSATA and USB 3.0 host interface connections
1:1 hard drive duplicator and docking station
Support SATA III (6 Gbps) and UASP for optimal performance
Supports dual drive capacity up to 4 TB per slot (8 TB in total)
Compatible with SATA revision I/II/III (1.5/3.0/6.0 Gbps) drives
Compatible with USB 3.0/2.0/1.1 (5 Gbps / 480 Mbps / 1.5 Mbps)
Dual bay, top slot-loading design with drive doors
The StarTech.com Advantage:
Create exact duplicates of your hard drives without having to connect to a computer
Maximize performance, with file transfer speeds up to 6Gbps using eSATA or 5 Gbps using USB 3.0 with UASP
Versatile connectivity options, through either USB or eSATA
Technical details
Product type
HDD/SSD duplicator
Number of simultaneous copies
1 copies
Interface
SATA
Duplicator operating modes
Copy
Product colour
Black
Sustainability certificates
RoHS
Hard drive
Supported HDD sizes
2.5, 3.5"
System requirements
Windows operating systems supported
Yes
Mac operating systems supported
Yes
Linux operating systems supported
Yes
Server operating systems supported
Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 x64
Power
AC input voltage
100 - 240 V
Operational conditions
Operating temperature (T-T)
5 - 35 °C
Operating relative humidity (H-H)
20 - 80%
Weight & dimensions
Width
132 mm
Depth
147 mm
Height
70 mm
Weight
500 g
Packaging data
Package width
190 mm
Package depth
118 mm
Package height
213 mm
Package weight
1.05 kg
Full specification and details can be found in the
USB 3.1 (10Gbps) Standalone Duplicator Dock for 2.5" & 3.5" SATA SSD/HDD Drives - with Fast-Speed Duplication up to 28GB/min
Duplicate or dock a SATA SSD/HDD with fast performance - works with both USB-C and USB-A enabled devices
Duplicate drives quickly, at rates of up to 28GB per minute for SSDs, without having to connect to your computer. This duplicator dock offers standalone drive cloning that makes it easy to back up your data and make exact images of your drives. You can also connect the dock to your computer through USB 3.1 (10Gbps), to dock and swap your drives as part of a scalable storage solution.
Clone your drives at high speed
Duplicating a hard drive or solid-state drive is an effective way to migrate your operating system and data from one drive to another, or create an exact copy for safeguarding your important data. This drive duplicator lets you create a sector-by-sector clone of your drive, including partitions and boot sector information, to ensure data integrity and consistency for sensitive operations such as data recovery.
The duplicator dock saves you valuable time with SSD duplication speeds of up to 28GB per minute. You can duplicate a 2.5” or 3.5” SATA SSD or HDD easily, without having to connect the duplicator to a host computer.
Transfer files quickly between the dock and your PC
The duplicator dock also provides an external storage solution, letting you dock your drives through USB 3.1 Gen 2 with UASP support, enabling fast data transfer rates of up to 10Gbps. Each drive slot individually supports a high-capacity hard drive or solid-state drive, tested up to 6 TB.
Includes two USB cables for versatility
The duplicator dock comes with two USB cables for flexible use with the latest laptops and tablets equipped with a USB-C™ port, as well as legacy devices. It includes both USB-C to B and USB-A to B cables. The duplicator dock is also compatible with a Thunderbolt™ 3 USB-C port.
Designed for easy use
The dock features a top-loading, toaster-style design that makes it easy to insert your drives. It also features drive doors to help stabilize drives that are inserted into the slot and prevent foreign objects from getting into the drive slots.
Both tool-less and tray-less, the duplicator dock helps to ensure quick and hassle-free drive insertions. LED indicators let you know, at a glance, the current state of the duplication process, including the specific duplication mode, the HDD status and clone progress. The HDD ejection button enables fast and simple drive removal.
For added compatibility with different drive types in duplication and docking applications, the SDOCK2U33RE supports the use of various drive adapters. The below list of StarTech.com adapters have been specifically tested, to ensure compatibility with this drive duplicator:
SATA to 2.5in or 3.5in IDE Drive Adapter - SAT2IDEADP
2.5in SATA to Mini SATA SSD Adapter - SAT2MSAT25
M.2 SSD to 2.5in SATA Adapter - SAT32M225
The SDOCK2U313R is backed by a StarTech.com 2-year warranty and free lifetime technical support.
Front View:
Rear View:
Applications:
Duplicate a 2.5 in. or 3.5 in. SSD/HDD to create an exact replica of a source drive onto a different drive
Create identical backups for system builds that require the same drive image
Quickly access or swap bare hard drives and solid-state drives for easy data backup/recovery
Features:
Duplicate hard drives quickly, without a host computer, at fast speeds of up to 28GB per minute for SSDs
Works with both USB-C and USB-A enabled devices, with two cables included
Compatible with Thunderbolt 3 USB-C port
Transfer files at high speed between a docked hard drive and a host computer
Supports 3.5in and 2.5in SATA SSDs/HDDs
USB 3.1 (10Gbps) with UASP support for high speed data transfers and backup
Provides TRIM support
Supports SATA I/II/III (up to 6Gbps)
Dual-bay, top slot-loading design (toaster-style) with drive doors and HDD ejection button
Tool-less and tray-less design
Compatible with SAT2IDEADP for additional IDE drive support
Multi-function LED indicators
Backward compatible
Technical details
Product type
HDD duplicator
Chipset
ASMedia - ASM1352R
Port multiplier
No
LED indicators
HDD, Power, Status
Housing material
Plastic
USB connector type
USB Type-B
Number of simultaneous copies
2 copies
Interface
USB 3.1
Duplicator operating modes
Copy
Transfer rate
10000 MB/s
Transfer rate
28 GB/min
Product colour
Black
Sustainability certificates
RoHS
Hard drive
Supported HDD sizes
2.5, 3.5"
Supported HDD interfaces
Serial ATA, Serial ATA II, Serial ATA III
Power
Output voltage
12 V
Output current
3 A
Input current
1.5 A
AC input voltage
100 - 240 V
Power plug type
Type M
Included power plug types
AU, EU, NA, UK
Power supply
36 W
Operational conditions
Storage temperature (T-T)
-20 - 50 °C
Operating temperature (T-T)
5 - 35 °C
Operating relative humidity (H-H)
20 - 80 %
Weight & dimensions
Width
132 mm
Depth
142 mm
Height
70 mm
Weight
508 g
Packaging data
Package width
300 mm
Package depth
166 mm
Package height
88 mm
Package weight
992 g
Manual
Yes
AC adapter included
Yes
Cables included
USB
Full specification and details can be found in the
Drive Eraser and Dock for 2.5 / 3.5in SATA SSD / HDD - USB 3.0
Securely erase a SATA HDD/SSD without a host device, or dock your drive for easy access
Make the most of your SATA drives. This standalone eraser dock lets you erase your 2.5” and 3.5” solid-state drives or hard drives without connecting to a host computer, making it easy to re-use or re-purpose your SATA drive. For added peace of mind, the dock offers a printed confirmation when data has been securely erased.
The eraser dock also gives you a single-bay dock for your SATA drive with fast USB 3.0 performance, also known as USB 3.1 Gen 1 (5 Gbps).
Industry-recognized erase modes
Using industry-recognized erase modes, you can rest assured that the standalone eraser securely cleans, erases or sanitizes the data from your 2.5” or 3.5” SSD or HDD.
The eraser dock supports nine erase modes including Quick Erase, Single and Multi-pass Overwrites, Custom Erase, Secure Erase and Enhanced Secure Erase. The Multi-pass Overwrite (3-Pass Full Disk Overwrite) erase procedures meet the requirements of DoD (5220.22-M) standards.
Wipe sensitive data securely, confirmed with a printed receipt
The eraser dock lets you connect to an RS232 serial printer to print a record of the erase procedure and confirm that the erase has been successfully completed. This feature is ideal for IT technicians, system administrators or any departments needing confirmation when erasing sensitive or confidential information. For your reference, the printed receipt clearly shows you the time and date of erase, as well as the erase mode used.This drive eraser ensures data is purged (a secure erase) which is required by government agencies and organizations who have strict guidelines on deleting data. Purging is a very secure method of erasing data from your storage device which complies with the NIST 800-88 Rev. 1 media sanitation standard established by the National Institute of Standards and Technology.
Easy drive management and wide compatibility
For IT technicians or business professionals who need to check files or test different hard drives, the dock lets you hot-swap drives in and out as needed. The dock features a single SATA bay with a top-loading design for easy access to your drives, which makes it easy to quickly back-up or transfer data to a hard drive or solid-state drive.
With support for SATA I and II and large capacity drives (tested up to 6TB), this docking station is compatible with virtually any 2.5” and 3.5” SATA SSD or HDD drive.
The eraser dock also works with mSATA drives and M.2 drives using a compatible StarTech.com adapter:
mSATA drives: Use StarTech.com adapter SAT32MSAT257
M.2 drives: Use StarTech.com adapter SAT32M225
Hassle-free set-up and a compact design
The eraser dock is OS independent, which ensures a quick and easy setup. Its compact design and small footprint allows it to tuck easily into your workspace.
The TAA compliant SDOCK1EU3P is backed by a StarTech.com 2-year warranty and free lifetime technical support.
Front view:
Rear view:
Applications:
IT technicians and business professionals who wish to quickly and securely erase data to repurpose SSDs or HDDs
System administrators, IT professionals and business administrators who need quick access to drives
IT technicians who regularly test or benchmark different hard drives and need to swap between them
Features:
Easy-to-use secure erasing with no host device required
Supports a serial printer (RS232) for receipt printing and erase confirmation
Fast access to files through USB 3.0 (5 Gbps)
Supports most 2.5” and 3.5” SATA HDD and SSD drives
Also supports 2.5” and 3.5” IDE hard drives, mSATA drives and M.2 drives, using a compatible StarTech.com adapter
TAA compliant
9 modes of erase including: Quick and NIST 800-88 Rev. 1 Purge compliant Secure Erase, Single Pass Overwrite and Multi-pass Overwrites - meets DoD (5220.22-M) standards
Supports SATA I and II
Plug-and-play installation
Supports drive hot-swapping
Built-in LCD display and menu navigation buttons
Power and activity LED
Features
Docking station supported HDD size
2.5, 3.5"
Serial ports quantity
1
Host interface
USB 2.0 Type B
Certification
CE, FCC, TAA, REACH
HDD interface
Serial ATA, Serial ATA II
SSD interface
IDE, M-SATA, M.2
Fast erase
Yes
Product colour
Black
Housing material
Plastic
Power
DC output voltage
12
Output current
5 A
AC input voltage
100 - 240 V
Power
60 W
Input current
1.4 A
Technical details
HDD interface
Serial ATA, Serial ATA II
SSD interface
IDE, M-SATA, M.2
Fast erase
Yes
Product colour
Black
Housing material
Plastic
Operational conditions
Storage temperature (T-T)
-10 - 65 °C
Operating temperature (T-T)
0 - 40 °C
Operating relative humidity (H-H)
10 - 90 %
Weight & dimensions
Width
123 mm
Depth
140 mm
Height
70 mm
Weight
656 g
Packaging data
Package width
189 mm
Package depth
376 mm
Package height
91 mm
Package weight
2 kg
Quick start guide
Yes
AC adapter included
Yes
Cables included
USB
Included power plug types
AU, EU, NA, UK
Full specification and details can be found in the
Hard Drive Eraser and Docking Station - Standalone w/ 4Kn Support
SATA Dock and Wiper | SATA III 6Gbps | 2.5"/3.5" SSD and HDD | TAA Compliant
This hard drive eraser lets you wipe a SATA solid-state drive (SSD) or hard drive (HDD) without connecting to a host computer. It’s compatible with 2.5" and 3.5" drives and supports SATA I, II, and III, and large capacity drives, including 4Kn drives.
Sanitize Your Drives with Confidence
You can rest easy when using this eraser to retire, re-use or re-purpose a drive. No data will remain on the drive and nothing will be accessible with data recovery software.
The SSD and HDD eraser supports nine erase modes to support a variety of security requirements, including:
• Quick Erase
• Single and Multi-pass Overwrites
• Custom Erase
• Secure Erase
• Enhanced Secure Erase
This drive eraser ensures data is purged (a secure erase) which is required by government agencies and organizations who have strict guidelines on deleting data. Purging is a very secure method of erasing data from your storage device which complies with the NIST 800-88 Rev. 1 media sanitation standard established by the National Institute of Standards and Technology
Monitor Erase Status and Keep Logs
The hard drive eraser can connect to an RS232 serial printer to print a record of the erase procedure. The receipt shows the time and date of the erasure, and the erase mode used.
The LCD also lets you monitor erase performance and completion.
Back Up Your Data before Wiping Your Drive
The eraser can be used as a SATA dock when connected to a USB 3.0 computer. It supports data transfer speeds of up to 5Gbps.
When used as a dock you can:
• Back up a drive
• Test a drive
• Transfer data to a drive
SDOCK1EU3P2 is TAA compliant and backed by a StarTech.com 2-year warranty with free lifetime technical support.
Front View:
Rear View:
Applications:
IT technicians and business professionals who need to quickly and securely erase SSDs or HDDs
System administrators, IT professionals and business administrators who need quick access to drives
IT technicians who regularly test or benchmark different drives and need to swap between them
Features:
Sanitize drives confidently using this SSD HDD eraser with erase modes that meet global standards, including NIST 800-88 Rev. 1 Purge compliant Secure Erase
Monitor the status of erasure procedures and keep printed logs for your records
Back up your data prior to erasing a drive, use the eraser as a SATA dock
Supports USB 3.0 data transfer speeds of 5Gbps
Technical details
Product type
HDD/SSD duplicator
Chipset
Xilinx - Spartan-6
Port multiplier
No
LED indicators
Activity, Power
Housing material
Plastic, Steel
USB connector type
USB Type-B
Serial ports quantity
1
Maximum supported storage capacity
10 TB
Number of simultaneous copies
1 copies
Interface
USB 3.2 Gen 1 (3.1 Gen 1)
Duplicator operating modes
Erase
Transfer rate
5000 MB/s
Product colour
Black
Sustainability certificates
RoHS
Power
Output voltage
12 V
Output current
5 A
Input current
1.4 A
AC input voltage
110 - 240 V
Power plug type
Type M
Included power plug types
AU, EU, JP, NA, UK
Power supply
60 W
Operational conditions
Storage temperature (T-T)
-10 - 65 °C
Operating temperature (T-T)
0 - 40 °C
Operating relative humidity (H-H)
10 - 90 %
Weight & dimensions
Width
123 mm
Depth
140 mm
Height
70 mm
Weight
656 g
Packaging data
Package width
183 mm
Package length
37.2 cm
Package height
90 mm
Package weight
2.1 kg
Manual
Yes
AC adapter included
Yes
Cables included
USB
Full specification and details can be found in the
Standalone 2.5 / 3.5” SATA Hard Drive Duplicator w/ Multi HDD / SSD Image Backup Library
Duplicate one 2.5/3.5” hard drive to another without connecting to a computer, or backup multiple drive images to a library drive to restore PC/Server images easily
The SATDUP11IMG standalone SATA hard drive duplicator, lets you create an exact duplicate of a SATA hard drive (HDD) / solid state drive (SSD), or create a single backup library drive containing multiple images you can copy to additional drives at any time.
Fast, Simple Drive Duplication
Reduce clutter with the SATDUP11IMG eliminating the number of drives required when creating backups of multiple unique drive images. Using a single backup library drive, you can store several unique drive images on a single SSD / HDD, ensuring fast duplication at 6 GBpm and minimal clutter.This is an ideal solution if you frequently re-image different computer systems, because it means you'll only have to carry a single backup library drive to restore multiple drive images onto different systems.
Hassle-free Performance
The versatile duplicator also offers standard one-to-one drive duplication in three different modes: file & system copy, all partitions copy and whole copy. This is ideal for one-time drive duplication, eliminating the hassle of creating a drive image for a one-time project.
Intuitive Operation
With an easy-to-read LCD display and intuitive four-button menu operation, the SATDUP11IMG ensures hassle-free setup and control. The menu gives you push-button access to many value-added features that ensure simple task management such as: drive to drive duplication, drive to Image library backup and restore, and many more. It also provides numerous advanced setup options for experienced users.
For added compatibility with different drive types in duplication, the SATDUP11IMG supports the use of various drive adapters. The below list of StarTech.com adapters have been specifically tested, to ensure compatibility with this drive duplicator:
2.5/3.5in IDE drives - SAT2IDEADP
mSATA drives - SAT2MSAT25
M.2 (NGFF) drives - SAT32M225
The SATDUP11IMG is TAA compliant and backed by a 2-year StarTech.com warranty and lifetime technical support.
Front View:
1. Source HDD Status LEDs
2. SATA HDD Source Port
3. Up Navigation Button
4. Down Navigation Button
5. OK Button
6. Esc Button
7. SATA HDD Target Port
8. Target HDD Status LEDs
Rear View:
1. Power Switch
2. Power Adapter Port
Applications:
Forensic investigators who require disk sector imaging/cloning to create an exact replica of a source drive onto a
different drive
Professionals who require identical backups for when data integrity is crucial, such as data recovery
Clone hard drives that contain hidden partitions, that some software disk cloning programs may skip
System builders / IT specialists who require multiple unique drive images for different types of system builds
Features:
Multi-image library drive for hassle-free duplication
Four modes of hard drive duplication including Sector-by-Sector at 6 GBpm
Supports 2.5in or 3.5in form factor hard drives (HDD) or solid state drives (SSD)
Digital LCD Display for operation and task progress
Supports SATA revision I/II/III (1.5/3.0/6.0 Gbps) drives
Universal Power Adapter (NA/UK/EU)
TAA Compliance (Trade Agreement Act)
The StarTech.com Advantage:
Hassle-free drive duplication with multiple unique drive images stored on the same HDD/SSD
Save time by quickly duplicating hard drives at speeds up to 6 GB per minute
Certifications, Reports and Compatibility:
Technical details
Product type
HDD/SSD duplicator
LED indicators
Activity, Power
Interface
SATA
Product colour
Black
Sustainability certificates
RoHS
Hard drive
Supported HDD sizes
2.5, 3.5"
Supported HDD interfaces
Serial ATA, Serial ATA II, Serial ATA III
Power
Output current
5 A
Input current
1.4 A
AC input voltage
100 - 240 V
Included power plug types
EU, NA, UK
Operational conditions
Storage temperature (T-T)
-20 - 85 °C
Operating temperature (T-T)
5 - 45 °C
Operating relative humidity (H-H)
20 - 80 %
Weight & dimensions
Width
77 mm
Depth
129 mm
Height
28 mm
Weight
358 g
Packaging data
Package width
185 mm
Package depth
260 mm
Package height
185 mm
Package weight
1.71 kg
Manual
Yes
AC adapter included
Yes
Cables included
SATA, eSATA
Full specification and details can be found in the
1:1 Drive Duplicator and Eraser for 2.5in / 3.5in SATA Drives
Clone or Erase 2.5in/3.5in SATA hard drives, without a host computer connection
The SATDUP11 standalone hard drive duplicator eraser enables you to copy 1-to-1, or erase up to 2 SATA hard drives simultaneously without a host computer.
Featuring three modes of standalone drive duplication including Data Only, All Partitions, and Sector by Sector, the HDD copier offers high performance duplication, and has been tested for speeds up to 14GB per minute.
Complete with integrated LCD display, and support for 2.5” and 3.5” SATA I/II/III hard drives (HDD) and Solid State Drives (SSD), the SATDUP11 is a user-friendly all-in-one solution for any application requiring hard drive duplication or erasing.
For added compatibility with different drive types in duplication and quick erase applications, the SATDUP11 supports the use of various drive adapters. The below list of StarTech.com adapters have been specifically tested, to ensure compatibility with this drive duplicator:
2.5/3.5in IDE drives - SAT2IDEADP
mSATA drives - SAT2MSAT25
M.2 (NGFF) drives - SAT32M225
The SATDUP11 features high quality aluminum construction, and is backed by a 2-year StarTech.com warranty and free lifetime technical support.
Front View:
1. Display Screen
2. Navigation buttons
3. OK button
4. Esc button
5. SATA HDD source port
6. SATA HDD Target port
Rear View:
1. Power Switch
2. Power Adapter Port
Applications:
IT administrators that wish to quickly clear/erase a drive in preparation for use in other applications
Securely erase/wipe the data on your hard drive before the drive is disposed
Forensic investigators who require disk sector imaging/cloning to create an exact replica of a source drive onto a different drive
Professionals who require identical backups for when data integrity is crucial, such as data recovery
Clone hard drives that contain hidden partitions, that some software disk cloning programs may skip
Features:
Four modes of hard drive duplication including Sector-by-Sector at 14 GBpm
Digital LCD Display for operation and task progress
Supports 2.5in or 3.5in form factor hard drives (HDD) or solid state drives (SSD)
Supports SATA revision I/II/III (1.5/3.0/6.0 Gbps) drives
Universal Power Adapter (NA/UK/EU)
Portable light weight design
TAA Compliance (Trade Agreement Act)
Erase up to 2 hard drives with single-pass and multi-pass overwriting / DoD erasing
The StarTech.com Advantage:
Quickly duplicate hard drives at speeds up to 14 GB per minute
Securely erase two drives simultaneously, with Single-Pass and Multi-Pass HDD overwriting (DoD)
Technical details
Product type
HDD duplicator
Housing material
Aluminium
Number of simultaneous copies
1 copies
Interface
SATA
Duplicator operating modes
Compare, Copy, Erase
Transfer rate
14 GB/min
Product colour
Black
Sustainability certificates
RoHS
Hard drive
Supported HDD sizes
2.5, 3.5"
Supported HDD interfaces
Serial ATA
HDD capacity
4000 GB
Power
Output voltage
14 V
Output current
5 A
Input current
1.4 A
AC input voltage
100 - 240 V
Included power plug types
EU, NA, UK
Power consumption (typical)
60 W
Operational conditions
Storage temperature (T-T)
-20 - 85 °C
Operating temperature (T-T)
5 - 45 °C
Operating relative humidity (H-H)
20 - 80 %
Weight & dimensions
Width
130 mm
Depth
80 mm
Height
30 mm
Weight
358 g
Packaging data
Package width
187 mm
Package length
26.5 cm
Package height
123 mm
Package weight
1.6 kg
Manual
Yes
AC adapter included
Yes
Cables included
SATA
Full specification and details can be found in the
4 Bay USB 3.0 eSATA to SATA Standalone 1:3 HDD Hard Drive Duplicator Dock
Duplicate one SATA Hard Drive onto three Hard Drives simultaneously
The SATDOCK4U3RE USB 3.0 and eSATA 1-to-3 Hard Drive Duplicator docking station enables you to duplicate/clone a single SATA hard drive to up to three other SATA drives simultaneously, as a standalone device. The duplicator can also function as a regular 4-bay hard drive docking station, by connecting to a host computer system. Large capacity drives (tested with up to 4TB 3.5" and 1TB 2.5" drives per bay) can be used to greatly enhance your computer's storage/backup capabilities.
Able to perform 1:3 sector duplication, including HPA, from a single SATA drive onto three others simultaneously (at a rate of up to 72 MBps), the duplicator/docking station can save you time and effort. As an external HDD dock, it can be connected to your host computer through USB 3.0 or eSATA, providing data transfer speeds up to 5 Gbps or 3Gbps respectively, from the hard drives to your computer system.
Features Quick and Secure Erase functions and support for IDE hard drives using the included SATA to IDE hard drive adapter (SAT2IDEADP). This drive eraser ensures data is purged (a secure erase) which is required by government agencies and organizations who have strict guidelines on deleting data. Purging is a very secure method of erasing data from your storage device which complies with the NIST 800-88 Rev. 1 media sanitation standard established by the National Institute of Standards and Technology.
Front View:
Rear View:
Applications:
Creating multiple exact replicas of a source drive onto a new drive for large deployment of identical computer systems
Law enforcement and forensic technicians who need one or more exact copies of the original hard drive for testing or investigation
SMB, OEM, System Integrators, IT and service technicians requiring quick access to bare external hard drive contents, or the ability to clone data for data / disk recovery.
Features:
Sector-by-Sector drive duplication, including the HPA
Integrated LCD display for duplication progress and options menu
SuperSpeed USB 3.0 compliant host interface with supported data transfer rates of up to 5 Gbps
High speed eSATA host interface with supported data transfer rates up to 3 Gbps
Built-in quick drive erase and NIST 800-88 Rev. 1 Purge compliant Secure Erase function
Dual 60mm cooling fans mounted below the drives with variable speed controls (including OFF)
Supports 2.5in or 3.5in form factor hard drives (HDD) or solid state drives (SSD)
Compatible with SATA (1.5/3.0/6.0 Gbps) drives
Patented hard drive eject push-buttons for each drive
Independent power buttons for each hard drive
Extra, easy-access spacing between each drive
Four large, stable, non-slip table-top feet
Includes a SATA to IDE drive adapter
The StarTech.com Advantage:
Create 3 exact copies of a source SATA drive simultaneously, without having to connect to a computer
Access up to 4 SATA hard drives simultaneously over a single USB 3.0 or eSATA connection
Dual, variable speed fans allows you to adjust the amount of cooling for any kind of environment or drive type
Technical details
Product type
HDD duplicator
Chipset
JMicron - JMB394 + JMS539
Port multiplier
Yes
Number of fans
2 fan(s)
LED indicators
Activity, Power
Fan diameter
6 cm
Housing material
Plastic
USB connector type
USB Type-B
Plug and Play
Yes
Maximum supported storage capacity
16 TB
Number of simultaneous copies
3 copies
Interface
USB/eSATA
Duplicator operating modes
Copy
Product colour
Black
Sustainability certificates
RoHS
Hard drive
Supported HDD sizes
2.5, 3.5"
Supported HDD interfaces
Serial ATA, Serial ATA II
Power
Output voltage
12 V
Output current
6.5 A
AC input voltage
110-240 V
Included power plug types
EU, NA, UK
Power consumption (typical)
78 W
Operational conditions
Storage temperature (T-T)
-40 - 70 °C
Operating temperature (T-T)
5 - 80 °C
Operating relative humidity (H-H)
8 - 90 %
Weight & dimensions
Width
285 mm
Depth
170 mm
Height
94 mm
Weight
1.1 kg
Packaging data
Package width
170 mm
Package depth
343 mm
Package height
215 mm
Package weight
2.73 kg
Manual
Yes
AC adapter included
Yes
Cables included
SATA, USB, eSATA
Full specification and details can be found in the
Drive Duplicator and Eraser for USB Flash Drives and 2.5 / 3.5" SATA Drives
Duplicate or erase a USB flash drive or a SATA SSD/HDD, with 1:1 and cross-interface duplication
This versatile drive duplicator and eraser lets you clone and erase both USB-based storage devices and 2.5-inch and 3.5-inch SATA SSDs and HDDs, without having to connect to a computer. Ideal for IT professionals and system administrators, this versatile device helps you manage your file and data storage more efficiently, providing both 1:1 copying and cross-interface duplication.
1:1 or cross-interface duplication of SATA or USB drives
As a drive cloner, this unit lets you easily copy SATA and USB drives without having to connect to a computer. It enables you to duplicate 1:1 (from SATA to SATA or USB to USB) as well as cross-interface duplication from SATA to USB or USB to SATA. The drive cloner provides four duplication modes, including Quick Copy, All Partitions, Sector-by-Sector (Whole Drive) at speeds of up to 6.6GB/min., and Percentage Copy.
Multiple erase modes
Erase SATA or USB flash drives with ease, without a host computer. As a drive eraser, the SU2DUPERA11 gives you six erase modes including Quick Erase, Single Pass Overwrite (Full Erase), 3-Pass Overwrite (DoD) Erase, 3-Pass Overwrite and Compare, Secure Erase and 7-Pass Overwrite. You can erase a single SATA or USB drive, or two drives simultaneously.
Designed for ease of use
The drive duplicator and eraser features a compact and lightweight design with easy-to-use features. It offers convenient menu navigation buttons and an LCD display that clearly identifies the active duplication or erase mode and task status, to ensure fast and efficient operation.
The SU2DUPERA11 is backed by a StarTech.com 2-year warranty and free lifetime technical support.
Front View:
Rear View:
Applications:
Forensic investigators who require disk sector imaging/cloning to create an exact replica of a source drive onto a different drive
Professionals who require identical backups for when data integrity is crucial, such as data recovery
Clone hard drives that contain hidden partitions, that some software disk cloning programs may skip
Securely erase/wipe the data on your hard drive before the drive is disposed
IT administrators who wish to quickly clear/erase a drive in preparation for use in other applications
Features:
Duplicate or erase 2.5/3.5” SATA SSDs/HDDs and USB attached storage
1:1 duplication plus cross-interface support: SATA-to-USB or USB-to-SATA
Supports four modes of hard drive duplication including Sector-by-Sector at 6.6 GB/min
Supports six erase modes, including: Quick Erase, Single Pass Overwrite (Full Erase), 3-Pass Overwrite (DoD) Erase, 3-Pass Overwrite and Compare, Secure Erase and 7-Pass Overwrite
Supports SATA revision I/II/III (1.5/3.0/6.0Gbps) drives
Digital LCD display for easy operation and task progress
Compact design
Technical details
Product type
HDD duplicator
Chipset
Xlinx - Spartan-6
Port multiplier
No
LED indicators
Activity, Power
Housing material
Steel
Number of simultaneous copies
2 copies
Duplicator operating modes
Copy, Erase
Transfer rate
6.6 GB/min
Product colour
Black
Sustainability certificates
RoHS
Hard drive
Supported HDD sizes
2.5, 3.5"
Supported HDD interfaces
Serial ATA, Serial ATA II, Serial ATA III
Power
Output voltage
12 V
Output current
5 A
Input current
1.4 A
AC input voltage
100 - 240 V
Power plug type
Type M
Included power plug types
AU, EU, NA, UK
Power consumption (typical)
60 W
Operational conditions
Storage temperature (T-T)
-20 - 85 °C
Operating temperature (T-T)
5 - 45 °C
Operating relative humidity (H-H)
5 - 95 %
Weight & dimensions
Width
90 mm
Depth
135 mm
Height
29 mm
Weight
462 g
Packaging data
Package width
185 mm
Package depth
265 mm
Package height
100 mm
Package weight
1.9 kg
Manual
Yes
AC adapter included
Yes
Number of pads included
2
Full specification and details can be found in the
4 Bay SSD/HDD Hard Drive Eraser - 2.5" & 3.5" SATA - Hostless Standalone Secure Erase External Disk Sanitizer - 9 Erase Modes - RS232 Printer Port - NIST/DOD & TAA Compliant
Securely erase up to four SATA drives simultaneously with this standalone hard drive sanitizer
This hard drive eraser provides standalone, simultaneous drive erasing for up to four 2.5 in. or 3.5 in. SATA hard drives or solid-state drives.
Save time with a four-bay, standalone eraser
Unlike hard-drive docking stations or adapters that require a computer connection and software to erase drives, this hard drive sanitizer features standalone erasing that doesn’t require a host computer. This avoids the hassle of connecting your drives to a host computer and protects your drives from external security threats like remote data access.
The four-bay design maximizes efficiency by batching multiple drives in single erase projects, saving you valuable time. The hard drive eraser supports USB 3.0, also known as USB 3.1 Gen 1, with file transfer rates of up to 5Gbps.
Maximum versatility with multiple erase modes
Using industry-recognized erase modes, the hard drive eraser securely sanitizes the data from your 2.5 in. or 3.5 in. SSDs or HDDs. It supports nine erase modes including Quick Erase, Single and Multi-pass Overwrites, Custom Erase, NIST 800-88 Rev. 1 Purge compliant Secure Erase and Enhanced Secure Erase. The Multi-pass Overwrite (3-Pass Full Disk Overwrite) erase procedures meet the requirements of DoD (5220.22-M) standards.
Support for a variety of erase modes makes this drive eraser perfect for virtually any professional application. Single-Pass Overwrite is ideal for IT technicians and system administrators who decommission and repurpose old hard drives, while Quick and Secure Erase, Single Pass Overwrite and Multi-pass Overwrite modes (meeting DoD standards) are ideal solutions for research laboratories, health offices, law offices and accountants who manage sensitive data and require secure erasing to avoid potential privacy breaches.
In addition to supporting 2.5 in./3.5 in. SATA SSDs and HDDs, the hard drive eraser also works with 2.5 in. and 3.5 in. IDE hard drives, mSATA drives and SATA M.2 drives using a compatible StarTech.com adapter:
IDE hard drives: Use StarTech.com adapter SAT2IDEADP
mSATA drives: Use StarTech.com adapter SAT32MSAT257
M.2 drives: Use StarTech.com adapter SAT32M225
Hassle-free operation and erase log recording
The hard drive eraser features convenient menu navigation that ensures fast and efficient performance, with push-button operation and a built-in LCD display that clearly identifies the erase modes and task status. You can also connect the eraser to a computer to quickly access the drive that's connected to port-1.
To ensure your records are complete for auditing, the hard drive eraser features a 9-pin serial port that can connect to a serial printer to provide on-demand erase logs.
The TAA compliant SATERASER4 is backed by a StarTech.com 2-year warranty and free lifetime technical support.
Top view:
1. Port LED indicators
2. GO button
3. Drive port
4. LCD display
5. UP button
6. DOWN button
7. OK button
8. ESC button
Front view:
9. SATA data connector
10. SATA power connector
Back view:
1. Power button
2. Power jack
3. USB 3.0 port
4. RS232 port
Applications:
Erase your hard drives before they’re decommissioned, to prevent your sensitive data from being recovered
Clear your hard drives before repurposing them
Features:
SECURELY ERASE UP TO 4 DRIVES: Standalone hard drive eraser for 2.5" & 3.5" SATA SSD/HDD, erase multiple drives independently or simultaneously; Hostless plug-and-play hardware external disk wiper
9 ERASE MODES: Quick Erase, Single/3/7 pass overwrite, Secure/Enhanced secure erase meets NIST SP 800-88 Rev 1 (clear/purge); Upgradeable firmware to comply with future DOD & Government standards; TAA
STATUS DISPLAY & PRINTED ERASE CONFIRMATION: LCD Display w/ push button navigation for drive setup/status/config; Print results & drive info w/ RS232 serial port to ESC/P receipt printer (not incl)
ACCESS/TRANSFER DATA BEFORE ERASING: The USB 3.0 SuperSpeed 5Gbps Type-B port on the sanitizer allows a single drive to connect to a laptop/PC host for data transfer; 3ft USB Type-B (9 pin) cable incl
BROAD COMPATIBILITY: Adapters available to expand compatibility with other types of drives including 2.5" and 3.5" IDE drives (SAT2IDEADP), mSATA drives (SAT32MSAT257), and SATA M.2 drives (SAT32M225)
Certifications, Reports and Compatibility:
Technical details
Docking station supported HDD size
2.5, 3.5"
Hot-swap
Yes
Bus type
USB
Erase modes
Custom, Enhanced secure, Multi-pass overwrites, Secure, Single-pass overwrite
Maximum HDD capacity
10000 GB
Data transfer rate (max)
5 Gbit/s
USB 3.2 Gen 1 (3.1 Gen 1) ports quantity
1
Serial ports quantity
1
LED indicators
Activity, Power
Host interface
USB 3.2 Gen 1 (3.1 Gen 1) Type-B
Plug and Play
Yes
Certification
RoHS, CE, FCC, TAA, REACH
HDD interface
Serial ATA, Serial ATA II
External power adapter
Yes
Product colour
Black
Housing material
Steel
Power
Output current
7 A
AC input voltage
100 - 240 V
Power
84 W
Input current
1.2 A
Output voltage
12 V
Power plug type
Type M
Technical details
HDD interface
Serial ATA, Serial ATA II
External power adapter
Yes
Product colour
Black
Housing material
Steel
Operational conditions
Storage temperature (T-T)
-20 - 85 °C
Operating temperature (T-T)
5 - 45 °C
Operating relative humidity (H-H)
20 - 80 %
Weight & dimensions
Width
96 mm
Depth
209 mm
Height
30 mm
Weight
712 g
Packaging data
Package width
231 mm
Package depth
450 mm
Package height
85 mm
Package weight
2.6 kg
Quick start guide
Yes
AC adapter included
Yes
Drive pads included
Yes
Included power plug types
ANZ, EU, JP, NA, UK
Cables included
USB
Full specification and details can be found in the
USB 3.0 / eSATA 6-Bay Hard Drive Duplicator Dock - 1:5 HDD / SSD Cloner and Eraser
Duplicate a 2.5 in. or 3.5 in. SATA drive to five drives simultaneously, or dock the source drive or the five target drives to a computer through USB 3.0 or eSATA
The SATDOCK5U3ER Hard Drive Duplicator & Docking Station lets you clone a 2.5in or 3.5in SATA hard drive (HDD) or solid-state drive (SSD) to five other SATA drives simultaneously, as a standalone device. The duplicator also lets you erase up to 5 drives, without a host connection.
You can also use the duplicator as a 5-bay HDD / SSD docking station, by connecting it to a host computer system through either USB 3.0 or eSATA. With support for high-capacity drives (tested with up to 6TB), this is a simple and cost-effective way to boost your data storage/backup capabilities.
Optimized Productivity
By copying data from one drive to five drives simultaneously, the hard drive cloner helps boost your productivity by avoiding the hassle of repeatedly swapping drives in and out during high volume duplication projects.
Plus, the dock supports erasing up to five drives simultaneously with multiple operating modes, including Quick Erase as well as Multipass Overwriting (DoD) -- the ideal solution for permanently erasing confidential information and helping to protect your business and your clients from identity theft.
Hassle-free Performance
With a built-in LCD display, the SATDOCK5U3ER makes it easy to monitor duplication progress and review copy/erase results and drive diagnostics during standalone operation.
The housing has also been specifically designed with ease-of-use in mind. The drive slots feature a dual-profile design to support hassle-free swapping between 2.5in and 3.5in hard drives and solid-state drives without having to use additional brackets or adapters.
Maximum Versatility
With the option to connect the docking station through either eSATA or USB 3.0, the SATDOCK5U3ER provides a versatile solution for expanding the storage capability of almost any laptop or desktop computer. For fast performance, you can connect the docking station to your computer through eSATA for efficient data transfer speeds up to 3 Gbps. For broader system compatibility, you can connect the dock through USB 3.0, which is also backward compatible with USB 2.0/1.1 host connections.
The SATDOCK5U3ER also provides two charge-only, fast-charge USB ports, that you can use to keep your iPhone®, iPad®, and Android™ tablets or smartphones charged.
You can also duplicate, erase or access other drive types in duplication and quick-erase applications using a drive adapter. The following StarTech.com adapters have been tested to ensure compatibility with this drive duplicator:
2.5/3.5in IDE drives - SAT2IDEADP
mSATA drives - SAT2MSAT25
M.2 (NGFF) drives - SAT32M225
Built for dependable, long-term performance the SATDOCK5U3ER is durably constructed and backed by a StarTech.com 2-year warranty and free lifetime technical support.
Front View:
1. Source 2.5/3.5in HDD/SSD Top Loading Slot Bays
2. Destination 2.5/3.5in HDD/SSD Top Loading Slot Bays
3. LCD Display
4. Menu Operation buttons
5. Power button
6. Drive Power Buttons/LEDs
7. USB Fast Charge Hub Ports
Rear View:
1. Fan Speed Controls
2. eSATA Port
3. USB 3.0 Port
4. Power Adapter Port
Applications:
Create multiple exact replicas of a source drive onto a new drive for large deployment of identical computer systems
Make exact copies of original hard drives for testing or investigation in law enforcement and forensic applications
Quickly access external hard drives
Clone data for disk recovery
Securely erase multiple drives simultaneously to protect yourself against identity theft
Features:
Save time with 1:5 mass drive duplication & 5-drive mass erasing
Hassle-free standalone operation with built-in digital LCD display
Maximize versatility with eSATA & USB 3.0 host connections, charge only USB fast-charge ports, plus docking station, eraser and duplicator in a single device
Sector-by-sector drive duplication at 7 GBs per minute
Erase up to five drives simultaneously with single-pass and multi-pass overwriting / DoD erasing
eSATA and USB 3.0 host interface connections
Supports SATA revision I/II/III (1.5/3.0/6.0 Gbps) drives
Supports 2.5in or 3.5in form factor hard drives (HDD) or solid-state drives (SSD)
Compatible with USB 3.0/2.0/1.1 (5 Gbps / 480 Mbps / 1.5 Mbps)
Built-in dual cooling fans with speed control
The StarTech.com Advantage:
Maximum versatility with HDD / SSD duplicator, docking station and eraser in a single device
Save time on mass drive duplication projects, by creating five duplicate drives simultaneously
Hassle-free standalone operation and easy-to-read task progress monitoring with built-in LCD display
Technical details
Product type
HDD duplicator
Chipset
SPIF260A, ASM1453, JMB393
Port multiplier
Yes
Number of fans
2 fan(s)
LED indicators
Activity, Power
Fan diameter
6 cm
Number of simultaneous copies
5 copies
Interface
USB 3.0/eSATA
Duplicator operating modes
Copy, Erase
Transfer rate
5000 MB/s
Product colour
Black
Sustainability certificates
RoHS
Hard drive
Supported HDD sizes
2.5, 3.5"
Supported HDD interfaces
Serial ATA II
HDD capacity
6000 GB
Power
Output voltage
19 V
Output current
5 A
Input current
2 A
AC input voltage
100 - 240 V
Operational conditions
Storage temperature (T-T)
-20 - 50 °C
Operating temperature (T-T)
5 - 35 °C
Operating relative humidity (H-H)
20 - 80 %
Weight & dimensions
Width
151.8 mm
Depth
315 mm
Height
75 mm
Weight
1.5 kg
Packaging data
Package width
276 mm
Package depth
383 mm
Package height
197 mm
Package weight
2.5 kg
Manual
Yes
AC adapter included
Yes
Cables included
eSATA, USB
Full specification and details can be found in the
1:1 Standalone Hard Drive Duplicator and Eraser for 2.5" / 3.5" SATA and SAS Drives
Easily clone or erase SATA and SAS drives, without having to connect to a computer
This standalone drive duplicator and eraser supports both SATA and SAS drives, making it a great fit for enterprise storage and data center applications. Compatible with 2.5” and 3.5” drive form factors, it provides a versatile and cost-effective drive management solution.
High-speed drive duplication
With the drive duplicator, you can clone SATA or SAS drives 1:1 at speeds of up to 13 GB per minute. It provides IT professionals and system administrators with a powerful tool to effectively manage drives for backend server infrastructure or drives distributed to organizational employees. It contributes to a more efficient workflow by enabling completion of duplication tasks without the use of a computer or software. You can quickly back up and archive data, duplicate data for disk imaging, or transfer content to additional drives for office professionals, medical staff, government personnel, or other employees.
The drive cloner/eraser provides four duplication modes including System and File, All Partitions, Sector-by-Sector (Whole Drive), and Percentage Copy.
Multiple erase modes - with real-time erase confirmation
Erase SATA or SAS drives with ease, without a host computer. As a drive eraser, the SATSASDUPE11 can erase two drives simultaneously and gives you a choice of six erase modes including Quick Erase, NIST 800-88 Rev. 1 Purge compliant Secure Erase, 1-Pass Overwrite, 3-Pass Overwrite (DoD), 3-Pass Erase and Compare, and 7-Pass Overwrite.
The multiple erasure modes give you the assurance that data can be securely erased when repurposing drives. This alleviates concerns over privacy-related issues when erasing sensitive data, important to many professional offices such as medical, legal and accounting firms.
The drive eraser also enables you to keep a record of completed erase jobs, with built-in erasure logging, for auditing purposes. It connects to an RS232 serial printer to print a record of the erase procedure and confirm that the erase has been successfully completed. The printed receipt clearly shows you the time and date of erase, as well as the erase mode used.
Designed for ease of use and portability
The drive duplicator and eraser provides IT professionals with an easy-to-use solution in an office or server environment. It offers convenient menu navigation buttons and a built-in LCD display that clearly identifies the duplication or erase mode and task status. Since it is OS independent, no software or drivers are required.
Its standalone operation provides quick setup, without having to connect to a computer. You can easily transfer the device from room to room, to work on drives in different locations.
The TAA compliant SATSASDUPE11 is backed by a StarTech.com 2-year warranty and free lifetime technical support.
Top view:
Front view:
Back view:
Applications:
Enhances drive management in enterprise storage and data center applications
Ideal for IT professionals and system administrators who need quick access to files to back up and archive data, duplicate data for disk imaging, or transfer content to additional drives
Confidently erase sensitive or confidential information - ideal for companies and organizations with privacy-related issues, such as legal and medical information
Securely erase data to repurpose SSDs or HDDs
Features:
Duplicates and erases 2.5 in. and 3.5 in. SSDs/HDDs, both SATA and SAS drives
Erase up to 2 drives with choice of 6 modes: Quick Erase, NIST 800-88 Rev. 1 Purge compliant Secure Erase, 1-Pass Overwrite, 3-Pass Overwrite (DoD), 3-Pass Erase and Compare, and 7-Pass Overwrite
Features four copying modes: System and File, All Partitions, Sector-by-Sector (Whole Drive), and Percentage Copy
Supports a serial printer for erase logging and receipt printing for erase confirmation
Supports high-speed drive duplication up to 13GB/min
Supports SATA I/II/III (up to 6Gbps) and SAS I/II
Menu navigation buttons and LCD display for ease of use
Technical details
Product type
HDD duplicator
Chipset
Xilinx - SPARTAN-6
Port multiplier
No
LED indicators
Yes
Housing material
Steel
Number of simultaneous copies
2 copies
Interface
USB 3.2 Gen 1 (3.1 Gen 1)
Duplicator operating modes
Copy, Erase
Transfer rate
13 GB/min
Product colour
Black
Sustainability certificates
RoHS
Hard drive
Supported HDD sizes
2.5, 3.5"
Supported HDD interfaces
SAS, SAS-2, Serial ATA, Serial ATA II, Serial ATA III
Power
Output voltage
12 V
Output current
7 V
Input current
1.2 A
AC input voltage
110 - 240 V
Power plug type
Type N
Included power plug types
AU, EU, NA, UK, US
Power consumption (typical)
90 W
Operational conditions
Storage temperature (T-T)
-20 - 85 °C
Operating temperature (T-T)
5 - 45 °C
Operating relative humidity (H-H)
20 - 80 %
Weight & dimensions
Width
90 mm
Depth
194 mm
Height
35 mm
Weight
695 g
Packaging data
Package width
192 mm
Package length
38.2 cm
Package height
91 mm
Package weight
2.4 kg
Manual
Yes
AC adapter included
Yes
Number of pads included
2
Full specification and details can be found in the
- Review: The 10 Best Wireless Access Points
- Review: The Top 10 Best Ethernet Cables
- What Is An Ethernet Cable And What Does It Do?
- 10 Best CCTV Security IP Cameras For Home & Business
- Review: Best Powerline Adapters In The UK
- Celebrating 20 Years Of Comms Express!
- The Top 10 DrayTek Wireless Access Points
- Best Selling APC Products At Comms Express
- Review: Top 5 Best Performing APC Uninterruptible Power Supply Units (UPS)
- Review: Top 10 Best PDU’s
